MANUAL FOR FINGERPRINT GUN CABINET
WARNING
Tip Over Hazard:
A child or adult can tip the safe and be killed or seriously injured.
Serious injury may occur to children and adults if not secured before installation.
Children should not play with or around the safe at any time.
Dear valued customer:
Thank you for choosing our products!You've taken an important step.Organize and protect your most valuable assets.Each of
our series of products is professionally manufactured and designed to provide safety.Please take the time to read and familiarize
yourself with the following pages of proper procedures for handling gun cabinets.Thank you again for choosing our products.
COMPONENT DESCRIPTION PARTS LIST
FIRST UNPACKING
In case you forget or lose your security password, we provide you with a spare key.The first time you open the box, you can use
the backup key to open the safe deposit box. Please follow the following steps :
1. Remove bonnet by turning bonnet counterclockwise.The lock can be hung on the connecting cable.
2. Insert the key into the keyhole and turn it 1/4 of a turn counterclockwise (until stopped).Turn the handle
clockwise and the door will open.
INSTALL THE BATTERY
Open the lock cover counterclockwise and put in the 9V battery, at which time the lock is powered
on.Follow the instructions for setting.
SYSTEM INITIALIZATION
the first time you use the system, you must initialize the system once to complete the pairing.
After 5 seconds, the green light flashes; after 10 seconds, the buzzer gives a long sound and the fingerprint headlight flashes
once, indicating that all information is deleted, the fingerprint library is empty, and the password is restored to "1-2-3-4-5-6"
(either the fingerprint or the password can be opened directly).
SUBSCRIBER FINGERPRINT (The lock can register 200 fingerprints)
1. Open the door and press the setting button.
2. The buzzer will beep twice (short sound), the fingerprint light will be on, put your finger on the collecting head, the fingerprint
light will be on after flashing once, leave your finger, the fingerprint light will be on and the buzzer "di di di di" cycle will beep,
after placing the same finger again, the buzzer will beep for a long time and the fingerprint light will be off, indicating the
registration is successful;If not, please press your finger again until you succeed.
FINGERPRINT VERIFICATION UNLOCK
Put your finger into the fingerprint collection port, the fingerprint light flashes once and the buzzer makes a long sound to
indicate that the fingerprint verification is successful. If the buzzer sounds three times and the LED light flashes three times, it
means there is no such fingerprint.
PASSWORD MODIFICATION (Factory password: 123456)
Press "11*" key, the green light is on, enter "#" buzzer "di" of 123456, and the indicator light is always on. Enter the new
password "#" twice (1-12 bits) and the buzzer makes a long sound, indicating that the password has been changed successfully;If
the original password is wrong or the buzzer rings 3 times and the LED flashes 3 times after two different inputs;Retype.
PASSWORD AUTHENTICATION UNLOCK
Enter the correct password + "#" buzzer long sound and green light, lock successfully;If the password is wrong, the buzzer
Three sounds and three LED flashes.
OPEN DOOR SECURITY MODE SETTINGS
1. Enter the correct password or fingerprint. During the green light, enter the "2" + "#" key.
2. When the electronic lock is in safe mode, enter the correct password + fingerprint or the correct fingerprint + password. During
the green light, enter "1" + "#" key, then switch to the normal mode.
LOCK THE KEYBOARD
Enter the wrong password for 5 times in a row or enter the wrong fingerprint for 5 times, the system will lock for 5 minutes, and
the keyboard and fingerprint will not work;The red indicator flashes every 5 seconds during the lockout. If the system is powered
down and powered up again, the time will be reset.
ALARM FUNCTION SETTINGS
Press * in the static state, the vibration alarm will be turned on. The electronic lock will alarm when it encounters vibration, and
will stop automatically after one minute of alarm. The alarm can be cancelled by inputting the correct password or fingerprint
during the alarm process. Three incorrect password or fingerprint entries will also trigger an alarm.
SOUND SETTINGS (factory default audio)
Turn on sound: Press 22* in silent state, the beep beep and the green light flashes once at the same time, the setting is successful;
Turn off the sound: Press 22* in the normal state, the buzzer beep and the green light flashes once at the same time, the setting is
successful;
VOLTAGE PARAMETER
1. Rated voltage: 6-9V
2. Static power consumption: & LT;30uA
3. Under-pressure point: 7±0.3V
MOUNTING INSTRUCTIONS
The safe may be mounted to a wall or floor.
·Drill the appropriate size holes for the anchors you are using
·Carefully press the anchor into the holes at this time
· Mount the safe by running screws from inside of the safe
and securing to anchors; ensure the safe is mounted securely Floor Mounting
·Use proper drill tools depending on the type of floor you are
mounting the safe (wood, tile, or concrete)
· Measure the location of the pre-set drill holes; mark their exact position onto the floor
·Drill the appropriate size holes for the anchors you are using
·Carefully press the anchor into the holes at this time
·Mount the safe by running screws from inside of the safe and securing to anchors; ensure the safe is mounted securely
Mounting Holes
~ Actual model may vary
