® R3000 | Internet Filter

USER

GUIDE

for Authentication

Model: R3000

Release 2.1.10 • Manual Version 1.01

ii 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

R3000 INTERNET FILTER A

UTHENTICATION USER GUIDE

Version 1.01, published September 2008 To be used with R3000 User Guide version 1.01 for software release 2.1.10

Printed in the United States of America

This document may not, in whole or in part, be copied, photocopied, reproduced, translated, or reduced to any electronic medium or machine readable form without prior written consent from 8e6 Technologies.

Every effort has been made to ensure the accuracy of this document. However, 8e6 Technologies makes no warranties with respect to this documentation and disclaims any implied warranties of merchantability and fitness for a particular purpose. 8e6 Technologies shall not be liable for any error or for incidental or consequential damages in connection with the furnishing, performance, or use of this manual or the examples herein. Due to future enhancements and modifications of this product, the information described in this documentation is subject to change without notice.

The latest version of this document can be obtained from http://www.8e6.com/docs/r3000_auth2_ug.pdf.

Trademarks

Other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies and are the sole property of their respective manufacturers.

Part# R3.2.1_AUG_v1.01-0809

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE iii

iv 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

HAPTER

About this User Guide ................................................................1

How to Use this User Guide ....................................................... 2

Filtering Elements ....................................................................... 8

1: I

Conventions ...................................................................................... 2

Terminology ...................................................................................... 3

Group Types ..................................................................................... 8

Global Group .............................................................................. 8

IP Groups . .................................................................................. 9

NT Domain Groups ................................................................... 10

LDAP Domain Groups . ............................................................. 11

Filtering Profile Types ..................................................................... 12

Static Filtering Profiles . ............................................................. 14

Master IP Group Filtering Profile......................................... 14

IP Sub-Group Filtering Profile ............................................. 14

Individual IP Member Filtering Profile ................................. 14

Active Filtering Profiles . ............................................................ 15

Global Filtering Profile......................................................... 15

NT/LDAP Group Filtering Profile ......................................... 15

NT/LDAP Member Filtering Profile...................................... 15

LDAP Container Filtering Profile ......................................... 16

Override Account Profile ..................................................... 16

Time Profile ......................................................................... 16

Lock Profile ......................................................................... 16

Filtering Profile Components ........................................................... 17

Library Categories . ................................................................... 18

8e6 Supplied Categories..................................................... 18

Custom Categories ............................................................. 18

Service Ports . ........................................................................... 19

Rules ........................................................................................ 19

Minimum Filtering Level ............................................................ 19

Filter Settings ............................................................................ 20

Filtering Rules ................................................................................. 21

NTRODUCTION

.............................................. 1

Authentication Solutions ..........................................................24

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE V

CONTENTS

R3000 Authentication Protocols ...................................................... 24

R3000 Authentication Tiers and Options ........................................ 24

R3000 authentication tiers ........................................................ 24

R3000 authentication options . .................................................. 25

Authentication Solution Compatibility .............................................. 26

Authentication System Deployment Options ................................... 27

Ports for Authentication System Access ......................................... 28

Configuring the R3000 for Authentication ....................................... 29

Configuration procedures ......................................................... 29

System section.................................................................... 29

Group section...................................................................... 32

HAPTER

2: N

ETWORK SETUP

........................................ 33

Environment Requirements .....................................................33

Workstation Requirements .............................................................. 33

Administrator ............................................................................ 33

End User ................................................................................... 34

Network Requirements .................................................................... 34

Set up the Network for Authentication ....................................35

Specify the operation mode ............................................................ 36

Specify the subnet mask, IP address(es) ........................................ 38

Invisible mode ........................................................................... 38

Router or firewall mode . ........................................................... 39

Enable authentication, specify criteria ............................................. 40

Net use based authentication ................................................... 42

Web-based authentication . ....................................................... 43

Enter network settings for authentication ........................................ 46

Create an SSL certificate ................................................................ 48

Create, Download a Self-Signed Certificate ............................. 49

Create, Upload a Third Party Certificate ................................... 50

Create a Third Party Certificate........................................... 50

Upload a Third Party Certificate ......................................... 52

Download a Third Party Certificate .................................... 53

View log results ............................................................................... 54

Specify block page settings ............................................................. 57

Block Page Authentication ........................................................ 58

Block page ......................................................................... 59

User/Machine frame ..................................................... 60

Standard Links.............................................................. 60

vi 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

Optional Links............................................................... 61

Options page ...................................................................... 62

Option 1 ........................................................................ 63

Option 2 ........................................................................ 64

Option 3 ........................................................................ 65

Common Customization ........................................................... 66

Enable, disable features ..................................................... 67

Authentication Form Customization .......................................... 69

Preview sample Authentication Request Form ..................71

Block Page Customization ........................................................ 73

Preview sample block page ............................................... 75

Set up Group Administrator Accounts ...................................77

Add Sub Admins to manage groups, users ..................................... 77

Add a group administrator account ........................................... 78

Update the group administrator’s password ............................. 78

Delete a group administrator account ....................................... 79

HAPTER

3: NT A

UTHENTICATION SETUP

........................ 80

Join the NT Domain ..................................................................80

CONTENTS

Create an NT Domain ................................................................82

Add an NT domain .......................................................................... 82

Refresh the NT branch .................................................................... 83

View or modify NT domain details ................................................... 84

Domain Settings ....................................................................... 84

Default Rule .............................................................................. 86

Delete an NT domain ...................................................................... 87

Set up NT Domain Groups, Members ......................................88

Add NT groups, members to the tree .............................................. 88

Specify a group’s filtering profile priority ......................................... 90

Manually add a user’s name to the tree .......................................... 92

Manually add a group’s name to the tree ........................................ 93

Upload a file of filtering profiles to the tree ...................................... 94

HAPTER

4: LDAP A

UTHENTICATION SETUP

................... 97

Create an LDAP Domain ...........................................................97

Add the LDAP domain ..................................................................... 97

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE vii

CONTENTS

Refresh the LDAP branch ............................................................... 98

View, modify, enter LDAP domain details ....................................... 99

LDAP Server Type .................................................................. 100

Group Objects ........................................................................ 101

User Objects ........................................................................... 103

Address Info ........................................................................... 104

Account Info ............................................................................ 107

SSL Settings ........................................................................... 109

Alias List ................................................................................. 111

Default Rule ............................................................................ 113

LDAP Backup Server Configuration ................................. 115

Configure a backup server.......................................... 115

Modify a backup server’s configuration ...................... 120

Delete a backup server’s configuration....................... 120

Delete a domain ............................................................................ 121

Set up LDAP Domain Groups, Members ...............................122

Add LDAP groups, users to the tree ............................................. 122

Perform a basic search ........................................................... 123

Options for search results ....................................................... 124

Apply a filtering rule to a profile .............................................. 124

Delete a rule ........................................................................... 125

Specify a group’s filtering profile priority ....................................... 126

Manually add a user’s name to the tree ........................................ 127

Manually add a group’s name to the tree ...................................... 128

Upload a file of filtering profiles to the tree .................................... 129

HAPTER

5: A

SSIGN/SET UP GROUPS

, M

EMBERS

.......... 132

Assign Sub Admin to NT/LDAP Entity ..................................132

Create and Maintain Filtering Profiles ...................................135

Add a group member to the tree list .............................................. 136

Add or maintain an entity’s profile ................................................. 137

Category Profile ...................................................................... 138

Redirect URL . ......................................................................... 141

Filter Options . ......................................................................... 142

Add an Exception URL to the profile ............................................. 143

URL entries ............................................................................. 144

Block URL frame . ................................................................... 145

ByPass URL frame ................................................................. 145

viii 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

Apply settings ......................................................................... 145

Create a Time Profile for the entity ............................................... 146

Add a Time Profile .................................................................. 146

Remove an entity’s profile from the tree ....................................... 151

HAPTER

6: A

UTHENTICATION DEPLOYMENT

................. 152

Test Authentication Settings .................................................152

Test Web-based authentication settings ....................................... 154

Step 1: Create an IP Group, “test” .......................................... 154

Step 2: Create a Sub-Group, “workstation” . ........................... 155

Step 3: Set up “test” with a 32-bit net mask ............................ 156

Step 4: Give “workstation” a 32-bit net mask .......................... 157

Step 5: Block everything for the Sub-Group . .......................... 158

Step 6: Use Authentication Request Page for redirect URL ... 159

Step 7: Disable filter options . .................................................. 160

Step 8: Attempt to access Web content . ................................ 161

Test net use based authentication settings ................................... 163

Activate Authentication on the Network ............................... 164

Activate Web-based authentication for an IP Group .....................165

Step 1: Create a new IP Group, “webauth” ............................ 165

Step 2: Set “webauth” to cover users in range . ...................... 166

Step 3: Create an IP Sub-Group . ........................................... 167

Step 4: Block everything for the Sub-Group . .......................... 169

Step 5: Use Authentication Request Page for redirect URL ... 170

Step 6: Disable filter options ................................................... 171

Step 7: Set Global Group to filter unknown traffic . ................. 172

Activate Web-based authentication for the Global Group .............177

Step 1: Exclude filtering critical equipment ............................. 177

Step 1A: Block Web access, logging via Range to Detect . .... 178

Range to Detect Settings .................................................. 178

Range to Detect Setup Wizard ......................................... 180

Step 1B: Block Web access via IP Sub-Group profile . ...........186

Step 2: Modify the Global Group Profile . ................................ 189

Activate NT authentication ............................................................ 193

Step 1: Modify the 3-try login script ........................................ 193

Step 2: Modify the Global Group Profile ................................. 194

CONTENTS

HAPTER

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE ix

7: T

ECHNICAL SUPPORT

................................ 196

CONTENTS

Hours ........................................................................................196

Contact Information ................................................................ 196

Domestic (United States) .............................................................. 196

International .................................................................................. 196

