ABtUS AB21234458 User Manual

For Airports, Exhibition Stands, Offices, Schools, Cafes, Home Theatres, etc.

Model: AB21234458

**Specification are subjected to changes without notice...for detail and updated information please visit www.abtussinagpore.com

16

Dear professional user/painter & decorator/installer,

This box contains enough Projection Screen Paint to treat several large screens or walls. You
need to use the right tools to achieve the best results. We advise you to purchase a number
of AB21234458 Tool Kits, which have been specially developed for use with ABtUS paint.

If your customers want an attractive dark border around their screen, we also advise you to
purchase a number of AB21234108 MagneBorder Kits before you start.

The enclosed instructions explain how to apply ABtUS Projection Screen Paint correctly. These
instructions are also used for ABtUS retail packs for consumers, so the explanations may
sometimes be more detailed than a professional user requires.

ABtUS SINGAPORE PTE LTD

www.abtussingapore.com

User Operation Guide

The following points require particular attention:

- On the first page of the instructions: This box contains:

This description of the contents of the box refers to the retail packs for consumers; you

must order the tool kit and MagneBorder separately (see above).

- If you/your customer do/does not require a black border, you can skip step 2 and step 5

- Step 3.1: Determining the contrast value, and

- Step 4.1: Determining the brightness value (Gain):

Note: if you mix the Boosters partially in the full buckets and some BaseCoat or TopCoat is left over
afterwards, this will automatically mean that the next screens you paint with the contents of these buckets
will have the same contrast value and brightness value. Of course you can add extra Boosters to the
buckets for the next screens, but it is no longer possible to reduce the contrast value or brightness value.

Instructions for use AB2123208 and AB2123308

This package contains:

MagneCoat, BaseCoat, ContrastBooster for BaseCoat, TopCoat, BrightnessBooster for TopCoat,
3 stir sticks, roller pan, paint roller, 1 small roller cover for the MagneCoat, 2 large roller covers for
the BaseCoat and the TopCoat, masking tape, sandpaper, MagneBorder, knife, metal triangle.

Congratulations on the purchase of your ABtUS Projection Screen Paint. Soon you will be enjoying the
benefits of the perfect projection screen for your specific situation. It is important that you carefully follow
each step of the instructions on the following pages. You also need to have a little bit of patience for the
next few hours. Because of the drying time that is required for the different layers of paint, you might easily
need eight hours to apply the product. (Of course, you can do the first steps today and continue later.)

MAKE YOUR OWN SCREEN IN SIX EASY STEPS:

Before you begin Page

- The surroundings and temperature 3

- The surface upon which ABtUS will be applied 3

Step 1: Determining the location, size and dimensions of the screen 4

Step 2: Applying the magnetic layer of paint (MagneCoat) 4~5

Step 3: Mixing and applying the basis layer of paint (BaseCoat) 6

- 3.1 Determining the contrast of the BaseCoat

- 3.2 Applying the BaseCoat

Step 4: Mixing and applying the top layer of paint (TopCoat) 10

- 4.1 Determining the brightness of the top layer

- 4.2 Applying the top layer

- 4.3 Wait for screen to harden

Step 5: Applying the magnetic strip (MagneBorder) 12

Step 6: The enormous fun can begin 14

Final notes - Maintenance 14~15

- Safety

- Guarantee

Appendix Question list to determine the Contrast & Brightness of your screen 16

BEFORE YOU BEGIN

Shake all products well for at least 15 seconds

The surroundings:

Make sure that the area and surface that will be painted are free of dust and that no air circulation
system is on (for example: air conditioning, fan). This ensures that no dust will stick to the wet
wall while the paint is being applied.

The temperature:

The ABtUS paint system can best be applied at a room temperature that is between 15 and 25º
Celsius (59 and 77º F) and with a humidity that is between 40 and 70 percent. A different room
temperature or humidity can require a longer drying and thereby waiting time. (Important: The
paint layers cannot be applied if the room temperature is lower than 5º Celsius (41º F).

