EURONOX
Model Code: EUA100
Included Accessories
Icp
Dimensions
860
460
356
6020
406
500
175
Seal Strip
193
Optional Accessories
CBB371 DR006
DR006
Specifications
Description
Overall Sink Size
Bowl Dimensions
Drainer Length
Technic
Material
Installation
Fixings
Template
Min Cabinet Size
Waste Holes
Single bowl with one Drainer, inset
sink
860mm x 500mm x 193mm deep
356mm x 406mm x 175mm deep
460mm
Pressed
Stainless steel SUS304
Inset clips supplied
Supplied
425mm
1 x 90mm round
Compatible with waste disposal
Plumbing
90
50
Satin Silk
Waste Fittings
Overflow
1 x (90mm x 2”) basket waste
included
Available, conditions apply
Packaging
Carton Type
Gross Weight
Sleeve Size
Pack QTY
Abey are Australi a’s leaders in sinkware, designing and manufacturing to the world’s highest quality specifications as well as sourcing and bringing you Europe’s very best,
leading edge designs – practical, affordable, inspirational, stylish, timeless or cutting edge. When you buy an Abey stainless steel sink you receive the highest quality and a
25 year warranty. Abey and the manufacturer are continually seeking ways to improve the design specifications, aesthetic and production techniques of the products. As a
result, alterations to the specifications and dimensions of the pro ducts and designs occur continually.
www.abey.com.au
EPS protection & individual sleeve
3.5Kg
900mm x 540mm x 210mm