E-Mail ............................................................................................ 196

Office Locations and Phone Numbers .......................................... 197

8e6 Corporate Headquarters (USA) ....................................... 197

8e6 Taiwan ............................................................................. 197

Support Procedures ................................................................198

PPENDIX

A: A

UTHENTICATION OPERATIONS

................ 199

Authentication Tier Selections ..............................................199

Tier 1: Net use based authentication ............................................ 199

Tier 2, Tier 3: Web-based authentication ...................................... 200

Tier 1: Single Sign-On Authentication ..................................201

Net use based authentication process .......................................... 201

Re-authentication process . ..................................................... 203

Tier 1 authentication methods ....................................................... 203

SMB protocol .......................................................................... 203

SMB Signing ..................................................................... 203

LDAP protocol ........................................................................ 204

Name resolution methods ............................................................. 205

Configuring the authentication server ........................................... 206

Enter net use syntax in the login script ............................. 206

View login script on the server console .................................. 207

Block page authentication login scripts ............................. 207

LDAP server setup rules ............................................................... 208

Tier 2: Time-based, Web Authentication ...............................209

Tier 2 implementation in an environment ...................................... 210

Tier 2 Script . ........................................................................... 211

Tier 1 and Tier 2 Script . .......................................................... 212

Tier 3: Session-based, Web Authentication .........................214

8e6 Authenticator ....................................................................215

x 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

Environment requirements ............................................................ 215

Minimum system requirements ............................................... 215

Recommended system requirements ..................................... 216

Workstation requirements ............................................................. 216

Work flow in a Windows environment ........................................... 217

8e6 Authenticator configuration priority . ................................. 218

8e6 Authenticator configuration syntax . ................................. 219

Sample command line parameters ................................... 219

Sample configuration file ............................................ 219

Sample R3000 configuration update packet ‘PCFG’ ..219

Table of parameters ............................................................... 220

Novell eDirectory Agent .........................................................223

Environment requirements ............................................................ 223

Novell eDirectory servers ........................................................ 223

Client workstations . ................................................................ 224

Novell clients .......................................................................... 224

Novell eDirectory setup ................................................................. 224

R3000 setup and event logs ......................................................... 225

Active Directory Agent ...........................................................226

Product feature overview .............................................................. 226

Windows server requirements . ............................................... 227

Work flow in a Windows environment ..................................... 227

Set up AD Agent ........................................................................... 228

Step 1: AD Agent settings on the R3000 ................................ 228

Step 2: Configure the domain, service account ...................... 230

Step 3: AD Agent installation on Windows server .................. 231

Step 3A: Download DCAgent.msi ..................................... 231

Step 3B: Run AD Agent installation setup......................... 231

Step 3C: Run AD Agent configuration wizard ...................234

Use the Active Directory Agent console ........................................ 239

Activity tab .............................................................................. 239

Sessions tab . .......................................................................... 242

Session table spreadsheet................................................ 244

Session Properties window .............................................. 245

Workstation Interactive Probe window .............................. 246

Active Directory Agent Configuration window ......................... 248

Service page .................................................................... 250

Appliance page ................................................................. 251

Agent hosts page ............................................................. 252

CONTENTS

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE xi

CONTENTS

Add a satellite ............................................................. 253

Remove a satellite ...................................................... 253

Configure a satellite .................................................... 254

Check the status of a satellite..................................... 256

Options page .................................................................... 258

Notifications page ............................................................. 260

PPENDIX

SMB Signing Compatibility ....................................................262

Disable SMB Signing in Windows 2003 ................................263

PPENDIX

Export an Active Directory SSL Certificate ..........................268

Export a Novell SSL Certficate ..............................................276

B: D

C: O

Verify certificate authority has been installed ................................ 268

Locate Certificates folder .............................................................. 269

Export the master certificate for the domain ................................. 272

ISABLE

BTAIN

SMB S

, E

XPORT AN

IGNING REQUIREMENTS

SSL C

ERTIFICATE

.... 268

... 262

Obtain a Sun ONE SSL Certificate .........................................278

PPENDIX

OpenLDAP Server Scenario ...................................................279

PPENDIX

Username Formats ..................................................................281

Rule Criteria .............................................................................281

File Format: Rules and Examples ..........................................284

xii 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

D: LDAP S

Not all users returned in User/Group Browser ..............................279

E: U

NT User List Format and Rules ..................................................... 285

NT Group List Format and Rules .................................................. 286

NT Quota Format and Rules ......................................................... 287

LDAP User List Format and Rules ................................................ 288

SER/GROUP FILE FORMAT AND RULES

ERVER CUSTOMIZATIONS

............. 279

... 280

LDAP Group List Format and Rules .............................................. 289

LDAP Quota Format and Rules .................................................... 290

PPENDIX

Yahoo! Toolbar Pop-up Blocker ............................................292

Google Toolbar Pop-up Blocker ............................................ 294

AdwareSafe Pop-up Blocker .................................................. 295

Mozilla Firefox Pop-up Blocker ..............................................296

Windows XP SP2 Pop-up Blocker .........................................297

F: O

If pop-up blocking is enabled ........................................................ 292

Add override account to the white list ........................................... 292

If pop-up blocking is enabled ........................................................ 294

Add override account to the white list ........................................... 294

If pop-up blocking is enabled ........................................................ 295

Temporarily disable pop-up blocking ............................................ 295

Add override account to the white list ........................................... 296

Set up pop-up blocking ................................................................. 297

Use the Internet Options dialog box ....................................... 297

Use the IE toolbar . .................................................................. 298

Temporarily disable pop-up blocking ............................................ 298

Add override account to the white list ........................................... 299

Use the IE toolbar ................................................................... 299

Use the Information Bar .......................................................... 300

VERRIDE POP-UP BLOCKERS

Set up the Information Bar ................................................ 300

Access your override account ........................................... 300

.................. 291

CONTENTS

PPENDIX

Definitions ................................................................................302

NDEX

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE xiii

G: G

LOSSARY

.............................................. 302

........................................................................... 309

CONTENTS

xiv 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 1: INTRODUCTION ABOUT THIS USER GUIDE

CHAPTER 1: INTRODUCTION

The R3000 Authentication User Guide contains information

about setting up authentication on the network.

About this User Guide

This user guide addresses the network administrator desig-

nated to configure and manage the R3000 server on the

network.

Chapter 1 provides information on how to use this user

guide, and also includes an overview of filtering compo-

nents and authentication solutions.

Chapters 2, 3, and 4 describe the R3000 Administrator

console entries that must be made in order to prepare the

network for using authentication for NT and/or LDAP

domains.

NOTE: Refer to the R3000 Quick Start Guide for information on

installing the unit on the network. This document also provides

information on how to access the R3000 console to perform the

initial installation setup defined in Chapter 2: Network Setup.

After all settings have been made, authentication is ready to

be used on the network. Chapter 5 explains how to assign

groups and members for management by Sub Admin group

administrators, and how group administrators create and

maintain filtering profiles for entities in their assignment.

Chapter 6 outlines the step you need to take to test and to

activate your settings before deploying authentication on

the network.

Chapter 7 provides support information. Appendices at the

end of this user guide feature instructions on authentication

operations; steps to modify the SMB protocol to disable

SMB Signing requirements; information on how to obtain or

export an SSL certificate and upload it to the R3000; notes

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 1

CHAPTER 1: INTRODUCTION HOW TO USE THIS USER GUIDE

on customizations to make on specified LDAP servers;

filtering profile file components and setup; tips on how to

override pop-up windows with pop-up blocker software

installed; a glossary on authentication terms, and an index.

How to Use this User Guide

Conventions

The following icons are used throughout this user guide:

NOTE: The “note” icon is followed by italicized text providing

additional information about the current subject.

TIP: The “tip” icon is followed by italicized text giving you hints on

how to execute a task more efficiently.

WARNING: The “warning” icon is followed by italicized text

cautioning you about making entries in the application, executing

certain processes or procedures, or the outcome of specified

actions.

2 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

Terminology

The following terms are used throughout this user guide.

Sample images (not to scale) are included for each item.

• alert box - a message box that opens in response to an entry you made in a dialog box, window, or screen. This box often contains a button (usually labeled “OK”) for you to click in order to confirm or execute a command.

• button - an object in a dialog box, window, or screen that can be clicked with your mouse to execute a command.

• checkbox - a small square in a dialog box, window, or screen used for indicating whether or not you wish to select an option. This object allows you to toggle between two choices. By clicking in this box, a check mark or an “X” is placed, indicating that you selected the option. When this box is not checked, the option is not selected.

CHAPTER 1: INTRODUCTION HOW TO USE THIS USER GUIDE

• dialog box - a box that opens in response to a command made in a window or screen, and requires your input. You must choose an option by clicking a button (such as “Yes” or “No”, or “Next” or “Cancel”) to execute your command. As dictated by this box, you also might need to make one or more entries or selections prior to clicking a button.

• field - an area in a dialog box, window, or screen that either accommodates your data

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 3

CHAPTER 1: INTRODUCTION HOW TO USE THIS USER GUIDE

entry, or displays pertinent information. A text box is a type of field.

• frame - a boxed-in area in a dialog box, window, or screen that includes a group of objects such as fields, text boxes, list boxes, buttons, radio buttons, checkboxes, and/or tables. Objects within a frame belong to a specific function or group. A frame often is labeled to indicate its function or purpose.

• grid - an area in a frame that displays rows and columns of data, as a result of various processes. This data can be reorganized in the R3000 console, by changing the order of the columns.

• list box - an area in a dialog box, window, or screen that accommodates and/or displays entries of items that can be added or removed.

• navigation panel - the panel that displays at the left of a screen. This panel can contain links that can be clicked to open windows or dialog boxes at the right of the screen. One or more tree lists also can display in this panel. When an item in the tree list is doubleclicked, the tree list opens to reveal items that can be selected.

