Abocom Systems WI5200 User Manual
802.11b/g/n
Wireless iNIC Module
User’s Guide
Federal Communication Commission
Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to
channels 1 through 11.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
The availability of some specific channels and/or operational frequency bands are
country dependent and are firmware programmed at the factory to match the intended
destination. The firmware setting is not accessible by the end user.
2
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20 cm is maintained between the antenna
and users. For laptop installations, the antenna must be installed to ensure that the
proper spacing is maintained in the event the users places the device in their lap
during use (i.e. positioning of antennas must be placed in the upper portion of the LCD
panel only to ensure 20 cm will be maintained if the user places the device in their lap
for use) and 2) The transmitter module may not be co-located with any other
transmitter or antenna.
As long as the 2 conditions above are met, further transmitter
required. However, the OEM integrator is still responsible for testing their end-product
for any additional compliance requirements required with this module installed (for
example, digital device emissions, PC peripheral requirements, etc.).
IMPORTANT NOTE: In the event that these conditions can not be met
certain laptop configurations or co-location with another transmitter), then the FCC
authorization is no longer considered valid and the FCC ID can not
final product. In these circumstances, the OEM integrator will be responsible for reevaluating the end product (including the transmitter) and obtaining a separate FCC
authorization.
End Product Labeling
This transmitter module is authorized only for use in devices where the antenna may
be installed such that 20 cm may be maintained between the antenna and users (for
example access points, routers, wireless ASDL modems, certain laptop configurations,
and similar equipment). The final end product must be labeled in a visible area with
the following: "Contains TX FCC ID: MQ4WI5200".
RF Exposure Manual Information That Must be Included
The users manual for end users must include the following information in a prominent
location "IMPORTANT NOTE: To comply with FCC RF exposure compliance
requirements, the antenna used for this transmitter must be installed to provide a
separation distance of at least 20 cm from all persons and must not be co-located or
operating in conjunction with any other antenna or transmitter."
Additional Information That Must be Provided to OEM Integrators
The end user should NOT be provided any instructions on how to remove or install the
device.
testing will not be
(for example
be used on the
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. Th ese limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is needed.
Consult the dealer or an experienced radio/TV technician for help.
3
Table of Content
CHAPTER 1: INTRODUCTION............................................................................................ 5
FEATURES ................................................................................................................................5
CHAPTER 2: ABOUT THE OPERATION MODES............................................................ 6
ACCESS POINT MODE............................................................................................................... 6
WDS MODE............................................................................................................................. 6
CLIENT MODE..........................................................................................................................7
CHAPTER 3: CONFIGURATION.........................................................................................8
LOGIN ......................................................................................................................................8
CONFIGURATION VIA WEB .....................................................................................................10
INTERNET SETTINGS...............................................................................................................10
WIRELESS SETTINGS ..............................................................................................................12
ADMINISTRATION...................................................................................................................23
CHAPTER 4: PC CONFIGURATION.................................................................................27
OVERVIEW .............................................................................................................................27
WINDOWS CLIENTS................................................................................................................27
MACINTOSH CLIENTS.............................................................................................................32
LINUX CLIENTS...................................................................................................................... 32
OTHER UNIX SYSTEMS........................................................................................................... 32
WIRELESS STATION CONFIGURATION ....................................................................................33
APPENDIX A: TROUBLESHOOTING.............................................................................. 34
OVERVIEW .............................................................................................................................34
GENERAL PROBLEMS .............................................................................................................34
INTERNET ACCESS..................................................................................................................34
WIRELESS ACCESS.................................................................................................................35
APPENDIX B: ABOUT WIRELESS LANS........................................................................36
BSS........................................................................................................................................36
CHANNELS .............................................................................................................................36
SECURITY............................................................................................................................... 36
WIRELESS LAN CONFIGURATION ..........................................................................................37
REGULATORY APPROVALS.....................................................................................................39
4
Chapter 1: Introduction
For easy configure and achieve stable wireless feature for household appliance and try to
create a new application for Wi-Fi module. By MII interface, user could embed our module in
projector, Set-Top BOX and Multimedia center etc.
Features
1. Support the IEEE 802.11b/g/n standard, high speed date rate up to 300Mbps.
2. High security with build-in Security: WEP 64/128 bits, WPA, WPA2, WPA Mixed,
802.1x Authenication.
3. Support AP, WDS and Client (Infrastructure) mode.
4. Advanced Quality of Service (QoS) - 802.11e, WMM.
5. Easy configuration for home user setup.
6. MAC filtering for wireless.
5
Chapter 2: About the Operation
Modes
This device provides operational applications with AP, WDS and Client modes, which are
mutually exclusive. If you want to change the settings in order to perform more advanced
configuration or even change the mode of operation, you can use the web-based utility
provided by the manufacturer as described in the following sections.