The wall (or other surface) upon which the ABtUS paint system will be applied

The ABtUS paint system can be applied on stone, cement, wood, plastic or sheetrock and on all materials
that have already been painted with a normal wall paint. You do, however, have to check the following:

- Flat:

Important: The wall must be flat or flat enough (if you stand 2 or 3 meters (6 or 9 feet) from the
wall it should look flat and even). (See illustration)

Tips

Inspect the wall closely and repair
any small irregularities, scratches
or holes. Then sand the wall lightly
to even it out.

- Walls with a synthetic finish:

If your wall or surface has a very smooth synthetic finish, you must first apply an adhesive layer
so that the Mighty Brighty paint system can adequately adhere to the wall. Walls made of particle
board or MDF should be thoroughly cleaned with turpentine or paint thinner. You must also apply
an adhesive layer to these walls.

Special Note:

A synthetic surface cannot absorb any liquid. While drying, temporary air bubbles may appear in the paint
that has been applied. Do not touch them. They will disappear by themselves as the paint dries.

- Absorbency

If the wall is very absorbent, you should first treat it with a pre-paint coating. (The amount that
you need will be determined by the type of surface)

- Dirt

If the wall is very dirty (for example, smoke stains, water stains) you will first have to treat it
with a good stain-blocking paint.

- Dark

If the surface is very dark you will first have to treat it with a standard white wall paint.

02

**Specification are subjected to changes without notice...for detail and updated information please visit www.abtussinagpore.com

03

User Operation Guide

STEP 1: DETERMINING THE LOCATION, SIZE AND

DIMENSIONS OF THE SCREEN

The big advantage of ABtUS compared to a traditional projection screen is that you can now
determine exactly the right format for your projection screen. The measurements of the dark
magnetic border around your screen are determined by the length of the dark magnetic border
that comes with the paint system. This so-called MagneBorder is 10 meters long. This means
the following for the maximum size of your screen:

Screen dimensions: Maximum screen size in cm (inch):

1 : 1 2.35 x 2.35 m / 93" x 93"
4 : 3 (= 1.33 : 1 + PAL / NTSC Video) 2.68 x 2.01 m / 106" x 79"
16 : 9 (= 1.78:1 = and Widescreen HDTV) 2.99 x 1.68 m / 118" x 66"

1.85 : 1 (Letterbox Video) 3.06 x 1.65 m / 121" x 65"

2.35 : 1 (Anamorphic) 3.30 x 1.40 m / 130" x 55"

1: Install the projector in its set location, according to the

instructions provided with the projector

2: Turn the projector on and project an image on the wall

(see illustration)

3: Select the desired dimensions on the projector (1:1, 4:3, 16:9, etc)

(see illustration)

4: Use the zoom function to determine the exact size of the screen

that you prefer. Check that the image does not extend past the
maximum dimensions given above.

5: Adjust the image until it is sharply in focus. Make the screen

exactly level using the keystone function of your projector. Now
you have determined the correct format of your screen. The next
important step is the final check.

6: To check the format of your screen, project an image from a TV channel and from a DVD

player onto the wall. While it is playing, make sure that the screen format remains the same.

Adjust the screen format as needed to fit the actual playing format.

3: The projector is on so you can see the exact edge of the projection format.
Stick the yellow colored tape on the wall about 4.5 cm away from the
outside of the screen format (if you have the AB2123208 product) or exactly
6,5 cm (if you have the AB2123308 product). (See illustration). Turn the
projector off.

4: Stir the MagneCoat using the smallest stir stick for at least 3 minutes
until it is well mixed. Pour the MagneCoat into the roller pan
(see illustration). Attach the smallest roller cover (12 cm) to the roller and
use this to apply a thin layer of MagneCoat inside the yellow tape. The
band will be about 10-12 cm wide. This ensures that it covers not just the

4.5 cm / 6,5 gap, but also a few centimeters/inches inside the screen area
(see illustration a). That is the intention. That means that you can later
adjust the MagneBorder so that it always encloses the actual projected
image. Important: Make sure that no edges are created by a thick layer of paint!!!
Apply the MagneCoat so that it is smoothly distributed towards the center
of the screen. (See illustration b) Continue with step 6.

