Page 1
Acuvim II Series Power Meter
Chapter 1: Introduction
V:1.0 Revised October 2018
1
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 2
Acuvim II Series Power Meter
Chapter 1: Introduction
V:1.0 Revised October 2018
2
Copyright© 2015 V2.03
This manual may not be altered or reproduced in whole or in part by any means without the expressed written consent of Accuenergy.
The information contained in this document is believed to be accurate at the time of publication, however, Accuenergy assumes no responsibility for any errors which may appear here and reserves the right to make changes without notice. Please ask the local representative for latest product specifications before ordering. [ Document #1040E2203 Revision Date: Oct., 2018]
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 3
Acuvim II Series Power Meter
Chapter 1: Introduction
V:1.0 Revised October 2018
3
CONTENTS
Chapter 1: Introduction .......................................................................................................... 9
1.1 Meter Overview ........................................................................................................................... 9
1.2 Areas of Application ................................................................................................................... 11
1.3 Functionality .............................................................................................................................. 11
Chapter 2 Installation ............................................................................................................ 16
2.1 Appearance and Dimensions ...................................................................................................... 18
2.2 Installation Methods .................................................................................................................. 19
2.3 Wiring ........................................................................................................................................ 21
2.3.1 Terminal Strips.................................................................................................................... 21
2.3.2 Power Requirement ............................................................................................................ 23
2.3.3 Voltage Input Wiring ........................................................................................................... 25
2.3.4 Current Input Wiring ........................................................................................................... 28
2.3.5 Frequently Used Wiring Method ......................................................................................... 30
2.3.6 Communication .................................................................................................................. 33
Chapter 3 Meter Display and Parameter Settings ...................................................... 34
3.1 Display Panel and Keys ............................................................................................................... 35
3.2 Metering Data ........................................................................................................................... 38
3.3 Statistics Data ............................................................................................................................ 44
3.4 Demand Data ............................................................................................................................. 46
3.5 Harmonic Data ........................................................................................................................... 46
3.6 Expanded I/O Module Data ........................................................................................................ 48
3.7 Parameter Setting Mode ............................................................................................................ 52
3.8 Page Recovery Function ............................................................................................................. 67
Chapter 4 Detailed Functions and Software ................................................................. 69
4.1 Basic Analog Measurements ...................................................................................................... 69
4.2 Max/Min.................................................................................................................................... 73
4.3 Harmonics and Power Quality Analysis ...................................................................................... 73
4.4 Over/Under Limit Alarming ........................................................................................................ 74
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 4
Acuvim II Series Power Meter
Chapter 1: Introduction
V:1.0 Revised October 2018
4
4.5 Data Logging .............................................................................................................................. 80
4.6 Time of use (TOU) ...................................................................................................................... 85
4.7 Power Quality Event Logging and Waveform Capture ................................................................ 89
4.8 Seal Function ............................................................................................................................. 99
Chapter 5 Extended Modules ........................................................................................... 106
5.1 IO Modules .............................................................................................................................. 106
5.1.1 The Purpose of IO Modules ............................................................................................... 106
5.1.2 List of Functions of IO Modules ......................................................................................... 107
5.1.3 Appearance and Dimensions ............................................................................................. 108
5.1.4 Installation Method .......................................................................................................... 108
5.1.5 Wiring of IO Modules ........................................................................................................ 109
5.1.6 Detection of Remote Signals ............................................................................................. 116
5.1.7 Pulse Counter ................................................................................................................... 120
5.1.8 Relay Output ..................................................................................................................... 122
5.1.9 Digital Output ................................................................................................................... 123
5.1.10 Analog Output ................................................................................................................ 125
5.1.11 Analog Input ................................................................................................................... 129
5.2 Ethernet Module (AXM-NET) .................................................................................................... 131
5.2.1 Introduction to Ethernet ................................................................................................... 131
5.2.2 Function Description of Ethernet module .......................................................................... 131
5.2.3 Appearance and Dimensions ............................................................................................. 132
5.2.4 Installation Method .......................................................................................................... 133
5.2.5 Definition of RJ45 Interface ............................................................................................... 134
5.2.6 Cable ................................................................................................................................ 135
5.2.7 Connection Method .......................................................................................................... 135
5.2.8 Initializing Ethernet Module .............................................................................................. 135
5.2.9 Searching IP Address of Ethernet Module ......................................................................... 146
5.2.10 Description of Modbus-TCP protocol ............................................................................... 147
5.2.11 Webpage Browsing and Parameter Settings .................................................................... 156
5.2.12 Email Function ................................................................................................................ 165
5.2.13 SNTP Function ................................................................................................................. 165
5.3 ProfiBus Module (AXM-PROFI) ................................................................................................. 165
5.3.1 Introduction of PROFIBUS Technology .............................................................................. 165
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 5
Acuvim II Series Power Meter
Chapter 1: Introduction
V:1.0 Revised October 2018
5
5.3.2 PROFIBUS module application notes ................................................................................. 166
5.3.3 Appearance and Dimensions ............................................................................................. 167
5.3.4 Installation Method .......................................................................................................... 168
5.3.5 Definition of DP Interface ................................................................................................. 168
5.3.8 Address Setting ................................................................................................................. 170
5.3.9 Baud Rate ......................................................................................................................... 171
5.3.10 GSD Files ......................................................................................................................... 171
5.3.11 Information Exchange ..................................................................................................... 172
5.3.12 Format of function code 01H .......................................................................................... 172
5.3.13 Format of function code 05H .......................................................................................... 174
5.3.14 Format of function code 02H .......................................................................................... 175
5.3.15 Format of function code 03H .......................................................................................... 176
5.3.16 Format of function code 10H .......................................................................................... 178
5.3.17 32 Word Output Interface ............................................................................................... 180
5.4 RS485 Module (AXM-RS485) .................................................................................................... 180
5.4.1 Communication Parameters Setting .................................................................................. 180
5.4.2 Function Description of RS485 module ............................................................................. 180
5.4.3 Appearance and Dimensions ............................................................................................. 181
5.4.4 Installation Method .......................................................................................................... 182
5.4.5 Connection Method .......................................................................................................... 183
5.4.6 Communication Address ................................................................................................... 184
5.5 BACnet Module (AXM-BACnet) ................................................................................................ 184
5.5.1 BACnet Overview .............................................................................................................. 184
5.5.2 Introduction ..................................................................................................................... 185
5.5.3 About BACnet Protocol ..................................................................................................... 185
5.5.5 Using The BACnet Module (AXM-BACnet) ......................................................................... 187
5.5.6 Acuvim II Series Power Meter’s BACnet Objects ................................................................ 203
5.5.7 Browse the web server ..................................................................................................... 205
Chapter 6 Communication ................................................................................................. 210
6.1 Modbus Protocol Introduction ................................................................................................. 210
6.2 Communication Format ........................................................................................................... 212
6.3 Data Address Table and Application Details ............................................................................. 217
6.3.1 System Parameter Setting ................................................................................................. 219
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 6
Acuvim II Series Power Meter
Chapter 1: Introduction
V:1.0 Revised October 2018
6
6.3.2 System Status Parameters................................................................................................. 221
6.3.3 Date and Time Table ......................................................................................................... 224
6.3.4 Over/Under Limit Alarming Setting ................................................................................... 224
6.3.5 I/O Modules Settings ........................................................................................................ 228
6.3.6 100ms Refresh Metering Parameter ................................................................................. 234
6.3.7 Metering Parameter Address Table ................................................................................... 236
6.3.8 Data Logging ..................................................................................................................... 249
6.3.9 Time of use ....................................................................................................................... 256
6.4 DNP3.0 Protocal Introduction .................................................................................................. 279
6.4.1 Overview .......................................................................................................................... 280
6.4.2 Physical Layer ................................................................................................................... 280
6.4.3 Data Link Layer ................................................................................................................. 280
6.4.4 Transport Layer ................................................................................................................. 281
6.4.5 Application Layer .............................................................................................................. 281
6.4.6 Error Reply ........................................................................................................................ 282
6.4.7 Profile ............................................................................................................................... 283
6.4.8 Data Address Table ........................................................................................................... 284
6.4.9 DNP3.0 Message Layout.................................................................................................... 289
Appendix................................................................................................................................... 296
Appendix A Technical Data and Specification ............................................................................. 296
Appendix B Ordering Information .............................................................................................. 300
Appendix C Revision History ...................................................................................................... 303
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 7
Acuvim II Series Power Meter
Chapter 1: Introduction
V:1.0 Revised October 2018
7
Congratulations!
You have purchased an advanced, versatile, multifunction power meter. This meter can work as a remote terminal unit (RTU) that contributes to your system's stability and reliability by providing real-time power quality monitoring and analysis. When you open the package, you will find the following items
1. Acuvim II series meter 1
2. Terminal Blocks 3
3. Installation clips 4
4. Rubber Gasket 1
5. Product Disk (Manual, Warranty, Software) 1
6. Additional documentation (Quick Setup Guide, Calibration Certificate) 2
To avoid complications, please read this manual carefully before installation and operation of the Acuvim II series meter.
Chapter 1: Introduction
Chapter 2: Installation and Wiring
Chapter 3: Meter Display and Parameter Settings
Chapter 4: Detailed Functions and Software
Chapter 5: Extended Modules
Chapter 6: Communication
Appendix: Technical Data, Specifications and Ordering Information
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 8
Acuvim II Series Power Meter
Chapter 1: Introduction
V:1.0 Revised October 2018
8
Acuvim II Series Power Meter
Chapter 1 Introduction
1.1 Meter Overview
1.2 Areas of Application
1.3 Functionality
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 9
Acuvim II Series Power Meter
Chapter 1: Introduction
V:1.0 Revised October 2018
9
Chapter 1: Introduction
1.1 Meter Overview
Powerful Multifunction Power Meter
The Acuvim II series multifunction digital power meter is designed using modern MCU and DSP technology. It integrates three-phase energy measuring and displaying, energy accumulating, power quality analysis, malfunction alarming, data logging and network communication. A vivid LCD display with large characters and, time of use programmable backlight provides a clear realtime data readout.
An Ideal for Electric Automation SCADA Systems
The Acuvim II series meter is the ideal choice for replacing traditional, analog electric meters. In additon to providing clear real-time readings on the meter front, it can also be used as a remote terminal unit (RTU) for monitoring and controlling for a SCADA system. Users can access all measurement parameters via the standard RS485 communication port (or the optional Ethernet port) with the ModbusTM protocol.
Energy Management
The Acuvim II series meter is able to measure bidirectional, four quadrants kWh and kvarh. It provides maximum/minimum records for power usage and power demand parameters. All power and energy parameters can be viewed remotely via software in order to easily monitor various parameters. In addition, measurement tables can be viewed from the free Acuview software.
Remote Power Control
This meter is designed for measuring and monitoring power quality parameters. Since different I/O modules can be added to the meter, this expands the capabilities and provides a very flexible platform for using the meter as a distributed RTU, for metering, monitoring and remote controlling, all in one unit.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 10
Acuvim II Series Power Meter
Chapter 1: Introduction
V:1.0 Revised October 2018
10
Power Quality Analysis
Utilizing digital signal processing (DSP) technology, the Acuvim II series meter provides high accuracy power quality analysis and supports remote monitoring via the Ethernet module. The meter continuously updates metering results and allows users to access the meter online to monitor parameters such as voltage and current THD, harmonics, voltage crest factor, current K factor, and voltage and current unbalance factor etc.
Data Logging
The Acuvim IIR/IIE/IIW meter contains 8 megabytes of onboard memory for data logging and historical trending. Since the meter contains a real-time clock, all events and logged data will be time stamped.
Time of use (TOU-Acuvim IIE)
User can assign up to 4 different tariffs (sharp, peak, valley and normal) to different time period within a day according to the billing requirements. The meter will calculate and accumulate energy to different tariffs according to the meter’s internal clock timing and TOU settings.
Power Quality Event Logging
When a power quality event happens, such as voltage sag and swell, etc, Acuvim IIW will record the timestamp and the triggering condition of the event. It can save up to 50, 000 power quality events.
Waveform Capture
Acuvim IIW contains another 8 megabytes of on board memory for power quality event logging and waveform capture. Acuvim IIW can record 100 groups of voltage and current waveforms. It logs at 64 points per cycle. It provides the waveform record of 10 cycles before and after the triggering point. It also supports a settable triggering condition.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 11
Acuvim II Series Power Meter
Chapter 1: Introduction
V:1.0 Revised October 2018
11
1.2 Areas of Application
• Power Distribution Automation
• Electric Switch Gear and Control Panels
• Industry Automation
• Building Automation
• Energy Management Systems
• Marine Applications
• Renewable Energy
1.3 Functionality
Multifunction
Acuvim II meters provide powerful data collecting and processing functions. In addition to measuring various parameters, the meter is able to perform demand metering, harmonic analysis, max/min statistic recording, over/under limit alarming, energy accumulating and data logging.
High Accuracy
Accuracy of Voltage and Current is 0.2%, True-RMS. Accuracy of Power and Energy is 0.2%, while monitoring all four quadrants.
Compact and Easy to Install
This meter can be installed into a standard ANSI C39.1 (4” Round) or an IEC 92mm DIN (Square) cut out. With the 51mm depth after mounting, the Acuvim II series meter can be installed in a small cabinet. Mounting clips are used for easy installation and removal.