Access Point Mode
When acting as an access point, this device connects all the stations (PC/notebook with
wireless network adapter) to a wired network. All stations can have the Internet access if only
the Access Point has the Internet connection.
WDS Mode
The WDS (Wireless Distributed System) function lets this access point act as a wireless LAN
access point and repeater at the same time. Users can use this feature to build up a large
wireless network in a large space like airports, hotels and schools and so on. This feature is
also useful when users want to bridge networks between buildings where it is impossible to
deploy network cable connections between these buildings.
6
Client Mode
If set to Client (Infrastructure) mode, this device can work like a wireless station when it’s
connected to a computer so that the computer can send packets from wired end to wireless
interface.
7
Chapter 3: Configuration
Login
1. Start your computer. Connect an Ethernet cable between your computer and the device.
2. Make sure your wired station is set to the same subnet as the device, i.e. 198.245.80.123
3. Start your WEB browser. In the Address box, enter the following: http:// 198.245.80.211
4. Please enter the username “admin” and password “admin” for login.
The configuration menu is divided into three folders: Internet Settings, Wireless Settings,
and Administration. Click on the desired setup item to expand the folder in the main
navigation page. The setup pages covered in this utility are described below.
8
Common Connection Types
Cable Modems
Type Details ISP Data required
Dynamic IP
Address
Static (Fixed) IP
Address
DSL Modems
Type Details ISP Data required
Dynamic
IP Address
Static (Fixed)
IP Address
PPPoE You connect to the ISP only
PPTP Mainly used in Europe.
Your IP Address is
allocated automatically,
when you connect to you
ISP.
Your ISP allocates a
permanent IP Address to
you.
Your IP Address is allocated
automatically, when you
connect to you ISP.
Your ISP allocates a
permanent IP Address to you.
when required. The IP address
is usually allocated
automatically.
You connect to the ISP only
when required. The IP address
is usually allocated
automatically, but may be
Static (Fixed).
Usually, none.
However, some ISP's may
require you to use a particular
Hostname, Domain name, or
MAC (physical) address.
IP Address allocated to you.
Some ISP's may also require
you to use a particular
Hostname, Domain name, or
MAC (physical) address.
None.
IP Address allocated to you.
User name and password.
• PPTP Server IP Address.
• User name and password.
• IP Address allocated to
you, if Static (Fixed).
Other Modems (e.g. Broadband Wireless)
Type Details ISP Data required
Dynamic
IP Address
Static (Fixed)
IP Address
Your IP Address is allocated
automatically, when you
connect to you ISP.
Your ISP allocates a permanent
IP Address to you.
9
None.
IP Address allocated to you.
Configuration via Web
Operation Mode
Select an operation mode then click Apply to enable the mode you preferred or click Reset
button to discard current settings. Default operation mode is AP mode.
Operation Mode
When acting as an access point, this device connects all the stations
Access Point
Adapter Mode
(PC/notebook with wireless network adapter) to a wired network. All
stations can have the Internet access if only the Access Point has the
Internet connection.
If set to Client (Infrastructure) mode, this device can work like a wireless
station when it’s conn ected to a comput er so that the comp uter can send
packets from wired end to wireless interface.
Internet Settings
LAN (Local Area Network) Settings
10
LAN Interface Setup
IP Address
Subnet Mask
DHCP Type
DHCP Start IP
DHCP End IP
DHCP Subnet Mask
DHCP Lease Time
Apply
Refresh
DHCP Clients
Shows the IP address of the device.
Shows the subnet mask of the device.
Disable: Select to disable this device to distribute IP addresse s.
Server: Select to enable this device to distribute IP Addresses
(DHCP Server). And the following field will be activated for you
to enter the starting IP Address.
The starting address of this local IP network address pool.
The ending address of this local IP network address pool.
Shows the DHCP subnet mask.
Default settings are 86400 seconds.
Click to save and apply the current settings.
Click to get the latest information.
DHCP Clients
MAC Address
IP Address
Expires in
Shows the client MAC address information.
Shows the client IP address information.
Shows the expired time of the client.
11
Wireless Settings
Basic
Wireless Network
Radio On/Off
Network Mode
Click Radio OFF button to turn off the radio function.
Select 11 b/g mixed mode, 11b only, 11g only or 11 b/g/n
mixed mode from the pull-down menu. Default setting is 11
b/g/n mixed mode.
12
Loading...