5: The projector is on so you can see the exact edge of the projection format.
Stir the MagneCoat paint with the smallest stir stick for at least 3 minutes
and then pour it in the roller pan. Attach the smallest roller cover (12 cm)
to the roller and use this to apply a thin layer of MagneCoat. The band will
be about 12 cm wide. This means that you will paint about 5 cm inside and
7 cm outside the screen area (see illustration c). This is the intention.
That means that you can later adjust the MagneBorder so that it always
encloses the actual projected image. Important: Make sure that no edges
are created by a thick layer of paint!!! Apply the MagneCoat so that it is

smoothly distributed towards the center of the screen. (see illustration d).

6: Let the MagneCoat dry for at least 45 minutes. Then apply a second layer
of MagneCoat on top of the first layer. Let this layer also dry for at least
45 minutes. Afterwards, clean all of the paint out of the roller pan.

Important: Make sure that absolutely no residue of paint remains in the
roller pan!!! Paint particles can cause problems in applying the basis paint
layer (BaseCoat)! Dispose of the small roller cover and clean the roller
thoroughly. (While waiting for the MagnetCoat to dry you can determine
the contrast of the BaseCoat. See the next chapter: step 3.1).

STEP 2: APPLYING THE MAGNETIC LAYER OF PAINT

(MagneCoat)

1: Cover the floor before you begin painting (carpet, parquet, etc.) to prevent damage.

2: -If you have the AB2123208, continue with step 3

-If you have the AB2123308, choose one of the following:

I want to paint one (or more) screens, but not the entire wall: continue with step 3

I want to paint my entire wall: continue with step 5

04

7: When appropriate, carefully remove the yellow tape

8: Very important! - sand the inside and outside edges of the magnetic layer
lightly with sandpaper. (see illustration). Why is this so important? If you
do not sand the edges of the area off, you may see these edges on your
projection screen!

9: Turn the projector off.

**Specification are subjected to changes without notice...for detail and updated information please visit www.abtussinagpore.com

05

User Operation Guide

STEP 3: MIXING AND APPLYING THE BASIS LAYER OF PAINT

(BaseCoat)

- 3.1 Determining the contrast of the basis layer (BaseCoat)

- 3.2 Applying the basis layer (BaseCoat)

3.1 Determining the contrast of the basis layer (BaseCoat)

1: Complete all of the questions on the Question List on page 15/16 in order to determine the contrast.
The calculated number determines the amount of ContrastBooster that you should add to the
basis paint. You will find this number in My ContrastBooster Total on the list of questions.

Enter the number again here. My ContrastBooster Total: . . . . . . . .

2: Turn the closed bottle of ContrastBooster upside down
and shake it for at least 15 seconds. Set the bottle on

a flat surface. Look at the scale (1-9) on the back of

the bottle (see illustration). Find the number that

corresponds to the number that you have just written
in above for My ContrastBooster Total. This is the
amount of ContrastBooster that you should add to the
BaseCoat.

3: Open the bottle and pour the correct amount of ContrastBooster into the large container of
BaseCoat. Stop now and then and set the bottle on a flat surface to check the amount that still
remains to be added. Slowly add the last amount of ContrastBooster until the level in the bottle
reaches the calculated number.

3.2 Applying the basis layer of paint (BaseCoat)

Do you have the AB2123208 product: Continue with instruction 1 (see page 7~8).

Do you have the AB2123308 product: Read the following information carefully:

In the AB2123308 package, you have enough paint to
cover an area of about 11 m
a choice: Do I paint just the screen area OR do I paint
my entire wall (maximum of about 11 m
advantage of painting the entire wall is that you will not
see any screen edges when you are not projecting: after
you remove the magnetic border. You see just a normal
white/light gray/gray wall.

