THE DIGITAL SYSTEM THAT’S SETTING NEW STANDARDS IN THE HIGH-VOLUME, NETWORKED PRODUCTION ENVIRONMENT

The pace of business has grown exponentially with the introduction of digital technology. In today’s print-on-demand environment, end-users must be able to print what they want, when they want it, and in the exact quantities they want. In addition to faster turnaround times, businesses are also looking for cheaper yet better quality output than ever before. Introducing the

imageRUNNER production solution designed to deliver high-volume, high-quality document output, without the expense of traditional production systems.

105 Networked Production System...a high-speed document

Canon’s imageRUNNER product offerings have a reputation for performance, image quality, and ease-of-integration that is virtually unmatched. At 105 pages per minute,* the imageRUNNER 105 brings Canon’s industry-leading technology to high-volume print-on-demand and centralized production environments. The imageRUNNER 105 comes with all the same award-winning attributes as its predecessors, while also being robust enough to handle consistent high volumes of document output. The result is a unique combination of speed, advanced digital features, and document-finishing capabilities that sets new benchmarks for the high-volume marketplace.

*105 pages per minute when printing/copying letter-sized documents

from paper sources other than the Stack Bypass and lower two Cassettes

corporate

Packed Full of Functionality to Ensure the Highest Levels of Productivity Possible

Designed to Meet the Needs of the Most Demanding Environments

The imageRUNNER 105 builds upon Canon’s current

digital product platform, offering both traditional

and new capabilities that allow users to accomplish

the most complex production jobs with ease. With the

ability to support network printing, copying, and both

local and network scanning, the imageRUNNER 105

can handle all document output needs, whether the

originals reside in electronic or hard-copy form. And

accessing the imageRUNNER 105’s capabilities is

easy, too. Users can program job functions using

either the free-standing LCD Control Panel at the

device, or its intuitive printer driver software.

Pushing the Speed Limit

In today’s fast-paced business environment, time is

of the essence. Production devices must consistently

deliver the highest levels of productivity in order

to meet increasingly shorter deadlines. The

imageRUNNER 105 delivers both copies and prints

at a quick 105 pages per minute. Unlike competitive

devices, the imageRUNNER 105 does not slow

down when performing advanced functions, such as

duplexing, stapling, and hole-punching. Finished

documents are continuously output at the machine

rated speed of 105 pages per minute at 2400 x 600 dpi

resolution. What’s more, scanning is achieved at

a remarkable 80 pages per minute on the

imageRUNNER 105—the fastest integrated scanner

of any multifunction device in the world.

Uncompromising Image Quality

Even with high-speed, high-volume jobs, the

imageRUNNER 105 maintains consistent high

image quality, whether it’s the first page of a job

or the last. With 600 x 600 dpi resolution that is

interpolated to 1200 x 600 dpi resolution for copy-

ing, and 2400 x 600 dpi for printing, the superiority

of imageRUNNER 105 output is clear to see.

The graphical control panel makes paper selection easy.

Standard 100-sheet Automatic Document Feeder

Maximum Throughput Efficiency

The imageRUNNER 105’s standard five-way paper

supply provides a total of 4,150 sheets. An optional

3,500-sheet paper deck can be added to boost over-

all paper capacity to a generous 7,650 sheets. In

addition to Trayless Duplexing technology, the

imageRUNNER 105 offers several automatic through-

put features, such as automatic paper tray switching

and automatic paper selection, to enhance system

productivity, eliminate operator error, and save on

paper and supplies. Plus, on-the-fly paper reloading

further maximizes uptime.

Impressive Input Capabilities

The imageRUNNER 105 ships standard with a 100-

sheet Automatic Document Feeder (ADF) that

accepts both simplex and duplex originals in sizes up

to 11" x 17" and in weights up to 110 lb. Index stock.

A Semi-Automatic Document Feeder (SADF) is also

available for making copies of extra light- or heavy-

weight originals that may not be able to handle the

bending that occurs inside the ADF. In addition, the

ADF supports mixed-size originals with the same

leading edge width, and a Job Build Mode, which

allows users to exceed the 100-sheet capacity of the

ADF and output originals as one job.