Easy to Use
All metering data and setting parameters can be accessed by using the front panel keys or via the communication port. Setting parameters are stored in the EEPROM so that content will be preserved when the meter is powered off.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 12
Acuvim II Series Power Meter
Chapter 1: Introduction
V:1.0 Revised October 2018
12
Multiple Wiring Modes
Category
Item
Parameters
Acuvi
m II
Acuvi
m IIR
Acuvi
m IIE
Acuvi
m IIW
Metering
Real Time Metering
Phase Voltage
V1, V2, V3, Vlnavg
= = =
=
Line Voltage
V12, V23, V31, Vllavg
= = =
=
Current
I1, I2, I3, In, Iavg
= = =
=
Power
P1, P2, P3, Psum
= = =
=
Reactive Power
Q1, Q2, Q3, Qsum
= = =
=
Apparent Power
S1,
S2, S3, Ssum
= = =
=
Power
Factor PF1, PF2, PF3, PF
= = =
=
Frequency
F
= = =
=
Load Features
Load Features
= = =
=
Four Quadrant Powers
Four Quadrant Powers
= = =
=
Energy & Demand
Energy
Ep_imp, Ep_exp, Ep_total, Ep_net Epa_imp; Epa_exp; Epb_imp; Epb_exp; Epc_imp; Epc_exp
= = =
=
Reactive Energy
Eq_imp, Eq_exp, Eq_total, Eq_net Eqa_imp; Eqa_exp; Eqb_imp; Eqb_exp; Eqc_imp;Eqc_exp
= = =
=
Apparent Energy
Es; Esa; Esb; Esc
= = =
=
Demand
Dmd_P, Dmd_Q, Dmd_S, Dmd_I1, Dmd_ I2, Dmd_I3
= = =
=
TOU
Time Of Use
Energy/max demand
TOU, 4 Tariffs, 12 Seasons, 14 Schedules
=
Daylight Saving Time
Two formats adjust
Month/Day/Hour/Minu te; Month/Week/ First few weeks/Hour/Minute
=
The Acuvim II series meter can be used in high voltage, low voltage, three phase three wires, three phase four wires and single phase systems using different wiring mode settings.
High Safety, High Reliability
Acuvim II series meter was designed according to industrial standards. It can run reliably under high power disturbance conditions. This meter has been fully tested for EMC and safety compliance in accordance with UL and IEC standards.
Function Comparison of Acuvim II series Meters
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 13
Acuvim II Series Power Meter
Chapter 1: Introduction
V:1.0 Revised October 2018
13
Category
Item
Parameters
Acuvim
II
Acuvim
IIR
Acuvim
IIE
Acuvim
IIW
Monitor­ing
Waveform Capture If 400Hz type, there is no this function
voltage and current Waveform
Trigger, Manual, DI change, Sag/Dips, Swell, Over Current
=
Power Quality
Voltage Unbalance Factor
U_unbl
= = =
=
Current Unbalance Factor
I_unbl
= = =
=
Voltage THD
THD_V1,THD_V2,THD _V3, THD_Vavg
= = =
=
Current THD
THD_I1, THD_I2, THD_I, THD_Iavg
= = =
=
Individual Harmonics
Harmonics 2nd to 63st If 400Hz, Harmonics 2nd to 15st
= = =
=
Voltage Crest Factor
Crest Factor
= = =
=
TIF
THFF
= = =
=
Current K factor
K Factor
= = =
=
Statistics
MAX with Time Stamp MIN with Time Stamp
Each phase of V & l; Total of P, Q, S, PF & F;Demad of P,Q & S; Each phase THD of V & I; Unbalance factor of V & I
= = =
=
Others
Alarm
Over/Under Limit Alarm
V,I,P,Q,S,PF,V_THD & I_THD each phase and total or average; Unbalance factor of V & I;load type;Analog Input of each channel
= = =
=
Power Quality Event Logging If 400Hz type, there is no this function
SAG/DIPS, SWELL
Voltage
=
Data Logging
Data Logging 1 Data Logging 2 Data Logging 3
F, V1/2/3/lnavg, V12/23/13/lavg, I1/2/3/ n/avg, P1/2/3/sum, Q1/2/3/sum, S1/2/3/ sum, PF1/2/3, PF, U_unbl, I_unbl, Load Type, Ep_imp, Ep_exp, Ep_total, Ep_ net, Eq_imp, Eq_exp, Eq_total, Eq_net, Es, THD_V1/2/3/avg, THD_I1/2/3/avg, Harmonics 2nd to 63rd, Crest Factor, THFF, K Factor, sequence and phase angles, DI counter, AI, AO, Dmd P/Q/S, Dmd I1/2/3Epa_imp; Epa_exp; Epb_imp; Epb_ exp; Epc_imp; Epc_exp;Eqa_imp; Eqa_ exp; Eqb_imp; Eqb_exp; Eqc_imp; Eqc_ exp; Esa; Esb; Esc
= = =
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 14
Acuvim II Series Power Meter
Chapter 1: Introduction
V:1.0 Revised October 2018
14
Category
Item
Parameters
Acuvi
m II
Acuvi
m IIR
Acuvi
m IIE
Acuvi
m IIW
Others
Onboard Memory Size
Memory
Bytes
_
8MB
8MB
8MB
Communication
RS485 Port,Half Duplex, Optical Isolated
Modbus-RTU/DNP3.0 Protocol
= = =
=
Time
Real Time Clock
Year, Month, Date, Hour, Minute, Second
= = =
=
400Hz type
Only support full-wave energy,support 2nd ~ 15th individual harmonics.
===
Option Module
I/O Option
Switch Status (DI)
Digital Input (Wet)
8 8 8 8
Power Supply for DI
24 Vdc
8 8 8 8
Relay Output (RO)
NO, Form A
8 8 8 8
Digital Output (DO)
Photo-MOS
8
8 8 8
Pulse Output (PO)
By using DO
8
8 8 8
Analog Input (AI)
0(4)~20mA, 0(1)~5V
8
8 8 8
Analog Output (AO)
0(4)~20mA, 0(1)~5V
8
8 8 8
Communication
Ethernet
Modbus-TCP, HTTP , SNMP, SMTP, SNTP
8
8 8 8
Profibus-DP
Profibus-DP/V0
8
8 8 8
The second way RS485 Module
Modbus-RTU Protocol
8
8 8 8
BACnet
IP or MS/TP
8
8 8 8
= Function;
8
Option; Blank NA
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 15
Acuvim II Series Power Meter
Chapter 1: Introduction
V:1.0 Revised October 2018
15
Acuvim II Series Power Meter
2.1 Appearance and Dimensions
2.2 Installation Methods
2.3.2 Power Requirements
2.3.3 Voltage Input Wiring
Chapter 2 Installation
2.3 Wiring
2.3.1 Terminal Strips
2.3.4 Current Input Wiring
2.3.5 Frequently Used Wiring Methods
2.3.6 Communication
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 16
Acuvim II Series Power Meter
V:1.0 Revised October 2018
16
Chapter 2 Installation
Considerations When Installing Meters
Installation of the meter must be performed by qualified personnel only, who follow standard safety precautions through the installation procedures. Those personnel should have appropriate training and experience with high voltage devices. Appropriate safety gloves, safety glasses and protective clothing are recommended.
During normal operation, dangerous voltage may flow through many parts of the meter, including terminals, and any connected CTs (Current Transformers) and PTs (Potential Transformers), all I/O (Inputs and Outputs) modules and their circuits. All primary and secondary circuits can, at times, produce lethal voltages and currents. AVOID contact with any current-carrying surfaces.
The meter and its I/O output channels are NOT designed as primary protection devices and shall NOT be used as primary circuit protection or in an energy limiting capacity. The meter and its I/O output channels can only be used as secondary protection. AVOID using the meter under situations where failure of the meter may cause injury or death. AVOID using the meter for any application where risk of fire may occur.
All meter terminals should be inaccessible after installation.
Do NOT perform Dielectric (HIPOT) test to any inputs, outputs or communication terminals. High voltage testing may damage electronic components of the meter.
Applying more than the maximum voltage the meter and/or its modules can withstand will permanently damage the meter and/or its modules. Please refer to the specifications for all devices before applying voltages.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 17
Acuvim II Series Power Meter
Chapter 2 Installation
V:1.0 Revised October 2018
17
When removing meter for service, use shorting blocks and fuses for voltage leads and power supply to prevent hazardous voltage conditions or damage to CTs. CT grounding is optional.
ACCUENERGY recommends using a dry cloth to wipe the meter.
NOTE: IF THE EQUIPMENT IS USED IN A MANNER NOT SPECIFIED BY THE MANUFACTURER, THE PROTECTION PROVIDED BY THE EQUIPMENT MAY BE IMPAIRED.
NOTE: THERE IS NO REQUIRED PREVENTIVE MAINTENANCE OR INSPECTION NECESSARY FOR SAFETY. HOWEVER, ANY REPAIR OR MAINTENANCE SHOULD BE PERFORMED BY THE FACTORY.
DISCONNECT DEVICE: The following part is considered the equipment disconnect device.
A SWITCH OR CIRCUIT-BREAKER SHALL BE INCLUDED IN THE INSTALLATION. THE SWITCH SHALL BE IN CLOSE PROXIMITY TO THE EQUIPMENT AND WITHIN EASY REACH OF THE OPERATOR. THE SWITCH SHALL BE MARKED AS THE DISCONNECTING DEVICE FOR THE EQUIPMENT.
The installation method is introduced in this chapter. Please read this chapter carefully before beginning installation.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 18
Acuvim II Series Power Meter
Chapter 2 Installation
V:1.0 Revised October 2018
18
2.1 Appearance and Dimensions
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 19
Acuvim II Series Power Meter
Chapter 2 Installation
V:1.0 Revised October 2018
19
Part Name
Description
1. LCD Display
Large bright white backlight LCD display.
2. Front Casing
Visible portion (for display and control) after mounting onto a panel.
3. Key
Four keys are used to select display and set.
4. Enclosure
The Acuvim II series meter enclosures is made of high strength anti-combustible engineering plastic.
5. DIN rail
Used for Installation 35mm rail of the DIN rail Meter.
6. Voltage Input Terminals
Used for voltage input.
7. Current Input Terminals
Used for current input.
8. Power Supply Terminals
Used for control power input
9. Communication Terminals
Communication output.
10. Interface
Used for link the remote display unit and the DIN rail meter.
11. Installation Clip
Used for fixing the meter to the panel.
12. Gasket
Insert the gasket in between the meter and the cutout to cover up gaps from the round hole.
Fig 2-1 Appearance and dimensions of Acuvim II series meter Table 2-1 Part name of Acuvim II series meter
2.2 Installation Methods
Environmental
Before installation, please check the environment, temperature and humidity to ensure the Acuvim II series meter is being placed where optimum performance will occur.
Temperature
Operation: -25˚C to 70˚C. Storage: -40˚C to 85˚C
Humidity
5% to 95% non-condensing. The Acuvim II series meter should be installed in a dry and dust free environment. Avoid exposing meter to excessive heat, radiation and high electrical noise source.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 20
Acuvim II Series Power Meter
Chapter 2 Installation
V:1.0 Revised October 2018
20
Installation Steps
The Acuvim II series meter can be installed into a standard ANSI C39.1 (4” Round) or an IEC 92mm DIN (Square) form.
1. Cut a square hole or round hole on the panel of the switch gear. The cutting size is shown in fig 2-2.
2. Remove the clips from the meter, and insert the meter into the square hole from the front side. Please note: optional rubber gasket must be installed on the meter before inserting the meter into the cut out.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 21
Acuvim II Series Power Meter
Chapter 2 Installation
V:1.0 Revised October 2018
21
3. Install clips on the back side of the meter and secure tightly to ensure the meter is
affixed to the panel.
Note: The display meter and the remote display unit have the same installation method. The DIN rail meter is simply installed on a 35mm DIN rail.
2.3 Wiring
2.3.1 Terminal Strips
There are four terminal strips at the back of the Acuvim II series meter. The three­phase voltage and current are represented by using 1, 2, and 3 respectively. These numbers have the same meaning as A, B, and C or R, S, and T used in other literature.
Current Input Terminal Strip
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 22
Acuvim II Series Power Meter
Chapter 2 Installation
V:1.0 Revised October 2018
22
Power Supply Terminal Strip
Communication Terminal Strip
Safety Earth Connection Before setting up the meter's wiring, please make sure that the switch gear has an earth ground terminal. Connect both the meter's and the switch gear's ground terminal together. The following ground terminal symbol is used in this user's manual.
DANGER
Only the qualified personnel does do the wire connection work. Make sure the power supply is cut off and all the wires are powerless. Failure to observe it may result in severe injury or death.
Voltage Input Terminal Strip
Fig 2-5 Terminal Strips of Acuvim II series meter
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 23
Acuvim II Series Power Meter
Chapter 2 Installation
V:1.0 Revised October 2018
23
2.3.2 Power Requirement
Control Power
There are 2 options for the Control Power of the Acuvim II series meter:
1. Standard: 100~415Vac (50/60Hz) or 100-300Vdc
2. Low Voltage DC Option: 20-60Vdc
The 2 options must be chosen according to the application. Please see the ordering information appendix for further details.
The meter's typical power consumption is very low and can be supplied by an independent source or by the measured load line. A regulator or an uninterrupted power supply (UPS) should be used under high power fluctuation conditions. Terminals for the control power supply are 11, 12 and 13 (L, N, and Ground). A switch or circuit-breaker shall be included in a building installation. It shall be in close proximity to the equipment, within easy reach of the operator, and shall be marked as the disconnecting device for the equipment.
NOTE
Make sure the control power terminal of the meter ground is connected to the safety Earth of switchgear.
NOTE
Make sure the voltage of power supply is the same as what the meter needed for its control power.
Find Quality Products Online at: sales@GlobalTestSupply.com
A fuse (typical 1A/250Vac) should be used in the auxiliary power supply loop. No.13 terminal must be connected to the ground terminal of the switchgear. An isolated transformer or EMC
Page 24
Acuvim II Series Power Meter
Chapter 2 Installation
V:1.0 Revised October 2018
24
filter should be used in the control power supply loop if there is a power quality problem in the power supply.