2

(118 sq.ft.). You must make

2

/ 118 sq.ft.). The

Tips

if you paint, only a screen area and
not the entire wall, you will have
enough paint to paint a second
projection screen in another room
(without painting MagneCoat and
MagneBorder).

You choose to paint the entire wall:

Read the following points a,b,c and d very carefully
before proceeding: The instructions below explain how
to paint only the screen area. The instructions for painting
the entire wall are the same except for a few small
differences: a. Instruction 1 (see page 7~8) is not
necessary: If you paint the entire wall, you do not need
to tape off the screen area. You can, however, use this
tape to tape up window casings, ceilings and side walls
(see illustrations).

b. In instruction 3, you paint just one band of BaseCoat,
about 15 cm wide, on top of the band of MagneCoat
(see illustration).

d.You must be aware, however, of exactly where the

screen area is located within the painted wall. And
where exactly you have placed the MagneBorder. To
do this, turn the projector on. Then mark the four
corners of the illuminated screen area. You can use
a needle to place a small hole in the four corners
(see illustration). After every layer of paint, check
that the holes can still be seen from close up (if not,
make a new hole).

1:Once again, stick the yellow tape on the wall. This
time, leave a very small gap of about 0.5 cm (0.2)
around the outside edge of the magnetic paint.
(see illustration).

c. In the rest of the instructions, it is

logical that you paint the entire wall

instead of just the screen area.

You choose to paint only the screen area:

Continue with instruction 1 (see page 8).

06

**Specification are subjected to changes without notice...for detail and updated information please visit www.abtussinagpore.com

07

User Operation Guide

Make the adhesive band wider by applying a second
strip next to the first strip. If you have enough tape, stick
a third strip above the others. If you still have tape, stick
a third strip on the bottom as well. (see illustration).

Check: Turn the projector on. The distance between the
illuminated image and the tape must be exactly 5 cm / 2
(if you have the AB2123208 product) or exactly 7 cm / 2.8
(if you have the AB2123308 product). (see illustration).

Turn the projector off again.

2: Stir the mixture of ContrastBooster and BaseCoat
with a new stir stick for at least 3 minutes until the
color of the mixture is uniform. Afterwards close the
bottle tightly and shake it well. Then pour the mixture
in a completely clean roller pan (see illustration).

3: Attach one of the two large roller covers (length

15 cm / 6) to the roller. Make sure the roller is
completely covered with BaseCoat and roll it over
the surface of the roller pan to distribute the paint evenly.

Special note!!! Apply the layer of BaseCoat on the
inside and about 15 cm away from the tape on top of
the magnetic paint (see illustration).

Roll the paint out smoothly towards the center of the
projection screen so that no edges are created. Let
this layer dry for at least 60 minutes.

During drying, place the roller in the roller pan and make sure that it is covered with sufficient
paint to prevent it from drying out.

4. Apply a second layer of BaseCoat on top of the magnetic paint in the same way and let this
layer dry for at least 60 minutes as well.

5: Apply the BaseCoat in an even layer over the entire screen
surface, that means the entire area between the tape strips.
Apply the layer as follows: Start in the upper lefthand corner.
Paint a strip that is about 50 cm wide. Apply the paint evenly.
Always start with horizontal strokes (see illustration a) and
then roll the paint on in vertical strokes without stopping in the
middle of a strip (see illustration b).

Always roll the paint on with even and smooth movements.

Then continue by painting a second strip of about 50 cm. Make
sure that there is a slight overlap with the first strip
(see illustration c).

Always apply the paint fully wet on wet. For larger areas (for
example, an entire wall), make sure you have a long enough
handle on your roller.

Repeat this until the screen area is completely painted.

Let this layer dry for at least 60 minutes. During drying, place
the roller in the roller pan and make sure that it is covered with
sufficient paint to prevent it from drying out.

6: Apply a second layer of BaseCoat
over the entire area in the same
way. As you do so, pay attention to
the following:

-

Never go over an area thats
already been painted a second time
with the roller.

