Accucold AL650BIIF Specification Sheet

AL650BIIF

32.25" x 23.63" x 23.5" (H x W x D)

Built-in undercounter ADA compliant refrigerator-freezer for
general purpose use, cycle defrost w/dual evaporator
cooling, panel-ready door, and white cabinet

Highlights:

32" height for use under lower ADA compliant counters
Flexible design allows built-in or freestanding use in 24"

spaces
Customizable door front accepts full overlay panels for a

seamless look that can blend into cabinetry

Product Features:

ADA compliant 32" height to fit under lower ADA compliant counters
Slim undercounter dimensions Less than 24 inches wide to fit tight spaces
Built-in capable Make the best use of space by installing your appliance under the counter and flush with

other cabinets
Fully finished white cabinet Allows the unit to be used freestanding
Integrated door frame Customize the front by mounting an overlay panel over the door; seamless look can blend

into other cabinetry with no exposed frame. Handle not included (panel size: 23 5/16" W x 28

1/4" H and at least 3/4" thick; maximum weight: 10 lbs.)
Cycle defrost This system utilizes user-friendly automatic defrost operation in the fresh food section and

efficient manual defrost operation in the freezer compartment
Dual evaporator Our unique and efficient design separately cools the refrigerator while maintaining a lower

temperature in the freezer compartment by utilizing two evaporators
Adjustable shelves Rearrange the refrigerator space to accommodate all shapes and sizes or remove shelves for

a simple clean-up
Clear crisper Get the longest life and best taste out of produce by storing greens in a convenient slide

SUMMIT APPLIANCE DIVISION, FELIX STORCH, INC. | ISO 9001:2015 Certified

770 Garrison Avenue Bronx, NY 10474 USA TEL [phone] FAX [phone] [e-mail] www.summitappliance.com

drawer

AL650BIIF Specifications:

Overview

Height of Cabinet 32.0" (81 cm)
Height to Hinge Cap 32.25" (82 cm)
Width 23.63" (60 cm)
Depth 23.5" (60 cm)
Capacity 5.1 cu.ft. (144 L)
Defrost Type Cycle
Door Panel-Ready
Cabinet White
US Electrical Safety UL
Canadian Electrical Safety ULC
Amps 1.3
Voltage/Frequency 115 V AC/60 Hz
Shipping Weight 100.0 lbs. (45

Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years

Refrigerator-Freezer

Door Swing RHD
Reversible Factory

Adjustable Shelves Yes
Crisper Qty 1
Crisper Finish Opaque
Crisper Cover Glass
Interior Light Yes
Refrigerator - Interior

Height
Refrigerator - Interior Width 20.5" (52 cm)
Refrigerator - Interior

Depth
Refrigerator - Shelf Type Wire
Refrigerator - Shelf Qty 2
Refrigerator - Full Door

Shelves
Freezer - Interior Height 5.0" (13 cm)
Freezer - Interior Width 19.0" (48 cm)
Freezer - Interior Depth 11.0" (28 cm)
Thermostat Type Dial
Fan Type Exterior
Refrigerant Type R134a

19.5" (50 cm)

17.0" (43 cm)

kg)

Reversible

Refrigerant Amount 2.6 oz.
High Side PSI 285.0
Low Side PSI 70.0
Compressor Step Height 7.0" (18 cm)
Compressor Step Width 20.5" (52 cm)
Compressor Step Depth 5.0" (13 cm)

3