With up to six paper sources available on-line at a

time, users have great flexibility when choosing

output stocks. The imageRUNNER 105 handles

paper sizes from Statement to 11" x 17", and offers

support for specialty stocks, such as labels, trans-

parencies, and tabs. It also accepts paper weights

from 17 lb. Bond to 110 lb. Index stock from every

on-line paper source—a significant advantage for

jobs requiring heavy covers or inserts. With its

generous paper supply, large number of paper

sources, and wide range of acceptable paper weights,

sizes, and stocks, the imageRUNNER 105 is capable of

performing the most common production-level jobs.

Generous paper supply can handle most long-run jobs.

The five-million-impression A-Si Drum achieves extremely fine images.

Prism structure frame design provides durability for intense work environments.

Remarkably Compact

The imageRUNNER 105 has a very small footprint

for a machine of its speed and strength, allowing it

to be placed in environments that previously couldn’t

accommodate a device of this caliber. Hidden in this

compact body are several design enhancements

that aid machine reliability and durability. The

frame of the device incorporates a prism design

structure that allows it to stand up to the rigors of

continuous, long runs and high output volumes.

Additionally, a dimpled bottom plate minimizes

movement and bending of the machine, thereby

providing increased rigidity and sturdiness.

Additional improvements to reduce paper jamming,

paper curling, and machine overheating have also

been implemented to allow the imageRUNNER 105

to deliver large volumes of output quickly, efficiently,

and reliably. Moreover, every primary component of

the imageRU NNER 105’s main unit is fully accessible

from the front, making jam clearance and supply

replenishment fast and efficient.

Front-access design

Toner can be replaced when a job is running.

Advanced Special Features can be easily

BCDE

100

150

200

Quarterly Sales Per Store

sales are computed based on reports that have been submitted by store managers

Speed Test Performance

measurements are based on miles per hour

Aug

Sept

Oct

Nov

Dec

5 10 15 20 25

accessed from the control panel.

Advanced Features, Simple Operation

Unique Solutions for Your Most Common Applications

Multipage documents—reports, proposals, and presentations, to name a few—are typical to high-

volume production environments. These jobs often have very specific requirements, such as covers

and inserts on specialty stock, as well as advanced finishing needs. The imageRUNNER 105 has a

number of unique functions that make the production of these everyday applications easier and

faster, with less manual intervention than ever before. The vast majority of these functions are

delivered via the imageRUNNER 105’s 10GB Internal Image Server and 192MB of RAM, which ship

standard with every unit. Examples of this functionality include:

More advanced Special Features

100 Individual Mail Boxes

Confidential Mail Boxes

Supports the creation of up to 100 individual

Mail Boxes. Mail Boxes can be used to accept

scanned and printed data, permitting users to

easily combine paper and electronic information.

Scan-Once-Print-Many and

Automatic Page Orientation

Minimizes scanner wear and tear while rotating

scanned pages to match the direction of the

available paper supply.

Automatic Page Imposition

Automatically imposes pages in correct order

for the creation of saddle-stitched booklets.

Copy Reservation

Allows users to store up to five copy jobs in

memory while current copy or print jobs are

being processed.

Job Build

Permits the building of jobs from disparate

originals, easily integrating documents scanned

through the document feeder with those directly

placed on the glass. Also allows users to process

jobs that exceed the 100-sheet capacity of the

document feeder.

SmartScan

Page Recognition

Automatically recognizes if a scanned page has

been fed incorrectly and corrects the orientation

upon output.

Chapterization

Supports the creation of chapters when copying

books and other materials requiring these types

of separations.

Tab Creation and Insertion

Enables users to create banks of tabs for later

collation, or copy onto tabs and insert them

automatically into the body of a document.

Produce professionally finished documents.

imageRUNNER 105 POD Solutions

A Variety of Finishings

PHARMA UPDATE

A Global Report

100-sheet Stapling

PowerPoint File

Cover Insertion and Bookletmaking

Two- or Threehole-punching

Excel File

Z-folding

Finishing

View and Print Documents in Mail Box by Using Remote UI

Hard-copy Original

Mail Box

SPECIFICATIONS:

MODEL EVG100398 EVG100398 EVG100398 EVG100398 EVG100398

OVEN CAPACITY 1.4 cu. ft. 1.2 cu. ft. 1.4 cu. ft. 1.2 cu. ft. 1.4 cu. ft.