Choice of wire of power supply is AWG22-16 or 0.6-1.5mm2.
Voltage Input
Maximum input voltage for the Acuvim II series meter shall not exceed 400LN/690LL VAC rms for three phase or 400LN VAC rms for single phase. Potential Transformer (PT) must be used for high voltage systems. Typical secondary output for PTs shall be 100V or 120V. Please make sure to select an appropriate PT to maintain the measurement accuracy of the meter. When connecting using the star configuration wiring method, the PT's primary side rated voltage should be equal to or close to the phase voltage of the system to utilize the full range of the PT. When connecting using the delta configuration wiring method, the PT's primary side rated voltage should be equal to or close to the line voltage of the system. A fuse (typical 1A/250Vac) should be used in the voltage input loop. The wire for voltage input is AWG16-12 or 1.3-2.0mm2.
Note: In no circumstance should the secondary of the PT be shorted. The secondary of the PT should be grounded at one end. Please refer to the wiring diagram section for further details.
Current Input
Current Transformers (CTs) are required in most engineering applications. Typical current rating for the secondary side of the CT shall be 5A (standard) or 1A (Optional), please refer to the ordering information appendix for further details. CTs must be used if the system rated current is over 5A. The accuracy of the CT should be better than 0.5% with rating over 3VA is recommended in order to preserve the meter's accuracy. The wire between CTs and the meter shall be as short as possible.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 25
Acuvim II Series Power Meter
Chapter 2 Installation
V:1.0 Revised October 2018
25
The length of the wire has an effect on the accuracy. The wire size of current input is AWG15­10 or 1.5-2.5mm2.
Note: The secondary side of the CT should not be open circuit in any circumstance when the power is on. There should not be any fuse or switch in the CT loop. One end of the CT loop should be connected to the ground.
Vn Connection
Vn is the reference point of the Acuvim II series meter voltage input. Low wire resistance helps improve the measurement accuracy. Different system wiring 20 modes require different Vn connection methods. Please refer to the wiring diagram section for more details.
Three Phase Wiring Diagram
This meter can satisfy almost any kind of three phase wiring diagrams. Please read this section carefully before choosing the suitable wiring method for your power system.
Voltage and current input wiring mode can be set separately in the meter parameter setting process. The voltage wiring mode can be set as 3-phase 4-line Wye (3LN), 3-phase 3-line direct connection(3LL), 3-phase 3-line open delta(2LL), single phase 2-line(1LN) and single phase 3­line(1LL). The current input wiring mode can be set as 3CT, 2CT and 1CT. The voltage mode can be grouped with the current mode as 3LN-3CT (3CT or 2CT, 3LL-3CT, 2LL-3CT, 2LL2CT, 1LL-2CT, 1LN-1CT).
2.3.3 Voltage Input Wiring
3-Phase 4-Line Wye Mode (3LN)
The 3-Phase 4-Line wye mode is commonly used in low voltage electric distribution power systems. For voltage lower than 400LN/690LL Vac, power line can be connected directly to the meter's voltage input terminal as shown in Fig 2-9a. For high voltage systems (over 400LN/690LL Vac), PTs are required as shown in Fig 2-9b. The meter should be set to 3LN for both voltage levels.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 26
Acuvim II Series Power Meter
Chapter 2 Installation
V:1.0 Revised October 2018
26
3-Phase 3-Line Direct Connection Mode (3LL)
In a 3-Phase 3-Line system, power line A, B and C are connected to V1, V2 and V3 directly. Vn is floated. The voltage input mode of the meter should be set to 3LL.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 27
Acuvim II Series Power Meter
Chapter 2 Installation
V:1.0 Revised October 2018
27
3-Phase 3-Line open Delta Mode (2LL)
Open delta wiring mode is often used in high voltage systems. V2 and Vn are connected together in this mode. The voltage input mode of the meter should be set to 2LL for this voltage input wiring mode.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 28
Acuvim II Series Power Meter
Chapter 2 Installation
V:1.0 Revised October 2018
28
2.3.4 Current Input Wiring
3CT
The 3CT current wiring configuration can be used when either 3CTs are connected (as shown in Fig 2-12) or 2CTs are connected (as shown in Fig 2-13) 23 to the system. In either case, there is current flowing through all three current terminals.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 29
Acuvim II Series Power Meter
Chapter 2 Installation
V:1.0 Revised October 2018
29
2CT
The difference between Fig 2-14 and Fig 2-15 is that no current flows through current input terminal I21 and I22. The meter should be set to the I2 value which is calculated from formula i1+i2+i3=0. The current input mode of the meter should be set to 2CT.
1CT
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 30
Acuvim II Series Power Meter
Chapter 2 Installation
V:1.0 Revised October 2018
30
2.3.5 Frequently Used Wiring Method
In this section, the most common voltage and current wiring combinations are shown in different diagrams. In order to display measurement readings correctly, please select the appropriate wiring diagram according your setup and application.
1. 3LN, 3CT with 3CTs
2. 3LN, 3CT with 2CTs
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 31
Acuvim II Series Power Meter
Chapter 2 Installation
V:1.0 Revised October 2018
31
3. 2LL, 3CT
4. 2LL, 2CT
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 32
Acuvim II Series Power Meter
Chapter 2 Installation
V:1.0 Revised October 2018
32
5. 1LN, 1CT (Wiring mode setting 1LN, 1CT)
6. 1LL, 2CT (Wiring mode setting 1LL, 2CT)
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 33
Acuvim II Series Power Meter
Chapter 2 Installation
V:1.0 Revised October 2018
33
2.3.6 Communication
Acuvim II series meter uses RS485 serial communication and the ModbusRTU protocol. The terminals of communication are A, B, and S (14, 15, 16). A is differential signal +, B is differential signal - and S is connected to the shield of the twisted pair cables. Up to 32 devices can be connected on a RS485 bus. Use good quality shielded twisted pair cable, AWG22 (0.5mm2) or higher. The overall length of the RS485 cable connecting all devices should not exceed 1200m (4000ft). The Acuvim II series meter is used as a slave device of masters such as a PC, PLC, Data Collector or RTU.
If the master does not have RS485 communication port, a converter (such as a RS232/RS485 or a USB/RS485 converter) will be required. Typical RS485 network topologies include line, circle and star (wye). The shield of each segment of the RS485 cable must be connected to the ground at one end only.
Every A(+) should be connected to A(+), B(-) to B(-), or it will influence the network, or even damage the communication interface.
The connection topology should avoid “T” type which means there is a new branch and it does not begin from the beginning point.
Keep communication cables away from sources of electrical noise whenever possible.
When using a long communication cable to connect several devices, an anti-signal reflecting resistor (typical value 120Ω-300Ω/0.25W) is normally added to the end of the cable beside the last meter if the communication quality is distorted.
Use RS232/RS485 or USB/RS485 converter with optical isolated output and surge protection.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 34
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
34
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
3.1 Display Panel and Keys
3.2 Metering Data
3.3 Statistics Data
3.4 Demand Data
3.5 Harmonic Data
3.6 Expanded I/O Module Data
3.7 Parameter Settings Mode
3.8 Page Recovery Function
Chapter 3: Meter Display and Parameter Settings
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 35
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
35
Detailed human-machine interface of the meter will be described in this chapter. This includes viewing real-time metering data and setting parameters using different key combination.
3.1 Display Panel and Keys
The front of the Acuvim II series meter consists of an LCD screen and four control keys. All the display segments are illustrated in Fig 3-1. Users should note that all the segments will not display in a single page under normal conditions.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 36
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
36
SN
Display
Description
1
Display mode indication
Shows different modes on the display area. “Meter” for real-time measurement; “Max/Min” for statistic data; “Demand” for power demand data; “Harmonic” for harmonic data; “Setting” for parameters setting; “Digital I/O” for expanded IO module data.
2
2 Four lines of “ ” digits in the metering area
Main display area: displays metering data such as voltage, current, power, power factor, frequency, unbalance, phase angle,etc. Displays statistics such as maximum and minimum, demand data, display settings and expanded I/O data.
3
Four “ ” and five “ ” digits
Displays energy data and real-time clock. Also used for the setting mode and digital I/O mode display
4
Three “ ” digits
Item Icons: “U” for voltage; “I” for current; “P” for active power; “Q” for reactive power; “S” for
apparent power; “PF” for power factor; “F” for frequency; “ ” for phase angles; “DMD” for demand; "Mxx" for expanded IO module type; and display setting page number.
5
Unbalance, THD, TDD, MAX, MIN
Item Icons: “Unbalance” for unbalance of the voltage and current; “THD” for total harmonics distortion; “ TDD” for total demand distor tion; “MAX” for maximum and “MIN” for minimum
6
Load rate
Displays the percentage of load current to the nominal current.
7
Four quadrant icon:
Load type icon:
: quadrant of the system power
: inductive load; : capacitive load
8
1-2, 2-3, 3-1, avg, N
1, 2, 3 for 3 phase A, B, C; 1-2, 2-3, 3-1 for 3 phase lineto-line AB, BC, CA; avg for average and N for neutral.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 37
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
37
9
Energy icon: Imp, Total, Net, Exp
Imp: import energy Exp: export energy Total: absolute sum of Imp and Exp energy Net: algebraic sum of Imp and Exp energy
10
Units measured
voltage: V, kV; current: A, kA:active power: kW, MW; reactive power: kvar, Mvar; apparent power: kVA, MVA; frequency: Hz; active energy:
kWh; reactive energy: kvarh; apparent energy: kVAh; percentage: %; phase angle: °
11
Communication icon
No icon: no communication One icon: query sent Two icons: query sent and response received
12
Energy pulse output indicator
No icon: no pulse output With icon: icon blinks when sending pulse output
13
Expanded I/O module indicator
M1: one AXM-IO1 connected M1x2: two AXM­IO1 connected None: no AXM-IO1 connected M2: one AXM-IO2 connected M2x2: two AXM­IO2 connected None: no AXM-IO2 connected M3: one AXM-IO3 connected M3x2: two AXM-
IO3 connected None: no AXM-IO3 connected
14
Profibus module indicator
No icon: Profibus module not connected With icon: Profibus module connected
15
Ethernet module indicator
No icon: Ethernet module not connected With icon: Ethernet module connected, when
the Second Communication Protocol is setting as Others BACnet module connected, when the Second Communication Protocol is setting as BACnet M esh module connec ted, when the second communication Protocol is setting as Mesh.
16
Current tarif
17
Time icon
Time display
There are four keys on the front panel, labeled H, P, E and V/A from left to right. Use these four keys to read real-time metering data, set parameters and 33 navigate the meter.
Note: If the LCD backlight is off, pressing any key one time will bring the backlight on.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 38
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
38
3.2 Metering Data
Pressing H and V/A simultaneously will activate the display mode selection and the cursor will flash. Press P or E to move the cursor right or left. To enter the metering mode, move the cursor to "Meter" then press V/A. In the metering mode, press P and E simultaneously will enter the TOU mode. In metering mode, the meter displays measurements such as voltage, current, power, power factor, phase angle, unbalance etc. In the TOU mode, meter displays the energy, maximum demand and it's time in different tariffs.
a) Voltage and Current:
Press V/A to read voltage and current in the metering area. The screen will roll to the next page when V/A is pressed again. It will go back to the first screen if you press V/A at the last screen. The following figure shows the sequence:
Note: When the meter is set to “2LL” or “3LL”, there is no phase voltage or neutral current display. Therefore, only the third screen (line voltage & avg) and the fourth screen (three phase current & avg) will be displayed. When the meter is set to “1LN”, there are only phase A voltage and phase A current display, without line voltages or other displays. When the meter is set to “1LL”, there are no phase C voltage and phase C current display.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 39
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
39
b) Power, Power Factor and Frequency:
Press P to display power related data. The screen will roll to the next page when P is pressed again. It will go back to the first screen if you press P at the last screen. The following figure shows the sequence:
Note: When the meter is set to “2LL” or “3LL”, only the fifth screen (system power) and the sixth screen (system power factor & frequency) will be displayed. When the meter is set to “1LN”, there are only phase A power and phase A power factor display.
When the meter is set to “1LL”, there are no phase C power and phase C power factor display.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 40
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
40
c) Phase Angles and Unbalance:
Press H to display phase angles and unbalance data. The screen will roll to the next page when H is pressed again. It will go back to the first screen if you press H at the last screen. The following figure shows the sequence:
When using "2LL" or "3LL" wiring setting mode, voltage stands for line to line voltage. Otherwise, voltage stands for line-to-neutral voltage
When the meter is set to “1LN”, there is only phase A current to phase A voltage angle display.
When the meter is set to “1LL”, there is no phase C voltage or current to phase A voltage angle factor display.
d) Energy:
Press E key to display energy and real time clock. The screen will roll to the next page when E is pressed again. It will go back to the first screen if you press E at the last screen.
Acuvim II series meter can be set to record primary energy or secondary energy. The unit of energy is kWh for active energy, kvarh for reactive energy and kVAh for apparent energy. The running time has a resolution of 0.01h. The meter begins accumulating time upon initial
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 41
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
41
powering up of the unit. The accumulated time is stored in the non-volatile memory. It can be reset via communication or from the meter front.
