Threat Analysis Reporter
®
QUICK START
GUIDE
Model: TAR
HL-005-004, SL-004-004, MSA-004-004
Release: 1.2.00 / Updated: 09.19.08
8e6 ThreaT analysis reporTer Quick sTarT Guide
© 2008 8e6 Technologies. All rights reserved.
This document may not, in whole or in part, be copied, photocopied, reproduced, translated, or reduced to any electronic medium or machine readable form without prior written consent from 8e6 Technologies.
Every effort has been made to ensure the accuracy of this document. However, 8e6 Technologies makes no war-
ranties with respect to this documentation and disclaims any implied warranties of merchantability and tness for a
particular purpose. 8e6 Technologies shall not be liable for any error or for incidental or consequential damages in
connection with the furnishing, performance, or use of this manual or the examples herein. The information in this
documentation is subject to change without notice.
The Threat Analysis Reporter products have been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the interference at his own expense.
Trademarks
Other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies and are the sole property of their respective manufacturers.
Part# TARul-QSG-080919
ii 8e6 ThreaT analysis reporTer Quick sTarT Guide
Contents
threat analysis reporter introduCtion ....................................................1
About this Document ....................................................................................................................2
Conventions Used in this Document ........................................................................................... 2
serviCe information .................................................................................. 3
preliminary setup proCedures ................................................................. 4
Unpack the Unit from the Carton .................................................................................................4
Select a Site for the Server ...........................................................................................................5
Rack Mount the Server ..................................................................................................................6
Check the Power Supply .............................................................................................................23
General Safety Information .........................................................................................................24
install the server ..................................................................................27
Step 1: Initial Setup Procedures ................................................................................................27
Step 1A: Quick Start Setup Procedures ....................................................................................28
Step 1B: LCD Panel Setup Procedures .....................................................................................44
Step 2: Wizard Setup Procedures ..............................................................................................50
ConClusion ............................................................................................. 59
led indiCators and Buttons ...................................................................60
SL and MSA Units ........................................................................................................................60
HL Unit ......................................................................................................................................... 61
HL and SL Units ........................................................................................................................... 63
regulatory speCifiCations and disClaimers .............................................64
Declaration of the Manufacturer or Importer ............................................................................64
appendix: optional ethernet tap installation ........................................ 67
Preliminary Setup Procedures ...................................................................................................67
Install the Ethernet Tap Unit .......................................................................................................68
index .......................................................................................................70
8e6 ThreaT analysis reporTer Quick sTarT Guide iii
iv 8e6 ThreaT analysis reporTer Quick sTarT Guide
threat analysis reporter introduCtion
Thank you for choosing to evaluate the 8e6 Technologies Threat Analysis Reporter. This
product addresses user-generated Web threats such as excessive use of bandwidth
and inappropriate Internet usage, and provides network administrators tools to monitor
such threats so management can enforce corporate Internet usage policies.
Working in conjunction with 8e6’s R3000 Enterprise Filter, the Threat Analysis Reporter
translates end user Internet activity from the R3000’s logs into dynamic graphical snap-
shots of network Internet trafc. Using remediation tools in the console, administrators
and management can then manage and control user-generated Web threats in real
time.
The TAR HL and SL server models include RAID technology for fault tolerance and high
performance.
8e6 ThreaT analysis reporTer Quick sTarT Guide 1
About this Document
This document is divided into the following sections:
Introduction - This section is comprised of an overview of the Threat Analysis Re-
•
porter product and how to use this document
Service Information - This section provides 8e6 Technologies contact information
•
Preliminary Setup Procedures - This section includes instructions on how to physi-
•
cally set up the Threat Analysis Reporter unit in your network environment
Install the Server - This section explains how to congure the Threat Analysis Re-
•
porter
Conclusion - This section indicates that the quick start steps have been completed
•
LED Indicators and Buttons - This section explains how to read LED indicators
•
and use LED buttons for troubleshooting the unit
Regulatory Specications and Disclaimers - This section cites safety and emis-
•
sions compliance information for the TAR models referenced in this document
Appendix: Optional Ethernet Tap Installation - This appendix explains how to
•
install the optional Ethernet Tap device on your network for bandwidth monitoring
Index - An alphabetized list of some topics included in this document
•
Conventions Used in this Document
The following icons are used throughout this document to call attention to important
information pertaining to handling, operation, and maintenance of the server; safety and
preservation of the equipment, and personal safety:
NOTE: The “note” icon is followed by additional information to be consid-
ered.
WARNING: The “warning” icon is followed by information alerting you to a
potential situation that may cause damage to property or equipment.