4 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 1: INTRODUCTION HOW TO USE THIS USER GUIDE

• pop-up box or pop-up window - a box or window

that opens after you click a button in a dialog box, window, or screen. This box or window may display information, or may require you to make one or more entries. Unlike a dialog box, you do not need to choose between options.

• pull-down menu - a field in a dialog box, window, or screen that contains a down-arrow to the right. When you click the arrow, a menu of items displays from which you make a selection.

• radio button - a small, circular object in a dialog box, window, or screen used for selecting an option. This object allows you to toggle between two choices. By clicking a radio button, a dot is placed in the circle, indicating that you selected the option. When the circle is empty, the option is not selected.

• screen - a main object of an application that displays across your monitor. A screen can contain panels, windows, frames, fields, tables, text boxes, list boxes, icons, buttons, and radio buttons.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 5

CHAPTER 1: INTRODUCTION HOW TO USE THIS USER GUIDE

• sub-topic - a subset of a main topic that displays as a menu item for the topic. The menu of subtopics opens when a pertinent topic link in the left panel—the navigation panel—of a screen is clicked. If a sub-topic is selected, the window for that sub-topic displays in the right panel of the screen, or a pop-up window or an alert box opens, as appropriate.

• text box - an area in a dialog box, window, or screen that accommodates your data entry. A text box is a type of field. (See “field”.)

• topic - a topic displays as a link in the left panel—the navigation panel—of a screen. By clicking the link for a topic, the window for that topic displays in the right panel of the screen, or a menu of sub-topics opens.

6 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 1: INTRODUCTION HOW TO USE THIS USER GUIDE

• tree - a tree displays in the navigation panel of a screen, and is comprised of a hierarchical list of items. An entity associated with a branch of the tree is preceded by a plus (+) sign when the branch is collapsed. By double-clicking the item, a minus (-) sign replaces the plus sign, and any entity within that branch of the tree displays. An item in the tree is selected by clicking it.

• window - a window displays on a screen, and can contain frames, fields, text boxes, list boxes, buttons, checkboxes, and radio buttons. A window for a topic or sub-topic displays in the right panel of the screen. Other types of windows include pop-up windows, login windows, or ones from the system such as the Save As or Choose file windows.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 7

CHAPTER 1: INTRODUCTION FILTERING ELEMENTS

Filtering Elements

Filtering operations include the following elements: groups, filtering profiles and their components, and rules for filtering.

Group Types

In the Group section of the Administrator console, group types are structured in a tree format in the navigation panel. There are four group types in the tree list:

• Global Group

• IP groups

• NT domain groups

• LDAP domain groups

NOTES: If authentication is enabled, the global administrator— who has all rights and permissions on the R3000 server—will see all branches of the tree: Global Group, IP, NT, and LDAP. If authentication is disabled, only the Global Group and IP branches will be seen.

A group administrator will only see entities assigned to him/her by the global administrator.

Global Group

The first group that must be set up is the global group,

represented in the tree structure by the global icon . The filtering profile created for the global group represents the default profile to be used by all groups that do not have a filtering profile, and all users who do not belong to a group.

8 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 1: INTRODUCTION FILTERING ELEMENTS

IP Groups

The IP group type is represented in the tree by the IP icon

. A master IP group is comprised of sub-group members

and/or individual IP members .

The global administrator adds master IP groups, adds and maintains override accounts at the global level, and establishes and maintains the minimum filtering level.

The group administrator of a master IP group adds subgroup and individual IP members, override account and time profiles, and maintains filtering profiles of all members in the master IP group.

Fig. 1-1 IP diagram with a sample master IP group and its members

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 9

CHAPTER 1: INTRODUCTION FILTERING ELEMENTS

NT Domain Groups

An NT domain on a network server is comprised of Windows NT groups and their associated members (users), derived from profiles on the network’s domain controller.

The NT group type is represented in the tree by the NT icon

. This branch will only display if authentication is

enabled. Using the tree menu, the global administrator adds

and maintains NT domains , and assigns designated group administrators (Sub Admins) access to entities (nodes) within that domain.

The group administrator creates and maintains filtering

profiles for groups and/or users assigned to him/ her.

If users belong to more than one group, the global administrator sets the priority for group filtering.

Fig. 1-2 NT domain diagram, with sample groups and members

10 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 1: INTRODUCTION FILTERING ELEMENTS

LDAP Domain Groups

An LDAP (Lightweight Directory Access Protocol) domain on a network server is comprised of LDAP groups and their associated members (users), derived from profiles on the network’s authentication server.

The LDAP group type is represented in the tree by the

LDAP icon . This branch will only display if authentication is enabled. Using the tree menu, the global adminis-

trator adds and maintains LDAP domains , and assigns designated group administrators (Sub Admins) access to specific entities (nodes) within that domain. The group administrator creates and maintains filtering profiles for entities assigned to him/her. For Active Directory or “Other” server types, these entities include primary or static

groups , users , or containers . For Novell eDirectory, SunOne, Sun IPlanet, or Netscape Directory server

types, these entities also include dynamic groups . If users belong to more than one group, the global administrator sets the priority for group filtering.

Fig. 1-3 LDAP domain diagram, with sample groups and members

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 11

CHAPTER 1: INTRODUCTION FILTERING ELEMENTS

Filtering Profile Types

A filtering profile is used by all users who are set up to be filtered on the network. This profile consists of rules that dictate whether a user has access to a specified Web site or service on the Internet.

The following types of filtering profiles can be created, based on the set up in the tree menu of the Group section of the console:

Global Group

• global filtering profile - the default filtering profile positioned at the base of the hierarchical tree structure, used by end users who do not belong to a group.

IP group (Master Group)

• master group filtering profile - used by end users who belong to the master group.

• master time profile - used by master group users at a specified time.

IP group member

• sub-group filtering profile - used by a sub-group member.

• individual filtering profile - used by an individual IP group member.

• time profile - used by a sub-group/individual IP group member at a specified time.

Authentication filtering profiles

• NT/LDAP group filtering profile - used by an NT or LDAP group.

• NT/LDAP member filtering profile - used by an NT or LDAP group member.

12 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 1: INTRODUCTION FILTERING ELEMENTS

• LDAP container filtering profile - used by an LDAP container in an LDAP domain.

• NT/LDAP time profile - used by an NT or LDAP domain/ group/member at a specified time.

Other filtering profiles

• override account profile - set up in either the global

group section or the master group section of the console.

NOTE: An override account set up in the master IP group section of the R3000 console takes precedence over an override account set up in the global group section of the console.

• lock profile - set up under X Strikes Blocking in the Filter Options section of the profile.

• Radius profile - used by end users on a Radius accounting server if the Radius server is connected to the R3000 and the Radius authentication feature enabled.

• TAR profile - used if a Threat Analysis Reporter (TAR) server is connected to the R3000 and an end user is locked out by TAR when attempting to access blocked content in a library category.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 13

CHAPTER 1: INTRODUCTION FILTERING ELEMENTS

Static Filtering Profiles

Static filtering profiles are based on fixed IP addresses and include profiles for master IP groups and their members.

Master IP Group Filtering Profile

The master IP group filtering profile is created by the global administrator and is maintained by the group administrator. This filtering profile is used by members of the group— including sub-group and individual IP group members—and is customized to allow/deny users access to URLs, or warn

users about accessing specified URLs, to redirect users to

another URL instead of having a block page display, and to specify usage of appropriate filter options.

IP Sub-Group Filtering Profile

An IP sub-group filtering profile is created by the group administrator. This filtering profile applies to end users in an IP sub-group and is customized for sub-group members.

Individual IP Member Filtering Profile

An individual IP member filtering profile is created by the group administrator.This filtering profile applies to a specified end user in a master IP group.

14 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 1: INTRODUCTION FILTERING ELEMENTS

Active Filtering Profiles

Active filtering profiles include the global group profile, NT/ LDAP authentication profile, override account profile, time profile, and lock profile.

Global Filtering Profile

The global filtering profile is created by the global administrator. This profile is used as the default filtering profile. The global filtering profile consists of a customized profile that contains a list of library categories to block, open, add to a white list, or assign a warn setting, and service ports that are configured to be blocked. A URL can be specified for use instead of the standard block page when users attempt to access material set up to be blocked. Various filter options can be enabled.

NT/LDAP Group Filtering Profile

An NT or LDAP group filtering profile is created by the group administrator assigned to the NT or LDAP group. This profile can be customized to allow/deny group users access to URLs, or warn users about accessing specified URLs, to redirect users to another URL instead of having the standard block page display, and to specify usage of appropriate filter options.

If users belong to more than one group, all groups to which they belong must be ranked to determine the priority each filtering profile takes over another.

NT/LDAP Member Filtering Profile

An NT or LDAP member filtering profile is created by the group administrator assigned to that member. This profile can be customized to allow/deny a user access to URLs, or warn a user about accessing specified URLs, to redirect the user to another URL instead of the standard block page, and

to specify usage of appropriate filter options.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 15

CHAPTER 1: INTRODUCTION FILTERING ELEMENTS

LDAP Container Filtering Profile

An LDAP container filtering profile is created by the group administrator assigned to that container. This profile can be

customized to allow/deny users access to URLs, or warn users about accessing specified URLs, to redirect users to another URL instead of the standard block page, and to

specify usage of appropriate filter options.

Override Account Profile

If any user needs access to a specified URL that is set up to be blocked, the global administrator or group administrator can create an override account for that user. This account grants the user access to areas set up to be blocked on the Internet.

Time Profile

A time profile is a customized filtering profile set up to be effective at a specified time period for designated users.

Lock Profile

This filtering profile blocks the end user from Internet access for a set period of time, if the end user’s profile has the X Strikes Blocking filter option enabled and he/she has received the maximum number of strikes for inappropriate Internet usage.

NOTE: Refer to the R3000 User Guide for additional information on the Override Account Profile, Time Profile, and Lock Profile.

