Smartvest Wireless Alarm System and App – Alarm
Control Panel
Art. no. FUAA35010A
Smart and reliable all-round security for your home that is easy to install yourself
•
The 5 V power supply unit and pre-configured detector means quick wireless Plug&Play installation of the
•
alarm control panel without the need for wires or drilling
All-round security with the auxiliary battery as the backup power supply and the option to extend to a
•
maximum of 32 wireless components and 4 IP cameras
Mobile access from any location via the free Smartvest app (for iOS and Android) that allows you to monitor
•
and control what is happening at home
Immediate triggering of alarms with the built-in, high-volume 90 dB siren and push notifications via app and
•
e-mail
Intuitive operation via app with live camera view, snapshot function and presence simulation thanks to
•
lighting/TV control (wireless socket as required accessory)
Peace of mind at all times with space to save up to 1000 events and camera recordings
•
Up to 32 scenarios that can be individually configured, such as smart lighting control: system disarmed, motion
•
detected, light on
Integrated hygrometer which displays room temperature and humidity
•
Page 1 of 2
Up to 32 wireless components and four IP cameras can be connected to the Smartvest alarm panel via the free
app, making it the hub of any modern home, combining reliable all-round security with attractive
home-automation functions. It is very easy to install any other components thanks to Plug and Play, as these are
preconfigured and can easily be integrated using the free app. All other settings (e.g. presence simulation) are
easy and intuitive to make using your tablet or smartphone. An integrated hygrometer makes it possible to react
to changes in room temperature and humidity at any time. If an alarm is triggered, the alarm panel activates its
built-in, high-volume 90dB siren; it can also raise the alarm simultaneously via push notifications in the app
and email.
Technical alterations reserved. Misprints and errors excepted. Copyright. © ABUS 04/2017
Smartvest Wireless Alarm System and App – Alarm
Control Panel
Art. no. FUAA35010A
Technical Data:
Number of simultaneous
accesses
Dimensions 280x194x89 mm
Alarming Email, push notification,
Number of users 1
Number of wired zones 0
Number of events 1.000
Number of wireless zones 32
Display LED
Outputs 0
Battery type 6 x AA Battery
Width 280 mm
Event log Yes
Radio frequency 868 MHz
Housing material ABS
Height 194 mm
Integrated siren < 90 dB
Length 89 mm
Luminous color Blue; yellow; red
Max. operating
temperature
Max. humidity 80 %
3
text message
40 °C
Max. receiving range
(outdoors)
Max. receiving range
(building)
Max. sending range
(outdoors)
Max. sending range
(building)
Min. operating
temperature
Modulation FSK
Installation location Ambient conditions
Net weight 0,54 kg
Network access Ethernet 10/100 Mbit
Backup power supply Yes
Switching outputs 0
DC voltage supply 5 V
Power consumption 480 mA
Encryption P2P: AES-128; Push: HTTPS
Certifications CE
100 m
30 m
100 m
30 m
0 °C
adapted to optimal
transmission power
Page 2 of 2
Powered by TCPDF (www.tcpdf.org)
Technical alterations reserved. Misprints and errors excepted. Copyright. © ABUS 04/2017
