ABB CP-A range, CP-S range, CP-C range Accessories Catalog
2CDC 271 061 F0b04
Accessories for primary switch mode power supplies
CP-A for CP-S and CP-C range
Ordering details
Redundancy unit CP-A RU
Redundancy unit with 2 inputs / channels for decoupling of 2 CP-S or 2 CP-C power supplies
쐍
up to 20 A per input / channel and output up to 40 A
쐍
True redundancy by 100 % decoupling with 2 integrated diodes
쐍
4
CP-A RU
2CDC 271 002 F0b05
CP-A CM
Type
CP-A RU
Control module CP-A CM
pluggable onto redundancy unit CP-A RU
쐍
one relay output per monitored input / channel
쐍
threshold values adjustable (14-28 V)
쐍
indicates the presence of both input voltages (of the CP-A RU) via LEDs and energized output relays
쐍
Type
CP-A CM
Redundancy unit
Control module
Description
Description
Order code
1SVR 427 071 R0000
Order code
1SVR 427 075 R0000
Pack.
unit
pieces
Pack.
unit
pieces
Price
1 piece
1
Price
1 piece
1
Weight
1 piece
kg / lb
Weight
1 piece
kg / lb
2CDC 271 003 F0005
CP-A RU + CP-A CM
• Approvals ......................................168 • Technical data ...............................181 • Dimensional drawings ......................173
172