The following figure shows the sequence:
e) TOU display
Press “P” and “E” simultaneously to enter the TOU Energy and maximum demand page. Press “E” display the TOU energy. Press “P” display the TOU maximum demand. Press again display the TOU maximum demand year, month and date. Press again display the TOU maximum demand hour, minute and second. Press “Would change the tariffs page. It displays energy under different tariffs in the energy page. It also displays demand under different tariffs in the maximum demand page. Press “V/A “would display different type energy and maximum demand. Press “P” and “E” simultaneously to exit current page and return to metering mode.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 42
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
42
The following figure shows the sequence:
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 43
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
43
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 44
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
44
3.3 Statistics Data
Pressing H and V/A simultaneously will activate the display mode selection and the cursor will flash. Press P or E to move the cursor right or left. To enter the statistics data mode, scroll the cursor to "Max/Min" then press V/A.
In statistics data mode, the meter displays the maximum values and minimum values for voltage, current, power, power factor, unbalance, demand, THD etc. User should note that time stamp for the parameters can be viewed only from the software through communication. No commands are associated with the key H in "Max/Min" display mode.
When P is pressed again, the screen will roll to the next page, and will roll back to the first screen when pressed at the last page.
When E is pressed the screen will roll back to the previous page, and will roll back to the last screen when pressed at the first page.
Press V/A to switch the view between maximum and minimum. For example, if the current display is the maximum phase voltage value, when V/A is pressed, the display will show the minimum phase voltage value. If V/A is pressed again, the display will switch back to show the maximum phase voltage value.
The following figure shows the sequence:
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 45
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
45
Note:
i) The figure shows the rolling sequence when pressing P. The sequence will be
reversed when pressing E.
ii) When the meter is set to “2LL” or “3LL”, the first screen(max value of phase
voltage) will not be displayed.
iii) When the meter is set to “1LL”, there are no such displays as phase C voltage,
Ubc and Uca line voltage, phase C current, three phase voltage and current unbalance factor, Uc and Ic THD, phase C current demand, etc.
iv) When the meter is set to “1LN”, there is only phase A display of phase voltage
and current, only Ua and Ia THD display, only demand display of phase A. And there are no such displays as three phase voltage and current unbalance factor, line voltage, etc.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 46
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
46
3.4 Demand Data
Pressing H and V/A simultaneously will activate the display mode selection and the cursor will flash. Press P or E to move the cursor right or left. To enter demand mode, move the cursor to "Demand" then press V/A.
In the demand data mode, the first screen displays the demand of active power, reactive power and apparent power, and the second screen displays the current demand of phase A, phase B and phase C. When the meter is set to “1LL”, there is no phase C current demand display. When the meter is set to “1LN”, there are no phase B and C current demand display.
As shown in the figure, system active power demand is 3.285kW, system reactive power demand is 0 kvar, system apparent power demand is 3.285 kVA.
3.5 Harmonic Data
Pressing H and V/A simultaneously will activate the display mode selection and the cursor will flash. Press P or E to move the cursor right or left. To enter harmonic mode, move the cursor to "Harmonic" then press V/A.
In the harmonic data mode, meter displays the harmonic ratio of voltage and current, THD, odd HD, even HD, THFF, CF and KF.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 47
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
47
a) Power Quality Data:
Press H to display power quality data. When H is pressed again, the screen will roll to the next page and will roll back to the first screen when pressed at the last page.
No commands are associated with keys P and E in "Harmonic" display mode.
Press V/A to switch to harmonic ratio data display.
Note: When the meter is set to “1LN”, there is only phase A display for voltage THD, voltage odd HD, voltage even HD, THFF, voltage crest factor, current THD, current odd HD, current even HD, and current K factor.
When the meter is set to “1LL”, there is no phase C display.
b) Harmonic Ratio Data
Press H to switch to power quality data display.
The harmonic order will increase by one each time P is pressed and will return to the 2nd when P is pressed at the 63rd harmonic.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 48
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
48
The harmonic order will decrease by one each time E is pressed and will return to the 63rd when E is pressed at the 2nd harmonic.
Press V/A to switch display between voltage harmonics and current harmonics.
The following figure shows the sequence:
Note:
1. The figure shows the rolling sequence when pressing P. If E is pressed, the sequence will reverse.
2. Harmonic is 2nd~63rd.
3. When the meter is set to “1LN”, there is only phase A display for voltage and current harmonic magnitude.
4. When the meter is set to “1LL”, there is no phase C display for voltage and current harmonic magnitude.
3.6 Expanded I/O Module Data
Pressing H and V/A simultaneously will activate the display mode selection and the cursor will flash. Press P or E to move the cursor right or left. To access data from the expanded I/O modules, move the cursor to "Digital I/O" then press V/A to enter the expanded I/O module data mode.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 49
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
49
In the expanded I/O module data mode, the meter displays the data from expanded I/O modules, such as DI status, pulse counter number, relay status, analog input, and analog output etc.
In this mode, the first page is module selection. You can choose to view the available modules that are attached to the meter. If no expanded I/O modules are connected, the screen will display "NO IO".
a) Module Selection:
No commands are associated with the key H in the module selection screen.
Press P to move the cursor downwards, the cursor will move to the top when it reaches the bottom. If only one module is connected, Pressing P will have no effect.
Press E to move the cursor upwards, the cursor will move to the bottom when it reaches the top. If only one module is connected, Pressing E will have no effect.
Press V/A to select the module and enter the I/O module data selection mode.
As shown in the figure, three modules are connected, AXM-IO11, AXM-IO21, AXM­IO31, which are indicated by M11, M21, M31 respectively. The cursor points to M21, which indicates that AXM-IO21 is chosen now.
b) I/O Module Data Selection
Press H to return to module selection screen.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 50
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
50
Press P to move the cursor downwards, the cursor will move to the top when it reaches the bottom. Please note that there are 3 parameters for AXM-IO1, 3 parameters for AXM-IO2 and 4 parameters for AXM-IO3.
Press E to move the cursor upwards, the cursor will move to the bottom when it reaches the top.
Press V/A to select the parameter and enter the display of the data.
c) I/O module data display
Press H to return to I/O module data selection screen.
The screen will roll to the next page each time P is pressed and will return to the first page when P is pressed at the last page. If only one page exists, pressing P will have no effect.
The screen will roll to the last page each time E is pressed and will return to the last page E is pressed at the first page. If only one page exists, pressing E will have no effect.
No commands are associated with the key V/A in this display.
The following figure shows the sequence:
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 51
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
51
Note: The figure shows the rolling sequence for using key P. If using E key for rolling page, the sequence will reverse.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 52
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
52
3.7 Parameter Setting Mode
Pressing H and V/A simultaneously will activate the display mode selection and the cursor will flash. Press P or E to move the cursor right or left. To enter parameter setting mode, move the cursor to "Setting" then press V/A.
In the parameter setting mode, parameters such as system parameters, expanded I/O module parameters, alarm parameters and Ethernet module parameters, can be read and modified.
a) Password Inquiry:
Parameter setting mode is password protected. Before entering the password and getting into the parameter setting mode, the meter's device communication address will display for 3 seconds. A four-digit password (0000 to 9999) is required every time before accessing the parameter setting mode. The default password is 0000. After entering the password, press V/A to go to the parameter selection page. The meter will be still in the password inquiry page if a wrong password is entered.
The following figure shows the password inquiry page.
To input password: Press H to move the flashing cursor to the next position. Press P to increase the number by 1. Press E to decrease the number by 1. Press V/A to confirm the password.
b) Parameter Selection Mode
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 53
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
53
There are four parameters to choose from in the parameter selection manual: system, expanded I/O module, Ethernet module and alarm.
No commands are associated with the H key in the parameter selection manual.
Press P to move the cursor downwards, the cursor will move to the top when it reaches the bottom.
Press E to move the cursor upwards, the cursor will move to the bottom when it reaches the top.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 54
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
54
Press V/A to select and modify the parameter. The figure shows the parameter selection page. “SYS” stands for system parameter, “I/O” stands for expanded I/ O module parameter, “NET” stands for Ethernet module parameter or BACnet module parameter ("MESH" stands for mesh module) and “ALM” stands for alarm parameter. As shown in the figure, the cursor points to the “SYS”, which 51 means system parameters is selected.
c) System Parameter Setting
Users can select and modify system parameter in the system parameter setting mode.
Key functions for selecting a parameter:
Press H to return to parameter selection mode.
The screen will roll to the next page each time P is pressed and will return to the first page when P is pressed at the last page.
The screen will roll to the last page each time E is pressed and will return to the last page when E is pressed at the first page.
Press V/A to modify the selected parameter.
Key functions for modifying the parameter:
Press H to move the flashing cursor to the next position.
Press P to increase the number by 1.
Press E to decrease the number by 1.
Press V/A to confirm the modification and return to parameter selection mode. The following figure shows the sequence:
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 55
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
55
MODBUS: range is 1~247 DNP3.0: range is 0~65534
Select form 1200, 2400, 4800, 9600, 19200, 38400 bps.
“Baud rate for external RS485 module Select from 4800, 9600, 19200, 38400 bps” Ethernet module and Profibus module only selects 38400 bps Mesh module only selects 9600bps.
Voltage wiring mode can be one of “3LN”, “2LL”, “3LL”, “1LN” or “1LL”
Current wiring mode can be one of “3CT”, “1CT”, “2CT”.
P1: primary nominal value of P, range from 50.0V~500,000.0V
PT2: secondary nominal value of PT, range from 50.0V~400.0V If no PT used, PT1 and PT2 as the nominal voltage of the meter.
CT1: primary value of CT, range from 1A-50000A;
CT2: secondary value of CT, choose from 1A or 5A When the CT is 333mV voltage type, choose 333. When the CT is Rope CT, choose 100. When the CT is mA, choose 80/100/200.
Which is active energy of each pulse from DO. The pulse of each 1kWh energy can be set to 1~60000 pul/kvarh (secondary) Description: The specific setting method, see the address table.
Which is reactive energy of each pulse from DO. The pulse of each 1kvarh energy can be set to 1~60000 pul/kvarh (secondary). Description: The specific setting method, see the address table.
The “on“ time can be set from 0 to 120 minute. He backlights will always be “on” if the setting value is 0. If it is other value, it means after that long time it will go off if no key
has been pressed. It will be “on” whenever you press any key if it is off.
1: sliding block, 2: thermal
Range from 1~30 minutes
Yes: clear; No: not clear
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 56
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
56
To clear the Max and Min value does not mean write 0 to all the registers, it will copy the metering value to the statistic registers and start a new statistic period.
Yes: clear; No: not clear
To adjust polarity of current, the three-current’s direction can be set as “Negative” which means reversing 180 degrees and “Positive” which means normal.
0: IEC, 1: IEEE
Yes: clear; No: not clear
0: true 1: generalized
Pre: primary energy; Sec: secondary energy;
Range from 0-6. 0: not clear; 1: AXM-IO11 clear; 2: AXM-IO21 clear; 3:AXM-IO31clear; 4:AXM-IO 12 clear, 5:AXM-IO22 clear; 6:AXM-IO32 clear;
Range from 0-6. 0: not clear; 1: AXM-IO11 clear; 2: AXM-IO21 clear; 3:AXM-IO31clear; 4:AXM-IO 12 clear, 5:AXM-IO22 enable; 6:AXM-IO32 enable;
Any integer from 0-126
Pre: primary basic energy; Sec: secondary basic energy;
Last page of the system parameter setting. Set the password in this page and make sure to remember the new password, or you may not use the meter properly. Onboard RS485 port Parity setting. It can be selected from NON1, NON2, Odd and Even.
NON1 represents non-parity, single stop bit; NON2 represents non-parity, double stop bit; odd represents odd-parity, single stop-bit; even represents even parity, single stop bit. By default, it is set as NON1.
RS485 module Parity setting. It can be selected from NON1, NON2, Odd and Even. Please refer to S31 for each selection details. By default, it is set as NON1. When user selects NET module or Profibus or Mesh module, Parity setting2 should set NON1.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 57
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
57
0: Base, 1: full
0:50HZ, 1:60HZ, 2:400HZ When select 400H type, only support full function.
2: Mesh, 1: BACnet, 0:Other Protocols if using BACNet module, you should select BACNet, Mesh module, you should select Mesh, if you are using Ethernet, Profibus, RS485 module, should select other
0: MODBUS, 1: DNO3.0
Optional range of 1~247
0x0A: clear, other: no
Note: The figure shows the rolling sequence for using the P key. If using the E key for rolling page, the sequence will reverse.
b) Expanded I/O Module Parameter
In the expanded I/O module parameter mode, user can choose to view the available modules that are attached to the meter and modify their parameters. If no expanded I/O modules are connected, the screen will display "NO IO". To return to system parameter setting mode main menu, press H (no commands are associated with other keys in this screen).
Key functions for I/O module selection:
Press H to return to parameter selection mode.
Find Quality Products Online at: sales@GlobalTestSupply.com
Press P to move the cursor downwards. The cursor will move to the top when it reaches the bottom.
If there is only one module connected, pressing P will have no effect. Press E to move the cursor upwards, the cursor will move to the bottom when it reaches
the top. 55 If there is only one module connected, pressing E will have no effect. Press V/A to select the module and enter the I/O module parameter setting mode.
Page 58
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
58
Key functions for setting the I/O module parameter:
DI of AXM-IO-1 can be used as the pulse counter, each DI function corresponds to one bit of a 6-bit register. The correspondence bit of 0 means that the DI works as the digital status input and the correspondence bit of 1 means that the DI works as the pulse counter. For example, if the setting value is 000001, it means that DI1 is set as the pulse counter and other Dis work as digital status inputs.
If the DI works as a pulse counter, when the number of pulses counted by the DI equals to the pulse constant, the pulse counter will increase by one. This means that the actual pulse number equals the number pulses counted multiplied by the pulse constant.
Relays of AXM-IO1 can be used as alarm output or control output. ALM:alarm output; control output.
When set as control output, relays have two control methods: latch or pulse.
LATCH: latch more; PUL: pulse mode
If relay pulse control method is selected, the relay contact will close for a present period and open afterwards. The pulse width range is 50~3000 ms.