COOKING UNIFORMITY Carousel Carousel Carousel Carousel Carousel

14" dia.glass turntable 16" dia. turntable 14" dia.glass turntable 16" dia. glass turntable 16" dia. turntable

DISPLAY 2-line 16 digit 5 digit LCD 2-color interactive 2-line 16 digit 5 digit LCD

SPECIAL FEATURES 16 Sensor Cook settings 12 Instant Action foods Minute Plus Minute Plus 16 Cook settings

More From Your Microwave CompuDefrost Breakfast Bar–5 foods 10 Power Levels 5 foods Child Lock One Dish Dinners–5 recipes Demo Mode Super Defrost CompuDefrost Timer Beverage Center Clock Touch On Audible Elimination

COLOR Black Black Silver Silver White

OUTPUT POWER 1100W 1100W 1100W 1100W 1100W

EXT DIMENSIONS(W x H x D) 19-1/2" x 14" x 20-5/8" 19-1/2" x 14" x 20-5/8" 19-1/2" x 14" x 20-5/8" 19-1/2" x 14" x 20-5/8" 19-1/2" x 14" x 20-5/8"

INT DIMENSIONS (W x H x D) 17-3/4" x 8-1/4" x 17" 17-3/4" x 8-1/4" x 17" 17-3/4" x 8-1/4" x 17" 17-3/4" x 8-1/4" x 17" 17-3/4" x 8-1/4" x 17"

INTERIOR Acrylic with light Acrylic with light Acrylic with light Acrylic with light Acrylic with light

APPROX. WEIGHT Net: 44 lb. Net: 44 lb. Net: 44 lb. Net: 44 lb. Net: 44 lb.

Shipping: 48 lb. Shipping: 48 lb. Shipping: 48 lb. Shipping: 48 lb. Shipping: 48 lb.

AC LINE VOLTAGE 120V, single phase, 60Hz, 120V, single phase, 60Hz, 120V, single phase, 60Hz, 120V, single phase, 60Hz, 120V, single phase, 60Hz,

AC only AC only AC only AC only AC only

AC POWER REQUIRED 1.65kW, 14.0A 1.65kW, 14.0A 1.65kW, 14.0A 1.65kW, 14.0A 1.65kW, 14.0A

SAFETY COMPLIANCE FCC, DHHS, UL listed FCC, DHHS, UL listed FCC, DHHS, UL listed FCC, DHHS, UL listed FCC, DHHS, UL listed

UPC CODE 0123456789 9876543210 0123456789 9876543210 9876543210

Specifications subject to change without notice. Specifications subject to change without notice.

Specifications change without notice.

321 Jane Street Suite XYZ Nowhere, NY 01000

023.777.7890 f023.777.7899 www.evg.erg

Output from Excel

Initial Savings Flow

savings flow is based the number of days

Nina

that have been included in this case study

Anton

Matt

Noel

Ging

1 2 3 4 5 6 7

DAY

Output from PowerPoint

Product Information Guide

MODEL EVG100398 EVG100398 EVG100398 EVG100398 EVG100398

OVEN CAPACITY 1.4 cu. ft. 1.2 cu. ft. 1.4 cu. ft. 1.2 cu. ft. 1.4 cu. ft.

COOKING UNIFORMITY Carousel Carousel Carousel Carousel Carousel

14" dia.glass turntable 16" dia. turntable 14" dia.glass turntable 16" dia. glass turntable 16" dia. turntable

DISPLAY 2-line 16 digit 5 digit LCD 2-color interactive 2-line 16 digit 5 digit LCD

SPECIAL FEATURES 16 Sensor Cook settings 12 Instant Action foods Minute Plus Minute Plus 16 Cook settings

COLOR Black Black Silver Silver White

OUTPUT POWER 1100W 1100W 1100W 1100W 1100W

EXT DIMENSIONS(W x H x D) 19-1/2" x 14" x 20-5/8" 19-1/2" x 14" x 20-5/8" 19-1/2" x 14" x 20-5/8" 19-1/2" x 14" x 20-5/8" 19-1/2" x 14" x 20-5/8"

INT DIMENSIONS (W x H x D) 17-3/4" x 8-1/4" x 17" 17-3/4" x 8-1/4" x 17" 17-3/4" x 8-1/4" x 17" 17-3/4" x 8-1/4" x 17" 17-3/4" x 8-1/4" x 17"

INTERIOR Acrylic with light Acrylic with light Acrylic with light Acrylic with light Acrylic with light

APPROX. WEIGHT Net: 44 lb. Net: 44 lb. Net: 44 lb. Net: 44 lb. Net: 44 lb.

