X-Chip 100 & 300
Model: XCA
Indoor Fixtures
www.acclaimlighting.eu
X-Chip 100 & 300
Indoor Fixtures
-xxx-xxxx
XCA
Control:
1 = Not Applicable
Housing:
3 = Gray Color
Cover:
4 = No Cover
Model number
LED Config:
A = 5 LEDs SMD 100 mm
B = 6 LEDs SMD 300 mm
System
Max. in Chain
Cabling System
Control
DMX Channels
Addressing DMX
Power requirements
Current Consumption
Light Source
Power Consumption
Weight
Housing
Source Life
Operating Temp.
Storage Temp.
Including
Beam angle:
A = Open beam
ACCLAIM
LIGHTING
24Vdc / 5-Wire
50 pcs
5 pin Flat Cable (2 wires 24V + 3 wires signal)
X-Power TV or X-Chip Driver TV
X-Chip Driver IR
Controled by 3 DMX Channels
-
50mA
X-Chip-100 = 5 x SMD 5050
X-Chip-300 = 6 x SMD 5050
X-Chip-100 = 1,2W / X-Chip-300 =1,5W
X-Chip-100 = 11 gr / X-Chip-300 =30 gr
PCB
50.000 hours
-0 °C ~ +40 °C
-20 °C ~ +70 °C
Mounting clips and one 10 cm Link Cable
Version:
Color:
C
= WW 3200k
G
= CW 6000k
H
= RGB
N
= Red
P
= Green
Q
= Blue
R
= Amber
N = Normal
Model Number
XCA-134-AAHN
XCA-134-BAHN
Product name
X-Chip 100 SMD RGB 5-LED‘s
X-Chip 300 SMD RGB 6-LED‘s
100mm [3.9"]
82mm [3.2"]
16mm [0.6"]
Length
100 mm
300 mm
16mm [0.6"]
Beam
120º
120º
Dimensions
Projects
Color
RGB
RGB
300mm [11.8"]
X-Chip 300X-Chip 100
Delivery including
Mounting clips and one 10 cm Link Cable
Mounting clips and one 10 cm Link Cable
www.acclaimlighting.eu
** All rights reserved. Improvements changes to specifications, design, and all contents in this catalog may be made at any time without prior notice.