Remove the roller from the wall only when it reaches the tape strip. Do not remove the roller

-

from the wall if it is still on the screen (this can leave behind a visible mark). (see illustration).

Let this layer dry for at least 120 minutes.
Remove the roller cover and clean the roller thoroughly.
Remove the rest of the paint from the roller pan and clean it completely.
Important: Make sure that absolutely no residue of paint remains in the roller pan!!!
Paint particles can cause problems in applying the top layer (TopCoat).

7: If you see any uneven spots on the second basis layer, sand very lightly and very very
carefully until they disappear.

(Be careful not to sand too deeply or you will expose
the magnetic layer (MagneCoat) and/or make the
basis layer visible!). Leave the tape on the wall. Use
a rag or soft brush te remove dust from the surface.

Tips

if you turn the projector on you can
easily see any irregularities or bad
spots.

08

**Specification are subjected to changes without notice...for detail and updated information please visit www.abtussinagpore.com

09

User Operation Guide

STEP 4: MIXING AND APPLYING THE TOP LAYER OF PAINT

(TopCoat)

- 4.1 Determining the brightness of the top layer (TopCoat)

- 4.2 Applying the top layer (TopCoat)

- 4.3 Wait for screen to harden

4.1 Determining the brightness of the TopCoat

1: Look again at the Question List on page 15/16. You have already completed this so you know
how much of the BrightnessBooster you have to add to the TopCoat: this is the number that you
filled in under My BrightnessBooster Total.

Enter the number again here. My BrightnessBooster Total: . . . . . . . .

2: Turn the closed bottle of BrightnessBooster upside down and
shake it for at least 15 seconds. Set the bottle on a flat
surface. Look at the scale (1-9) on the back of the bottle
(see illustration). Find the number that corresponds to the
number that you have just written in above for
My BrightnessBooster Total. This is the amount of
BrightnessBooster that you should add to the TopCoat.

3: Open the bottle and pour the correct amount of BrightnessBooster into the large container of
TopCoat. Stop now and then and set the bottle on a flat surface to check the amount that still
remains to be added. Slowly add the last amount of BrightnessBooster until the level in the
bottle reaches the calculated number.

4.2 Applying the top layer (TopCoat)

1: Stir the TopCoat mixture with a new stir stick for at least three
minutes. Afterwards close the big bottle tightly and shake it
well. Pour the mixture into the clean roller pan (see illustration).

2: Attach the last new large roller cover of 15 cm (6) to the roller.
Make sure the roller is completely covered with TopCoat and roll
it over the surface of the roller pan to distribute the paint evenly.
Apply the TopCoat over the entire area between the tape strips.

Apply the layer as follows:
Start in the upper lefthand corner.
Paint a strip that is about 50 cm
wide. Apply the paint evenly.
Always start with horizontal
strokes (see illustration a)
and then roll the paint on in
vertical strokes without stopping
in the middle of a strip (see illustration b). Always roll the paint on with even and smooth
movements.

Then continue by painting a second strip of about 50 cm.
Make sure that there is a slight overlap with the first strip
(see illustration c).

Always apply the paint fully wet on wet. For larger areas
(for example, an entire wall), make sure you have a long
enough handle on your roller. Repeat this until the screen
area is completely painted.

Tips

Important: Always paint wet on
wet! By this we mean the

You should only change the direction of painting on the tape border.
That means not on the screen! (see illustration d). Remove the
roller from the wall only when it reaches the tape strip. Do not
remove the roller from the wall if it is still on the screen (this can
leave behind a visible mark). (See illustration e).

3. After you are finished keep the tape strips on the wall. Let the TopCoat dry for at least 120
minutes. During drying, place the roller in the roller pan and make sure that it is covered with
sufficient paint to prevent it from drying out.

4: Apply the second layer of TopCoat in the exact same
manner (see point 2). Important: Let this last layer of
TopCoat dry for a minimum of two hours and a maximum
of three hours. Carefully remove the tape strips. Make sure
that the tape does not touch the screen surface while you
are removing it!