Shipping: 48 lb. Shipping: 48 lb. Shipping: 48 lb. Shipping: 48 lb. Shipping: 48 lb.

AC LINE VOLTAGE 120V, single phase, 60Hz, 120V, single phase, 60Hz, 120V, single phase, 60Hz, 120V, single phase, 60Hz, 120V, single phase, 60Hz,

AC only AC only AC only AC only AC only

AC POWER REQUIRED 1.65kW, 14.0A 1.65kW, 14.0A 1.65kW, 14.0A 1.65kW, 14.0A 1.65kW, 14.0A

SAFETY COMPLIANCE FCC, DHHS, UL listed FCC, DHHS, UL listed FCC, DHHS, UL listed FCC, DHHS, UL listed FCC, DHHS, UL listed

UPC CODE 0123456789 9876543210 0123456789 9876543210 9876543210

Specifications subject to change without notice.

ELECTRONICS INC

EVG

321 Jane Street Suite XYZ Nowhere, NY 01000

023.777.7890 f023.777.7899 www.evg.erg


The imageRUNNER 105 allows users to combine files from different applications with scanned hard-copy originals to produce fully finished documents.

Document Output Possibilities

The imageRUNNER 105 offers a choice of finishers

providing the greatest flexibility and quality avail-

able for producing finished sets of documents. From

basic collated and stapled output to multipage,

saddle-stitched booklets, the imageRUNNER 105 is

up to the task.

The imageRUNNER 105’s optional Finisher-K1N and

Finisher-K2N offer two trays to manage statement- to

ledger-sized output. Up to 3,000 sheets can be

accommodated, enough to effectively handle even

the longest print or copy runs. Additionally, both

Finishers can staple up to 100 sheets in any corner

of the page, or place two staples in either the left-

or right-hand margin. The Finisher-K2N also offers

hole-punching in addition to stapling, and output

can be automatically two- or three-hole punched,

depending on paper size and orientation.

If finishing requirements are more extensive, the

optional Saddle Finisher-K3N is also available. Like the

Finisher-K1N and Finisher-K2N, the Saddle Finisher-K3N

holds a maximum of 3,000 sheets in two trays. It

offers 100-sheet single- and double-position

stapling, two- and three-hole punching, and saddle-

stitched booklet-making as standard. The Saddle

Finisher-K3N can also be equipped with the optional

Document Insertion Unit-B1, Paper Folding Unit-C1,

and the Booklet Trimmer-A1.** The Document

Insertion Unit-B1 allows preprinted stock to be

merged with finished documents post-process; the

Paper Folding Unit-C1 Z-folds 11" x 17" documents

so that they fit neatly within letter-sized output; and

the Booklet Trimmer-A1 cleans up finished edges of

saddle-stitched booklets.

The optional Document Insertion Unit-B1 allows users to incorporate preprinted covers and inserts into output.

The Finisher-K1N offers multiposition stapling as standard.

Saddle Finisher-K3N offers stapling, holepunching and saddle-stitched booklet-making.

** Please check with your local Canon-authorized Dealer

for availability.

Booklet Trimmer-A1 Control Panel

capabilities

The optional Booklet Trimmer-A1 trims lead edge of saddle-stitched booklets.

The standard Canon controller (embedded)

The optional imagePASS-M1 Print Controller

Connectivity Without Complications

The imageRUNNER 105, like its predecessors, carries

on Canon’s networking tradition. imageRUNNER 105

customers can select both copying and printing capa-

bilities at the time of their initial purchase, or they

can add network printing capabilities later on.

Unparalled Print Performance

The imageRUNNER 105 offers two ways to connect

to the network—the Canon-designed Network

Multi-PDL Printer Kit-B2, and the imagePASS-M1

Print Controller, developed by Canon and Electronics

for Imaging (EFI

interpolated print resolution, and allow users to pro-

gram imageRUNNER system capabilities directly

from their desktops. However, each controller also

has distinctive strengths that make each ideally suited

to very different types of printing environments.

Canon’s Network Multi-PDL Printer Kit-B2 leverages

the standard 250MHz processor built into each

imageRUNNER 105 base model. Using this Canon-

customized processor, the Network Multi-PDL Printer

Kit-B2 is best suited for the text-intensive, everyday

printing needs of busy corporate in-plants and print-

). Both solutions enable 600 x 2400 dpi

excel

for-pay environments where PCL page description

language represents the bulk of jobs sent to the printer.