Press H to return to I/O module selection mode. The screen will roll to the next page each time P is pressed and will return to the first page when P is pressed at the last page. The screen will roll to the last page each time E is pressed and will return to the last page when E is pressed at the first page. Press V/A to modify the selected parameter.
Key functions for modifying the parameter:
Press H to move the flashing cursor to the next position. Press P to increase the number by 1. Press E to decrease the number by 1. Press V/A to confirm the modification and return to parameter selection mode.
The following table shows the sequence:
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 59
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
59
DI of AXM-IO2 can be used as the pulse counter, each DI function corresponds to one bit of a 4-bit register. The correspondence bit of 0 means that the DI works as the digital status input and the correspondence bit of 1 means that the DI works as the pulse counter. For example, if the setting value is 0001, it means that DI1 is set as the pulse counter and other DIs work as digital status inputs.
If the DI works as a pulse counter, when the number of pulses counted by the DI equals to the pulse constant, the pulse counter will increase by one. This means that the actual pulse number equals the number of pulses counted multiplied by the pulse constant.
DO of AXM-IO1 can be used as either alarm output or energy pulse output. ALM: alarm output; PUL: energy pulse output
Range from 20-1000ms
Choose output energy type for DO1. Range from 0-4. 0: no output; 1: import active energy; 2: export active power; 3: import reactive energy; 4: export reactive energy.
Follow the DO1 setup method to setup DO2. If DO type is set as alarm output, DO1 and DO2 output type parameters will have no effect.
Range from 0 to 3, 0: 0-20mA; 1: 4~20mA; 2: 0-5V; 3: 1-5V.
Be aware that modules with current option cannot be set as voltage type (i.e. option 2 and 3 are unavailable); modules with voltage option cannot be set as current type (i.e. option 0 and 1 are unavailable).
For AO1 and AO2 transforming parameter: Range: 0~29, see Chapter 5 page 99 "AO transforming parameter settings" for more detail When modifying AO parameter, AO input/output values reset s. default value.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 60
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
60
DI of AXM-IO3 can be used as the pulse counter, each DI function corresponds to one bit of a 4-bit register. The correspondence bit of 0 means that the DI works as the digital status input and the correspondence bit of 1 means that the DI works as the pulse counter. For example, if the setting value is 0001, it means that DI1 is set as the pulse counter and other DIs work as digital status inputs.
If the DI works as a pulse counter, when the number of pulses counted by the DI equals to the pulse constant, the pulse counter will increase by one. This means that the actual pulse number equals the number of pulses counted multiplied by the pulse constant.
When set as control output, relays have two control methods: latch or pulse
Relays of AXM-IO3 can be used as alarm output or control output. ALM:alarm output; CTRL:control output
If relay pulse control method is selected, the relay contact will close for a pre-set period and open afterwards. The pulse width range is 50~3000ms.
Range from 0 to 3. 0: 0~20mA; 1: 4~20mA; 2: 0~5V; 3: 1~5V. Be aware that modules with current option cannot be set as voltage type (i.e. option 2 and 3 are unavailable); modules with voltage option cannot be set as current type (i.e. option 0 and 1 are unavailable).
Find Quality Products Online at: sales@GlobalTestSupply.com
Note: The figure shows the rolling sequence for using key P. If using key E for rolling page, the sequence will reverse.
Page 61
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
61
e) BACnet and Ethernet Module Parameter
When the second communication protocol is set to BACnet, there is parameters display related to BACnet, while these pages only show as modules successfully connecting with meter. If meter does not detect any module, there will show LOADING page. To set these parameters, first, select, then modify and save. On the one side, if there is no extra BACnet module, setting will be meaningless and not saved after shutting down. On the other side, setting is valid and will be saved into BACnet module when there is a BACnet module attached. When the second communication is set to MESH, where is parameter display related to MESH module.
When second communication protocol is other protocol, there is parameters display related to Ethernet. The condition is same as above.
Key functions for finding the Ethernet module parameter:
Press H to return to parameter selection mode. The screen will roll to the next page each time P is pressed and will return to the first page when P is pressed at the last page. The screen will roll to the last page each time E is pressed and will return to the last page when E is pressed at the first page. Press V/A to modify the selected parameter.
Key functions for modifying the parameter:
Press H to move the flashing cursor to the next position. Press P to increase the number by 1, while the number was 9(Ethernet), or 7(BACnet IP), or 3(BACnet MS/TP), the number will return to 0 after press P. Press E to decrease the number by 1, while the number was 0, the number will return to 9(Ethernet), or 7(BACnet IP), or 3(BACnet MS/TP) after press E.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 62
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
62
Press V/A to confirm the modification and return to parameter selection mode. The
The selection of DHCP setting: MANU or AUTO
Default setting: MANU
IP address has four segments. Any segment can be set from 0~255. Default setting: 192.168.1.254
Submask has four segments. Any segment can be set from 0~255. Default setting: 255.255.255.0
Gateway has four segments. Any segment can be set from 0~255. Default setting: 192.168.1.1
DNS1 has four segments. Any segment can be set from 0~255. Default setting: 202.106.0.20
DNS2 has four segments. Any segment can be set from 0~255. Default setting: 0.0.0.0
Range from 2000-5999, the default value is 502
Range from 6000-9999, the default value is 80
0: No resetting; 1: Reset module after modifying parameters; 2: Reset module to default values
0: No resetting; 1: Reset password
following figure shows the sequence of Ethernet module.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 63
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
63
The selection of DHCP setting: MANU or AUTO Default setting: MANU
IP address has four segments. Any segment can be set from 0~255. Default setting :0.0.0.0
Submark has four segments. Any segment can be set from 0~255. Default setting:0.0.0.0
Gateway has four segments. Any segments can be set from 0~255. Default setting:0.0.0.0
DNS1 has four segments. Any segments can be set from 0~255. Default setting:0.0.0.0
DNS2 has four segments. Any segments can be set from 0~255. Default setting:0.0.0.0
Range from 1~65535, the default value is 47808
0: No resetting 1: Reset module; 2: Reset module to default values before module reset
Note: The figure shows the rolling sequence for using key P. If using E key for rolling page, the sequence will reverse. BACnet IP module rolling sequence:
BACnet IP module rolling sequence:
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 64
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
64
Range from 0~127, the default value is 0
Baud, 0:9600; 1:19200; 2: 38400; 3:57600
Range from 1~255, the default value is 1
0: No resetting; 1: Reset modules 2: Reset module to default values before module reset
NO: No Reset YES: Reset Module
NO: No Reset YES: Reset Module
BACnet MS/TP module rolling sequence
MESH module interface part
Find Quality Products Online at: sales@GlobalTestSupply.com
f) Alarm Parameter
In the alarm parameter mode, user can view and modify the parameters.
Page 65
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
65
Key functions for finding the alarm parameter:
Press H to return to parameter selection mode.
The screen will roll to the next page each time P is pressed and will return to the first page when P is pressed at the last page.
The screen will roll to the last page each time E is pressed and will return to the last page when E is pressed at the first page.
Press V/A to modify the selected parameter.
Key functions for modifying the parameter:
Press H to move the flashing cursor to the next position.
Press P to increase the number by 1.
Press E to decrease the number by 1.
Press V/A to confirm the modification and return to parameter selection mode.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 66
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
66
Yes: Alarm enable; No: Alarm disable It can be selected as cue signal for alarming. Yes: backlight flashes upon alarm condition; No: no backlight flashing
There are 16 alarm channels available. Each channel is controlled and enabled 1 bit each from a 16-bit register. Bit value of 1 means that the corresponding alarm channel is enabled whereas 0 means that the channel is disabled. The meter will display the value of this 16-bit register in decimal numbers (for different channel combination). For example, 00000 means that all channels are disabled; 00001 means only the first channel is enabled; 65535 means that all channels are enabled. Refer to section 4.4 on page 65 for more details.
"AND" logic relationship can be set among channels. When an "AND" logic is in place, both channels have to be triggered before the meter sends out the alarm signal. The logic can be set according to the predefined rule (refer to section 4.4 for more details). User can setup up to 8 logic relationships for alarming. Each logic relationship is controlled and enabled 1 bit each from a 16-bit register (only the lower 8 bits are used). Bit value of 1 means that the corresponding logic relationship is enabled whereas 0 means that the relationship is disabled. The meter will display this 8-bit value in decimal numbers (for
different relationship combination). For example, 000 means that all relationships are disabled; 001 means only the first relationship is enabled; 255 means that all relationships are enabled.
When DO1 works in alarming mode, a 16-bit register is used to control which channels are associated with this output. Similar to the alarm channel selection, this 16-bit value is expressed in decimal when reading on the meter front. For example, 00000 means that no alarm channels are associated to this output; 00001 means that alarm channel 1 is associated to DO1; 65535 means that all alarm channels are associated to DO1. Refer to
section 4.4 for more details.
If 2 AXM-IO2 modules are attached to the meter, DO1 and DO2 denote to the first and the second DO channel of AXM-IO21; DO3 and DO4 denote to the first and the second DO channel of
AXMIO22 respectively. DO2, DO3 and DO4 use the same setup method as DO1.
Find Quality Products Online at: sales@GlobalTestSupply.com
Note: The figure shows the rolling sequence for using key P. If using E for rolling page, the sequence will reverse.
Page 67
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
67
3.8 Page Recovery Function
Acuvim II series meter has a page recovery function. This means that the meter stores current display page in the non-volatile memory upon power loss and reloads the page when power recovers. If power goes off when viewing under the parameter setting mode, the meter will show voltage display when power recovers. If power goes off when viewing under the expanded I/O module data mode, and if this expanded I/O module is not connected when power recovers, the meter will show the voltage display page instead.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 68
Acuvim II Series Power Meter
Chapter 3: Meter Display and Parameter Settings
V:1.0 Revised October 2018
68
Acuvim II Series Power Meter
Chapter 4: Detailed Functions and Software
4.1 Basic Analog Measurements
4.3 Harmonics and Power Quality Analysis
4.2 Max/Min
4.4 Over/Under Limit Alarming 4.5 Data Logging
4.6 Time of Use (TOU)
4.7 Power Quality Event Logging and Waveform Capture
4.8 Seal function
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 69
Acuvim II Series Power Meter
Chapter 4 Detailed Functions and Software
V:1.0 Revised October 2018
69
Chapter 4 Detailed Functions and Software
The Acuvim II series meter contains advanced metering tools and is able to measure a multitude of power, energy and power quality parameters. Some advanced functions may not be accessible directly from the meter front; therefore, every meter comes with a powerful software that helps access the information. This chapter introduces these functions and the software.
4.1 Basic Analog Measurements
Acuvim II series meter can measure voltage, current, power, frequency, power factor, demand, etc. With high accuracy, as shown via the software below:
Fig 4-1 Real-Time Metering
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 70
Acuvim II Series Power Meter
V:1.0 Revised October 2018
70
Demand:
This meter consists of several types of demand calculation: total active power demand, total reactive power demand, total apparent power demand, phase A current demand, phase B current demand, and phase C current demand. When demand is reset, demand memory registers are set as 0.
Demand calculating mode can be set as sliding window and thermal according to user. The Fig 4-7 shows how it works.
When using the sliding window interval method, user selects an interval from 1 to 30 minutes, which is the period of the calculation. The demand updates every 1 minute as the window slides once.
Thermal demand method calculates the demand based on a thermal response which mimics a thermal demand meter. User selects the period for the calculation and the demand updates at the end of each period.
Energy:
This meter measures and accumulates energy in different directions (import and export). For real-time energy monitoring, it accumulates energy for kWh, kvarh and kVAh continuous (since its last reset).
Calculating mode
1. User can select different energy calculating modes, fundamental based or full-wave based either from the meter front or via communication. Fundamental based calculating is used to accumulate energy without taking harmonics into consideration while full-wave based calculating is used to accumulate energy including fundamental and harmonics.
Note: 1) When fundamental based calculating mode is selected, PF calculation will be based on the fundamental wave.
2)When selecting 400Hz type, only support full-wave.
2. There are two ways to calculate reactive energy (power)
Mode 0: real reactive energy Mode 1: general reactive energy
3. User can choose primary energy or secondary energy either by pressing keys from the meter front or via communication as shown in Fig 4-7.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 71
Acuvim II Series Power Meter
V:1.0 Revised October 2018
71
Note: Acuvim II is able to display either primary energy or secondary energy on the LCD screen; however, it is only able to send out pulses according to secondary energy via the AXM­IO module.
Fig 4-2 Energy and Power Quality Parameters
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 72
Acuvim II Series Power Meter
V:1.0 Revised October 2018
72
Current direction adjustment
Under normal circumstances, current flows from input terminal 1 to terminal 2 (i.e. from I11 to I12 for phase A current); however, current may flow in the opposite direction due to incorrect wiring setup. Instead of rewiring the system, the meter provides users an option to reverse the polarity of the current. By default, current direction is set as "positive", to reverse the current polarity by 180 degrees, user can set current direction as "negative". Refer to Fig 4-7 for more details.
Fig 4-3 Max/Min
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 73
Acuvim II Series Power Meter
V:1.0 Revised October 2018
73
4.2 Max/Min
Acuvim II series meter logs maximum and minimum value statistics for phase/ line voltages, current, power, reactive power, apparent power, power factor, frequency, demand, unbalance factor, THD as well as the time they occur. All data is stored in non­volatile memory so that statistic information can be preserved even when meter is shut off. All maximum and minimum data can be accessed via communication or from the meter front but time stamps can only be accessed via communication. Statistics can be cleared via communication or from the meter front.
