Smartvest Wireless Motion Detector
Art. no. FUBW35000A
Smartvest extension for monitoring rooms
•
Quick and cable-free installation without the need for wires or drilling thanks to battery operation
•
Detection of people using infrared with a horizontal detection range of 105° and a maximum range of 12 m
•
Visual notification via blue LED when starting up and functioning
•
Automatic supervision, with functional tests repeated daily and feedback sent to the Smartvest alarm control
•
panel
Low battery notification sent to the Smartvest alarm control panel
•
Battery life of up to 2 years
•
Tamper protection via cover contact
•
Page 1 of 2
The Smartvest Wireless Motion Detector enables you to monitor rooms, while its battery operation makes it easy
to install, avoiding the need for drilling and wiring. It can be relied upon to detect people in the room using
infrared, and has a range of up to 12 metres. When the battery is low, the Smartvest Wireless Motion Detector
sends an automatic notification to the alarm panel. The free Smartvest app then guides you step by step through
the process of replacing the batteries. In combination with the Smartvest Wireless Socket, you can then initiate
certain smart functions such as "motion detected" or "light on", in addition to monitoring.
Technical alterations reserved. Misprints and errors excepted. Copyright. © ABUS 04/2017
Smartvest Wireless Motion Detector
Art. no. FUBW35000A
Technical Data:
Power consumption
0,03 mA
Standby
Dimensions 61x110x52 mm
Battery type 3 x AA
Width 61 mm
Type of detection Heat recognition
Detection range of detector
12 m
(m)
Radio frequency 868 MHz
Housing material ABS
Height 110 mm
Length 52 mm
Max. battery life 2 year(s)
Max. operating
40 °C
temperature
Max. humidity 80 %
Max. receiving range
100 m
(outdoors)
Max. receiving range
30 m
(building)
Page 2 of 2
Max. sending range
(outdoors)
Max. sending range
(building)
Min. operating
temperature
Modulation FSK
Installation location Ambient conditions
Net weight 0,163 kg
PIR angle of view Horizontal: 105°, Vertical:
Tamper monitoring Yes
Sensor type PIR
Power consumption 15 mA
Pet-proof No
Certifications CE
100 m
30 m
0 °C
adapted to optimal
transmission power
45° °
Powered by TCPDF (www.tcpdf.org)
Technical alterations reserved. Misprints and errors excepted. Copyright. © ABUS 04/2017
