TouchWare™ Software for Windows CE .NET
OEM Developer’s Guide
3M Touch Systems
™
3M Touch Systems Proprietary Information
The information provided in this document is intended as a guide only. For the latest detailed engineering specifications, please contact your 3M Touch Systems Application Engineer. 3M Touch Systems is committed to continually improving product designs, as a result, product specifications may be subject to change without notification.
NOTICE: Given the variety of factors that can affect the use and performance of a 3M Touch Systems Product (the “Product”), including that solid state equipment has operation characteristics different from electromechanical equipment, some of which factors are uniquely within User’s knowledge and control, it is essential that User evaluate the 3M Touch Systems Product and software to determine whether it is suitable for User’s particular purpose and suitable for User’s method of application. 3M Touch Systems’ statements, engineering/technical information, and recommendations are provided for User’s convenience, but their accuracy or completeness is not warranted. 3M Touch Systems products and software are not specifically designed for use in medical devices as defined by United States federal law. 3M Touch Systems products and software should not be used in such applications without 3M Touch Systems’ express written consent. User should contact its sales representative if User’s opportunity involves a medical device application.
IMPORTANT NOTICE TO PURCHASER: Specifications are subject to change without notice. These 3M Touch Systems’ Products and software are warranted to meet their published specifications from the date of shipment and for the period stated in the specification. 3M Touch Systems makes no additional warranties, express or implied, including but not limited to any implied warranties of merchantability or fitness for a particular purpose. User is responsible for determining whether the 3M Touch Systems Products and software are fit for User’s particular purpose and suitable for its method of production, including intellectual property liability for User's application. If the Product, software or software media is proven not to have met 3M Touch Systems’ warranty, then 3M Touch Systems’ sole obligation and User’s and Purchaser’s exclusive remedy, will be, at 3M Touch Systems’ option, to repair or replace that Product quantity or software media or to refund its purchase price. 3M Touch Systems has no obligation under 3M Touch Systems’ warranty for any Product, software or software media that has been modified or damaged through misuse, accident, neglect, or subsequent manufacturing operations or assemblies by anyone other than 3M Touch Systems. 3M Touch Systems shall not be liable in
any action against it in any way related to the Products or software for any loss or damages, whether non-specified direct, indirect, special, incidental or consequential (including downtime, loss of profits or goodwill) regardless of the legal theory asserted.
© 2002-03 3M All rights reserved. Document Title: TouchWare™ Software for Windows CE .NET™ OEM Developer’s Guide Document Number: 19-261, Version 2.3
MicroTouch, the MicroTouch logo, ChassisTouch, ClearTek, Microcal, ThruGlass, TouchPad, TouchPen, TouchWare, TouchTek, TruePoint, and ToughTouch are either registered trademarks or trademarks of 3M in the United States and/or other countries.
Microsoft, MS-DOS, Windows, Windows NT, Windows CE .NET Platform Builder, eMbedded Visual Tools, and Visual C++ are registered trademarks or trademarks of Microsoft Corporation.
3M Touch Systems Proprietary Information
Contents
Chapter 1 Introduction
What You Need to Know .............................................................................................. 6
Chapter 1 Installing TouchWare for Windows CE .NET
Step 1: Copy Binary Files to the platform .................................................................... 7
Step 2: Install Touch Screen Drivers ............................................................................ 7
Step 3: Install Touch Screen Driver Registry Settings ................................................. 8
Step 4: Setting up the Control Panel (optional) ............................................................ 9
Step 5: Build ................................................................................................................. 9
Appendix A Frequently Asked Questions
What 3M Touch Systems drivers are loaded for the touch screen?............................. 11
How can I start the TouchWare control panel from my application? Do I need
to run the control panel that exposes other applets to the user?.................................. 11
How can I adjust the double-click properties of the 3M Touch Systems
touch screen? .............................................................................................................. 11
How much space do the 3M Touch Systems touch screen drivers add to my Windows
CE .NET image?.......................................................................................................... 12
Appendix B Files Contained In Distribution Media .........................................................13
3M Touch Systems Proprietary Information
CHAPTER 1
Introduction
The TouchWare™ software for Windows CE .NET™ OEM Developer’s Guide describes the steps necessary to integrate 3M Touch Systems TouchWare™ software into a Microsoft Windows CE .NET™ system build. This kit contains the following items:
1. The TouchWare™ software touch screen driver for Windows CE .NET™ is the
software the system uses to communicate with the touch screen. It provides “mouse emulation” touch screen functionality for applications running under Windows CE .NET™.