4.3 Harmonics and Power Quality Analysis
1. Harmonics
Acuvim II series meter can measure and analyze THD, harmonics support 2nd to 63rd, even HD, odd HD, crest factor, THFF, K factor etc. They are shown in Fig 4-2.
Note: When selecting 400Hz type, only support 2nd~15th harmonics;
2. Phase angle
Phase angle indicates the angle between phase A voltage and other voltage/ current parameters. Angle ranges from 0 to 360 degrees. This function is to help users find out the relationship between all input signals avoiding wrong wiring. When it is set to “2LL” or “3LL”, it gives out the phase angles of u23, u31, i1, i2, i3 corresponding to u12. When it is set to “3LN”, it gives out the phase angles of u2, u3, i1, i2 and i3 corresponding to u1. When it is set to “1LL”, it gives out the phase angles of u2, i1, i2 corresponding to u1. They are shown in Fig 4-4.
3. Sequence component and unbalance analysis
Acuvim II series meter is able to perform sequential analysis for the input signal. It looks at the positive sequence, negative sequence and zero sequence of 73 the fundamental frequency and performs unbalance analysis for voltage and current. Sequence components are shown in Fig 4-4, unbalance of voltage and current are shown in Fig 4-
1.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 74
Acuvim II Series Power Meter
V:1.0 Revised October 2018
74
Fig 4-4 Sequence component and Phase angle
4.4 Over/Under Limit Alarming
Acuvim II series meter has over/under limit alarming capabilites. When the monitored parameter goes over/under the preset limit and stays at the level over the preset amount of time delay, the over/under limit alarm will be triggered. The over/under limit value and its time stamp will be recorded in the 74-alarming log. The meter can record up to 16 alarming records. When extended I/O modules are attached, digital outputs (DO) and relay outputs (RO) can be triggered upon alarm conditions and used to activate downstream devices such as a beacon light or a buzzer.
Before using the alarming function, alarm conditions such as logic dependency, target setpoint, time delay etc must be set correctly. Settings can be accessed and modified from the software via communication connection as shown in Fig 4-5.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 75
Acuvim II Series Power Meter
V:1.0 Revised October 2018
75
Address
Parameter
Range
Property
104EH
First group: parameter code
0~79
R/W
104FH
First group: comparison mode
1:larger,2:equal,3:smaller
R/W
1050H
First group: setpoint value
Related with parameters
R/W
1051H
First group: delay time
0~3000(*10ms)
R/W
1052H
First group: output to relay
0:none,1-8:related relay
R/W
Fig 4-5 Alarm Setting
1. Single Alarming Group Setting
Table 4-1 indicates the first group of settings, there are 16 groups in total with the same format.
Table 4-1 First Group of Alarming Settings
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 76
Acuvim II Series Power Meter
V:1.0 Revised October 2018
76
Parameter code: select target parameter for alarm monitoring for example: 0-frequency, 44­AI4 sampling data.
Comparison mode: set alarming condition 1: greater than, 2: equal to, 3: smaller than. For example: if you choose target parameter to be "frequency", condition to be "greater than" and setpoint to be "50", alarm will be triggered when the frequency is greater than 50Hz.
Note: setpoint value is the same as the actual value of the selected parameter.
Delay time: If the alarms condition lasts for the preset time period, the alarm signal will be
triggered. The delay range is from 0 to 3000 (unit: 10ms). When it is set to 0, there is no delay, alarm will be triggered when the alarm condition is met. If it is set to 20, there will be a 200ms (20 x 10ms) delay. Output to relay: 0-alarming signal will not be sent to RO; if it is set as 1 and AXMIO11 is connected, it will output to RO1 when alarm triggers. RO1 will be turned off when all alarms output to RO1 are cleared. RO2~RO8 work in the same manner as RO1.
Note: 1) If RO is under alarming mode, it can only work in “latch” mode. 2) If the number is 51~79, there are special guide for contrast method and meaning of parameters, please refer to Chapter 6. After setting up the alarming parameters, user must also setup the global settings in order for the alarm to work properly.
2. Global settings
Register addresses for global alarm settings are from 1046H~104DH. Please refer to section
5.3, page 95 "Global alarming settings" for more details.
“Global alarming enable” determines whether the alarming function of the meter is activated or not. The alarming function is enabled when it is set as "1".
When “Alarming flash enable“ is set as “1”, backlight will flash when alarm is triggered.
“Alarming channel enable setting” determines whether the corresponding alarm group is enabled or not. There are 16 groups in all and each one is corresponding to one bit of a 16­bit register. The corresponding bit must be set to "1" in order to activate the alarm channel.
Logic "AND" between alarm setting: The 16 alarming records in the meter are divided into 8 pairs. Each pair has two alarm groups. The two groups can be logically “AND” by controlling the logic check box. When two groups are “AND”, alarming triggers only if both AND conditions are met. If the "AND" logic box is unchecked, the two alarm channels will work independently.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 77
Acuvim II Series Power Meter
V:1.0 Revised October 2018
77
The 8 "AND" logic pairs are arranged as follows: 1st, 2nd channel form Pair 1; 3rd, 4th channel form Pair 2; 5th, 6th channel form Pair 3; 7th, 8th channel form Pair 4; 9rd, 10th channel form Pair 5; 11th, 12th channel form Pair 6; 13th, 14th channel form Pair 7; 15th, 16th channel form Pair 8.
This function is controlled by the lower 8 bits of the 16-bit register and each bit is corresponding to a pair. “1” means this function is enabled and “0” means disabled.
“Alarming output to DO1 setting”: When “Digital output mode” is set to “1”, DO1 can be used as alarming output. A 16-bit register is used to perform this function, its bit0~bit15 correspond to the 1st ~16th group respectively. When the related I/O module is connected and is under alarming mode, and if the corresponding bit is set to 1 and the alarming condition is met, alarm signal will be sent to DO1. DO1 will be turned off when all alarms correspond to DO1 are cleared. If related bit is set to 0, that alarm channel will not issue alarm signal to DO1. DO2~DO4 work in the same manner DO1.
After completing the setup steps correctly, alarming function can be used.
3. Setting Example
Here is an example showing how to apply the logic "AND" function for a pair of alarm channels.
The conditions are as follows: I1 greater than 180A, delay 5s for the 1st alarm channel; U1 less than 9980V, delay 10s for the 2nd alarm channel. No alarm signals will be sent to outputs. The CT primary value of I1 is 200A, and CT2 is 5A. The PT ratio for U1 is 10000:100. The following shows how all the related registers are to be set.
Settings of first group:
“Parameter code (104EH)” is set to 9, which stands for I1. “Comparison mode (104FH)” is set to 1, which stands for "greater than". “Setpoint value (1050H)” is set to 4500, according to the relationship between actual
value and communication value (I=Rx * (CT1/CT2) /1000). 78 “Delay time (1051H)” is set to 500, so the actual delay time is 500*10ms=5s. “Output to relay (1052H)” is set to 0, because there is no output to RO.
Settings of second group:
“Parameter code (1053H)” is set to 1, which stands for U1. “Comparison mode (1054H)” is set to 3, which stands for "smaller than".
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 78
Acuvim II Series Power Meter
V:1.0 Revised October 2018
78
Address
Parameter
Range
42A9H
First group: alarming status
0~65535
42AAH
First group: parameter code
0~79
42ABH
First group: over/under limit or reset value
Related with parameters
42ACH~42B2H
First group: occur time: yyyy:mm:dd:hh:mm:ss:ms
time
“Setpoint value (1055H)” is set to 998, according to the relationship between actual value and communication value (U=Rx X (PT1/PT2) /10). “Delay time (1056H)” is set to 1000, so the actual delay time is 1000*10ms=10s. “Output to relay (1057H)” is set to 0, because there is no output to RO.
Global settings:
“Alarming channel enable setting (1048H)” set to 0003H to enable the first and the second channel. “Logic "AND" between alarming setting (1049H)” set to 0001H to enable logic "AND" in Pair 1. “Alarming output to DO1 setting (104AH)” set to 0, since no output to DO1. “Alarming output to DO2 setting (104BH)” set to 0. “Alarming output to DO3 setting (104CH)” set to 0. “Alarming output to DO4 setting (104DH)” set to 0. “Alarming flash enable (1047H)” set to 0 to disable backlight flashing when alarming occurs. “Global alarming enable (1046H)” set to 1 to enable over/under limit alarming.
4. Records of Alarming Event
Acuvim II series meter has built in alarm logging capabilities. 16 entries can be recorded in total. The record sequence of these entries do not depend on the sequence of the 16 alarm channels. The meter begins logging alarm status starting from the 1st record location to the last one. Alarm logs are being recorded in a "cycle" fashion which means the latest event will overwrite the oldest record. When over/under limit parameters return to normal, its value and time stamp will be recorded as well. Therefore, users can determine the over/ under limit duration by checking the time difference.
Here is the 1st group of records. Other groups of records have the same format.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 79
Acuvim II Series Power Meter
V:1.0 Revised October 2018
79
“Alarming status” indicates information of current alarm status. It is a 16-bit unsigned integer. Parameter code is stored in the higher 8 bits. Bit1 indicates whether logic "AND" is enabled or not, 1 means enabled and 0 means not. Bit0 indicates whether alarming has occured or recovered, 1 means occurred and 0 means recovered. Undefined bits are 0.
“Parameter code” specifies the monitored parameter.
“Value” shows the recorded value of the selected parameter when an alarm is triggered and when it recovers.
“Time” indicates the time stamp with the accuracy in milliseconds (ms).
Alarming event will set bit0 of “system status (102EH)” to be 1. When software sends clear alarm command, Bit0 of “system status (102EH)” will be set to 0.
Alarming group number (1032H): the range is 0~16, 0 is no alarm record, and others stand for which record is newest alarm. Alarming group number can be saved during meter power off, and it is cycling recording.
Here is an example:
Fig 4-6 Alarming records
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 80
Acuvim II Series Power Meter
V:1.0 Revised October 2018
80
Fig 4-7 Basic settings
4.5 Data Logging
The Acuvim IIR/IIE/IIW meter provides data logging that records the data at a set interval. This meter has 8 MegaBytes of memory which gives it extensive datalogging capabilities. It has a real-time clock that allows logs to be time-stamped when log events are created.
1. Data log settings
The Acuvim IIR/IIE/IIW meter has three sets of historical data logs. Each log can be independently programmed with individual settings, meaning that each can be used to monitor different parameters. You can program up to 117 parameters per log. You also have the ability to allocate available system resources among the three logs, to increase
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 81
Acuvim II Series Power Meter
V:1.0 Revised October 2018
81
or decrease the size of the individual historical logs. The total size is no more than 100 sectors that has 64k bytes. The data log 1 setting is shown in Fig 4-8.
Fig 4-8 The data log 1 setting
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 82
Acuvim II Series Power Meter
V:1.0 Revised October 2018
82
Having three sets of historical logs provides you with the option of programming each log with unique parameters. For example, you can program Historical Log 1 to record measured values parameters (for example, Frequency, Voltage, Current), Log 2 to record energy values parameters, and Log 3 to record power quality parameters. Historical Log parameters can be selected from the following thirteen groups:
• Real-Time Metering (Frequency; Instantaneous Voltage; Instantaneous Current; Total and Per Phase Power and Power Factor; Neutral Current; unbalance V/I; load type; Current demand; and Per Phase/ Total Power demand)
• Energy (Ep_imp; Ep_exp; Ep_total; Ep_net; Eq_imp; Eq_exp; Eq_total; Eq_net; Es; Epa_imp; Epa_exp; Epb_imp; Epb_exp; Epc_imp; Epc_exp; Eqa_imp; Eqa_exp; Eqb_imp; Eqb_exp; Eqc_imp; Eqc_exp; Esa; Esb; Esc)
• THD Volts AN/AB (THD, 2nd -63rd Harmonic Magnitudes, ODD, EVEN, CF and THFF of Volts AN/AB)
• THD Volts BN/BC (THD,2nd -63rd Harmonic Magnitudes, ODD, EVEN, CF and THFF of Volts BN/BC)
• THD Volts CN/CA (THD, average THD, 2nd-63rd Harmonic Magnitudes, ODD, EVEN, CF and THFF of Volts CN/CA)
• THD IA (THD, 2nd-63rd Harmonic Magnitudes, ODD, EVEN, KF of IA)
• THD IB (THD, 2nd-63rd Harmonic Magnitudes, ODD, EVEN, KF of IB)
• THD IC (THD, average THD, 2nd-63rd Harmonic Magnitudes, ODD, EVEN, KF of IC)
• Sequence Component (positive, negative and zero sequence)
• Phase Angles (the angle between U1 and other voltage and current parameters.)
• DI Counter (the DI numbers of the IO modules)
• AO/AI Raw Value (the AO output register values and the AI sample register values)
• AO/AI Value (the AO output values and the AI sample values)
The following procedures show how to select and store parameters in historical log 1. The Group field determines the items that are available for selection.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 83
Acuvim II Series Power Meter
V:1.0 Revised October 2018
83
1) Select a Group. The possible selections are: Real-Time Metering, Energy, THD Volts AN/AB, THD Volts BN/BC, THD Volts CN/CA, THD IA, THD IB, THD IC, Sequence Component, Phase Angles, DI Counter, AO/AI Raw Value and AO/AI Value.
2) Select items for your log: a. Highlight the parameter(s) you want to log into the meter's memory. b. Click Add to add the parameter to the Selected Parameter Area. c. To remove parameter(s), highlight them in the Selected Parameter Area and click Remove.
3) Set the logging interval (in minutes). Interval can be set from 0 - 1444 minutes according to different application.
The logging interval determines when the meter takes a snapshot. When interval is set as 0, the set of historical data log is disabled.
