3M™ D Sub EMI Junction Shell
Metalized Plastic
• Protection from EMI/ESD
• Easy assembly reduces time and labor to ensure
low applied cost
• Light weight, compact design
• Strain relief compensates for multiple cable
diameters
• Jackscrews provide positive retention
• RoHS* compliant
Physical
Shell
Material:
Plating:
Compression Insert:
Material:
Flammability:
Durometer:
Hardware:
Material:
Plating:
Mounting Hardware:
Date Modified: August 19, 2005
ABS
Nickel Over Copper
Thermo Plastic Elastomer
UL 94V-0
75 + / - 5
(2) Jackscrews #4-40 × .438
(2) Saddle Washers
(2) Nuts 4-40 UNC for 9, 15 & 25 position
(3) Nuts 4-40 UNC for 37 position
(2) Screws 4-40 UNC for 9, 15 & 25 position
(3) Screws 4-40 UNC for the 37 position
Steel
Zinc
See Specification Sheet TS-0142
TS-0032-10
Sheet 1 of 2
Environmental
Temperature Rating:
"RoHS compliant" means that the product or part does not contain any of the following substances in excess of the following maximum concentration values
in any homogeneous material, unless the substance is in an application that is exempt under RoHS: (a) 0.1% (by weight) for lead, mercury, hexavalent
chromium, polybrominated biphenyls or prolybromianted diphenyl ethers; or (b) 0.01% (by weight) for cadmium. Unless otherwise stated by 3M in writing,
3M
Interconnect Solutions
http://www.3M.com/interconnects/
*RoHS = Directive 2002/95/EC, Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment
0°C to +75°C
this information represents 3M's knowledge and belief based upon information provided by third party suppliers to 3M.
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
3M™ D Sub EMI Junction Shell
y
Metalized Plastic
Table 1 - Compression Inserts
0.285
[ 7.24 ]
0.370
[ 9.40 ]
0.570
[ 14.48 ]
Dimensions
0.360
[ 9.14 ]
0.450
[ 11.43 ]
0.655
[ 16.64 ]
0.255
[ 6.48 ]
0.300
[ 7.62 ]
0.500
[ 12.70 ]
Insert
For
3357-6509
3357-6515
3357-6525
3357-6537
1 2 3 4 5 6
OD ID OD ID OD ID OD ID OD ID OD ID
0.475
[ 12.07 ]
0.600
[ 15.24 ]
0.810
[ 20.57 ]
0.320
[,8.13 ]
0.450
[ 11.43 ]
0.650
[ 14.48 ]
0.360
[ 9.14 ]
0.450
[ 11.43 ]
0.700
[ 17.78 ]
D
0.315
[ 8.00 ]
0.410
[ 10.41 ]
0.620
[ 15.75 ]
0.360
[ 9.14 ]
0.450
[ 11.43 ]
0.655
[ 16.64 ]
0.360
[ 9.14 ]
0.450
[ 11.43 ]
0.655
[ 16.64 ]
0.210
[ 5.33 ]
0.230
[ 5.84 ]
0.425
[ 10.80 ]
N/A N/A
N/A N/A 0.600
0.655
[ 16.64 ]
0.350
[ 8.89 ]
G
0.475
[ 12.07 ]
[ 15.24 ]
0.810
[ 20.58 ]
F
E
A
B
See note 3
C
Junction Shell
see Table 2
Table 2- Junction Shell
3M Part
Number
3357-6509
3357-6515 1.54
3357-6525 2.09
3357-6537 2.73
Note:
1. Compression inserts cannot be ordered separately.
2. Use appliable Jack Screw or Jack Socket Kit mounting hardware.
3. The 37 position shell has 3 cover screw holes.
A B C D E F Min Max
1.22
[ 31.2 ]
0.64
[ 16.3 ]
[ 39.1 ]
[ 53.1 ]
[ 69.3 ]
Dimensions Cable O.D. Range
1.58
[ 40.13 ]
1.88
[ 47.75 ]
1.71
[ 43.43 ]
2.12
[ 53.85 ]
0.40
[ 10.2 ]
0.52
[ 13.2 ]
0.73
[ 18.5 ]
Ordering Information
3357-65XX-XX
G (Dia Collar)
A
B
C
D
E
F
Compression Inserts
see Table 1
0.984
0.64
[ 16.3 ]
0.71
[ 18.0 ]
0.91
[ 23.11 ]
[ 24.99 ]
1.312
[ 33.32 ]
1.857
[ 47.17 ]
2.500
[ 63.50 ]
0.210
[ 5.33 ]
0 . 2 3
[ 5.84 ]
0.35
[ 8.89]
0.320
[ 8.13 ]
0.45
[ 11.43]
0.65
[ 16.51 ]
Inch
[mm]
Tolerance Unless Noted
.0 .00 .000
inch ±.1 ±.01 ±.005
[ ] Dim e ns ion s for Re fere nce
Onl
3M
Interconnect Solutions
http://www.3M.com/interconnects/
Connector Size
09 = 9 Position
15 = 15 Position
25 = 25 Position
37 = 37 Position
Blank = Non-RoHS compliant backshells
1C = RoHS compliant backshells
3M is a trademark of 3M Company.
For technical, sales or ordering information call
TS-0032-10
Sheet 2 of 2
800-225-5373
