Accucold ALF620BIIF Specification Sheet

ALF620BIIF

32.25" x 23.63" x 23.5" (H x W x D)

Built-in medical all-freezer capable of -25º C operation;
door accepts full overlay panels

Highlights:

Designed for use in medical facilities
32 inch height fits under lower ADA compliant counters
Flexible design allows built-in or freestanding use

Product Features:

ADA Compliant 32 inch height is designed to fit under ADA compliant counters
Slim undercounter dimensions Less than 24 inches wide to fit tight spaces
Built-in capable Make the best use of space by installing your appliance under the counter and flush with

other cabinetry
Fully finished white cabinet Allows the unit to be used freestanding
Integrated door frame Customize the front by mounting an overlay panel over the door; seamless look can blend

into other cabinetry with no exposed frame. Handle not included (panel size: 23 5/16" W x 28

1/4" H and at least 3/4" thick; maximum weight: 10 lbs.)

-25º capable Low temperature operation ideal for vaccines, pharmaceuticals, and long-term preservation of

frozen food
Three slide-out drawers Conveniently organize your items while keeping the temperature stable when the door is

opened
Manual defrost Static cooling system reduces temperature fluctuations
Digital thermostat Electronic controls located in the front kickplate for easy and intuitive temperature

management

SUMMIT APPLIANCE DIVISION, FELIX STORCH, INC. | ISO 9001:2015 Certified

770 Garrison Avenue Bronx, NY 10474 USA TEL [phone] FAX [phone] [e-mail] www.summitappliance.com

ALF620BIIF Specifications:

Overview

Height of Cabinet 32.0" (81 cm)
Height to Hinge Cap 32.25" (82 cm)
Width 23.63" (60 cm)
Depth 23.5" (60 cm)
Depth with door at 90° 45.0" (114 cm)
Capacity 3.2 cu.ft. (91 L)
Defrost Type Manual
Door Panel-Ready
Cabinet White
US Electrical Safety UL
Canadian Electrical

Safety
Amps 1.3
Voltage/Frequency 115 V AC/60 Hz
Shipping Weight 104.0 lbs. (47 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years

Freezer

Door Swing RHD
Reversible Factory Reversible
Interior Height 24.25" (62 cm)
Interior Width 17.75" (45 cm)
Interior Depth 16.5" (42 cm)
Thermostat Type Digital
Fan Type Exterior
Refrigerant Type R134a
Refrigerant Amount 2.7 oz.
High Side PSI 235.0
Low Side PSI 70.0
Level Legs 4
Interior Drawers Yes
Drawers Qty 3
Compressor Step Height 6.5" (17 cm)
Compressor Step Width 17.5" (44 cm)
Compressor Step Depth 5.5" (14 cm)
Temperature Range -12ºC to -25ºC

ULC