16 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 1: INTRODUCTION FILTERING ELEMENTS

Filtering Profile Components

Filtering profiles are comprised of the following components:

• library categories - used when creating a rule, minimum filtering level, or filtering profile for the global group or any entity

• service ports - used when setting up filter segments on the network, creating the global group (default) filtering profile, or establishing the minimum filtering level

• rules - specify which library categories should be blocked, left open, assigned a warn setting, or white listed

• filter options - specify which features will be enabled: X Strikes Blocking, Google/Yahoo!/Ask.com/AOL Safe Search Enforcement, Search Engine Keyword Filter Control, URL Keyword Filter Control

• minimum filtering level - takes precedence over filtering profiles of entities who are using a filtering profile other than the global (default) filtering profile

• filter settings - used by service ports, filtering profiles, rules, and the minimum filtering level to indicate whether users should be granted or denied access to specified Internet content

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 17

CHAPTER 1: INTRODUCTION FILTERING ELEMENTS

Library Categories

A library category contains a list of Web site addresses and keywords for search engines and URLs that have been set up to be blocked or white listed. Library categories are used when creating a rule, the minimum filtering level, or a filtering profile.

8e6 Supplied Categories

8e6 furnishes a collection of library categories, grouped under the heading “Category Groups” (excluding the “Custom Categories” group). Updates to these categories are provided by 8e6 on an ongoing basis, and administrators also can add or delete individual URLs within a specified library category.

Custom Categories

Custom library categories can be added by either global or group administrators. As with 8e6 supplied categories, additions and deletions can be made within a custom category. However, unlike 8e6 supplied categories, a custom category can be deleted.

NOTE: 8e6 cannot provide updates to custom categories. Maintaining the list of URLs and keywords is the responsibility of the global or group administrator.

18 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 1: INTRODUCTION FILTERING ELEMENTS

Service Ports

Service ports are used when setting up filter segments on the network (the range of IP addresses/netmasks to be detected by the R3000), the global (default) filtering profile, and the minimum filtering level.

When setting up the range of IP addresses/netmasks to be detected, service ports can be set up to be open (ignored). When creating the global filtering profile and the minimum filtering level, service ports can be set up to be blocked or filtered.

Examples of service ports that can be set up include File Transfer Protocol (FTP), Hyper Text Transfer Protocol (HTTP), Network News Transfer Protocol (NNTP), Secured HTTP Transmission (HTTPS), and Secure Shell (SSH).

Rules

A rule is comprised of library categories to block, leave open, assign a warn setting, or include in a white list. Access to an open library category can be restricted to a set number of minutes. Each rule that is created by the global administrator is assigned a number. A rule is selected when creating a filtering profile for an entity.

Minimum Filtering Level

The minimum filtering level consists of library categories set up at the global level to be blocked or opened, and service ports set up to be blocked or filtered. If the minimum filtering

level is created, it applies to all users in IP, NT, and LDAP groups, and takes precedence over filtering settings made for group and member filtering profiles.

The minimum filtering level does not apply to any user who does not belong to a group, and to groups that do not have a filtering profile established.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 19

CHAPTER 1: INTRODUCTION FILTERING ELEMENTS

NOTE: If the minimum filtering level is not set up, global (default) filtering settings will apply instead.

Filter Settings

Categories and service ports use the following settings to specify how filtering will be executed:

• block - if a category or a service port is given a block setting, users will be denied access to the item set up as “blocked”

• open - if a category or the filter segment detected on the network is given an open (pass) setting, users will be allowed access to the item set up as “opened”

NOTE: Using the quota feature, access to an open category can be restricted to a defined number of minutes.

• always allowed - if a category is given an always allowed setting, the category is included in the user’s white list and takes precedence over blocked categories

• warn - If a category is given a warn setting, a warning page displays for the end user to warn him/her that accessing the intended URL may be against established policies and to proceed at his/her own risk

• filter - if a service port is given a filter setting, that port will use filter settings created for library categories (block or open settings) to determine whether users should be denied or allowed access to that port

• ignore - if the filter segment detected on the network has a service port set up to be ignored, that service port will be bypassed

20 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

Filtering Rules

Individual User Profiles - A user in an NT or LDAP domain can have only one individual profile set up per domain.

Filtering Levels Applied:

1. The global (default) filtering profile applies to any user under the following circumstances:

• the user does not belong to a master IP group

• the user has not been assigned a domain default

profile from an NT or LDAP authentication domain

2. If a minimum filtering level is defined, it applies to all master IP groups (and their members) and NT/LDAP groups who have been assigned filtering profiles after authenticating. The minimum filtering level combines with the user’s profile to guarantee that categories blocked in the minimum filtering level are blocked in the user’s profile.

3. For master IP group members:

CHAPTER 1: INTRODUCTION FILTERING ELEMENTS

a. A master IP group filtering profile takes precedence

over the global profile.

b. A master IP group time profile takes precedence over

the master IP group profile.

4. For IP sub-group members:

a. An IP sub-group filtering profile takes precedence over

the master IP group’s time profile.

b. An IP sub-group time profile takes precedence over

the IP sub-group profile.

5. For individual IP members:

a. An individual IP member filtering profile takes prece-

dence over the IP sub-group’s time profile.

b. An individual IP member time profile takes precedence

over the individual IP member profile.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 21

CHAPTER 1: INTRODUCTION FILTERING ELEMENTS

6. For NT/LDAP users, if a user is authenticated, settings for the user’s group or individual profile from the NT/ LDAP domain are applied and take precedence over any IP profile.

a. If the user belongs to more than one group in an

authentication domain, the profile for the user is determined by the order in which the groups are listed in the Group Priority list set by the global administrator. The user is assigned the profile for the group highest in the Group Priority list.

NOTE: On an LDAP domain, if a user belongs to a container, that profile takes precedence over the group profile for that user.

b. If a user has an individual profile set up, that profile

supercedes all other profile levels for that user. The user can have only one individual profile in each domain.

c. If the user has a time profile, that profile takes prece-

dence over other profiles. A group time profile takes precedence over a domain time profile, and an individual time profile takes precedence over a group time profile.

NOTE: A Radius profile is another type of authentication profile and is weighted the same as NT/LDAP authentication profiles in the precedence hierarchy.

7. An override account profile takes precedence over an authentication profile or a time profile. This account may override the minimum filtering level—if the override account was set up in the master IP group tree, and the global administrator allows override accounts to bypass the minimum filtering level, or if the override account was set up in the global group tree.

NOTE: An override account set up in the master IP group section of the R3000 console takes precedence over an override account set up in the global group section of the console.

22 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 1: INTRODUCTION FILTERING ELEMENTS

8. A lock profile takes precedence over all filtering profiles. This profile is set up under Filter Options, by enabling the X Strikes Blocking feature.

NOTE: A Threat Analysis Reporter (TAR) profile is another type of lock profile that is weighted the same as a lock profile in the precedence hierarchy.

Fig. 1-4 Sample filtering hierarchy diagram

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 23

CHAPTER 1: INTRODUCTION AUTHENTICATION SOLUTIONS

Authentication Solutions

R3000 Authentication Protocols

The R3000 supports two types of authentication protocols: Windows NT LAN Manager (NTLM), and Lightweight Directory Access Protocol (LDAP).

• NTLM authentication supports NTLM authentication running on any of the following servers: Windows NT 4.0, Windows 2000 Mixed Mode, and Windows 2003 Mixed Mode.

• LDAP authentication supports all versions of LDAP, such as Microsoft Active Directory, Novell eDirectory, Sun ONE, and OpenLDAP.

R3000 Authentication Tiers and Options

R3000 authentication tiers

The R3000 authentication architecture for NTLM and LDAP authentication protocols is comprised of three tiers. When using NT and/or LDAP authentication with the R3000, one of these three tiers is selected for use on the network, depending on the server(s) used on the network and the preferred authentication method(s) to be employed.

• Tier 1: Single sign-on, net use based authentication for NT or Active Directory domains.

• Tier 2: Time-based, Web authentication for NT and LDAP authentication methods.

• Tier 3: Session-based, Web authentication for NT or LDAP authentication method.

24 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 1: INTRODUCTION AUTHENTICATION SOLUTIONS

R3000 authentication options

Depending on the setup of your network, any of the following authentication options can be enabled to ensure the end user is authenticated when logging into his/her workstation: 8e6 Authenticator, Active Directory Agent, and Novell eDirectory Agent.

NOTE: See Appendix A: Authentication Operations for information on using Tier 1, Tier 2, and Tier 3 on the network, and configuring 8e6 Authenticator, Novell eDirectory Agent, and Active Directory Agent.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 25

CHAPTER 1: INTRODUCTION AUTHENTICATION SOLUTIONS

Authentication Solution Compatibility

Below is a chart representing the authentication solution compatibility for a single user:

Tier 1

Tier 2

Tier 3

8e6 Authenticator

eDirectory Agent

Active Directory Agent

Tier1 net use

-- Yes Yes N/R N/A N/R

Yes -- N/A Yes Ye s Ye s

Yes N/A -- Yes Ye s Ye s

N/R Yes Yes -- N/R N/R

N/A Yes Yes N/R -- N/A

N/R Yes Yes N/R N/A --

Tier 2 time based

Tier 3 session based

8e6 Authenticator

eDirectory Agent

Active Directory Agent

KEY:

• N/A = Not Applicable

• N/R = Not Recommended

26 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 1: INTRODUCTION AUTHENTICATION SOLUTIONS

Authentication System Deployment Options

Below is a chart representing authentication system deployment options on a network:

Authentication System Single Sign-On (SSO)

SunOne OpenLDAP CommuniGate Pro (Stalker)

Windows NT 4.0 Tier 1 “net use” Tier 2 or Tier 3

Windows 2000/2003 Server (both Mixed and Native modes)

Novell eDirectory 8e6 Authenticator

Windows 2000/2003 Server and Novell eDirectory Mixed environment

None Tier 2 or Tier 3

Tier 1 “net use” 8e6 Authenticator AD Agent

Novell eDirectory Agent (for eDirectory server version

8.7 and higher)

8e6 Authenticator Novell eDirectory Agent AD Agent

Force Authentication

Tier 2 or Tier 3

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 27

CHAPTER 1: INTRODUCTION AUTHENTICATION SOLUTIONS

Ports for Authentication System Access

The following ports should be used for authentication system access:

Type No. Function

TCP 8081 Used between the R3000’s transmitting inter-

face and the SSL block page for Tier 2 or Tier 3 authentication.

