User Manual for KT04
Kids Smart Watch
T
hank you very much for choosing our Children Color Screen watch . You could fully get
to know how to use the overall system and relevant device upon reading the booklet,
finding out its utility in function and simplicity in operation.
This device is mainly used in location and tracking, with the function of dialing and
answering, which is convenient to keep a close watch on children’s movements anytime
and anywhere.
Our company reserves the right to revise the content of this booklet without notice in
advance.
When you get the KT04, you need first download and install the “kid mate” APK in your
smart phone in order to enable each operation on the watch.
Website: www.abardeen.com
Due to product software will update constantly, the content is different from final product
operations. If any change, we’ll not do for further notice. For the latest version of the
operating instructions, please refer to the official website www.abardeen.com
Quick Guide
1. Install SIM Card
2. Button Descriptions
3. W a tch Screen
4. Charging
5.W eari ng Watch
6. Download APP, connect watch
7. Waking up watch;
8. Main Menu
9. Calling
10.Voice message
11.Colorful Icons
2
1.Install SIM Card
1) Buy suitable SIM Card
Buy GSM Nano SIM Card, Please make sure your sim card has the caller ID display function and
GPRS service.Our watch only support GSM SIM Card with 2G network , it can be compatible with 3G,
4G Sim card if they support 2G network at the same time.
2) Install SIM Card
① Before installing SIM Card, make sure this watch is power off;
② Please use Screwdriver to open this SIM Card case on the back of the watch ;
③ We are using standard Nano SIM card (SIM card for iPhone6S). Insert the card with the
mental side up into the Sim card case;
④ Cover the Sim card case, use the screwdriver to tighten the screws;
⑤ Start the watch , if it is no signal , please install Sim card again.
3
2. Button Descriptions:
① 1.1 Power On / Off button
Press button for 3 seconds to ③ boot, press button ③ for 8 seconds to turn off the watch;
② SOS Button ( button )④
In emergency, press SOS button ( button )④ for 5-7 seconds, the watch will call the first three
family number in turns , and send location by SMS automatically.
③ Calling Family number quickly
Under main menu, Press button for 3 seconds , call the family number 1. ① press button ② for 3
seconds , call the family number 2.
④ Switch button
Under standby screen, press button ① and button ④ to switch function ; under volume interface,
press button ① and button ④ to adjust volume .
⑤ Confirm button ( button ②)
In function interface, press button ② to enter the different functions; under contact list , press
button ② to record, release to send the voice.
Back Button
Click back button to back or hang up the calling.
Reset button
Press this button to restart the watch quickly
Microphone :Don’t cover it during calling
Speaker:Don’t cover it during calling
4
Watch Screen:
KT04 is color screen , touch operating smart kids watch.
:Monday
:Signal
: Internet
: Battery
5
:Time
: Back
Time, date will update automatically when the watch connect to server.
Charging:
Please use the original power adapter and cable to charge the watch
1, This watch is pin charging, tightening this pin and power adapter.
: W eari ng off sensor
6
: When watch is charging , this battery icon show charging .
W earin g Watch:
Please wearing this watch as photo shows:
7
About APP
1. APK Brief Introduction
★ Abardeen KT04 relationship with APP:
Before using KT04, you should download APP : Kids Mate . APP software is the core of
the watch, all functions are implemented on the APP
2. APP Download
★ Where to download the APP
You can search “ kid mate” from Apple store and Google play, then install it into your
smart mobile
(Note: You could operate on the following steps after the APK is downloaded successfully)
3. Connect watch with APP
Register and Login on APP, scan the QR code on the back of watch to connect this watch.
4. Add family number on APP
Add your mobile number as family number on APP.
Waking Up Watch
1.When watch under sleeping, click any button to wake up the watch .
2. Main interface slide to enter main menu
Slide like photo shows:
8
1) Slide left or right to enter function interface;
2) When watch in function interface , slide up or left to enter next function ;
3) When watch in function interface slide down or right to last function.
Add family number:
When add family number on APP, watch will add this number as contact number automatically
1. Click More- Family number, can add 60 family number in total
9
2. Input telephone number, then save, add it successfully.
3. Watch will add this number as contact number automatically
Calling
T ou ch calling : Touch the avatar to callin g
Calling quickly
10
Press button ① and button ② for 3 seconds to calling quickly
Button Calling
When watch is in contact interface, press button to calling
2, Answering calling :
T ou ch answ eri ng:
Smart
Smart Answering: : Shaking arms to answer the calling
11
Button answering:click any button except power on/off button to answering
Voice message
T ou ch to send ing the voi ce message:
1) Touch the avatar
2) Recording
3) Release it and sending
12
Button sending:
1) Press button ② for 3 seconds;
2) Recording;
3) Release it and sending
2. Answering Voice message
Touch answering: Click avatar to playing the voice message.
Button answering: Press button ①for 3 seconds, to playing the voice message
Colorful Icons
13
1. When in voice message on APP, select one icon, select sending
2. Sending it successfully, this icons will show on the watch screen .
Make friends via Bluetooth
1. Under function interface, enter to the white hand, switch to colorful hand;
2. Within 1M, one watch show white hand, another watch show colorful hand, then can make friends via
bluetooth.
14
Add this friend successfully
3. Add this friend successfully, you can change friend’s name on APP;
4. Press friends’ avatar shortly to call friend, press friends’ avatar long to send voice message.
Watch Parameters:
1. Specifications:
Watch Size 54mm*34mm*16mm( not including strap)
Screen Materials OLED Color screen, resolution:96*64
Waterproof Waterproof IP65
Standby Time 96 hours
Battery capacity 500MAH
2. Package:
Watch Device 1 pcs Power adapter 1 pcs
USB Cable 1 pcs Gift Card 1 pcs
Warranty Card 1 pcs Manual 1 pcs
Certification Card 1 pcs Screen Protector 1 pcs
Screwdriver 1 pcs Screw 2 pcs
15
4.Q&A
4.1. How long this watch can working with full charging?
A: Standby time is 2-3 days, need 2-3 hours to charge.
4.2.APP indicate watch is not online?
A: The watch has not connected to the network. Check watch SIM card is install
right or not , confirm this Sim card open GPRS function
4.3 Set up family number already, but the phone can’t call watch
A: Please check the watch Sim card opened Caller ID display function.
4.4. Your watch is anti-collision and waterproof?
A: The watch is waterproof IP 65, it is life waterproof, splash or rain is
ok , please do not wear the watch when you are taking shower or swimming .
FCC Statement
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions
(1)this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
FCCRegulatoryCompliance
Body worn operation
The device complies with RF specifications when used near your ear or at a
distance of 0cm from your body. Ensure that the device accessories, such as
a device case and device holster, are not composed of metal components.
Keep the device away from your body to meet the distance requirement.
Certification information (SAR)
This device is also designed to meet the requirements for exposure to radio
waves established by the Federal Communications Commission (USA). The
SAR limit adopted by the USA is 1.6 W/kg averaged over one gram of tissue.
The highest SAR value reported to the FCC for this device type complies with
this limit. SAR Max. Values:3.08 W/Kg (10g) for extremity; 0.40 W/Kg (1g) for
next tomouth