2. TouchWare™ software for Windows CE .NET™ adds an applet to the Windows
CE .NET™ control panel. This applet allows the user to calibrate the touch screen and to adjust certain touch screen preferences.
3. The source files for the touch screen control panel are included to allow
modification of the control panel or integration of touch screen functions into an application, as required.
TouchWare™ software for Windows CE .NET™ supports the serial RS-232 controller on the X86 platform only.
To successfully install TouchWare™ software for Windows CE .NET™, you need to install the following components:
1. The drivers for the controller
2. The TouchWare™ software control panel. If you like the way the control panel
looks as delivered, you can use the binary files supplied and concentrate on the drivers only. If you want to change the control panel, you must install both the drivers (using Microsoft Windows CE .NET™ Platform Builder ®) and the TouchWare™ software control panel sources (using Microsoft eMbedded® Visual Tools VC++).
3M Touch Systems Proprietary Information
TouchWare™ Software for Windows CE .NET™ 6
The process involves 5 steps.
1. Copying the appropriate binary files for your controller to the platform.
2. Install touch screen driver DLLs.
3. Install touch screen driver registry settings.
4. (Optional) Modifying the TouchWare™ software control panel using eMbedded Visual C++.
5. Building the program.
What You Need to Know
This document assumes you are familiar with and have the skills necessary to successfully modify, build, and run the Windows CE .NET™ operating system on your target hardware.
3M Touch Systems Proprietary Information
CHAPTER 2
Installing TouchWare™ Software for Windows CE .NET™
Step 1: Copy Binary Files to the platform
From the supplied source packet (\x86 directory), copy the files listed below to \WINCE420\PLATFORM\<PLATFORMNAME>\FILES\:
• MTmouse.dll - mouse DDI touch screen driver
• MTTchCmn.dll - common functions
• MtsUtils.dll - control utilities
• MtsLin.dll – linearization function
• MTTchSer.dll - serial touch screen driver
If you are NOT changing the control panel also copy:
• MtsPanel.cpl - control panel applet
Step 2: Install Touch Drivers
Cut and paste the x86\Platform.bib.txt file into the end of your Platform.bib file.
; ******************************************************* ; * Platform.bib for * ; * 3M Touch Systems TouchWare™ for Windows CE .NET * ; * Copyright © 1999-2003 3M * ; ******************************************************* IF ODO_NOTOUCH ! ; --- Touch Driver --­; files: MTmouse.dll - Mouse DDI touch screen driver ; MTTchCmn.dll - common functions ; MTTchSer.dll - serial touch screen driver ; MtsLin.dll - linearization function ; MtsPanel.cpl - control panel ; MtsUtils.dll - control panel utilities MTmouse.dll $(_FLATRELEASEDIR)\MTmouse.dll NK SH MTTchCmn.dll $(_FLATRELEASEDIR)\MTTchCmn.dll NK SH
; Include Serial touch screen driver in Windows CE .NET image
3M Touch Systems Proprietary Information
TouchWare™ Software for Windows CE .NET™ 8
MTTchSer.dll $(_FLATRELEASEDIR)\MTTchSer.dll NK SH
; Control panel files. ; Remove them if you do not want a control panel.
MtsPanel.cpl $(_FLATRELEASEDIR)\MtsPanel.cpl NK SH MtsUtils.dll $(_FLATRELEASEDIR)\MtsUtils.dll NK SH MtsLin.dll $(_FLATRELEASEDIR)\MtsLin.dll NK SH
ENDIF ; *** end TouchWare™ for Windows CE .NET ******
Step 3: Modify Platform.reg
Cut and paste the x86\Platform.reg.txt file into the end of your Platform.reg file.
