E
W
N
Shanghai 37 Degree Technology Co.,Ltd.
Quick Start Guide
www.37body.com
S
N
Installing the app and assembling the
bracelet
Installing the app: Scan the RQ code underside of the packaging
to install the app.
Assembling the bracelet: Install the bracelet body into the band
as shown.
1
Bracelet Charging and Smartphone Pairing
Bracelet charging: Charge the 37° Bracelet as shown below.
Aim the metal surface of the charging adapter at the metal
contact on the back of the bracelet. (Red flash on the indicator
light means low battery, in which case the bracelet should be
charged.)
Smartphone pairing: Pairing the 37° Bracelet with a smartphone
via the app must be performed when charging is connected via
a USB cable. Search for the bracelet as prompted. Indigo flash on
the bracelet means pairing is completed.
2
Optimal Measurement
Ulna styloid process
1. The bracelet is best worn at two fingers’ width
from the ulna styloid process of the left hand.
metal contact
2. The metal contact on the back of the bracelet
should be in the same direction with the thumb.
3
left hand
Specifications
Weight
21g
Battery type
Lithium polymer
Full length
247mm
Working temperature
-10°C to 45°C
System requirement
Android 4.3 or above;
iOS7 or above
Adjustable length
145mm to 209mm
4
Battery capacity
157mAh
Connected by
Bluetooth 4.0
Disclaimer
This product measures biorhythms by monitoring ambulatory blood pressure
changes to help the user live a healthier life. It cannot be used as a basis for any
medical diagnosis.
The 37° Bracelet is not categorized as medical apparatus. The 37° Bracelet, its related
applications, and information thereby obtained shall not be used in medical diagnosis,
treatment, or relieving of any disease or any conditions. To prevent injuries from
excessive exercise or user’s self-diagnosis, please consult a licensed doctor before
making changes to your exercise, sleep, nutrition, or medication.
Note: Ambulatory blood pressure is not the same concept as clinical blood pressure
used in medical settings.
Indicator lights
Green light Fully charged
Green flash Charging
Red flash Low battery
Indigo flash once Bracelet paired successfully.
Yellow flash Bracelet turning off or entering flight mode
Yellow light Bracelet turning on or exiting flight mode
Blue flash Bracelet running measurement
Pink flash Please open the app and connect the bracelet to
synchronize data.
5
Names and content of toxic substances
Hazardous substance
Lead
Mercury (Hg)
Cadmium (Cd) ○
Hexavalent chromium (Cr VI) ○
Polybrominated biphenyl (PBB) ○
Polybrominated diphenyl ether (PBDE) ○
Remarks
〇 Means the toxic substance content in the materials used in the part conforms to
SJ/T 11363-2006 regulations.
× Means the toxic substance content in at least one of the materials used in the part
is higher than the limit stated in SJ/T 11363-2006.
This product conforms to the RoHS Directive of the E.U.
(Pb)
For those with sensitive skin and in hot and humid environments, do
not wear the bracelet tightly for extended periods of time. Otherwise,
!
rashes and itches may occur due to the skin's lack of opportunity to
breathe.
Body Clasp Band
×
○ ×
○
○
○ ○
○
○ ○
○
○ ○
○
○
○
○
○
Power adapter
○
○
6
FCC Regulations:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
This device has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiated radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
7
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC Note:
Caution: Changes or modifications not expressly approved by the party responsible
for compliance could void the user‘s authority to operate the equipment.
S8
RF Exposure Information
This device meets the government’s requirements for exposure to radio waves.
This device is designed and manufactured not to exceed the emission limits for
exposure to radio frequency (RF) energy set by the Federal Communications
Commission of the U.S. Government.
This device complies with FCC radiation exposure limits set forth for an uncontrolled
environment.
Assessment of compliance of the product with the requirements relating to the Radio
and Telecommunication Terminal Equipment Directive (EC Directive 1999/5/EC) was
performed by Telefication BV (Notified Body No.0560),
9
