AccuCold ALF620BISSTB Specifications

ALF620BISSTB

32.25" x 23.63" x 23.5" (H x W x D)

Built-in undercounter medical all-freezer capable of -25º C
operation, with wrapped stainless steel door and towel bar
handle

Highlights:

Designed for use in medical facilities
32 inch height fits under lower ADA compliant counters
Flexible design allows built-in or freestanding use

Product Features:

ADA Compliant 32 inch height is designed to fit under ADA compliant counters
Slim undercounter dimensions Less than 24 inches wide to fit tight spaces
Built-in capable Make the best use of space by installing your appliance under the counter and flush with

other cabinetry
Fully finished white cabinet Allows the unit to be used freestanding
Stainless steel door 304 grade stainless steel wrapped door for lasting durability
Professional towel bar handle A curved handle in brushed stainless steel provides generous room for a comfortable grip

-25º capable Low temperature operation is ideal for vaccine, pharmaceuticals, and other temperature

sensitive materials
Three slide-out drawers Conveniently organize your items while keeping the temperature stable when the door is

opened
Manual defrost Static cooling system reduces temperature fluctuations

ACCUCOLD DIVISION, FELIX STORCH, INC. | ISO 9001:2008 Certified

770 Garrison Avenue Bronx, NY 10474 USA TEL [phone] FAX [phone] [e-mail] www.accucold.com

ALF620BISSTB Specifications:

Overview

Height of Cabinet 32.0" (81 cm)
Height to Hinge Cap 32.25" (82 cm)
Width 23.63" (60 cm)
Depth 23.5" (60 cm)
Depth with Handle 24.25" (62 cm)
Depth with door at 90° 45.0" (114 cm)
Capacity 3.2 cu.ft. (91 L)
Defrost Type Manual
Door Stainless Steel
Cabinet White
US Electrical Safety UL
Canadian Electrical

Safety
Amps 1.3
Voltage/Frequency 115 V AC/60 Hz
Shipping Weight 113.0 lbs. (51 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years

Freezer

Door Swing RHD
Reversible Factory Reversible
Interior Height 24.25" (62 cm)
Interior Width 17.75" (45 cm)
Interior Depth 16.5" (42 cm)
Thermostat Type Dial
Fan Type Exterior
Refrigerant Type R134a
Refrigerant Amount 2.7 oz.
High Side PSI 235.0
Low Side PSI 70.0
Level Legs 4
Interior Drawers Yes
Drawers Qty 3
Compressor Step Height 6.5" (17 cm)
Compressor Step Width 17.5" (44 cm)
Compressor Step Depth 5.5" (14 cm)

ULC