; ******************************************************** ; * Platform.reg for * ; * 3M Touch Systems TouchWare™ for Windows CE .NET * ; * Copyright © 1999-2003 3M * ; ******************************************************** ; Touch screen driver settings ; -----------------------------------------------------------­ [HKEY_LOCAL_MACHINE\HARDWARE\DEVICEMAP\TOUCH] “DriverName”=“MTmouse.dll” [HKEY_LOCAL_MACHINE\HARDWARE\DEVICEMAP\TOUCH\Parameters] "VersionMajor"=dword:5 "VersionMinor"=dword:6 "VersionReleaseType"=dword:1 ; CommPort set to serial port used by touch screen controller. ; CommPort is one of the following: ; 1-4 = COM1-COM4 Serial Port touch screen [HKEY_LOCAL_MACHINE\HARDWARE\DEVICEMAP\TOUCH\Parameters\0000] ; For serial (RS232) controller set dword: to 1 or 2 (COM1 or COM2). ; Remember that Windows CE .NET uses the first COM port for ; debugging so that PC COM2 is Windows CE .NET COM1
; Commport is set to 1 (default) COM1 without debugging ; or COM2 with debugging port. "CommPort"=dword:1
; Baudrate is set to 9600 baud (default) 9600 = 0x2580. "Baudrate"=dword:2580 "Is_X_Horiz"=dword:1 "Flip_X"=dword:0 "Flip_Y"=dword:0 ; TouchMode is one of the following: ; 0 = desktop (default) ; 1 = drawing ; 2 = button [HKEY_CURRENT_USER\ControlPanel\MtsTch\0000] "TouchMode"=dword:0 "SwapMouseButton"=dword:0 "HorizontalOffsetOn"=dword:0 "VerticalOffsetOn"=dword:0 "VerticalCursorOffset"=dword:0 ; *** end TouchWare™ for Windows CE .NET ********
3M Touch Systems Proprietary Information
TouchWare™ Software for Windows CE .NET™ 9
Step 4: (Optional) Setting up the Control Panel
Note: Not available with TouchWare™ Software for Windows CE .NET™ part 19-657
1. Start eMbedded Visual C++.
2. Click on File / Open Workspace and locate MtsPanel.vcw in the folder you created when you installed TouchWare™ software.
3. After changing the control panel skin and rebuilding it, copy MtsPanel.cpl to your platform, \WINCE420\PLATFORM\<PLATFORMNAME>\FILES\.
Step 5: Build
After making the necessary platform modifications, the project may be built as usual. The TouchWare™ software applet should appear on the Windows CE .NET™ control panel. It may be used to calibrate the touch screen and configure touch screen preferences.
3M Touch Systems Proprietary Information
APPENDIX A
Frequently Asked Questions
What TouchWare™ software drivers are loaded for the touch screen?
TouchWare™ software loads the following drivers:
• MTmouse.dll – touch screen mouse driver
• MTTchCmn.dll – touch screen common functions
• MTTchSer.dll – touch screen serial port driver
(for RS-232 serial touch screen controller used)
How can I start the TouchWare™ software control panel from my application? Do I need to run the control panel that exposes other applets to the user?
An application may start the TouchWare™ software control panel without running Control.exe (which will show all control panel applets to the user).
The TouchWare™ software control panel may be started programmatically by running Ctlpnl.exe and passing it the name of the TouchWare™ software control panel applet.
Example:
CreateProcess( TEXT(“Ctlpnl.exe”), TEXT(“MtsPanel.cpl”), NULL, NULL, 0, 0, NULL, NULL, NULL, NULL );
How can I adjust the double-click properties of TouchWare™ software?
Use the Mouse control panel applet to adjust the double-click properties. Since the touch screen emulates the mouse, this setting controls the double-click sensitivity for the touch screen as well.
3M Touch Systems Proprietary Information
TouchWare™ Software for Windows CE .NET™ 12
How much space do the TouchWare™ software touch screen drivers add to my Windows CE .NET™ image?
Driver Bytes
MTTchCmn.dll 20992 MTTchSer.dll 5632 MtsLin.dll 18944 MtsPanel.cpl 20480 MtsUtils.dll 20992 MTmouse 3584
Altogether, adding these files into your Windows CE .NET™ platform will add 90624 bytes to the image (nk.bin).