Special Note: After two hours of drying time you can already project onto your new screen.

Make sure that you do not touch it, because you will leave behind visible fingerprints or damage

on the TopCoat!

5: Remove the rest of the TopCoat paint from the roller pan and clean it thoroughly until all of
theresidue is removed.

following: Once you start applying
the topcoat it is very important
that you continue until the layer
is completely finished. Do not stop
in between.

Tips

if you turn the projector on after
the paint has dried you can easily

see if the top layer (TopCoat)
has been smoothly applied.

4.3 Wait for screen to harden

It takes at least one week for the ABtUS coatings to sufficiently harden. During this week the
coatings will continue to improve in appearance. You will also notice that small irregularities
and stripes will disappear or become much less visible. The magnetic border (MagneBorder)
can only be attached to a completely dry and completely hardened top layer (TopCoat), so you
must wait one week before attaching the magnetic border (MagneBorder).

10

**Specification are subjected to changes without notice...for detail and updated information please visit www.abtussinagpore.com

11

User Operation Guide

STEP 5: APPLYING THE MAGNETIC BORDER

(MagneBorder)

Your week of waiting is rewarded. You can attach the MagneBorder as follows:

(If you have painted the entrire wall with the AB2123308 product: see instruction on page 13).

For the AB2123208 and AB2123308 (painting only a screen area):

1: Turn the projector on again according to the exact settings of a
week ago. If all goes well, your painted screen is still 5 cm (2)
larger than the illuminated area (if you have the AB2123208 product)
or exactly 7 cm / 2.8 (if you have the AB2123308 product) larger.

You should see the following: (See illustration)

2: Your roll of MagneBorder is 5.5 cm / 2.2 wide (if you have the
AB2123208 product) or 7.7 cm / 3 (if you have the AB2123308 product).
The roll of MagneBorder is about 10 meters / 432.8 ft. long.

Determine the length of the MagneBorder that you will need on the top and bottom of the screen:

- Measure the exact width of the
illuminated screen and add exactly 11
cm / 4.3 to that number (if you have
the AB2323208 product) or exactly

15.4 cm / 6 (if you have the AB2123308
product). This is the precise length that
you will need (See illustration).

- Cut the magnetic border at this
exact length (use a knife with a
metal triangle to cut the border at
an exact 90° angle

(See illustration).

Tips

It is much easier to hang the magnetic border straight with two people.

- Attach the magnetic border to
the correct place above and
below the illuminated area of
the screen

(See illustration).

Why is the outside edge of the magnetic border
1/1.4 cm (0.4/0.6) larger than my painted screen?

Because this gives you two important advantages:

1. You can attach the magnetic border very straight and exact against the illuminated screen, because
you can adjust the border a few millimeters to the left or right or up or down.

2. If you do this, the painted screen remains hidden under the magnetic border, because you have
about 0,5 / 0,7 cm (0.2 / 0.3) of extra room.

Continue with Step 6 (see page 14).

For painting the entire wall with the AB2123308 product:

Because this gives you two important advantages:

1. Turn the projector on again using the same settings as a week ago. If all goes well, you will see four
small holes in the corners of the illuminated screen. Now you know that a band of magnetic paint

is present around the illuminated screen and under the layer of paint.

2. Your roll of MagneBorder is 7.7cm / 3 wide. The roll of MagneBorder is 10 meters (32.8 ft.) long. Determine
the length of MagneBorder that you will need on the bottom and top of the screen:

Tips

It is much easier to hang the magnetic border straight
with two people.

- Measure the exact width
of the illuminated area of
the screen and add 15.4
cm / 6 to that number.
This is the exact length
that you will need.

(See illustration)

3: Determine the length of the MagneBorder that
you need for the sides of the screen:

- Measure the exact
length between the
outside edges of the
bottom and top
magnetic border. This
is the exact length that
you need.