4) There are 100 sectors in total for the 3 historical data logs. User can assign different sector size to each log according to different applications (as long as the total sector sizes of the 3 logs do not exceed 100).
5) Three Modes of historical log:
A. Mode1: if correctly set historical log, can record without setting date and time, depending on first-in first-out recycling log.
B. Mode2: if correctly set historical log, as set date and time, can record within begin to end time. Record will stop after buffer is full.
C. Mode3: if correctly set historical log, as set hour and minute, only can record while the running time is equal to setting hour and minute, depending on firstin first-out recycling log.
NOTES:
• If the memory of the historical data log is full, the meter will erase the first sector in which the memory size is 65536 bytes (64kb). The following sector (the second sector) will become the first sector and the data from the erased sector will not be recoverable. Therefore, user should save the whole log before memory is full to maintain all the data.
• There are two display fields at the bottom of the data log setting screen. They show the registers in the logs, the total bytes used and the bytes remaining for this historical log. These fields are updated as you make selections on the screen. The total number of bytes available per log record is approximately 234.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 84
Acuvim II Series Power Meter
V:1.0 Revised October 2018
84
2. Retrieving logs
There are two ways of retrieving the logs: "read one window" and "read all". The retrieval screen is shown in Fig 4-9.
Fig 4-9 Retrieval screen
The "read one window" method allows you to access and read a specific log location at an offset from the first log. The "window record num" is the maximum number of record entries the software can read at a time, it is calculated by 246 / Record Size. The larger this number is, the faster data can be retrieved. Log type is the logs you want to retrieve, for example, log type 0 is data logging 1, log type 1 is data logging 2 and log type 2 is data logging 3. The "read all" method accesses and reads the historical data log automatically, the offset increases automatically until all the logs are retrieved.
The data logs contents are shown at the bottom of the page.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 85
Acuvim II Series Power Meter
V:1.0 Revised October 2018
85
4.6 Time of use (TOU)
User can assign up to 4 different tariffs (sharp, peak, valley and normal) to different time period within a day according to the billing requirements. The meter will calculate and accumulate energy to different tariffs according to the meter’s internal clock timing and TOU settings.
TOU setting: User can set a maximum of 12 TOU seasons, each season can be assigned to a TOU schedule (a maximum of 14 TOU schedules are available). Each schedule can be divided up into 14 segments (in which each segment can have its own tariff). User can customize the TOU calendar (including its tariffs, seasons, schedules and segments) according to different applications. To make sure that the TOU calendar is setup correctly, the meter will check the TOU settings according to the predefined rules (see below for “TOU setting format requirement” for details). TOU function will be disabled if the TOU calendar is set up incorrectly. If no errors are found in the calendar and the TOU function is enabled, TOU energy accumulation will begin.
TOU setting format requirement:
1. Season setting parameter: The calendar year will be divided up into different seasons depending on the season setting parameter. The parameter can be selected from any integer between 1 to 12. User must enter the correct value for the season setting parameter in accordance to the TOU season table. If the season setting parameter is set as 2, the first 2 slots of the TOU season table must be set, otherwise it will be considered as an invalid input (TOU function will be disabled).
2. TOU season format: Enter the start date into the TOU season table slot following this format “MM-DD ID” - MM stands for the month, DD stands for the day and ID stands for the TOU schedule ID (available from 01 to 14). The dates should be organized so that they are in sequence according to the calendar 88 year (the earlier date comes first and the later date comes last). For example, if 3 seasons are selected, the date parameters are January 1, June 6 and September 7, and TOU schedule 02, 01, 03 will be used respectively, the first TOU season table slot shall enter 01-01 02, the second slot shall enter 06-06 01, and the third slot shall enter 09-07 03. Entering 01-01 02 for the first slot, 09-07 03 for the second slot and 06-06 01 for the third slot is considered invalid.
3. Schedule setting parameter: The number of available TOU schedules depends on the schedule setting parameter. The parameter can be selected from any integer between 1 to 14. This parameter determines the number of TOU schedules available for the TOU calendar setting. A maximum of 14 TOU schedules (from TOU Schedule #1 to TOU Schedule #14) can be used.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 86
Acuvim II Series Power Meter
V:1.0 Revised October 2018
86
4. Segment setting parameter: Each TOU schedule consists of various timing segments. The number of segments depends on the segment setting parameter setup. The parameter can be selected from any integer between 1 to 14 (inclusively). User must enter the correct value for the segment setting parameter in accordance to the TOU schedule table. If the segment setting parameter is set as 3, the first 3 slots of the TOU schedule table must be set, otherwise, it will be considered as an invalid input (TOU function will be disabled).
5. TOU schedule format: Each TOU schedule represents a 24 hour cycle. Similar to TOU season format, enter the start time into the TOU schedule table slot following this format “HH:MM ID” - HH stands for hour (in 24 hr format), MM stands for minutes and ID stands for tariffs (available from 00 to 03). The time should be organized according to the hour sequence. For example, if 3 segments are selected, timing parameters are 01:00, 15:30, 22:45, the order of the 3 segments should be one of the following: 01:00, 15:30, 22:45 or 15:30, 22:45, 01:00 or 22:45, 01:00, 15:30 Entering time information in a wrong sequence (for example, entering 15:30, 01:00, 22:45) is considered as an invalid 89 operation, TOU function will be disabled.
6. Tariff setting parameter: This parameter corresponds to the number of tariffs available for the TOU calendar and can be selected from any integer from 0 to 3. The four tariffs: sharp, peak, valley and normal are represented by 4 integers: 0, 1, 2 and 3 respectively. If the tariff setting parameter is set to 3, all of the 4 tariffs will be available for the TOU calendar; if the parameter is set to 1, only the first 2 tariffs (sharp and peak) will be available.
7. Holiday setting parameter: This parameter can be set from any integer between 1 and 30, meaning a maximum of 30 holidays can be programmed to the TOU calendar. If the holiday setting parameter is set as 3, the first 3 slots of the holiday schedule must be set, otherwise it will be considered as an invalid input (TOU function will be disabled).
Note: User can either customize the TOU calendar factory settings or use the default factory settings. User can reset the TOU calendar to its default value either via communication or from the meter front.
8. Holiday schedule: The holiday schedule uses the same format as the TOU seasons “MM­DD ID”. User can select which TOU schedule to be used for the holiday. The dates of the holiday schedule do not need to be organized in a sequential order (i.e. the first slot can be January 1, the second slot can be December 26 and the third slot can be December 25).
9. Daylight saving time (DST): Daylight saving time can be enabled in one of two formats: The fixed date option, or a fixed day of one of the weeks in the month (also named as the non-fixed date option). if you choose a fixed date option, you set the format according to a fixed date, for the daylight-saving time switch: the format month / day / hour / minute /
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 87
Acuvim II Series Power Meter
V:1.0 Revised October 2018
87
adjust time (in minutes). If you choose non-fixed date option, DST will be implemented by which day of which week, whose setting format is month/which day (i. e. Tuesday)/which week (i. e. 1st 90 week)/hour/minute/adjust time (in minutes).
By using the function, you can cause the instrument to automatically switch to and from daylight saving time. When the clock starts to run to daylight saving time, the meter will automatically adjust the clock to a time period in advance, while the clock is running to the end of daylight-saving time, meter will automatically adjust the clock pushed back to a time period, as shown in Fig 4-10
Fig 4-10 Daylight saving time setting interface
10. Ten-year Holiday setting
Users can preset holidays of the next decade via the meter software. The holiday format is month/day/year; holiday code; holiday schedule. After the format setup, click on "Make Holiday Settings (10 year)", then a holiday table for the next decade will be generated.
Holiday Auto Switch: When Ten-year Holiday is enabled, if the current year of the meter falls into the Ten-year Holiday setting, it automatically loads the Tenyear Holiday settings into the current TOU settings. If the current year of the meter does not fall into the Ten­year Holiday setting, it remains the current TOU settings.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 88
Acuvim II Series Power Meter
V:1.0 Revised October 2018
88
Fig 4-11 ten years holiday table
11. Weekend Schedule: Weekend Setting (bit0: Sunday; bit1 ~ bit6: Monday to Saturday; bit 0 means not effective, bit 1 means effective). For example, when the Weekend Setting bit0 is 1, it means Sunday is effective. When the Weekend Setting bit1 is 1, it means Monday is effective. For example, if a user wants to set Saturday and Sunday effective, he should put 65 (1000001) into the Weekend 92 Setting field. When the meter clock is within the preset Weekend Schedule, the energy will accumulate under the tariff that corresponds to the Schedule.
Note: Holiday schedule has the highest priority among all the schedules. Weekend schedule's priority is followed by Holiday schedule. When Holiday schedule is not enabled, Weekend schedule has the highest priority, overiding the normal (weekday) schedule.
Acuvim IIE can record maximum power and current demand under different tariffs, as well as the time stamp of the maximum value. It can also clear the maximum demand under diferent tarifs.
Except normal energy parameter readings, Acuvim IIE has 4 separate logs: Current Accumulation Month TOU, Prior Accumulation Month TOU, Current Month TOU and Prior Month TOU. When setup appropriately and when TOU is enabled, energy will be
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 89
Acuvim II Series Power Meter
V:1.0 Revised October 2018
89
accumulated in a month-to-month basis. The current energy usage will be stored under Current Month TOU (or Current Accumulation Month TOU) and is divided up into different tariffs. When next month (or counting period) starts, all Current Month TOU values will be moved to Prior Month TOU (or Prior Accumulation Month TOU).
There are two ways of automatic resetting of current month TOU.
1. End of Month: This is the default method. All values from Current Accumulation Month TOU will be copied over to Prior Accumulate Month TOU at the very beginning of each month (the first day of each month at time 00:00:00). Current Accumulation Month TOU will continue to accumulate. All values from Current Month TOU will be copied over to Prior Month TOU at the very beginning of each month (the first day of each month at time 00:00:00) be cleared and reset to 0.
2. Assigned Clock: User can select when the values from Current Accumulation Month TOU or Current Month TOU would be copied over to Prior Accumulation 93 Month TOU or Prior Month TOU. User can set the time in the following format: DD HH:MM:SS"-DD stands for day, HH stands for hour, MM stands for minute, SS stands for second. Similar to the previous method, once Current Accumulation Month TOU is transferred to Prior Accumulation Month TOU, Current Accumulation Month TOU will continue to accumulate. once Current Month TOU is transferred to Prior Month TOU, Current Month TOU will be cleared and reset to 0.
4.7 Power Quality Event Logging and Waveform Capture
Power Quality Event Logging
When a power quality event happens, such as voltage sag and swell, Acuvim IIW will record the event timestamp and the triggering condition. It can save up to 50,000 events.
1. Event Logging Data format
Timestamp (4 words) + Triggering Condition (1 word) + Rated Value (1 word) + Threshold (1 word) + Half Cycle Count (1 word)
Each event has 8 words in total.
Event Time: W1: Year—High Byte; Month-Low Byte; W2: Day-High Byte, Hour— Low Byte; W3: Minute—High Byte; Second—Low Byte; W4: Millisecond
Triggering Condition: W5—Voltage Sags or Voltage Swells 0: logging disabled; Bit0: 1 – u1 voltage sag, 0 – no u1 voltage sag;
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 90
Acuvim II Series Power Meter
V:1.0 Revised October 2018
90
Bit1: 1 – u2 voltage sag, 0 – no u2 voltage sag; Bit2: 1 – u3 voltage sag, 0 – no u3 voltage sag; Bit3: 1 – u1 voltage swell, 0 –u1 no voltage swell; Bit4: 1 – u2 voltage swell, 0 –u2 no voltage swell; Bit5: 1 – u3 voltage swell, 0 –u3 no voltage swell; Rated Value: W6—Voltage rated value;
Threshold: W7—Threshold for voltage sag and swell.
Half Cycle count: W8 (Voltage Swell: 0; Voltage Sag: 4~200)
2. Logging Events
The event logging feature can log 50000 events. If the 50000 events are full, no more events will be logged even if the triggering condition happens. The user must clear the event log, and then the logging will log the new event. When the log is cleared, the new event will be logged from the first event happening. There will be no data loss after the power is of
3. Event Logging Triggering Conditions
1) Voltage Sag
When any phase of the three-phase voltage is lower than the set value (voltage rated value x threshold %), there will be a voltage sag event. When one phase voltage sag happens, the other phase will not respond to voltage sag event logging. Only when all of the phases voltage restore back to normal, a new voltage sag event will be responded.
2) Voltage Swell
When any phase of the three-phase voltage is higher than the set value (voltage rated value x threshold %), there will be an Voltage Swell event. When one phase Voltage Swell happens, the other phase will not respond to Voltage Swell event logging. Only when all of the phases voltage restore back to normal, a new Voltage Swell event will be responded.
Note:
The following figure depicts how to set the parameters for Power Quality Event Logging and Waveform Capture. In the parameter settings, Voltage Sag and Voltage Swell share the same voltage rated value. The parameters for event logging include: voltage rated value, voltage sag threshold, voltage sag half cycle count and voltage swell threshold. Those parameters also fit voltage sag 95 waveform capture. The other triggering conditions for Waveform Capture can be set when necessary. When the Waveform
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 91
Acuvim II Series Power Meter
V:1.0 Revised October 2018
91
Capture triggering by Voltage Sag and Voltage Swell is enabled, the corresponding event log and waveform will be recorded when Voltage Sag or Voltage Swell happens.
Fig. 4-12
4. Event Log Retrieve
When a new event log commences, the newest event number address (0X8CFDH) contains the newest event number. When the log is being retrieved, the starting event log number (0X8CFEH) and the event quantity for 96 each retrieve (0X8CFF) must be set correctly. It must be ensured that the starting number of event log should equal or smaller than the newest log number. When setup is correct, reading registers 0X8D00H—0X8D4FH will acquire the event log data. Each time a maximum of 10 logged events can be retrieved. The event log retrieve page is in the figure below. The Modbus register address of the event log is in the table below (see details in Chapter 6).
