AccuCold FF7WBI Specifications

FF7WBI

33.25" x 23.63" x 23.5" (H x W x D)

Commercially listed built-in undercounter all-refrigerator for
general purpose use, with flat door liner, automatic defrost
operation and white exterior

Highlights:

Commercially approved for use in foodservice
establishments

Flexible design allows built-in or freestanding use in 24"
spaces

Automatic defrost minimizes user maintenance

Product Features:

Commercially approved ETL-S listed to NSF-7 commercial standards
Built-in capability Make the best use of space by installing your refrigerator under the counter and flush with

other cabinets
Fully finished white cabinet Allows the refrigerator to be used as a freestanding model
Height Adjustable Adjustable legs allow the unit to be sized from 33 1/4" to 34 1/2" high
Automatic defrost Reduced user maintenance with automatic defrost
One piece seamless interior liner Enjoy easy clean-up with a one piece liner that won't hold a mess in hidden crevices
Hidden evaporator Cold wall design with hidden evaporator and seamless interior
Adjustable shelves Rearrange your refrigerator space to accommodate all shapes and sizes or remove shelves

for a simple clean-up
Interior light on rocker switch Turn the light on when you need it and off when you're done with a convenient rocker switch

located just behind the thermostat

SUMMIT APPLIANCE DIVISION, FELIX STORCH, INC. | ISO 9001:2015 Certified

770 Garrison Avenue Bronx, NY 10474 USA TEL [phone] FAX [phone] [e-mail] www.summitappliance.com

FF7WBI Specifications:

Overview

Height of Cabinet 32.63" (83 cm)
Height to Hinge Cap 33.25" (84 cm)
Width 23.63" (60 cm)
Depth 23.5" (60 cm)
Depth with Handle 24.75" (63 cm)
Depth with door at 90° 45.63" (116 cm)
Capacity 5.5 cu.ft. (156 L)
Defrost Type Automatic
Door White
Cabinet White
US Electrical Safety ETL
Canadian Electrical

Safety
Sanitation ETL-S
Amps 1.4
Voltage/Frequency 115 V AC/60 Hz
Weight 100.0 lbs. (45 kg)
Shipping Weight 105.0 lbs. (48 kg)
Estimated Time to Ship 2 to 4 days
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years

Refrigerator Features

Door Swing RHD
Reversible Yes
Shelf Type Wire
Shelf Qty 3
Adjustable Shelves Yes
Thermostat Type Dial
Fan Type Exterior
Refrigerant Type R600a
Refrigerant Amount 0.64oz.
High Side PSI 180.0
Low Side PSI 80.0
Level Legs Qty 4
Interior Light Yes

Dimensions

Interior Height 27.75" (70 cm)
Interior Width 20.0" (51 cm)

ETL-C

Interior Depth 17.5" (44 cm)
Compressor Step Height 7.0" (18 cm)
Compressor Step Width 20.0" (51 cm)
Compressor Step Depth 6.0" (15 cm)