3M Touch Systems Proprietary Information
APPENDIX B
Files Contained In Distribution Media
Table 1: Pre-built Modules
Path Description
\tw561ce\x86\MTTchSer.dll Touch screen serial port driver
\tw561ce\x86\MTmouse.dll Touch screen mouse emulator
\tw561ce\x86\MTTchCmn.dll Touch screen common functions
\tw561ce\x86\MtsLin.dll Touch screen linearization function
\tw561ce\x86\MtsUtils.dll Touch screen control panel utilities
\tw561ce\x86\MtsPanel.dll Touch screen control panel applet
Table 2: Configuration files
Path Description
\tw561ce\x86\platform.bib Touch screen platform.bib
\tw561ce\x86\ platform.reg Touch screen platform.reg
3M Touch Systems Proprietary Information
TouchWare™ Software for Windows CE .NET™ 14
Table 3: Control Panel Source Files
(Not available with TouchWare™ Software for Windows CE .NET™ part 19-657)
Path Description
\tw561ce\Cepanel\INCLUDE\APISET.H API header
\tw561ce\Cepanel\INCLUDE\BLOCK1.H Block1 header
\tw561ce\Cepanel\INCLUDE\BLOCK2.H Block2 header
\tw561ce\Cepanel\INCLUDE\CEFOOBAR.H Platform builder link ‘fix’
\tw561ce\Cepanel\INCLUDE\CPL.H Control Panel header
\tw561ce\Cepanel\INCLUDE\ENUMS.H Enum header
\tw561ce\Cepanel\INCLUDE\MTSAPI.H MtsUtils.dll API functions
\tw561ce\Cepanel\INCLUDE\MTSLIN.H Mtslin.dll header
\tw561ce\Cepanel\INCLUDE\ MTSTYPES.H Types header
\tw561ce\Cepanel\INCLUDE\ MTSUTILS.H 3M Touch Systems Utility header
\tw561ce\Cepanel\LIB\X86REL\MtsPanel.lib MtsPanel.cpl import library
\tw561ce\Cepanel\LIB\X86REL\MtsUtils.lib MtsUtils.dll import library
\tw561ce\Cepanel\LIB\X86REL\MtsPanel.lib MtsPanel.dll import library
\tw561ce\Cepanel\MtsPanel\CEARROW.H Cursor offset
\tw561ce\Cepanel\MtsPanel\MISC.CPP Miscellaneous control panel functions
\tw561ce\Cepanel\MtsPanel\MTSFREQ.H Frequency header
\tw561ce\Cepanel\MtsPanel\MtsPanel.cpp Control panel main module source
\tw561ce\Cepanel\MtsTouch\MtsPanel.def Control panel export definitions
\tw561ce\Cepanel\MtsTouch\MtsPanel.h Control panel header file
\tw561ce\Cepanel\MtsTouch\MtsPanel.ico 3M Touch Systems icon
\tw561ce\Cepanel\MtsTouch\MtsPanel.rc Control panel resources
\tw561ce\Cepanel\MtsTouch\MtsPanel.vcp Control panel project file
\tw561ce\Cepanel\MtsTouch\MtsPanel.vcw Control panel workspace
\tw561ce\Cepanel\MtsPanel\MTSPEN.H Pen header
\tw561ce\Cepanel\MtsTouch\PAGE1.CPP Control panel property sheet page 1 source
\tw561ce\Cepanel\MtsTouch\PAGE2.CPP Control panel property sheet page 2 source
\tw561ce\Cepanel\MtsTouch\PAGE3.CPP Control panel property sheet page 3 source
\tw561ce\Cepanel\MtsTouch\PAGE4.CPP Control panel property sheet page 4 source
\tw561ce\Cepanel\MtsTouch\PAGE5.CPP Control panel property sheet page 5 source
\tw561ce\Cepanel\MtsTouch\RESOURCE.H Control panel resource header
\tw561ce\Cepanel\MtsTouch\SHEET.CPP Control panel property sheet source
3M Touch Systems Proprietary Information
