Outdoor IP Tube IR Ultra Low-Light 1080p (2.8 - 12 mm)
Art. no. IPCA62520
Full HD 1080p resolution: 1920 x 1080 @ 25 fps
• Improved performance in poor lighting conditions thanks to the large image sensor (1/1.8")
2.8–12.0 mm motorised zoom lens with automatic focussing
• High-power IR LEDs for effective illumination over large distances (50 m)
• True WDR function to compensate for high image contrasts (120 dB)
• Integrated video content analysis (VCA) (e.g. tripwire detection, intrusion detection, object counting)
• Integrated microSD card slot for edge recording
• Integrated ROI function that saves on bandwidth and storage space
• Automatic backup recording to ensure uninterrupted recording
• Weatherproof housing with IP67 protection class
Page 1 of 4
This 2megapixel IP tube camera excels when it comes to colour recordings in low lighting conditions thanks to its special ultra-low-light function. Its 1920x1080pixel resolution (2MPx) guarantees an excellent overview of even expansive areas.Full HD 24/7 outdoor surveillance in low lighting conditionsThe IR LEDs integrated in the IP66 housing provide useful images both during the day and at night. The ultra-low-light function ensures that poorly lit locations (such as underground parking garages, car parks and production halls) are recorded optimally in colour mode. Glare is also compensated for and state-of-the-art motion detection technology put to use (in entrance areas and at access points).Unbeatable overview and freely controllable angle of viewThe autofocus motorised zoom lens can be adjusted to the desired angle of view at the touch of a button. Its focal length of between 2.8 and 12mm covers a range of between 24° and 78° (3.25x optical zoom).Decentralised video content analysis (VCA) – in the camera itselfThe camera offers VCA functions such as tripwires, intrusion detection and face detection, all without the need for any VMS software. This saves on bandwidth, hard disk space and additional costs, while also making the evaluation of recordings faster.Easy set-up – innovative user managementThe practical installation wizard ensures quick and easy set-up. Innovative user management also facilitates user authorisation configuration that is tailored to your individual security needs.Suitable accessories:An installation box (TVAC31350) is available for mounting the camera with protected cabling.The effective IR range will depend on the installation location. If there are surfaces that absorb light or no objects that reflect IR light in the field of view, the IR range will be reduced and/or the video image will be too dark.
Technical alterations reserved. Misprints and errors excepted. Copyright. © ABUS 09/2019
Outdoor IP Tube IR Ultra Low-Light 1080p (2.8 - 12 mm)
Art. no. IPCA62520
Reflective objects in the immediate vicinity of the camera (e.g. roof gutter or wall) may also result in the reflection of IR light, which can disturb the image.
Page 2 of 4
Technical alterations reserved. Misprints and errors excepted. Copyright. © ABUS 09/2019
Outdoor IP Tube IR Ultra Low-Light 1080p (2.8 - 12 mm)
Art. no. IPCA62520
Technical Data:
ONVIF Profile S Image enhancement True WDR, BLC, Vertical
Display, Defog, 50/60 fps (PAL/NTSC), Region of Interest, Distortion
Correction Video Content Analysis (VCA)
Technology IP Design Tube Compatible with Secvest Yes Compatible with wAppLoxx Yes Other features Ultra Low Light, Auto
Dimensions LxWxH (390x160x160) mm Alarming E-Mail, NAS, FTP Connections 1 x RJ45, 1 x DC, 1 x video
Number of users 10 Number of IR LEDs 4 Number of streams 3 Resolution 2MPx Resolution modes 1920 x 1080, 1280 x 720,
Motion detection 1 Image sensor 1/1.8" Sony Exmor™ CMOS Pixels (effective) 1920 x 1080 pixel Frame rate 25 / 60 (WDR off) fps Width 160 mm Focal length 2.8 – 12.0 mm Gross weight 2,45 kg Dynamic range (WDR) 120 dB Electronic shutter 1 – 1/100.000 s Functions Scene Change Detection,
Backlight compensation True WDR, BLC Height 160 mm Horizontal angle of view 24 – 78 °
Tripwire Detection,
Intrusion Detection, Face
Detection, Object Counting
Backup Recording
output
704 x 576, 320 x 240
Cover Detection, Defocus
Detection, IPC Hot Spare,
Ultra Low Light
Page 3 of 4
IR LEDs Yes IR range (up to) 50 m Compatible with NVR, Hybrid DVR, IPCam
Plus Length 390 mm Power consumption 12 W Max. resolution @ frame rate Max. operating temperature Max. humidity 95 % Min. operating temperature Minimum illumination (color) Minimum illumination (IR) 0 lx Video network bandwidth 32 kBit/s – 16 MBit/s Network access RJ45 LAN network access RJ45 Network camera protocols TCP/IP, UDP, IPv4/v6, HTTP,
Lens Motor-Zoom Optical zoom 4.2 x PoE Standard IEEE 802.3at Private zones 4 Noise reduction 3D-DNR, 2D-DNR IP protection class 67 DC voltage supply 12 (+/-10 %) V Storage medium microSD card, 128 GB
Power consumption 1.000 mA Day/night switching Electromechanically
Supported browsers IE10, IE11, Firefox Encryption HTTPS Video compression H.264, MJPEG Video system IP
1920 x 1080 @ 60 fps
60 °C
-30 °C
0,002 lx
HTTPS, FTP, SMTP, UPnP,
DNS, DynDNS, ABUS Server,
NTP, RTSP, DHCP, ONVIF,
SNMP, QoS, 802.1X, PSIA
(option)
removable IR cut filter
(ICR), colour/B&W
Technical alterations reserved. Misprints and errors excepted. Copyright. © ABUS 09/2019
Outdoor IP Tube IR Ultra Low-Light 1080p (2.8 - 12 mm)
Art. no. IPCA62520
Technical Data:
Page 4 of 4
White balance AWB, manual