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 92
Acuvim II Series Power Meter
V:1.0 Revised October 2018
92
8CFDH
The newest event number
word
R
Range: 1~50000 0: No event
8CFEH
The starting event log number
word
R/W
Range: 1-50000 Note: smaller than or equal to the newest event number.
8CFFH
The event quantity of each time retrieve
word
R/W
1-10
Fig. 4-13
Waveform Capture
Acuvim IIW can record 100 groups of voltage and current waveform data at a sampling rate of 64 points per cycle. It provides the captured waveform of 10 cycles before and after the triggering point (including U1, U2, U3, I1, I2, I3). The triggering condition is settable.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 93
Acuvim II Series Power Meter
V:1.0 Revised October 2018
93
1. Waveform Capture Data Format
Timestamp (7 words) + Triggering Condition (9 words)+ Kept Data Storage (48 words)+ U1, U2, U3, I1, I2, I3(Before triggering point 10 waveforms 64 x 10 x 6 words)+ U1, U2, U3, I1, I2, I3(After triggering point 10 waveforms 64x10x6 words). Timestamp: Year (W1), Month (W2), Day (W3), Hour (W4), Minute (W5), Second(W6), Millisecond(W7)
Triggering Condition:
W8—Manual Triggering (0: disable; 1: enable);
W9— AXM-11 DI Triggering (bit1bit0: DI1(bit3bit2: DI2) bit5bit4: DI3; bit7bit6: DI4; bit9bit8: DI5; bit11bit10: DI6);
W10—AXM-21 DI Triggering (bit1bit0: DI7; bit3 bit2: DI8; bit5bit4: DI9; bit7bit6: DI10);
W11—AXM-31 DI Triggering (bit1bit0: DI11; bit3 bit2: DI12; bit5bit4: DI13; bit7bit6: DI14);
(Two bits meaning: 00: No DI Triggering; 01: DI Triggering from OFF to ON; 10: DI Triggering From On to OFF)
W12— Voltage Sag Triggering (0: disabled; Bit0: 1 – u1 voltage sag waveform, 0 – no u1 waveform; Bit1: 1 – u2 voltage sag waveform, 0 – no u2 waveform; Bit2: 1 – u3 voltage sag waveform, 0 – no u3 waveform)
W13— Voltage Swell Triggering (0: disabled; Bit0: 1 – u1 voltage swell waveform, 0 – no u1 waveform; Bit1: 1 – u2 voltage swell waveform, 0 – no u2 waveform; Bit2: 1 – u3 voltage swell waveform, 0 – no u3 waveform;)
W14— Over-current Triggering (0: disabled; Bit0: 1 – I1 voltage over-current waveform, 0 – no I1 waveform; Bit1: 1 – I2 voltage over-current waveform, 0 – no I2 waveform; Bit2: 1 – I3 voltage over-current waveform, 0 – no I3 waveform;)
W15, W16----0 (Reserved)
Waveform Order:
Before triggering point 10 U1 waveforms, 10 U2 waveforms, 10 U3 waveforms, 10 I1 waveforms, 10 I2 waveforms, 10 I3 waveforms.
After triggering point 10 U1 waveforms, 10 U2 waveforms, 10 U3 waveforms, 10 I1 waveforms, 10 I2 waveforms, 10 I3 waveforms.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 94
Acuvim II Series Power Meter
V:1.0 Revised October 2018
94
2. Waveform Capture Group
Waveform Capture can log up to 100 groups of waveform data. When the 100-group data is full, it does not respond to any waveform triggering condition. Only when all the waveform data is reset / emptied, waveform capturing function will be normal. When the waveform data is emptied, new waveform data starts from the 1st group. The waveform data will not be lost when the power is off.
Note: since the amount of each waveform group data is large, it takes more time to write into the flash memory. Therefore, Waveform Capture only responds to one triggering condition at one time. During the process of writing data into the flash memory, it does not respond to new triggering condition. After 99 the process of memory writing, it will respond to new waveform triggering condition.
3. Waveform Capture Triggering Condition
1) Manual Triggering
Manually trigger one group waveform capture.
2) DI Triggering
DI Triggering must fulfill the following two conditions at the same time.
IO modules with the logical address of 1 (AXM-IO11, AXM-IO21, AXM-IO31). DI channel type is set as “State”.
The Modbus address assigns two bits for the DI channel. When they are set as “00”, it means DI Triggering Disabled; “01” means DI Triggering will be implemented when DI state changes from OFF to ON; “10” means DI Triggering will be implemented when DI state changes from ON to OFF; “11 “means DI Triggering will be implemented when DI state has any change.
3) Voltage Sag Triggering
As mentioned in Voltage Sag event logging, when Voltage Sag Triggering Waveform is enabled, both event logging and waveform capture will be implemented at the same time once a voltage sag happens.
4) Voltage Swell Triggering
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 95
Acuvim II Series Power Meter
V:1.0 Revised October 2018
95
As mentioned in Voltage Swell event logging, when Voltage Swell Triggering Waveform is enabled, both event logging and waveform capture will be implemented at the same time once a voltage swell happens.
5) Over-current Triggering
When Over-current Triggering is enabled, if any phase of the three-phase current is higher than the set value (rated value x threshold %), the waveform 100 capture will be implemented. If one phase is over-current, any other phase overcurrent cannot implement the waveform capture. Only when all of the phase current restores back to normal, waveform capture will be responding.
4. Waveform Capture Retrieve
Because of large quantity of saved waveform, waveform retrieving window use 64 addresses to make retrieving data easier, which keeps consistent with recording points of one period. There are two retrieving methods, one retrieve waveform record reasons, another retrieve all data of one group waveform. Two methods are shown below.
First retrieving method is only retrieving waveform record reasons.
When 0x8E01H (Waveform Group Number) is set to 0, waveform record reason can be retrieved from data retrieving window, by changing Waveform Group Number for Retrieving (8E00H). Waveform record reason is 16 bytes and data window are 64 bytes, so that is the reason why each retrieving access include 4 group records.
For example, if the total number of Waveform Group Number for Retrieving is 19, the by this method, only through 5 times retrieving, all 20 groups waveform can be retrieved. Before retrieving, user should write 0 to 8E01H, and 1 to 8E00H, while at first time retrieving addresses from 8E00 to 8E43, these window data are the reasons of waveform group 1, 2, 3,
4. After retrieving, Waveform Group Number for Retrieving (8E00H) will automatically update to 5. While at second time retrieving addresses from 8E00 to 8E43, these window data are the reasons of waveform group 5, 6, 7, 8. Waveform Group Number for Retrieving (8E00H) will stop increasing after the value reaches 17.
Note: Unless user retrieves all data from 8E00H to 8E43H in one time, Waveform Group Number for Retrieving (8E00H) will automatically add 4, otherwise Waveform Group Number for Retrieving (8E00H) will keep present value if only 101 retrieving partial data. Waveform Group Number for Retrieving (8E00H) will stop increasing while value reaches Newest Waveform Group Number. If the value added 4, the value will be larger than Newest Waveform Group Number.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 96
Acuvim II Series Power Meter
V:1.0 Revised October 2018
96
Second retrieving method is retrieving all waveforms data. When 0x8E01H (Waveform Group Number) is set to 1~121, each time only one group data of each number will be retrieved, then Waveform Group Number for Retrieving (8E01H) will automatically add 1 after retrieving. At next time, new Waveform Group Number will be retrieved. Waveform Group Number will stop increasing after value reach 121.
Note: The range of 0x8E01H is 0~121, within setting range, windows (8E04H~8E43H) are corresponding to waveform data.
0: Only retrieving waveform record reasons
1: Time and reasons of waveforms
2~11: Each waveform number of ten waveforms before U1 waveform is triggered
12~21: Each waveform number of ten waveforms before U2 waveform is triggered
22~31: Each waveform number of ten waveforms before U3 waveform is triggered
32~41: Each waveform number of ten waveforms before I1 waveform is triggered
42~51: Each waveform number of ten waveforms before I2 waveform is triggered
52~61: Each waveform number of ten waveforms before I3 waveform is triggered
62~71: Each waveform number of ten waveforms after U1 waveform is triggered
72~81: Each waveform number of ten waveforms after U2 waveform is triggered
82~91: Each waveform number of ten waveforms after U3 waveform is triggered
92~101: Each waveform number of ten waveforms after I1 waveform is triggered
102~111: Each waveform number of ten waveforms after I2 waveform is triggered
112~121: Each waveform number of ten waveforms after I3 waveform is triggered
Note: Unless user retrieves all data from 8E00H to 8E43H in one time, Waveform Group Number for Retrieving (8E01H) will automatically add 1, or Waveform Group Number for Retrieving (8E01H) will keep present value if only retrieving partial data.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 97
Acuvim II Series Power Meter
V:1.0 Revised October 2018
97
8E00H
Waveform Group Number for Retrieving
1~100 Note: When the value is smaller than or equal to newest waveform record group number, this value is valid
8E01H
Waveform Group Number
Waveform number 0~121
8E02H
Waveform record window status
0x0BH: window data is valid. 0xFF: window data is invalid. 0xAA: waveform record memory is clearing (data is invalid)
8E03H
Newest Waveform Group Number
1~100 0~no record
8E04H - 8E43H
--------
Waveform record data retrieving window
-32768~ 32767
5. Relationship between voltage or current waveform value and real value
The relationship between voltage waveform value and real value:
Real Value (Unit: V) = Waveform Value / 37.59105
The relationship between current waveform value and real value:
1) 5A,1A: Real Value (Unit: A) = Waveform Value/1683.153;
2) 333mV: Real Value (Unit: A) = Waveform Value/K (firmware above 3.21,K=14427.15; other: K = 15869.87);
3)100mV(Rope-CT):Real Value(Unit: A) = Waveform Value/K (firmware above
3.21,K=20291.1; firmware 3.20, K=22068.8,other: K = 15869.87); 4)mA CT:Real Value (Unit: A) = Waveform Value/K (80mA CT:K=7414.289; 100mA:K=9267.440; 200mA:K=18514.68 );The voltage and current value obtained from the waveform are the PT or CT secondary side value. The waveform capture retrieve page is shown in Fig 4-14.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 98
Acuvim II Series Power Meter
V:1.0 Revised October 2018
98
Fig. 4-14
Note: When selecting 400Hz type, not support event logging and wave capture.
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 99
Acuvim II Series Power Meter
V:1.0 Revised October 2018
99
101EH
Sealed Nonstandard Parameters Selection
Bit0: 1st communication parameters Bit1: 2nd communication parameters Bit2: run time clear Bit3: DI pulse count Bit4: TOU 1: valid of corresponding selection 0: invalid
101FH
Seals status
0x0A: Seal sealed; Other: Seal opened.
Address
Parameters
Keys
Communications
1003H
Voltage input wiring
type
√
√
1004H
Current input wiring
type
√
√
1005H
PT1(High 16 bit)
√
√
1006H
PT1(Low 16 bit)
√
√
1007H
PT2 √ √
1008H
CT1 √ √
1009H
CT2 √ √
4.8 Seal Function
The panel with seal, which has sealed key control, is different with one without seal. When the seal is in opened status, functions are same like normal meters. But when the seal is in sealed status, some functions of meters, which include parameters blocked by seal and optional parameters, will be blocked. These parameters can still be accessible by keys and communication way if they can be accessed before, but in sealed status, these parameters cannot be modified by keys or communication way anymore. Addresses about seal function are 101EH and 101FH.
Address 101EH is about parameters blocked by seal, which can be configured by users. These setting will be valid only when seal is in sealed status. Address 101FH is about if seal function is valid. When the panel is normal one, or the seal panel is in invalid sealed status, this address will show seal is open. When the seal is valid, this address will show sealed status and corresponding parameters will be blocked.
Parameters blocked by seal.
As long as seal is in sealed status, parameters below must be blocked, no matter what value of address 101EH.
System parameters setting:
Find Quality Products Online at: sales@GlobalTestSupply.com
Page 100
Acuvim II Series Power Meter
V:1.0 Revised October 2018
100
Address
Parameters
Keys
Communications
100AH
kWh pulse constant
√
√
100BH
Kvarh pulse constant
√
√
100DH
Demand slid window
time
√
√
100EH
Demand calculating
mode
√
√
100FH
Clear demand
memory
√
√
1012H
Current I1 direction
√
√
1013H
Current I2 direction
√
√
1014H
Current I3 direction
√
√
1015H
VAR/PF convention
√
√
1016H
Energy clear
√
√
1017H
Energy calculating
mode
√
√
1018H
Reactive power
measuring mode
√
√
1019H
Energy display mode
√
√
101DH
Basic parameter mode
√
√
101EH
Sealed Nonstandard
Parameters Selection
-
√
Address
Parameter
Keys
Communications
4048H--4049H
Energy IMP - √
404AH--404BH
Energy EXP - √
404CH--404DH
Reactive energy IMP
- √ 404EH--404FH
Reactive energy EXP
- √ 4050H--4051H
Energy TOTAL
- √ 4052H--4053H
Energy NET - √
4054H--4055H
Reactive energy TOTAL
- √ 4056H--4057H
Reactive energy NET
- √ 4058H--4059H
Apparent energy
- √ 4620H~4621H
Phase A Energy IMP
- √ 4622H~4623H
Phase A Energy EXP
-
√
Note: “√” means these addresses will be blocked for keys and communication, and”-“
means this function is unavailable.
Energy:
Find Quality Products Online at: sales@GlobalTestSupply.com
Loading...