CAUTION: The “caution” icon is followed by information warning you that a
situation has the potential to cause bodily harm or death.
2 8e6 ThreaT analysis reporTer Quick sTarT Guide
serviCe information
The user should not attempt any maintenance or service on the unit beyond the procedures outlined in this document.
Any initial hardware setup problem that cannot be resolved at your internal organization should be referred to an 8e6 Technologies solutions engineer or technical support
representative.
8e6 Corporate Headquarters (USA)
Local : 714.282.6111
Domestic US : 1.888.786.7999
International : +1.714.282.6111
8e6 Taiwan
Taipei Local : 2397-0300
Domestic Taiwan : 02-2397-0300
International : 886-2-2397-0300
Procedures
When calling 8e6 Technologies regarding a problem, please provide the representative
the following information:
Your contact information.
•
Serial number or original order number.
•
Description of the problem.
•
Network environment in which the unit is used.
•
State of the unit before the problem occurred.
•
Frequency and repeatability of the problem.
•
Can the product continue to operate with this problem?
•
Can you identify anything that may have caused the problem?
•
8e6 ThreaT analysis reporTer Quick sTarT Guide 3
preliminary setup proCedures
Unpack the Unit from the Carton
Inspect the packaging container for evidence of mishandling during transit. If the packaging container is damaged, photograph it for reference.
Carefully unpack the unit from the carton and verify that all accessories are included.
Save all packing materials in the event that the unit needs to be returned to 8e6 Technologies.
The carton should contain the following items:
1 Threat Analysis Reporter unit
•
1 AC Power Cord, 2 AC Power Cords for HL servers
•
1 Serial Port Cable
•
1 CAT-5E Crossover Cable
•
Rack Mount Brackets (2)
•
1 End User License Agreement (EULA)
•
1 envelope containing a CD-ROM with a PDF of the Threat Analysis Reporter User
•
Guide. The latest version of the user guide can be obtained from our Web site at
http://www.8e6.com/docs/tar_ug.pdf.
NOTES: A coupler is included in the carton if a three-foot CAT-5E crossover
cable is packaged with your unit instead of a 14-foot CAT-5E crossover cable. For
HL and SL servers, 1 bezel to be installed on the front of the chassis also is included,
as well as 1 spare parts kit. For HL servers, this kit contains a hard drive and power
supply. For SL servers, this kit contains a hard drive.
Inspect the server and accessories for damage. If the contents appear damaged, le a
damage claim with the carrier immediately.
WARNING: To avoid danger of suffocation, do not leave plastic bags used for
packaging the server or any of its components in places where children or infants
may play with them.
4 8e6 ThreaT analysis reporTer Quick sTarT Guide
Select a Site for the Server
The server operates reliably within normal ofce environmental limits. Select a site that
meets the following criteria:
Clean and relatively free of excess dust.
•
Well-ventilated and away from sources of heat, with the ventilating openings on the
•
server kept free of obstructions.
Away from sources of vibration or physical shock.
•
Isolated from strong electromagnetic elds and noise caused by electrical devices
•
such as elevators, copy machines, air conditioners, large fans, large electric motors,
radio and TV transmitters, and high-frequency security devices.
Access space provided so the server power cord can be unplugged from the power
•
supply or the wall outlet—this is the only way to remove the AC power cord from the
server.
Clearance provided for cooling and airow: Approximately 30 inches (76.2 cm) in the
•
back and 25 inches (63.5 cm) in the front.
Located near a properly earthed, grounded, power outlet.
•
8e6 ThreaT analysis reporTer Quick sTarT Guide 5
Rack Mount the Server
Rack Setup Precautions
Warning:
Before rack mounting the server, the physical environment should be set up to safely accommodate the server. Be sure that:
The weight of all units in the rack is evenly distributed. Mounting of the equipment in
•
the rack should be such that a hazardous condition is not achieved due to uneven
mechanical loading.
The rack will not tip over when the server is mounted, even when the unit is fully
•
extended from the rack.
For a single rack installation, stabilizers are attached to the rack.
•
For multiple rack installations, racks are coupled together.
•
Reliable earthing of rack-mounted equipment is maintained at all times. Particular
•
attention should be given to supply connections other than direct connections to the
branch circuit (e.g. use of power strips).
A power cord will be long enough to t into the server when properly mounted in the
•
rack and will be able to supply power to the unit.
The connection of the server to the power supply will not overload any circuits. Con-
•
sideration should be given to the connection of the equipment to the supply circuit
and the effect that overloading of the circuits might have on overcurrent protection
and supply wiring. Appropriate consideration of equipment nameplate ratings should
be used when addressing this concern.