TCP 836 Used between the R3000’s Virtual IP address

and Java applet for Tier 3 authentication.

TCP 139 Used between the R3000 and workstations

requiring Tier 1 or Tier 3 authentication.

TCP/ UDP

LDAP 389 Used for communicating with domain control-

LDAPS 636 Used for communicating with domain control-

137 Used between the R3000 and workstations

requiring Tier 1 authentication.

lers in order to bind with them so that user/ group information can be queried/accessed.

28 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 1: INTRODUCTION AUTHENTICATION SOLUTIONS

Configuring the R3000 for Authentication

Configuration procedures

When configuring the R3000 server for authentication, settings must be made in System and Group windows in the Administrator console.

NOTES: If the network has more than one domain, the first one

you add should be the domain on which the R3000 resides.

The entries described in this section represent entries to be made on a typical network.

System section

The first settings for authentication must be made in the System section of the Administrator console in the following windows: Operation Mode, LAN Settings, Enable/Disable Authentication, Authentication Settings, Authentication SSL Certificate (if Web-based authentication will be used), and Block Page Authentication.

1. Select “Mode” from the navigation panel, and then select “Operation Mode” from the pop-up menu.

The entries made in the Operation Mode window will vary depending on whether you will be using the invisible mode, or the router or firewall mode.

In the Listening Device frame, set the Listening Device to

“LAN1”.

In the Block Page Device frame:

• If using the invisible mode, select “LAN2”.

• If using the router or firewall mode, select “LAN1”.

2. Select “Network” from the navigation panel, and then select “LAN Settings” from the pop-up menu.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 29

CHAPTER 1: INTRODUCTION AUTHENTICATION SOLUTIONS

The entries made in this window will vary depending on whether you are using the invisible mode, or the router or firewall mode. The LAN1 and LAN2 IP addresses usually should be in a different subnet.

• If using the invisible mode: For the LAN1 IP address,

select 255.255.255.255 for the subnet mask.

• If using the router or firewall mode: Specify the appro-

priate IP address and subnet mask in the applicable fields.

3. Select “Authentication” from the navigation panel, and then select Enable/Disable Authentication from the popup menu.

Enable authentication, and then select one of three tiers in the Web-based Authentication frame:

• Tier 1: Choose this option if you will only be using net

use based authentication for NT or Active Directory servers.

• Tier 2: Choose this option if you wish to use timed

Web-based authentication for NT and LDAP domains. This option gives the user a timed session for his/her Internet access. After the timed profile expires, the user will have to log in again if he/she wants to continue to have Internet access.

• Tier 3: Choose this option if you wish to use persistent

Web-based authentication for NT and LDAP domains. This option gives the user a persistent network connection via a pop-up window that keeps the user’s session open until the window is closed, so the user does not have to log in repeatedly.

If you wish to use the tier you specified as a fallback authentication solution, you have the option to enable any of the following authentication solutions as appropriate to your environment: 8e6 Authenticator, Active Directory Agent, Novell eDirectory Agent.

30 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 1: INTRODUCTION AUTHENTICATION SOLUTIONS

4. Select “Authentication” from the navigation panel, and then select “Authentication Settings” from the pop-up menu.

In the Settings frame, enter general configuration settings for the R3000 server such as IP address entries.

From the NIC Device to Use for Authentication pull-down menu:

• If using the invisible mode: Select “LAN2” as the

device to send traffic on the network.

• If using the router or firewall mode: Select “LAN1”.

Information should only be entered in the NT Authentication Server Details frame if the R3000 will use the NT Authentication method to authenticate users.

5. Select “Authentication” from the navigation panel, and then select Authentication SSL Certificate from the popup menu. This option should be used if Web-based authentication will be deployed on the R3000 server.

Using this option, you create either a self-signed certificate or a Certificate Request (CSR) for use by the Secure Sockets Layer (SSL). The certificate should be placed on client machines so that these machines will recognize the R3000 as a valid server with which they can communicate.

6. Select “Control” from the navigation panel, and then select “Block Page Authentication” from the pop-up menu.

In the Block Page Authentication window, select the Reauthentication Options to be used. The items you select will be listed as options for re-authentication on the Options page, accessible from the standard block page. If the “Re-authentication” (NET USE) option is selected, enter the login script path to be used by the R3000 for reauthentication purposes.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 31

CHAPTER 1: INTRODUCTION AUTHENTICATION SOLUTIONS

7. Select “Administrator” from the navigation panel to access the Administrator window. Add group administrator (Sub Admin) accounts in this window. Sub Admin group administrators will later be assigned to manage entities in the NT and/or LDAP branch(es) of the Group tree.

Group section

In the Group section of the Administrator console, choose NT or LDAP, and then do the following:

1. Add a domain from the network to the list of domains that will have users authenticated by the R3000.

NOTE: If the network has more than one domain, the first one you add should be the domain on which the R3000 resides.

2. Do either of the following as necessary:

• Assign a group administrator to oversee the newly-

added domain and to set up filtering profiles for all groups and members within that domain

• Assign Sub Admin group administrators to specific

groups and let them create filtering profiles for their group and its members

3. Set the group priority by designating which group profile will be assigned to a user when he/she logs in. If a user is a member of multiple groups, the group that is positioned highest in the list is applied.

32 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 2: NETWORK SETUP ENVIRONMENT REQUIREMENTS

CHAPTER 2: NETWORK SETUP

Environment Requirements

Workstation Requirements

Administrator

Minimum system requirements for the administrator include the following:

• Windows 2000 or later operating system (not compatible with Windows server 2003) running Internet Explorer (IE)

6.0 or later (Windows Vista running IE7)

• Macintosh OS X Version 10.5 running Safari 2.0, Firefox

2.0

• JavaScript enabled

• Java Virtual Machine

• Java Plug-in (use the version specified for the R3000 software version)

• Java Runtime Environment, if using Tier 3 authentication

NOTE: R3000 administrators must be set up with software installation privileges in order to install Java used for accessing the interface.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 33

CHAPTER 2: NETWORK SETUP ENVIRONMENT REQUIREMENTS

End User

• Windows 98 or later operating system (not compatible with WIndows server 2003) running Internet Explorer (IE)

5.5 or later

• Macintosh OS X running Safari 1.0 or later, Firefox 1.0 or later

• JavaScript enabled

• Java Runtime Environment, if using Tier 3 authentication

• Pop-up blocking software, if installed, must be disabled

Network Requirements

• High speed connection from the R3000 server to the client workstations

• HTTPS connection to 8e6’s software update server

• Internet connectivity for downloading Java Virtual Machine—and Java Runtime Environment, if necessary—if not already installed

34 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Set up the Network for Authentication

The first settings for authentication must be made in the System section of the console in the following windows: Operation Mode, LAN Settings, Enable/Disable Authentication, Authentication Settings, Authentication SSL Certificate (if Web-based authentication will be used), View Log File (for troubleshooting authentication setup), and Block Page Authentication. Entries for customizing the block page and/ or authentication request form are made in the Common Customization, Authentication Form Customization, and Block Page Customization windows.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 35

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Specify the operation mode

Click Mode and select Operation Mode from the pop-up menu to display the Operation Mode window:

Fig. 2-1 Operation Mode window

The entries made in this window will vary depending on whether you will be using the invisible mode, or the router or firewall mode.

1. In the Mode frame, select the mode to be used: “Invisible”, “Router”, or “Firewall”.

2. In the Listening Device frame, set the Device to “LAN1”.

36 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

3. In the Block Page Device frame:

• If using the invisible mode, select “LAN2”.

• If using the router or firewall mode, select “LAN1”. If using the invisible mode, the Block Page Delivery

Method frame displays. Choose from either of the two Protocol Methods:

• “Send Block Page via ARP Table” - this option uses the

Address Resolution Protocol method to find the best possible destination MAC address of a specified host, usually the R3000 gateway.

• “Send Block to Specified Host MAC Address” - using

this preferred method, the block page will always be sent to the MAC address of a specified host, usually the R3000 gateway.

Choose from either of the two Block Page Route To selections:

• “Default Gateway” - this option indicates that the default gateway on your network will be used for sending block pages.

• “Alternate IP Address” - this option should be used if block pages are not being served.

Enter the IP address of the router or device that will serve block pages.

4. Click Apply.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 37

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Specify the subnet mask, IP address(es)

Click Network and select LAN Settings from the pop-up menu to display the LAN Settings window:

Fig. 2-2 LAN Settings window

The entries made in this window will vary depending on whether you are using the invisible mode, or the router or firewall mode.

NOTE: If the gateway IP address on the network changes, be sure to update the Gateway IP address in this window.

Invisible mode

For the LAN1 IP address, select 255.255.255.255 for the subnet mask, and click Apply.

38 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Router or firewall mode

1. Enter the following information:

• In the LAN1 IP field of the IP/Mask Setting frame, enter the IP address and specify the corresponding subnet of the “LAN1” network interface card to be used on the network.

• In the LAN2 IP field, enter the IP address and specify the corresponding subnet of the “LAN2” network interface card to be used on the network.

TIP: The LAN1 and LAN2 IP addresses usually should be placed in different subnets.

