ACCENT ADVANCED SYSTEMS S.L.U.

Byte

Value

CONFIGURATION OVER GATT SERVICE 0xFFF0

Characteristic UUID

Characteristic value length

Default factory value

0

0x02

CONSTANT PREAMBLE

1

0x01

2

0x1A

3

0x1A

4

0xFF

5

0x4C

6

0x00

7

0x02

8

0x15

9

UUID[0]

0xFFF1

16 bytes

0x53

10

UUID[1]

0xFFF1

16 bytes

0x44

11

UUID[2]

0xFFF1

16 bytes

0x58

12

UUID[3]

0xFFF1

16 bytes

0x30

13

UUID[4]

0xFFF1

16 bytes

0x35

14

UUID[5]

0xFFF1

16 bytes

0x84

15

UUID[6]

0xFFF1

16 bytes

0x11

16

UUID[7]

0xFFF1

16 bytes

0xE3

17

UUID[8]

0xFFF1

16 bytes

0xAA

18

UUID[9]

0xFFF1

16 bytes

0x6E

19

UUID[10]

0xFFF1

16 bytes

0x08

20

UUID[11]

0xFFF1

16 bytes

0x00

21

UUID[12]

0xFFF1

16 bytes

0x20

22

UUID[13]

0xFFF1

16 bytes

0x0C

e-mail:[e-mail] www.accent-systems.com

Bluetooth Low Energy ® advertising beacon device

Ibks10 – Version 2.0

IBks10 – Version 2.0

Features Product image

• Bluetooth LE Advertising packets

• Compatible with Apple® iBeacons definition

• Compatible with all Bluetooth 4.0 (and above)

devices

• Ultra low power

• Up to 2 years life battery with CR2032

• User button feature

• Configurable parameters

◦ TX Power
◦ Advertising frequency
◦ UUID, Major and Minor values
◦ Password change

• Password protected ODA firmware upgrade (wireless)

Applications

• Indoor location applications

• Indoor/outdoor tracking

• Bluetooth marketing

Advertising Packet

iBks series devices start to send the advertising packet as soon as they are
powered up with standard 3V CR2032 coin cell. The advertising packet follows
the Apple iBeacons standard and has the following structure:

www.accent-systems.com pag.1/8

ACCENT ADVANCED SYSTEMS S.L.U.

23

UUID[14]

0xFFF1

16 bytes

0x9A

24

UUID[15]

0xFFF1

16 bytes

0x66

25

Major[0]

0xFFF2

2 bytes

0x01

26

Major[1]

0xFFF2

2 bytes

0xFF

27

Minor[0]

0xFFF3

2 bytes

0x00

28

Minor[1]

0xFFF3

2bytes

0xEE

29

MeasuredCalPower1m

0xFFF4

1 byte

0xC6

30

batteryLevel + Button
state

read Only. bXXXXXXXY, where X bits are Battery level and Y Button status.

Charcteristic UUID

Length

Parameter

Comments

0xFFF1

16 Bytes

UUID

iBeacon protocol

0xFFF2

2 Bytes

Major

iBeacon protocol

0xFFF3

2 Bytes

Minor

iBeacon protocol

0xFFF4

1 Bytes

Measured Cal Power 1m

iBeacon protocol

0xFFF5

2 Bytes

Change adv interval

625us/step from 32 to 16384

0xFFF6

1 Byte

Change TX power

Possible values:

0: -23 dBm

1: -6 dBm

2: + 0 dBm

3: +4Bm

0xFFF7

1 Byte

Change password

8 bit micro-switch

e-mail:[e-mail] www.accent-systems.com

Bluetooth Low Energy ® advertising beacon device

Ibks10 – Version 2.0

www.accent-systems.com pag.2/8

ACCENT ADVANCED SYSTEMS S.L.U.

e-mail:[e-mail] www.accent-systems.com

Bluetooth Low Energy ® advertising beacon device

Configuration

Ibks10 – Version 2.0

Set the secret password (default factory value 00000000) in the 8 bit
microswitch and press the button to enter in configuration mode, then a GATT
service will be available for some time. iBks parameters can be configured by
any BLE Central device writing on the following characteristics of the 0xFFF0
service:

Usage

Accordingly to the Apple® iBeacons protocol, iBks10 will advertise the
packet with the fixed preamble and the user data as described above. All other
platforms can also read this data and process like iOS does it.

Broadcast the button status is interesting for user interaction applications
since smartPhone APP can detect the status and how close the user is to the
iBks. The applications are limited just by imagination.

www.accent-systems.com pag.3/8

ACCENT ADVANCED SYSTEMS S.L.U.

e-mail:[e-mail] www.accent-systems.com

Ibks10 – Version 2.0

Bluetooth Low Energy ® advertising beacon device

iBks also broadcasts the Battery level, so developers can use the
smartPhone APP as a battery level tracking tool. If some of them have to be
replaced the APP can report to the server.

www.accent-systems.com pag.4/8

ACCENT ADVANCED SYSTEMS S.L.U.

e-mail:[e-mail] www.accent-systems.com

Bluetooth Low Energy ® advertising beacon device

Dimensions (in mm)

Ibks10 – Version 2.0

www.accent-systems.com pag.5/8

ACCENT ADVANCED SYSTEMS S.L.U.

e-mail:[e-mail] www.accent-systems.com

Bluetooth Low Energy ® advertising beacon device

Images

Ibks10 – Version 2.0

www.accent-systems.com pag.6/8

ACCENT ADVANCED SYSTEMS S.L.U.

e-mail:[e-mail] www.accent-systems.com

Bluetooth Low Energy ® advertising beacon device

Label info

Ibks10 – Version 2.0

1. FCC Caution:

"Changes or modifications not expressly approved by the part responsible for compliance could
void the user's authority to operate the equipment." 2. FCC Statement:

"This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:

www.accent-systems.com pag.7/8

ACCENT ADVANCED SYSTEMS S.L.U.

e-mail:[e-mail] www.accent-systems.com

Ibks10 – Version 2.0

Bluetooth Low Energy ® advertising beacon device

—Reorient or relocate the receiving antenna.

—Increase the separation between the equipment and receiver.

—Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

—Consult the dealer or an experienced radio/TV technician for help."

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