The server is only connected to a properly rated supply circuit. Reliable earthing
•
(grounding) of rack-mounted equipment should be maintained.
The air ow through the server’s fan or vents is not restricted. Installation of the
•
equipment in a rack should be such that the amount of air ow required for safe operation of the equipment is not compromised.
The maximum operating ambient temperature does not exceed 104°F (40°C). If
•
installed in a closed or multi-unit rack assembly, the operating ambient temperature
of the rack environment may be greater than room ambient. Therefore, consideration
should be given to installing the equipment in an environment compatible with the
maximum ambient temperature (Tma) specied by the manufacturer.
WARNING: Extend only one component at a time. Extending two or more
components simultaneously may cause the rack to become unstable.
6 8e6 ThreaT analysis reporTer Quick sTarT Guide
Rack Mount Instructions for HL Servers
Rack Setup Suggestions
Determine the placement of each component in the rack before you install the rails.
•
Install the heaviest server components on the bottom of the rack rst, and then work
•
up.
Identify the Sections of the Rack Rails
You should have received two rack rail assemblies with the 8e6 server unit. Each of
these assemblies consists of two sections: An inner xed chassis rail that secures to the
unit (A), and an outer xed rack rail that secures directly to the rack itself (B). Two pairs
of short brackets to be used on the front side of the outer rails are also included.
Install the Inner Rails
Both the left and right side inner rails have been pre-attached to the chassis. Proceed to
the next step.
Install the Outer Rails
Begin by measuring the distance from the front rail to the rear rail of the rack. Attach a
short bracket to the front side of the right outer rail and a long bracket to the rear side of
the right outer rail. Adjust both the short and long brackets to the proper distance so that
the rail can t snugly into the rack. Secure the short bracket to the front side of the outer
rail with two M4 screws and the long bracket to the rear side of the outer rail with three
M4 screws. Repeat these steps for the left outer rail.
8e6 ThreaT analysis reporTer Quick sTarT Guide 7
Locking Tabs: Both chassis rails have a locking tab, which serves two functions. The
rst is to lock the server into place when installed and pushed fully into the rack, which
is its normal position. Secondly, these tabs also lock the server in place when fully extended from the rack. This prevents the server from coming completely out of the rack
when you pull it out for servicing.
8 8e6 ThreaT analysis reporTer Quick sTarT Guide
Install the Server into the Rack
You should now have rails attached to both the chassis and the rack unit. The next step
is to install the server chassis into the rack. Do this by lining up the rear of the chassis
rails with the front of the rack rails. Slide the chassis rails into the rack rails, keeping the
pressure even on both sides (you may have to depress the locking tabs when inserting).
When the server has been pushed completely into the rack, you should hear the locking
tabs “click.”
8e6 ThreaT analysis reporTer Quick sTarT Guide 9
Install the Server into a Telco Rack
If you are installing the 8e6 server unit into a Telco type rack, use two L-shaped brackets
on either side of the chassis (four total). First, determine how far follow the server will extend out the front of the rack. A larger chassis should be positioned to balance the weight
between front and back. If a bezel is included on your server, remove it. Then attach
the two front brackets to each side of the chassis, then the two rear brackets positioned
with just enough space to accommodate the width of the telco rack. Finish by sliding the
chassis into the rack and tightening the brackets to the rack.
10 8e6 ThreaT analysis reporTer Quick sTarT Guide
Rack Mount Instructions for SL Servers
Rack Setup Suggestions
Determine the placement of each component in the rack before you install the rails.
•
Install the heaviest server components on the bottom of the rack rst, and then work
•
up.
Install the Inner Slides
1. Locate the right inner slide, (the slide that will be used on the right side of chassis
when facing the front panel of the chassis).
2. Align the four (4) square holes on the right inner slide against the hooks on the right
side of the chassis as show below on the left.
3. Securely attach the slide to the chassis with two M4 at head screws and repeat the
steps 1-3 to install the left inner slide to the left side of the chassis.
Install the Outer Slides
1. Measure the distance from the front rail of the rack to the rear rail of the rack.
2. Attach a short bracket to the rear side of the right outer slide, and a long bracket to
the front side of the right outer slide as shown above on the right.
3. Adjust the short and long brackets to the proper distance so that the chassis can
snugly t into the rack.
4. Secure the slides to the cabinet with screws.
5. Repeat steps 1-4 for the left outer slide.
8e6 ThreaT analysis reporTer Quick sTarT Guide 11
Install the Slide Assemblies to the Rack
1. After you have installed the short and long brackets to the outer slides, you are ready
to install the whole slide assemblies (outer slides with short and long brackets attached) to the rack. (See the previous page.)