• In the Primary IP field of the DNS frame, enter the IP address of the first DNS server to be used for resolving the IP address of the authentication server with the machine name of that server.

• In the Secondary IP field of the DNS frame, enter the IP address of the second DNS server to be used for resolving the IP address of the authentication server with the machine name of that server.

• In the Gateway IP field of the Gateway frame, enter the IP address of the default router to be used for the entire network segment.

2. Click Apply to apply your settings.

NOTE: Whenever modifications are made in this window, the server must be restarted in order for the changes to take effect.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 39

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Enable authentication, specify criteria

1. Click Authentication and select Enable/Disable Authentication from the pop-up menu to display the Enable/ Disable Authentication window:

2. Click Enable to enable authentication.

3. Select one of three tiers in the Web-based Authentication frame:

Fig. 2-3 Enable/Disable Authentication window

NOTES: See information on the following pages for details about each of the tiers, and for steps that must be executed to enable your tier selection.

See Appendix A: Authentication Operations for more information about each tier and for configuring various authentication options.

40 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

4. Enable any of the following authentication options, as pertinent to your environment:

• In the 8e6 Authenticator frame, be sure the 8e6

Authenticator is “On”—unless the Novell eDirectory Agent option will be used instead. When enabling the 8e6 Authenticator option, and then downloading and installing the 8e6 Authenticator (authenticat.exe) on a network share accessible by the domain controller or a Novell eDirectory server, the 8e6 Authenticator automatically authenticates the end user when he/she logs into his/her workstation.

• If you have a Novell eDirectory server and the 8e6

Authenticator will not be used, turning “On” Novell eDirectory Agent will enable end user logon and logoff events to be logged. To use this option, the LDAP domain must be set up and activated in the Group tree.

WARNING: When enabling Novell eDirectory Agent, the agent will immediately begin scanning Novell eDirectory-based domain labels.

• If using a Windows 2000 or Windows 2003 server for

authentication, the Active Directory Agent option can be used for capturing end user logon and logoff events and sending a session table to the R3000 so end users receive the correct filtering profile. To use this feature, turn “On” the AD Agent, and then specify settings for administrator computers authorized to configure the AD Agent via the Active Directory Agent console. Download and install the AD Agent (DCAgent.msi) on the administrator workstation.

5. If using Tier 1, in the Sending Keep Alive frame, click "On" to specify that keep alives should be sent on a connection to verify whether it is still active. Click "Off" to specify that the end user's session will be kept alive based on the number of minutes entered in the text box.

6. Click Apply.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 41

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Net use based authentication

Tier 1: Web-based Authentication disabled (Net Use enabled) – Choose this option if you will be using net use

based authentication for NT or Active Directory.

1. Click “Tier 1”.

2. In the Sending Keep Alive frame, click the radio button corresponding to the option to be used:

• “On” - This option specifies that keep alives should be

sent on a connection to verify whether it is still active.

• “Off” - This option specifies that the end user's session

will be kept alive based on the number of minutes entered in the text box.

In the Inactive session lifetime (in minutes) field, enter the number of minutes the end user’s session will be kept alive.

3. Click Apply to open the alert box that confirms your selection.

42 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Web-based authentication

Choose either Tier 2 or Tier 3 if Web-based authentication will be used.

NOTE: If selecting either Tier 2 or Tier 3, please be informed that in an organization with more than 5000 users, slowness may be experienced during the authentication process. In this scenario, 8e6 recommends using an R3000 Filter with an SSL accelerator card installed. Please contact 8e6 for more information.

Tier 2: Use time-based profiles, with time-out (in minutes) – Choose this option if using NT and/or LDAP

authentication, and you want the user to have a time limit on his/her Internet connection. This option uses an authentication servlet that lets the user log into either domain with no persistent connection between the client PC and the R3000.

1. Click “Tier 2”.

2. Enter a whole number for the duration of time the user will retain his/her Internet connection.

3. Click Apply to open the alert box that confirms your selection.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 43

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Tier 3: Use persistent logins via a Java Applet – Choose this option if using NT and/or LDAP authentication, and you want the user to maintain a persistent network connection.

This option—the preferred method for NT authentication— opens a profile window that uses a Java applet:

Fig. 2-4 Java applet

The profile window must be kept open during the user’s session in order for the user to have continued access to the Internet.

NOTE: Tier 3 Authentication requires a current version of Java Runtime Environment (JRE) on end-users' PCs. In some cases, a JRE will need to be downloaded and installed on workstations and the R3000 will allow the JRE download at the time of login. However some operating systems may require this action to be performed manually.

1. Click “Tier 3”.

2. Click Apply to open the dialog box that informs you about the requirement of a current Java Runtime Environment (JRE) to be installed on each end user’s workstation:

44 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Fig. 2-5 Tier 3 dialog box

3. To ensure that end-users are using the most current version of JRE, choose the method for distributing the current version to their workstations: “8e6 automatically distributes JRE during user login” or the default selection, “Administrator manually distributes JRE to user workstations”.

4. Click Continue to open the alert box that confirms your selection.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 45

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Enter network settings for authentication

1. Click Authentication and select Authentication Settings from the pop-up menu to display the Authentication Settings window:

Fig. 2-6 Authentication Settings window

In the Settings frame, at the R3000 NetBIOS Name field the NetBIOS name of the R3000 displays. This information comes from the entry made in the Host Name field of the LAN Settings window.

2. In the IP Address of WINS Server field, if using a WINS server for name resolution, enter the IP address of each Windows DNS server to be filtered by this R3000, with a space between each IP address.

46 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

3. In the Virtual IP Address to Use for Authentication field,1.2.3.5 displays by default. If using Tier 1 or Tier 3, enter the IP address that from now on will be used for communicating authentication information between the R3000 and the PDC. This must be an IP address that is not being used, on the same segment of the network as the R3000.

WARNING: If the IP address entered here is not in the same subnet as this R3000, the net use connection will fail.

4. From the NIC Device to Use for Authentication pull- down menu:

• if using the invisible mode, select “LAN2” for sending

traffic on the network—in particular, for transferring authentication data.

• if using the router or firewall mode, select “LAN1”.

5. Click Apply to apply your settings.

NOTE: If using the NT authentication method, you will later return to this window to join the domain. See the section on Join the NT domain in Chapter 3: NT Authentication Setup for information about these procedures.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 47

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Create an SSL certificate

Authentication SSL Certificate should be used if Web-based authentication will be deployed on the R3000 server. Using this feature, a Secured Sockets Layer (SSL) self-signed certificate is created and placed on client machines so that the R3000 will be recognized as a valid server with which they can communicate.

Click Authentication and select Authentication SSL Certificate from the pop-up menu to display the Authentication SSL Certificate window:

Fig. 2-7 Authentication SSL Certificate window

This window is comprised of three tabs: Self Signed Certificate, Third Party Certificate, and Download/View/Delete Certificate. These tabs are used to create, view, and/or delete self-signed or third party SSL certificates.

48 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Create, Download a Self-Signed Certificate

1. On the Self Signed Certificate tab, click Create Self Signed Certificate to generate the SSL certificate.

2. Click the Download/View/Delete Certificate tab:

Fig. 2-8 Download/View/Delete Certificate tab

3. Click Download/View Certificate to open the File Down- load dialog box where you indicate whether you wish to Open and view the file, or open the Save As window so that you can Save the SSL certificate to a specified folder on your workstation.

NOTE: While the SSL certificate can be downloaded on a Macintosh computer, the best method to import the certificate is via the Authentication Request Form, when prompted by the Security Alert warning message to add the certificate to the trusted certificate store.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 49

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Once the certificate is saved to your workstation, it can be distributed to client workstations for users who need to be authenticated.

TIP: Click Delete Certificate to remove the certificate from the server.

Create, Upload a Third Party Certificate

Create a Third Party Certificate

1. Click the Third Party Certificate tab:

Fig. 2-9 Third Party Certificate tab

NOTE: If a third party certificate has not yet been created, the Create CSR button is the only button activated on this tab.

50 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

2. Click Create CSR to open the Create CSR pop-up window:

Fig. 2-10 Create CSR pop-up window

The Common Name (Host Name) field should automatically be populated with the host name. This field can be edited, if necessary.

3. Enter your Email Address.

4. Enter the name of your Organization, such as 8e6 Technologies.

5. Enter an Organizational Unit code set up on your server, such as Corp.

6. Enter Locality information such as the name of your city or principality.

7. Enter the State or Province name in its entirety, such as California.

8. Enter the two-character Country code, such as US.

9. Click Create to generate the Certificate Signing Request.

NOTE: Once the third party certificate has been created, the Create CSR button displays greyed-out and the Download/View CSR, Upload Certificate, Delete CSR buttons are now activated.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 51

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Upload a Third Party Certificate

1. Click Upload Certificate to open the Upload Signed SSL Certificate for R3000 pop-up window:

Fig. 2-11 Upload Signed SSL Certificate box

The Message dialog box also opens with the message: "Click OK when upload completes."

TIP: Click Cancel in the dialog box to cancel the procedure.

2. In the Upload Signed SSL Certficate for R3000 pop-up window, click Browse to open the Choose file window.

3. Select the file to be uploaded.

4. Click Upload File to upload this file to the R3000.

5. Click OK in the Message dialog box to confirm the upload and to close the dialog box.

52 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Download a Third Party Certificate

1. In the Authentication SSL Certificate window, click Download/View CSR to open a pop-up window containing the contents of the certificate request:

Fig. 2-12 Download CSR pop-up window

2. Click the “X” in the upper right corner of the window to close it.

TIP: Click Delete CSR to remove the certificate from the server.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 53

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

View log results

Use the View Log File window if you need to troubleshoot any problems with the authentication setup process.

1. Click Diagnostics and select View Log File from the popup menu to display the View Log File window:

Fig. 2-13 View Log File window

NOTE: In this user guide, only authentication-related options will be addressed. For information about all other options, see the View Log File window in the R3000 User Guide.

