ABB S202M-B16UC Technical data

PRODUCT-DETAILS

S202M-B16UC

Miniature Circuit Breaker - S200MUC - 2P - B ­16 ampere

General Information

Extended Product Type

Product ID

EAN

Catalog Description

ABB System pro M compact® product range with an MCB for DC and AC applications.

The S 200 M UC impresses with its performance range and the accordingly large

amount of approvals. Its high inbuilt short circuit breaking capacity across the

Long Description

entire model line, its flexible AC and DC application and its approval and compliance in

accordance with all major international and local standards make it truly unique.

All current System pro M compact® accessories can be combined easily with the new

model line. Whether warehousing or project engineering, planning, installing or

maintaining your equipment, the S 200 M UC is a simple and flexible solution.

The miniature circuit breaker S 200 M UC extends the established

Miniature Circuit Breaker - S200MUC - 2P - B - 16 ampere

S202M-B16UC

2CDS272061R0165

4013614432842



Technical

Standards

Poles

)

n

Rated Operational
Voltage

acc. to IEC 60898-1 400 V AC
acc. to IEC 60898-1 440 V DC
acc. to IEC 60898-2 400 V AC

IEC/EN 60898-2
IEC/EN 60947-2

2 Number of Poles

2 Number of Protected

B Tripping Characteristic

16 A Rated Current (I

S202M-B16UC

acc. to IEC 60898-2 440 V DC

acc. to IEC 60947-2 440 V AC

acc. to IEC 60947-2 440 V DC

Power Loss

(Ui)

Operational Voltage

Rated Frequency (f)

Rated Short-Circuit
Capacity (I

Rated Ultimate Short­Circuit Breaking
Capacity (I

Circuit Breaking
Capacity (I

Rated Impulse
Withstand Voltage (U
)

Indication

Remarks

Connecting Capacity

Driver

Mounting on DIN Rail

Connection

)

cn

)

cu

)

cs

imp

at Rated Operating Conditions per Pole 2.47 W

acc. to IEC/EN 60664-1 484 V Rated Insulation Voltage

Maximum (Incl. Tolerance) 440 V AC
Maximum (Incl. Tolerance) 500 V DC

Maximum 440 V AC
Maximum 500 V DC

Minimum 12 V AC
Minimum 12 V DC

(253 V AC) 10 kA
(400 V AC) 10 kA
(440 V DC) 10 kA

(220 V DC) 25 kA
(440 V AC) 10 kA
(440 V DC) 10 kA

(220 V DC) 20 kA Rated Service Short-

(6.2 kV @ sea level)

(5.0 kV @ 2000 m)

50 / 60 Hz, 1 min: 2 kV Dielectric Test Voltage

Insulation Group I, RAL 7035 Housing Material

Insulation group II, black, sealable Actuator Type

Insulation Group II, Black, Sealable Actuator Material

Red ON / Green OFF Contact Position

IP40 in enclosure with cover

Please note polarity of device

Screw Terminals Terminal Type

Failsafe Bi-directional Cylinder-lift Terminal Screw Terminal Type

Busbar 10 / 10 mm²

Flexible with Ferrule 0.75 ... 25 mm²

Flexible 0.75 ... 25 mm²

Rigid 0.75 ... 35 mm²

Stranded 0.75 ... 35 mm²

TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715

TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715

acc. to DIN 43880 1 Installation Size

Please Note Polarity of Device Power Supply

4.94 W

50 Hz
60 Hz

DC

3 Energy Limiting Class

III Overvoltage Category

2 Pollution Degree

4 kV

I / O Actuator Marking

IP20 Degree of Protection

20000 AC cycle Electrical Endurance

20000 cycle

2.8 N·m Tightening Torque

Pozidriv 2 Recommended Screw

Any Mounting Position

69 mm Built-In Depth (t2)

2

Environmental

Operation -25 ... +55 °C Ambient Air
