3M Building and Construction Market Center
HVAC
Solutions
Building Your Success on Our Products
ofContents
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
..............................................Printed UL Tapes |
3 |
|
................................................Specialty Tapes |
8-10 |
|||||||
Aluminum Foil Tapes....................................... |
4 |
|
Fire Barrier........................................................ |
10 |
|||||||
Duct Tapes........................................................ |
5-6 |
Electrical Products........................................... |
11 |
||||||||
Spray Adhesives and Accessories................. |
6-7 |
Personal Safety................................................ |
11-12 |
||||||||
Sealants and Aerosols .................................... |
7 |
|
Abrasive Products............................................ |
12 |
|||||||
2
PrintedUL TapesULTapes
3M™ Venture Tape™ Aluminum Foil Tape 1581A
Printed 2 mil heavy duty, high strength aluminum foil coated with a specially formulated pressure sensitive acrylic adhesive system. Superior adhesion and conformance for use with fiberglass ductboard systems. Performance and materials guaranteed to meet or exceed UL181A-P quality standards; also meets the requirements of UL181B-FX, flexduct standard. Listed 89FL.
Applications: Primarily used for sealing fiberglass ductboard and flexduct. May also be used on metal connections, flexible duct, flexible duct connections to ductboard, and metal duct.
Technical Data |
Imperial |
Metric |
|
|
|
|
|
Thickness |
4.0 mils |
0.10 mm |
|
Peel Adhesion |
60 oz/in |
16.7 N/25 mm |
|
Shear Strength |
>24 hrs @ 2.2 psi |
>24 hrs @ 15.2 kPa |
|
Tensile Strength |
27 lb/in |
122 N/25 mm |
|
Elongation |
10% |
10% |
|
Service Temperature |
-40°F to 300°F |
-40°C to 149°C |
|
Roll Size |
2½, 3 in x 60 yds |
64, 72 mm x 55 m |
|
3M™ Venture Tape™
Flexible Duct Closure Tape
1599B UL181B-FX
Printed 3 mil, UV resistant polypropylene film with a cold weather acrylic adhesive system. This adhesive performs well in either sub-zero cold or warm temperatures. Meets or exceeds all requirements of UL181B-FX related to closure systems for flexible air ducts and air connectors. 25/50 rated for Flame Spread and Smoke Development.
Applications: Primarily used for sealing flexible air ducts, air connectors, for securing flex ducts to duct wrap facings and for metal and metal to metal connections. Adheres well to rubberized foam pipe
insulation.
Colors: Black, Silver
Technical Data |
Imperial |
Metric |
|
|
|
|
|
Thickness |
3.0 mils |
0.08 mm |
|
Peel Adhesion |
30 oz/in |
8.3 N/25 mm |
|
Shear Strength |
>24 hrs @ 2.2 psi |
>24 hrs @ 15.2 kPa |
|
Tensile Strength |
20 lb/in |
90 N/25 mm |
|
Elongation |
130% |
130% |
|
Service Temperature |
-40°F to 185°F |
-40°C to 85°C |
|
Roll Size |
2, 3 in x 120 yds |
48, 72 mm x 110 m |
|
3M™ Venture Tape™
Mastik Duct Sealing Tape
1580P UL181B-FX
1580P is a printed, 2 mil annealed aluminum foil coated with a heavy mastik adhesive. 1580P meets UL181B-FX requirements, and excels in demanding temperature and humidity
environments. Provides superior performance and durability. Hand tearable and conformable.
Applications: Indoor/outdoor, instant water resistant bond on sheet metal, flex duct and duct wrap vapor barriers.
Technical Data |
Imperial |
Metric |
|
|
|
|
|
Thickness |
17.0 mils |
0.43 mm |
|
Peel Adhesion |
112 oz/in |
31.2 N/25 mm |
|
Shear Strength |
>24 hrs @ 2.2 psi |
>24 hrs @ 15.2 kPa |
|
Tensile Strength |
20 lb/in |
89 N/25 mm |
|
Elongation |
5% |
5% |
|
Service Temperature |
-20°F to 200°F |
-29°C to 93°C |
|
Roll Size |
2, 3 in x 100 ft |
48, 72 mm x 30.5 m |
|
3M™ Venture Tape™
Cloth Duct Tape 1515
UL181B-FX
Printed 1515 is a high strength, premium quality UL181B-FX cloth tape coated with a high performance pressure sensitive adhesive system. Specifically designed to meet demanding HVAC requirements.
Applications: Sealing, closure, and repair of sheet metal ductwork and general purpose heavy duty service.
Colors: Black, Grey
Technical Data |
Imperial |
Metric |
|
Thickness |
14.0 mils |
0.36 mm |
|
Peel Adhesion |
75 oz/in |
20.8 N/25 mm |
|
Shear Strength |
>24 hrs @ 2.2 psi |
>24 hrs @ 15.2 kPa |
|
Tensile Strength |
38 lb/in |
171 N/25 mm |
|
Elongation |
21% |
21% |
|
Service Temperature |
0°F to 180°F |
32°C to 82°C |
|
Roll Size |
2 in x 60 yds |
48 mm x 55 m |
|
3M™ Venture Tape™ Line
Set Tape 1507
A printed UV resistant polypropylene film with a solvent acrylic "CW" adhesive system. This adhesive performs well in either sub-zero cold or tropical temperatures. Designed to perform in direct sunlight, this product is UV resistant and UL Listed.