54 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

2. In the Log File Details frame, select the type of Log File to view:

• “User Name Log (usage.log)” - used for viewing the

time and date a user logged on and off the network, along with the user's profile information.

• “Wbwatch Log (wbwatch.log)” - used for viewing

messages on attempts to join the domain via the Authentication Settings window.

• “Authentication Log (AuthenticationServer.log)” - used

for viewing information about the authentication process for users, including SEVERE and WARNING error messages.

• “Admin GUI Server Log (AdminGUIServer.log)” - used

for viewing information on entries made by the administrator in the console.

• “eDirectory Agent Debug Log (edirAgent.log)” - used

for viewing the debug log, if using eDirectory LDAP authentication.

• “eDirectory Agent Event Log (edirEvent.log)” - used for

viewing the event log, if using eDirectory LDAP authentication.

• “Authentication Module Log (authmodule.log)” - used

for viewing information about SEVERE error messages pertaining to LDAP authentication connection attempts.

3. Choose the Last Number of Lines to view (100-500) from that file.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 55

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

4. Click View to display results in the Result pop-up window:

Fig. 2-14 View Log File Result pop-up window

5. Click the “X” in the upper right corner of the pop-up window to close it.

56 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Specify block page settings

Click Control and select Block Page Authentication from the pop-up menu to display the Block Page Authentication window:

Fig. 2-15 Block Page Authentication window

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 57

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Block Page Authentication

1. In the Re-authentication Options field of the Details

frame, all block page options are selected by default, except for Web-based Authentication. Choose from the following options by clicking your selection:

• Web-based Authentication - select this option if

using Web authentication with time-based profiles or persistent login connections for NT or LDAP authentication methods.

• Re-authentication - select this option for the re-

authentication option. The user can restore his/her profile and NET USE connection by clicking an icon in a window to run a NET USE script.

• Override Account - select this option if any user has

an Override Account, allowing him/her to access URLs set up to be blocked at the global or IP group level.

TIP: Multiple options can be selected by clicking each option while pressing the Ctrl key on your keyboard.

NOTE: See the R3000 User Guide for information about the Override Account feature.

2. If the “Re-authentication” option was selected, in the Logon Script Path field, \\PDCSHARE\scripts displays by default. In this field, enter the path of the logon script that the R3000 will use when re-authenticating users on the network, in the event that a user's machine loses its connection with the server, or if the server is rebooted. This format requires the entry of two backslashes, the authentication server’s computer name (or computer IP address) in capital letters, a backslash, and name of the share path.

3. Click Apply to apply your settings.

58 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Block page

When a user attempts to access Internet content set up to be blocked, the block page displays on the user’s screen:

Fig. 2-16 Block page

NOTES: See Block Page Customization for information on adding free form text and a hyperlink at the top of the block page. Appendix C: Create a Custom Block Page from the R3000 User Guide for information on creating a customized block page using your own design.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 59

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

User/Machine frame

By default, the following data displays in the User/Machine frame:

• User/Machine field - The username displays for the NT/ LDAP user. This field is blank for the IP group user.

• IP field - The user’s IP address displays.

• Category field - The name of the library category that blocked the user’s access to the URL displays. If the content the user attempted to access is blocked by an Exception URL, “Exception” displays instead of the library category name.

• Blocked URL field - The URL the user attempted to access displays.

Standard Links

By default, the following standard links are included in the block page:

• HELP - Clicking this link takes the user to 8e6’s Technical Support page that explains why access to the site or service may have been denied.

• 8e6 Technologies - Clicking this link takes the user to 8e6’s Web site.

60 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Optional Links

By default, these links are included in the block page under the following conditions:

• For further options, click here

. - This phrase and link is included if any option was selected at the Re-authentication Options field in the Block Page Authentication window. Clicking this link takes the user to the Options window, described in the Options page sub-section that follows.

• To submit this blocked site for review, click here This phrase and link is included if an email address was entered in the Submission Email Address field in the Common Customization window. Clicking this link launches the user’s default email client. In the composition window, the email address from the Submission Email Address field populates the “To” field. The user’s message is submitted to the global administrator.

. -

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 61

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Options page

The Options page displays when the user clicks the following link in the block page: For further options, click

here.

Fig. 2-17 Options page

The following items previously described for the Block page display in the upper half of the Options page:

• BACK and HELP links

• User/Machine frame contents

The frame beneath the User/Machine frame includes information for options (1, 2, and/or 3) based on settings made in the Block Page Authentication window.

62 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Option 1

Option 1 is included in the Options page if “Web-based Authentication” was selected at the Re-authentication Options field in the Block Page Authentication window. The following phrase/link displays:

Click here

for secure Web-based authentication.

When the user clicks the link, the Authentication Request Form opens:

Fig. 2-18 Authentication Request Form

NOTE: See Authentication Form Customization for information on adding free form text and a hyperlink at the top of the Authentication Request Form.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 63

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Option 2

The following phrase/link displays, based on options selected at the Re-authentication Options field in the Block Page Authentication window:

• Re-start your system and re-login - This phrase displays for Option 1, whether or not either of the Reauthentication Options (Re-authentication, or Webbased Authentication) was selected in the Block Page Authentication window. If the user believes he/she was incorrectly blocked from a specified site or service, he/ she should re-start his/her machine and log back in.

• Try re-authenticating your user profile

- This link displays if “Re-authentication” was selected at the Reauthentication Options field, and an entry was made in the Logon Script Path field. When the user clicks this link, a window opens:

Fig. 2-19 Re-authentication option

The user should click the logon.bat icon to run a script that will re-authenticate his/her profile on the network.

64 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Option 3

Option 3 is included in the Options page, if “Override Account” was selected at the Re-authentication Options field in the Block Page Authentication window.

This option is used by any user who has an override account set up for him/her by the global group administrator or the group administrator. An override account allows the user to access Internet content blocked at the global or IP sub-group level.

The user should enter his/her Username and Password, and then click Override to open the Profile Control window. This window must be left open throughout the user’s session in order for the user to be able to access blocked Internet content.

NOTES: See Appendix F: Override Pop-up Blockers for information on how a user with an override account can authenticate if a pop-up blocker is installed on his/her workstation.

See the R3000 User Guide for information about the Override Account feature.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 65

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Common Customization

Common Customization lets you specify elements to be included in block pages and/or the authentication request form end users will see.

Click Customization and then select Common Customization from the pop-up menu to display the Common Custom-

ization window:

Fig. 2-20 Common Customization window

By default, in the Details frame all elements are selected to display in the HTML pages, the Help link points to the FAQs page on 8e6's public site that explains why access was denied, and a sample email address is included for administrator contact information. These details can be modified, as necessary.

66 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Enable, disable features

1. Click “On” or “Off” to enable or disable the following elements in the HTML pages, and make entries in fields to display customized text, if necessary:

• Username Display - if enabled, displays “User/

Machine” followed by the end user’s username in block pages

• IP Address Display - if enabled, displays “IP” followed

by the end user’s IP address in block pages

• Category Display - if enabled, displays “Category”

followed by the long name of the blocked category in block pages

• Blocked URL Display - if enabled, displays “Blocked

URL” followed by the blocked URL in block pages

• Copyright Display - if enabled, displays 8e6 R3000

• Title Display - if enabled, displays the title of the page

in the title bar of the block pages and the authentication request form

• Help Display - if enabled, displays the specified help

link text in block pages and the authentication request form. The associated URL (specified in the Help Link URL field described below) is accessible to the end user by clicking the help link.

NOTE: If enabling the Help Display feature, both the Help Link Text and Help Link URL fields must be populated.

• Help Link Text - By default, HELP displays as the help

link text. Enter the text to display for the help link.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 67

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

• Help Link URL - By default, http://www.8e6.com/tech-

support/deniedresponse.html displays as the help link URL. Enter the URL to be used when the end user clicks the help link text (specified in the Help Link Text field).

• Submission Review Display - if enabled, displays in

block pages the email address of the administrator to receive requests for a review on sites the end users feel are incorrectly blocked. The associated email address (specified in the Submission Email Address field described below) is accessible to the end user by clicking the click here

NOTE: If enabling the Submission Review Display feature, an email address entry of the designated administrator in your organization must be made in the Submission Email Address field.

link.

• Submission Email Address - By default, admin

@company.com displays in block pages as the email address of the administrator to receive feedback on content the end user feels has been incorrectly blocked. Enter the global administrator's email address.

2. Click Apply to save your entries.

TIP: Click Restore Default and then Apply to revert to the default settings.

68 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Authentication Form Customization

To customize the Authentication Request Form, click Customization and select Authentication Form from the pop-up menu:

Fig. 2-21 Authentication Form Customization window

NOTE: This window is activated only if Authentication is enabled via System > Authentication > Enable/Disable Authentication, and Web-based Authentication is specified.

TIP: An entry in any of the fields in this window is optional, but if an entry is made in the Link Text field, a corresponding entry must also be made in the Link URL field.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 69

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

1. Make an entry in any of the following fields:

• In the Header field, enter a static header to be

displayed at the top of the Authentication Request Form.

• In the Description field, enter a static text message to

be displayed beneath the Authentication Request Form header.

• In the Link Text field, enter text for the link's URL to be

displayed beneath the Description in the Authentication Request Form, and in the Link URL field, enter the corresponding hyperlink in plain text using the http:// or https:// syntax.

Any entries made in these fields will display centered in the Authentication Request Form, using the Arial font type.

2. Click Apply.

TIP: Click Restore Default and then Apply to revert to the default text in this window.

70 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Preview sample Authentication Request Form

1. Click Preview to launch a separate browser window containing a sample Authentication Request Form, based on entries saved in this window and in the Common Customization window:

Fig. 2-22 Sample Customized Authentication Request Form

By default, the following data displays in the frame:

• Username field - The username displays.

• Password field - The user’s IP address displays.