(See illustration)

3: Determine the length of the
MagneBorder that you need for
the sides of the screen:

- Measured the exact length
between the outside edges of the
bottom and top magnetic border.
This is the exact length that you
need. (see illustration)

12

- Cut the magnetic border at
this exact length (use a knife
with a metal triangle to cut the
border at an exact 90° angle

(see illustration).

- Attach the magnetic border to
the correct place on the left and
right sides of the illuminated area
of the screen (see illustration).

- Cut the magnetic border
at exactly this length. (use
a knife with a metal
triangle to cut the border
at an exact 90° angle

(See illustration)

- Attach the magnetic
border to the correct place
above and below the
illuminated area of the
screen.

(See illustration)

**Specification are subjected to changes without notice...for detail and updated information please visit www.abtussinagpore.com

- Cut the magnetic
border at this exact
length use a knife with
a metal triangle to cut
the border at an exact
90° angle

(See illustration)

- Attach the magnetic
border to the correct
place on the left and
right sides of the
illuminated area of the
screen

(See illustration)

13

User Operation Guide

STEP 6: THE ENORMOUS FUN CAN BEGIN

Your screen is finished. Congratulations! You can now use your screen. But your screen will get even
better: The active brightness boosting ingredients in the top layer require at least six weeks of extra
drying time to produce their optimal reflective performance.

Are you satisfied with the end result? Do you have additional questions or comments? Please mail us.
Preferably with a picture of your ABtUS projection screen or home theater. Mail it to:

[e-mail]

We would like to thank you for your patronage and your trust in our product. We hope that you shall
enjoy your self-made ABtUS screen for many many years to come.

FINAL NOTES

- Maintenance:

The screen should not be cleaned for the first eight weeks. After that, you can clean the screen with a
soft, fuzz free cloth and lukewarm water. You can also add some mild liquid soap to the lukewarm water
if desired.

- Safety:

All ABtUS Coatings are completely water-based and contain no hazardous solvents or other hazardous
ingredients. The products do not have any special handling requirements. We do advise that ABtUS
screen paint Products be stored and kept out of reach of children.

The ABtUS MagneBorder also has no specific safety precautions. The product complies with the European
standard for children's toys (EN 71-3: 1994).

The complete safety specifications (MSDS sheets) can be downloaded at: www.abtussingapore.com

QUESTION LIST

Question list to determine the Contrast & Brightness of your screen

By adding ContrastBooster to the BaseCoat you can create exactly the right contrast for your
screen: Matt white Light grey Grey Extra grey (also called High Contrast).

By adding BrightnessBooster to the TopCoat you can create exactly the right brightness
(also called Gain) for your screen.

But how do you determine the correct contrast and brightness for your projector and projection
environment?

It is very easy: Just answer the following questions, add up the results, and you will know exactly
how much ContrastBooster and BrightnessBooster you need to add to create the perfect screen
for your specific situation.

- GUARANTEE TERMS AND CONDITIONS

1. ABtUS guarantees that if during the guarantee period of a product, faults arise due to defects in
manufacturing and/or materials, it will, at its discretion, repair or if necessary replace the product, free
of cost. A guarantee for normal wear and tear is hereby expressly excluded.

2. If the guarantee is invoked, the product should be sent to ABtUS together with the original purchase
document (invoice, sales slip or cash receipt). The purchase document should clearly show the name
of the supplier and the date of purchase.

3. ABtUS guarantee shall lapse in the following cases:

- If the product has not been drilled, installed and used in accordance with the Instructions for Use;

- If the product has been altered or repaired by someone a party other than ABtUS;

- If a fault arises due to external causes (outside the product) such as for example lightning, water
nuisance, fire, scuffing, exposure to extreme temperatures, weather conditions, solvents or acids,
wrong use or negligence;

- If the product is used for different equipment than is mentioned on or in the packing.

14

ALWAYS EXACTLY

THE RIGHT SCREEN SURFACE

- SOME EXAMPLES -

**Specification are subjected to changes without notice...for detail and updated information please visit www.abtussinagpore.com

15
