721v1.7
Package Contents
7” Tablet PC 1 set
USB Cable 1 set
AC Adaptor 1 set
User manual 1 set
Product overview
<1>
9
721v1.7
Power On/Off
Power On: Slide and hold the power button 3
seconds.>>Tap and slide “unlock icon” to the
other side.
Power Off: Normal power off- Slide and hold the
power button 3 seconds.>>Tap “Power off”.>> OK
to confirm the power off.
Sleep Mode On/Off (power save mode):
Device can turn sleep mode on/off with sliding &
releasing the power button when user wants to
save the battery power.
Disable the sleep mode: User can slide the power
button, and then slide the Unlock bar on screen.
Volume buttons
Enlarge or silent down the volume of speaker.
HDMI
Connect with HDMI input of other device.
LED indicator
Status:
LED off :
1. Device off
2. Device on
3. Fully charged
10
721v1.7
Red LED on:
1. Device on or off
2. Charging
Green LED on: Turn device on
Touch-Screen Navigation
The touch-screen allows for visual, easy and
touchable navigation to activate all of
applications.
Activating methods:
Tap: touch and release by finger.
Touch and hold: touch an application icon with
finger and hold in same place until the application
respond.
Touch and drag: touch and hold an application
icon with finger, and drag to where you want it stay,
and then release your finger.
Slide: slide and release with finger
Function Buttons
Home : Return to home page
applications.
Menu : Activate function menu to set up device
or application’s functions.
11
<2>
of device from
721v1.7
Back : Return to previous page or exit
application.
Search : Launch search function which has
search function support.
Add allow to add shortcut of applications and
folders to your home page.If Add is not available,
the reason could be the home page is full. Please
remove application or folder to add new one. This
removing will not delete application from device.
Manage Apps display current status and
uninstall of applications from device.
Wallpaper Change the image of background
of home page.
Search Perform quick search which support
application search function.
Notifications View the pending list of
notificatons. (example: email, new events,
downloads, etc.).
12
721v1.7
Settings Set up functions of application and
device. Meanwhile, view the information of this
device.
DC jack
Charge the device. Plug the AC adapter into an
electric socket, and connect with the device.
Mini USB
Connect with PC or other device. This port can
reach internal and outside storage.
Micro SD slot
Plug in microSD card to save data and
applications.
Front/Back Camera
Take picture or perform video function.
Microphone
Collect voice and sound into this device.
Earphone jack
Plug earphone. Receive voice and sound via
earphone.
13
721v1.7
Speaker
Output voice and sound via speaker.
Stylus
Touch screen to activate applications.
Strap hold
To bind the favor strap.
14
721v1.7
Applications
AppInstaller: Install and uninstall
applications.
Browser: Connect with the internet.
Calculator: Perform the basic math
equations.
Calendar: State event, appointments and
schedules
Camera: Take picture and video shot.
Clock: View time and alarm setting.
Downloads: Display the history of downloads,
and operate the activating and deleting
applications.
Email: Perform sending and receiving email
function.
FW update: Renew the firmware of device.
15
721v1.7
Gallery: Display and manage photos and files
of this device.
Music: Play and manage audio data.
Search: Perform quick search which support
application search function.
Settings: Set up functions of application and
device. Meanwhile, view the information of this
device.
Video Player: Play and manage video data.
Yozo office: allow to edit, view and manage
documents(doc,xls,pdf,ppt).
16
721v1.7
License Agreement & Terms of Use
Before activating and using this device, you
hereby consent and agree to our License
Agreement and Terms of Use as outlined in the
device User Guide.
2OPTOP, Co., Ltd.; all rights reserved. 2OPTOP
and the 2OPTOP logo are trademarks of 2OPTOP
Co., Ltd.; all rights reserved. microSD
trademark of SD Card Association; all rights
reserved. Yozosoft Ltd.; all rights reserved.
<1> The physical color and home page could be
TM
is a
different by device using. The outside printing of
box is only imitating picture.
<2> Home page: it means the home page of this
device, not website’s home page.
17
721v1.7
Notice : The changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, no change to the
antenna or the device is permitted. Any change to the antenna or the device could result in the device exceeding
the RF exposure requirements and void user’s authority to operate the device.
The Federal Communication Commission Radio Frequency Interference
Statement includes the following paragraph:
The equipment has been tested and found to comply with the limits for a Class
B Digital Device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction, may cause
harmful interference to radio communication. However, there is no grantee that
interference will not occur in a particular installation. If this equipment dose cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on , the user is encouraged to try to correct the
interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
The user should not modify or change this equipment without written approval
Form 2OPTOP CO.,LTD Modification could void authority to use this equipment.
To comply with the FCC RF exposure compliance requirements, the antenna(s) used for this
transmitter must be installed to provide a separation distance of at least 20 cm from all
persons and must not be co-located or operating in conjunction with any other antenna or
transmitter. No change to the antenna or the device is permitted. Any change to the antenna
or the device could result in the device exceeding the RF exposure requirements and void
user’s authority to operate the device.
Model: 2GOSML721
FCC ID. :Z4F2GOSML721
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device
must accept any interference received, including interference
that may cause undesired operation.
18
721v1.7
Product Specifcications (規格表 )
LCD 7” 600 x 800 4:3
CPU ARM Cortex-A9 process 800 MHz
Memory DDR2 512MB
Storage 2G
TF Card Card Reader,up to 32GB
Touch screen Resistance / Dual touch
WIFI 802.11 b/g/n
G-Sensor Rotator Screen
Camera 0.3MP/2MP ( front/back)
HDMI HD video output
USB Mini USB 2.0 Host/OTG
Speaker 8Ω/1W x 2 Earphone jack 3.5mm
Battery 3000mAh
Adapter
Input: 100-240V 50/60Hz 0.3A
Output: 5VDC 2.1A
