Quickstart Guide:
Candy Corn
www.ablenetinc.com
Screw Mounting Option
4
Overview
1
Activation indicator
light (yellow)
Top
Turn on or turn o
Changing The Battery
5
Activation Area
Base Cover
Screw Hole
Battery low
light (red)
Magnetic Area
How To Use
2
Insert 3.5 mm switch
1
jack into device
Turn power on
2
Hold hand or other part
3
of body within 10 mm of
the activation area to
activate your device
Changing The Battery Continued
6
Magnetic Mounting Option
3
Magnetic area
Stick onto any
magnetic surface
PN 980-00003 - Rev. A (05/2012)
Changing The Battery Continued
7
Hold top and turn
1
base clockwise
Insert screws into
2
holes and tighten
Turn top counter-
3
clockwise to
hide screws
Hold and turn
1
base clockwise
Insert end of paperclip
2
into hole and press down
to release internal tab.
Continue to turn clockwise.
Remove base
3
Remove old battery and
4
replace with new CR2032
battery
Align arrow on base with
5
arrow on inside of switch.
Push and turn base
clockwise.
Match the direction of
6
the top and the base
Turn the base
7
counter clock-wise
to secure