2. Use M5 screws and washers to secure the slide assemblies into the rack as shown
below:
12 8e6 ThreaT analysis reporTer Quick sTarT Guide
Install the Chassis into the Rack
1. Push the inner slides, which are attached to the chassis, into the grooves of the outer
slide assemblies that are installed in the rack as shown below:
2. Push the chassis all the way to the back of the outer slide assemblies as shown below:
8e6 ThreaT analysis reporTer Quick sTarT Guide 13
Rack Mount Instructions for MSA Servers
Optional: Install the Chassis Rails
NOTE: If your chassis does not come with chassis rails, please follow the
procedure listed on the last page of this sub-section to install the unit directly into
the rack.
CAUTION: Please make sure that the chassis covers and chassis rails are
installed on the chassis before you install the chassis into the rack. To avoid
personal injury and property damage, please carefully follow all the safety steps
listed below:
Before installing the chassis rails:
• Close the chassis using the chassis cover.
• Unplug the AC power cord(s).
• Remove all external devices and connectors.
1. Included in the shipping package are a pair of rail assemblies. In each rail assembly,
locate the inner rail and the outer rail.
2. Press the locking tab to release the inner rail from its locking position and pull out the
inner rail from the rail assembly.
NOTE: The inner rails are to be attached to the chassis and the outer rails are
to be installed in the rack.
14 8e6 ThreaT analysis reporTer Quick sTarT Guide
3. Locate the three holes on each side of the chassis and locate the three correspond-
ing holes on each of the inner rail.
4. Attach an inner rail to each side of the chassis and secure the inner rail to the chas-
sis by inserting three Type G screws through the holes on each side of the chassis
and the inner rail. (See the diagram below for a description of the Type G screw.)
5. Repeat the above steps to install the other rail on the chassis.
8e6 ThreaT analysis reporTer Quick sTarT Guide 15
Optional: Install the Traditional UP Racks
After you have installed the inner rails on the chassis, you are ready to install the outer
rails of rail assemblies to the rack.
NOTE: The rails are designed to t in the racks with the depth of 28” to 33”.
• Determine the placement of each component in the rack before you install
the rails.
• Install the heaviest server components on the bottom of the rack rst, and
then work up.
1. In the package, locate a pair of front (short) and rear (long) brackets. Please note
that the brackets are marked with Up/Front Arrows (front) and Up/Rear arrows (rear).
2. Secure the front (short) bracket (marked with the Up/Front arrows) to the outer rail
with two Type G screws. (See the previous page for a description of the Type G
screw.)
3. Attach the rear (long) bracket to the other end of the outer rail and secure the rear
(long) bracket to the outer rail with a Type G screw as shown below.
4. Measure the depth of your rack and adjust the length of the rails accordingly.
5. Repeat the same steps to install the other outer rail on the chassis.
6. Secure both outer rail assemblies to the rack with Type H screws and Type I washers. (See the previous page for descriptions of Type H and Type I hardware components.)
16 8e6 ThreaT analysis reporTer Quick sTarT Guide
7. Slide the chassis into the rack as shown below.
NOTE: The chassis may not slide into the rack smoothly or easily when installed
the rst time. Some adjustment to the slide assemblies might be needed for easy
installation.
8. You will need to release the safety taps on both sides of the chassis in order to completely remove the chassis out of the rack.
8e6 ThreaT analysis reporTer Quick sTarT Guide 17
Optional: Install the Open Racks
After you have installed the inner rails on the chassis, you are ready to install the outer
rails of rail assemblies to the rack.
NOTE: The rails are designed to t in the racks with the depth of 28” to 33”.
• Determine the placement of each component in the rack before you install the
rails.
• Install the heaviest server components on the bottom of the rack rst, and
then work up.
1. In the package, locate a pair of front (short) and rear (long) brackets. Please note
that the brackets are marked with Up/Front Arrows (front) and Up/Rear arrows (rear).
2. Secure the front (short) bracket (marked with the Up/Front arrows) to the outer rail
with two Type G screws as shown below.
18 8e6 ThreaT analysis reporTer Quick sTarT Guide
3. Attach the front (short) bracket to the front end of the rack, and secure it to the rack
with two Type H screws and Type I washers as shown below. (See the previous page
for descriptions of Type H and Type I hardware components.)
4. Attach the rear (long) bracket to the rear end of the rack, and secure it to the rack
with two Type H screws and Type I washers as shown below. Repeat the same steps
to install the other outer rail to the other side of rack.
8e6 ThreaT analysis reporTer Quick sTarT Guide 19
Loading...
