Accusplit AE1640M4 User Manual

ACCUSPLIT®

ACCUSPLIT EAGLE 1640M4

TW15MG

TODAY

TOTAL

MODE

SET

RESET

MY

3-WAY

PYRAMID

STEPS

™

MILES

KM

DISTANCE

EAGLE

MEMORY PEDOMETER

OPERATING INSTRUCTIONS

Congratulations on taking the first step to wellness

with your purchase of an ACCUSPLIT pedometer.

It’s easy to set up your new pedometer.

Just follow the steps below, and start walking!

SETTING UP YOUR PEDOMETER

To record your distance and calories accurately, you will
need to set your stride length.

CHOOSING A MEASUREMENT SYSTEM

This unit is initially set to use English measurement units
(Miles). To change the unit back and forth between English
and Metric units (Kilometers), press the green RESET button
for 5 seconds.

Finding Your Stride Length: Your stride length is the length of
one of your steps, measured from “toe to toe.” To measure,
walk 10 steps with your normal stride and measure the
TOTAL DISTANCE from the toe of your starting step to the
toe of your 10th step (see diagram below). Divide the TOTAL
DISTANCE by 10. This is your stride length. Example: If you
walk 22 feet, your stride length is 2.2 feet.

Setting Your Stride Length: Press the yellow MODE button
until arrow on bottom of display points to “DIST.” Press the
dark blue SET button once to enter setting mode. Display will
shift to show stride (for example, “F 1.95” means stride is set
to 1.95 feet). Press the dark blue SET button to increase stride
length. Press the green RESET button to reduce stride length.
Press the yellow MODE button to exit setting mode.

First, loop the
pedometer clip

Next, loop the metal
clip, then clasp clothing

™

1640M4

DISPLAY MODES

• STEPS - TODAY: Counts steps taken since last

 RESET.Resetdailytocounteachday’ssteps.

• STEPS - TOTAL: Keeps track of all steps taken,
 evenafterDay’sSTEPs are reset.

• DISTANCE: Shows distance walked or jogged since
last reset, in miles or kilometers.

•

(ACTIVITY TIMER): Shows total activity time in
minutes and seconds since last reset. The timer runs
automatically whenever steps are being recorded.

Aqua:

MODE

Cream:

SET

Yellow:

RESET

WEARING YOUR PEDOMETER

While gently holding the belt clip open, slide the pedometer
onto your belt or the top edge of your pants or skirt. It
should fit snugly and level, above one knee.
Note: The pedometer should be as vertical as possible.
Walkers with larger stomachs may find it helpful to wear the
pedometer farther back on the body, toward one hip.
The cover must be closed for the pedometer to work. To
avoid losing or dropping your pedometer, use the included
leash and clip to fasten the pedometer securely to your
clothing.

Attaching the Leash: Attach the pedometer to the leash by
looping the leash around the pedometer belt clip. Next, clasp
the waistband of your clothing with the attached metal clip.
You can also use a safety pin to fasten the leash to your
clothing, or loop the leash through your belt or belt loop.

Or, loop a belt
or belt loop

10 steps

800-965-2008 • 925-226-0888 • FAX [phone] • www.ACCUSPLIT.com • [e-mail]

VIEWING YOUR RESULTS

Once you put on your pedometer with the cover closed,
it will automatically begin to record your steps, distance,
calories burned, and activity time. Repeatedly press the
yellow MODE button to cycle through the pedometer modes:
STEPS → DISTANCE → ACTIVITY TIMER → STEPS

badge holder, then

Or, loop a

put into pocket

(Badge holder

not included)

Eat Right! Walk More! Live Well!

The ACCUSPLIT Lifestyle

ACCUSPLIT, Inc. • 2290M Ringwood Ave. • San Jose, CA 95131

970-047

MEMORIES

This pedometer has memories to keep track of your activity
data for today, this week, and last week. The unit stores
your steps, distance, calories, and activity time data for
each of these time periods. It can also display your daily
averages of these measures for the previous week.

To view today’s data, press the aqua DAY.CUM button until
a bar appears underneath the DAY indicator in top right
hand corner of display. Now, repeatedly press the yellow
MODE button to view steps, distance, calorie, and activity
time values for the day.

To view this week’s total data, press the aqua DAY.CUM
button until a bar appears underneath the CUM indicator in
top right hand corner of display. Now, repeatedly press the
yellow MODE button to view steps, distance, calorie, and
activity time values accumulated so far this week.

To view the previous week’s data, you must start from
the steps, distance, calories, or activity timer mode. Press
the cream MEMORY (WK-AVG) button until a bar appears
underneath the WEEK indicator in the top right hand
corner of display, and the indication “TL” (for Total)
appears on the left hand side of the display. The day of
the week indicators will all star t to flash. Now, repeatedly
press the yellow MODE button to view the TOTAL steps,
distance, calorie, and activity time values for last week.
Press the cream MEMORY button once more to view the
DAILY AVERAGE of steps, distance, calories, and activity
time for last week. The indicator on the left hand side
of display will change to say “Avg” (for AVERAGE). To
exit back to today’s or this week ’s data, press the cream
MEMORY button one more time.

AUTO MOVEMENT SENSOR

1. To filter out random movements, the unit remains in
standby mode until 5 continuous steps are registered.
Only then are the 5 steps calculated in, and an Active
indicator “▲” appears on the upper left of display.

2. When regular walk/run movement stops, after 2 seconds
the timer pauses and the unit switches to standby status
(Active indicator “▲” disappears).

RESETTING YOUR PEDOMETER

Most people prefer to reset step counts daily. To reset: While
displaying Day’s STEPs, DISTANCE, or ACTIVITY TIME, press and
hold yellow RESET button for at least two seconds to reset all of
these to zero. When displaying Total STEPs, press aqua RESET
button for two seconds to reset all counts, including Total STEPS,
to zero.

REPLACING THE BATTERY

When the display starts to dim or goes blank, it is time to replace
the battery. Your pedometer uses one Type LR43 (L1142) 1.5 volt
alkaline battery. To replace:

1.

Insert a coin into the slot on the bottom of the case, and twist

counterclockwise to loosen the case front. Lift case front away.

2. Using a pen or other thin object, push battery sideways out
of its holder. Replace it with a new battery. The battery’s
positive (+) terminal should be FACE UP while you put it into
the pedometer.

3. Align case front over the pedometer and press gently to snap
cover back into place, starting with top.

REGISTER NOW Please return

your AE1640M4 Registration to
the Repair Center address in the
warranty, and we will let you know
about future products.

Email (preferred)

User

NO-PROOF-OF-PURCHASE LIMITED WARRANTY

See label inside the lid of your pedometer