Applications: Primarily used for taping
line sets. Works well on foam pipe insulation used in line sets. 1507 is waterproof, weatherproof and designed for outdoor use.
Colors: Black, Black Printed, White
Technical Data |
Imperial |
Metric |
|
|
|
|
|
Thickness |
3.0 mils |
0.08 mm |
|
Peel Adhesion |
30 oz/in |
8.3 N/25 mm |
|
Shear Strength |
>24 hrs @ 2.2 psi |
>24 hrs @ 15.2 kPa |
|
Tensile Strength |
20 lb/in |
90 N/25 mm |
|
Elongation |
130% |
130% |
|
Service Temperature |
-40°F to 185°F |
-40°C to 85°C |
|
Roll Size |
2, 3 in x 60 yds |
48, 72 mm x 55 m |
|
3
AluminumFoil Tapes Foil Tapes
3M™ Venture Tape™ Aluminum Foil Tape 3520CW
A 2 mil, high strength aluminum foil with an aggressive, high temperature acrylic adhesive system. Provides an excellent vapor seal on fibrous and sheet metal ducts. Malleable foil conforms well around corners and to irregular surfaces.
Special cold weather acrylic pressure sensitive adhesive system combines superior quick stick at normal temperatures with superior low temperature performance - the ultimate in cold weather tapes, excellent at normal and elevated temperatures.
Technical Data |
Imperial |
Metric |
||
Thickness |
3.5 mils |
0.09 mm |
|
|
Peel Adhesion |
50 oz/in |
13.9 N/25 mm |
||
Shear Strength |
>24 hrs @ 2.2 psi |
>24 hrs @ 15.2 kPa |
||
Tensile Strength |
21 lb/in |
95 N/25 mm |
||
Elongation |
4% |
4% |
|
|
Service Temperature |
-40°F to 250°F |
-40°C to 121°C |
||
Roll Size |
2, 2½, 3, 4 in |
48, 64, 72, 99 mm |
||
x 50 yds |
x 46 m |
|||
|
||||
3M™ Venture Tape™ FSK
Insulation Tape 1525CW
Tri-directionally reinforced with a 2x3 fiberglass scrim, UL 723 listed foil/scrim/ kraft lamination. This tape conforms well to both fibrous ductboard and blankets. Coated with a special cold weather, acrylic, pressure sensitive adhesive system, 1525CW combines superior quick stick at normal temperatures with superior low temperature performance.
Recommended for use down to -40°F (-40°C) as well as normal and very high temperatures. This is the ultimate in cold weather tapes.
Technical Data |
Imperial |
Metric |
|
Thickness |
9.5 mils |
0.24 mm |
|
Peel Adhesion |
45 oz/in |
12.5 N/25 mm |
|
Shear Strength |
>24 hrs @ 2.2 psi |
>24 hrs @ 15.2 kPa |
|
Tensile Strength |
40 lb/in |
181 N/25 mm |
|
Elongation |
2% |
2% |
|
Service Temperature |
-40°F to 240°F |
-40°C to 116°C |
|
Roll Size |
2, 3, 4, 5, 6 in |
48, 72, 99, 127, |
|
|
x 50 yds |
152 mm x 46 m |
|
3M™ Venture Tape™ Aluminum Foil Tape 1520CW
A 1.75 mil, high strength aluminum foil coated with an aggressive, high temperature acrylic adhesive system. Provides an excellent vapor seal on both fibrous and sheet metal ducts. Malleable foil also conforms well around corners and to irregular surfaces.
Special cold weather acrylic pressure sensitive adhesive system combines superior quick stick at normal temperatures with superior low temperature performance excellent at elevated temperatures as well; UL 723 Listed.
Technical Data |
Imperial |
Metric |
|
|
|
|
|
Thickness |
3.3 mils |
0.08 mm |
|
Backing Thickness |
1.8 mils |
0.05 mm |
|
Peel Adhesion |
45 oz/in |
12.5 N/25 mm |
|
Shear Strength |
>24 hrs @ 2.2 psi |
>24 hrs @ 15.2 kPa |
|
Tensile Strength |
21 lb/in |
95 N/25 mm |
|
Elongation |
4% |
4% |
|
Service Temperature |
-40°F to 250°F |
-40°C to 121°C |
|
Roll Size |
2, 2½, 3 in |
48, 64, 72 mm |
|
|
x 50 yds |
x 46 m |
|
3M™ Venture Tape™
Aluminum Foil High
Temperature Tape 3243
A 2 mil dead soft aluminum foil coated with a high temperature, extremely aggressive solvent acrylic adhesive system. Specifically designed for high heat flue closure applications; applies easily to sheet metal
ducts on flat and irregular surfaces and excels in demanding temperature applications.
Applications: Can be used in most flue pipe and chimney pipe applications in temperatures up to 425°F.
Technical Data |
Imperial |
Metric |
|
Thickness |
4.0 mils |
0.10 mm |
|
Peel Adhesion |
45 oz/in |
12.5 N/25 mm |
|
Shear Strength |
>24 hrs @ 2.2 psi |
>24 hrs @ 15.2 kPa |
|
Tensile Strength |
25 lb/in |
113 N/25 mm |
|
Elongation |
5% |
5% |
|
Service Temperature |
-40°F to 425°F |
-40°C to 218°C |
|
Roll Size |
3 in x 50 yds |
72 mm x 46 m |
|
4
