AccuCold CT66JBIDPL Specifications

CT66JBIDPL

33.25" x 23.63" x 23.5" (H x W x D)

Built-in undercounter refrigerator-freezer for general
purpose use, with dual evaporator cooling, diamond plate
door, TB handle, and white cabinet

Highlights:

Flexible design allows built-in or freestanding use in 24"
spaces

Over 5 cu.ft. of storage capacity in a perfectly sized 24"
footprint

Textured diamond plate door in aluminum with polished
towel bar handle offers an industrial look

Zero degree freezer compartment

Product Features:

Built-in capable Make the best use of space by installing your appliance under the counter and flush with

other cabinets
Fully finished cabinet Allows the unit to be used freestanding
Diamond plate finish on door Textured diamond plate finish in wrapped aluminum creates a unique industrial look
Professional towel bar handle Curved handle in polished stainless steel completes the look
Dual evaporator Our unique and efficient design separately cools the refrigerator while maintaining zero

degrees in the freezer with two evaporators
Cycle defrost This system utilizes user-friendly automatic defrost operation in the fresh food section and

efficient manual defrost operation in the freezer compartment
Zero degree freezer Static manual defrost freezer section offers more stability
Adjustable thermostat Dial thermostat located inside for easy temperature management
Adjustable shelves Rearrange the refrigerator space to accommodate all shapes and sizes or remove shelves for

a simple clean-up

CT66JBIDPL Specifications:

Overview

Height 33.25"
Height to Hinge Cap 33.5"
Width 23.63"
Depth 23.5"
Depth with Handle 24.25"
Depth with door at 90° 45.0"
Capacity 5.1 cu.ft.
Defrost Type Cycle
Door Diamond Plate
Cabinet White
US Electrical Safety UL
Canadian Electrical

Safety
Amps 1.3
Voltage/Frequency 115 V AC/60 Hz
Shipping Weight 113.0 lbs.
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years

Refrigerator-Freezer

Door Swing RHD
Reversible Factory

Crisper Qty 1
Crisper Finish Transparent
Crisper Cover Glass
Refrigerator - Interior

Height
Refrigerator - Interior

Width
Refrigerator - Interior

Depth
Refrigerator - Shelf Type Wire
Refrigerator - Shelf Qty 2
Refrigerator - Full Door

Shelves
Freezer - Interior Height 5.0"
Freezer - Interior Width 19.0"
Freezer - Interior Depth 11.5"
Adjustable Shelves Yes
Interior Light Yes

ULC

Reversible

19.5"

20.5"

17.0"

Thermostat Type Dial
Fan Type Exterior
Freon R134a
Freon Amount 2.6
High Side PSI 285.0
Low Side PSI 70.0
Level Legs 2
Compressor Step Height 7.0"
Compressor Step Width 20.5"
Compressor Step Depth 5.0"

3