• Domain field - All LDAP domain names set up on the

R3000 display in the pull-down menu.

• Alias field (optional) - All alias names associated with

the LDAP domain specified in the field above display in the pull-down menu, if the account names were entered for that LDAP domain.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 71

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

By default, the following standard links are included in the Authentication Request Form:

• HELP - Clicking this link takes the user to 8e6’s Tech-

nical Support page that explains why access to the site or service may have been denied.

• 8e6 Technologies - Clicking this link takes the user to

8e6’s Web site.

2. Click the “X” in the upper right corner of the window to close the sample Authentication Request Form.

TIP: If necessary, make edits in the Authentication Form Customization window or the Common Customization window, and then click Preview in this window again to view a sample Authentication Request Form.

72 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Block Page Customization

To customize the block page, click Customization and select Block Page from the pop-up menu:

Fig. 2-23 Block Page Customization window

NOTE: See Appendix C: Create a Custom Block Page from the R3000 User Guide for information on creating a customized block page using your own design.

TIP: An entry in any of the fields in this window is optional, but if an entry is made in the Link Text field, a corresponding entry must also be made in the Link URL field.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 73

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

1. Make an entry in any of the following fields:

• In the Header field, enter a static header to be

displayed at the top of the block page.

• In the Description field, enter a static text message to

be displayed beneath the block page header.

• In the Link Text field, enter text for the link's URL to be

displayed beneath the Description in the block page, and in the Link URL field, enter the corresponding hyperlink in plain text using the http:// or https:// syntax.

Any entries made in these fields will display centered in the customized block page, using the Arial font type.

2. Click Apply.

TIP: Click Restore Default and then Apply to revert to the default text in this window.

74 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

Preview sample block page

1. Click Preview to launch a separate browser window containing a sample customized block page, based on entries saved in this window and in the Common Customization window:

Fig. 2-24 Sample Customized Block Page

By default, the following data displays in the User/ Machine frame:

• User/Machine field - The username displays for the

NT/LDAP user. This field is blank for the IP group user.

• IP field - The user’s IP address displays.

• Category field - The name of the library category that

blocked the user’s access to the URL displays. If the content the user attempted to access is blocked by an Exception URL, “Exception” displays instead of the library category name.

• Blocked URL field - The URL the user attempted to

access displays.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 75

CHAPTER 2: NETWORK SETUP SET UP THE NETWORK FOR AUTHENTICATION

By default, the following standard links are included in the block page:

• HELP - Clicking this link takes the user to 8e6’s Tech-

nical Support page that explains why access to the site or service may have been denied.

• 8e6 Technologies - Clicking this link takes the user to

8e6’s Web site.

By default, these links are included in the block page under the following conditions:

• For further options, click here

. - This phrase and link is included if any option was selected at the Reauthentication Options field in the Block Page Authentication window. Clicking this link takes the user to the Options window, described in the Options page subsection.

2. Click the “X” in the upper right corner of the window to close the sample customized block page.

TIP: If necessary, make edits in the Block Page Customization window or the Common Customization window, and then click Preview in this window again to view a sample block page.

. -

76 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 2: NETWORK SETUP SET UP GROUP ADMINISTRATOR ACCOUNTS

Set up Group Administrator Accounts

The global administrator creates group administrator (Sub Admin) accounts so that these group administrators can be assigned to manage specific NT or LDAP entities set up in the Group tree. Sub Admin group administrator accounts are set up in the Administrator window from the System section of the console.

NOTE: IP group administrator accounts are set up in the IP branch of the Group tree when new IP groups are created. See Chapter 2: Group screen from the Global Administrator Section of the R3000 User Guide for information on creating IP groups.

Add Sub Admins to manage groups, users

Click Administrator to display the Administrator window:

Fig. 2-25 Administrator window

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 77

CHAPTER 2: NETWORK SETUP SET UP GROUP ADMINISTRATOR ACCOUNTS

Add a group administrator account

To add an NT/LDAP group administrator (Sub Admin) account:

1. In the Account Details frame, enter the username in the Username field.

2. In the Password field, enter eight to 20 characters— including at least one alpha character, one numeric character, and one special character. The password is case sensitive.

3. Make the same entry again in the Confirm Password field.

4. Select “Sub Admin” from the Type pull-down menu.

5. Click Add to include the username and account type in the Current User list box.

Update the group administrator’s password

1. Select the username from the Current User list box; this action populates the Account Details frame with data.

2. In the Password field, enter eight to 20 characters for a new password—including at least one alpha character, one numeric character, and one special character. The password is case sensitive.

3. Enter the same new password again in the Confirm Password field.

4. Click Modify to apply your settings.

78 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 2: NETWORK SETUP SET UP GROUP ADMINISTRATOR ACCOUNTS

Delete a group administrator account

To delete an administrator account:

1. Select the username from the Current User list box.

2. Click Delete to remove the account.

NOTE: If a group administrator assigned to an NT/LDAP entity is deleted, that group administrator must be removed from assignment to that NT/LDAP entity and another group administrator set up for assignment to manage that entity. See Chapter 5: Assign/ Set up Groups, Members for information on assigning and reassigning an entity for management.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 79

CHAPTER 3: NT AUTHENTICATION SETUP JOIN THE NT DOMAIN

HAPTER

3: NT A

NOTE: If you are running a Windows 2000 or Windows 2003 Server and are using the NTLM authentication protocol, then you need to make SMB Signing “not required.” See Appendix B: Disable SMB Signing Requirements for steps on how to disable SMB Signing restrictions.

UTHENTICATION

Join the NT Domain

In the System section of the console, click Authentication and select Authentication Settings from the pop-up menu to display the Authentication Settings window:

ETUP

Fig. 3-1 Authentication Settings window

Information should only be entered in the NT Authentication Server Details frame if the R3000 will use the NT Authentication method to authenticate users.

80 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 3: NT AUTHENTICATION SETUP JOIN THE NT DOMAIN

NOTE: The following Windows servers are supported by the current version of authentication: NT 4.0 SP4 or later, Mixed Mode 2000, and 2003. A Windows 2003 server may require changes to the default settings for SMB signing to allow communications.

The account that is provided for accessing the Windows server must have the administrative rights to add a machine account to the specified domain on the R3000. This requirement ensures the R3000 will be able to authenticate users from the Windows domain.

1. Enter the alphanumeric Name of Domain on which this server resides, using capital letters.

2. Using capital letters, enter up to 15 alphanumeric characters of the PDC NetBIOS Name, which is the computer name of the authentication server, or Primary Domain Controller.

3. Enter the PDC IP Address, which is the authentication server's IP address.

4. Enter the Administrator Username and Administrator Password. This account used for joining the domain must have administrator privileges.

5. Click Join Domain to save your entries and to submit a request for the R3000 to join the domain.

TIP: If entries in the NT Authentication Server Details frame are

modified after joining the domain, you must join the domain again.

NOTE: Click Save if you are only pre-configuring the box. This option lets you save credentials without re-entering the information each time the domain is joined, or if the R3000 gets out of sync with the Primary Domain Controller.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 81

CHAPTER 3: NT AUTHENTICATION SETUP CREATE AN NT DOMAIN

Create an NT Domain

After joining the domain, go to the Group section of the console and add an NT domain that contains entities to be authenticated.

Add an NT domain

1. Click NT in the navigation panel to open the pop-up menu, and select Add Domain to open the Create Domain Controller dialog box:

Fig. 3-2 Create Domain Controller

2. In the Domain Name field, enter the name of the domain on which the R3000 resides, using capital letters.

NOTES: The Domain Name must be the same name entered in the Authentication Settings window’s Name of Domain field.

The alphanumeric NT domain name must be at least two characters but less than 64 characters in length, and can contain a hyphen (-) and underscore (_), though the hyphen cannot be the first or last character of the name.

3. In the Domain Controller field, enter the name of the authentication server for the domain.

4. Enter the domain controller’s IP Address.

82 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 3: NT AUTHENTICATION SETUP CREATE AN NT DOMAIN

5. In the UserName field, enter the username of the admin- istrator.

6. Enter the password in the Password and Confirm Pass- word fields.

7. Click Apply to add the domain to the tree.

Refresh the NT branch

Click NT in the navigation panel to open the pop-up menu, and select Refresh whenever changes have been made in this branch of the tree.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 83

CHAPTER 3: NT AUTHENTICATION SETUP CREATE AN NT DOMAIN

View or modify NT domain details

Domain Settings

1. Double-click NT in the navigation panel to open the NT branch of the Group tree. Select the NT domain you added, and choose Domain Details from the pop-up menu to display the default Settings tab of the NT Domain Details window:

Fig. 3-3 NT Domain Details window, Settings tab

NOTE: To enter profile information for NT groups and users once domain settings are established, see Set up NT Domain Groups, Members.

84 8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE

CHAPTER 3: NT AUTHENTICATION SETUP CREATE AN NT DOMAIN

2. For the Domain Settings:

• The Domain Name entered in the Create Domain

Controller dialog box displays greyed-out and cannot be modified.

• The following fields can be modified: name of the

domain Controller, IP Address, User Name, Pass- word, and Confirm Password.

Whenever criteria on this tab is modified:

a. The password from the Password field must be

entered in the Confirm Password field for verification.

b. Click Modify to apply your settings.

8E6 TECHNOLOGIES, R3000 INTERNET FILTER AUTHENTICATION USER GUIDE 85

CHAPTER 3: NT AUTHENTICATION SETUP CREATE AN NT DOMAIN

Default Rule

1. Click the Default Rule tab to display the Default Rule settings of the NT Domain Details window:

Fig. 3-4 NT Domain Details window, Default Rule tab

2. For the Default Rule:

• “Rule0, the Minimum Filtering Level” displays by

default as the Default Rule. If this rule is used, it will be applied to all groups and members in the NT domain without a filtering profile established.

• “Default Block Page” is selected by default as the
