BLUETOOTH SPEAKER
Front
Rear
BLUETOOTH SPEAKER USER MANUAL
6
7
/
/
/
/
9
1
2
3
4
5
6
7
8
8
9
Power on/off, Bluetooth pairing, Answer / End a call
Play / Pause
/
Forward / Volume up
Backward / Volume down
/
Driver unit
LED indicator
Internal Microphone
3.5mm AUX in
DC power input (For charging speaker only)
8
.1.
BLUETOOTH SPEAKER USER MANUAL
Note : The control buttons functions maybe difference
4
32
in some mobile phone.
Specication
Speaker
Output: 2W x 1
Speaker unit: Full range, d40 x 18.5 mm / 4 Ohm
Frequency response: 200Hz-20 KHz
S/N Ratio: 75dB
Audio input : Bluetooth or 3.5 mm AUX ( Priority )
Power input : Built-in rechargeable Li-Polymer battery, 430 mAh,
DC 3.7V or Micro-USB female (DC 5V / 500mA)
Weight: 75g
Dimension: D65 x 55 mm
Bluetooth
Bluetooth 3.0+EDR compliant
( Compatible with V2.1, V2.0, V1.1 and V1.2 standard )
Operation Scope : ≦ 10 meters
Bluetooth protocol support: HSP, HFP, A2DP, AVRCP, PBAP
Frequency range : 2.402 ~ 2 .480 GHz (2.4GHz ISM Segment)
Microphone: Omni-Directional Type
LED Indicator:
Color
Blue( Blink twice around 5 seconds)
Blue( Blink once around 5 seconds)
Blue/Red blink alternately
Red
Status
Bluetooth connecting mode
Bluetooth Standby mode
Pairing mode
AUX in / Battery in charge /
Low power warning
.2.
BLUETOOTH SPEAKER USER MANUAL
Control buttons
All the functions be controlled by these four buttons, such as
(Power on/off), (Answer/End a phone call),(Pairing), (Play/ pause),
(Volume up / down), (Backward / Forward ). Operation methods
showed as below:
Power on/off, Bluetooth pairing and
Answer / End a call button
1.Power on / off
Press for 3 seconds for Power on
/
/
Press for 3 seconds for Power off
2.Bluetooth Pairing ( after power on ) mode
Double Click Enter pairing status
It is necessarily only for the rst time of
connection.
Pairing mode
mode after 90 seconds, you have to operate
double click again if it is necessary to run the
pairing once more.
will turn to the standby
3.Answer / End a call
One click Pick up the phone
One click Hang up the phone
.3.
BLUETOOTH SPEAKER USER MANUAL
Play / Pause
One click Play or resume play
One click Pause
/
/
Note : Some mobile phone will be acts as “stop”
function when this button is pressed.
Forward / Volume up
/
1.Forward
/
/
One click forward to next Track
2.Volume up
Press for more than 2 seconds
Increase volume
/
Backward / Volume down
1.Backward
Double click Previous Track
/
/
2.Volume down
Press for more than 2 seconds
Decrease volume
.4.
BLUETOOTH SPEAKER USER MANUAL
Play Music
Bluetooth Mode
Step 1. Press button for 3 seconds for Power on
Press for 3 seconds
/
/
* Note : User no need to run the step 2 again, if the Bluetooth
pairing had been done before.
Step 2. Double click the button and enter Bluetooth Pairing mode
Double click
/
/
.5.
BLUETOOTH SPEAKER USER MANUAL
Step 3. Turn on the Bluetooth function of mobile phone or other
Bluetooth device and start to search for a new Bluetooth device.
Note :
1.
Pairing mode will turn to the sleeping mode after 90 seconds,
you have to operate double click again if it is necessary to run
the pairing once more.
2.
Suitable for iPhone, Android Smartphone and iPad, Tablet PC
and other Bluetooth device
Step 4. Select device “SP-1056” And enter the password 0000
if it is required.
Step 5. Bluetooth mobile phone will show the sign that it is
connected to a Bluetooth audio device.
Step 6. For playing music please refer to the manual of your
Bluetooth mobile phone.
Hands Free Mode
Press a click on “Power” button to Answer a call and another
click to End a call.
Note: This function only work on Bluetooth mode.
One click
/
/
.6.
BLUETOOTH SPEAKER USER MANUAL
AUX in Mode
3.5 mm AUX in
Step 1. Connect speaker via audio
cable with d3.5mm audio plug.
Step 2. Connect this cable to your media
player, such as MP3 / MP4 player, mobile
AUX-IN
aux in
d3.5 Plug
phone, etc
Note : Bluetooth Mode and AUX in Mode
can not work at the same time.
Battery Recharging
For speaker internal Battery
Step 1. Plug Micro USB connector to the
speaker
Step 2. LED indicators will show red light when
charging power, and go off when
charging stops
Step 3. It will take around 2 to 3 hours to
recharge when the battery is out
of power.
Step 4. Please disconnect the power cable
after the battery is recharged.
.7.
BLUETOOTH SPEAKER USER MANUAL
Accessories
USB power input cable:100 cm ± 5 cm
d3.5mm AUX in cable : 60 cm ± 5 cm
Pouch
Protect cover for Speaker (option)
User manual
d3.5mm AUX in cable
Power Bank
BLUETOOTH SPEAKER
Protect cover for
Speaker
The contents are subject to change without prior notice due to product inprovement
and specication changes.
User manual
.8.