Canon’s imagePASS-M1 Print Controller features an

Pentium®III 500MHz processor, and is designed

Intel

to meet the needs of customers printing true Adobe

PostScript®files, complex graphics, and variable data

output, as well as support EFI utilities such as Fiery

FreeForm

When printing large, sophisticated files, the print

performance of an imageRUNNER 105 is at its best

when equipped with the imagePASS-M1 Print

Controller. But there are also some imageRUNNER 105

capabilities that can only be enabled through the

use of the Canon Network Multi-PDL Printer Kit-B2,

such as Canon’s Universal Send** functionality.

imageRUNNER 105 customers should select the

print controller best suited for their particular printing

requirements. Both solutions have been designed to

integrate seamlessly with a customer’s existing

network infrastructure, and come with a full suite

of system utilities to simplify device installation

and management.

Driver Page Setup Tab

xcellence

** Please check with your local Canon-

authorized Dealer for availability.

Page Composer is a make-ready tool allowing users to review and manipulate whole documents before printing.

Operation Made Easy

One of the reasons why Canon has become the leading provider of

network-connected systems in the marketplace today is because of

its intuitive printer driver software. imageRUNNER 105 users will find

that the graphical printer drivers are extremely easy to use, even if

they have had no prior experience using a network-connected device.

Through the printer driver software, users have immediate access to all

imageRUNNER 105 output functions directly from their desktops. A

dynamic image of the installed imageRUNNER 105 is displayed on the

screen and indicates all available hardware options, paper sizes, and

paper levels so that users are aware of the latest device capabilities.

the document to remain in memory until the user enters a password at

the device control panel, thus releasing the document for printing.

Canon’s Page Composer software also ships standard with the

imageRUNNER 105 PCL

print drivers. This document make-ready

application, which is embedded in the driver, allows users to combine

documents that were created in different applications and output them

as a single job. Prior to printing, documents can be previewed and

manipulated through a thumbnail view and then sent to the

imageRUNNER 105 for finishing.

More advanced capabilities of the drivers include the ability to save

frequently used print-job profiles; insert document annotations such

as names, dates, etc.; add watermarks; and, send confidential docu-

ments to the imageRUNNER 105 as a Secured Print. This option allows

Managing Information Regardless of Form

As the widespread use of electronic-based infor-

mation continues to grow, office devices need to be

able to easily integrate both hard-copy and electronic

documents. Through its Mail Box feature, Network

ScanGear software, and Universal Send functions,

the imageRUNNER 105 provides users with

unmatched flexibility in converting hard-copy

documents to digital form.

Network ScanGear

Network ScanGear is Canon’s TWAIN-compliant

scanning program that ships standard with every

Network Multi-PDL Printer Kit-B2 and imagePASS-M1

Print Controller. Using a ScanGear-enabled

imageRUNNER 105, users running TWAIN-compliant

application software can scan documents from the

device for transmission over the network. Scanned

images can then be manipulated and managed

according to specific user-requirements.

Mail Box

The imageRUNNER 105’s Mail Box function allows

users to scan and store hard-copy originals directly

to the device’s internal hard drive. Once scanned,

documents can be moved between Mail Boxes, com-

bined, renamed, erased, and printed as required.

Documents stored in Mail Boxes can also be viewed at

a user’s desktop using the Remote UI

JBIG Viewer.

Universal Send

Canon’s optional Universal Send function, com-

bined with eCopy

imageRUNNER 105’s network scanning capabili-

ties even further. Using Universal Send, hard-copy

documents can be scanned and delivered:

• as E-mail attachments in TIFF, multipage TIFF, or

PDF format;

• as fax transmissions over the Internet (I-fax

messages) at no cost;

• to databases and file servers for storage, archival

purposes, or sharing within workgroups; and

• to a Mail Box for later sharing, merging, printing,

or sending.

Canon’s printer driver software is the only one on the market capable

of discovering devices on the network, allowing administrators to

select imageRUNNER 105 devices and automatically configure their

equipped options with just a click of the mouse.

eCopy ShareScanTMdirectly connects the imageRUNNER 105 to E-mail, fax, and user-desktops, enabling document

DesktopTMSoftware,** takes the

distribution at the touch of a button.

eCopy Desktop delivers advanced document annotation and distribution features, further enhancing imageRUNNER 105 Universal Send

functions.

Up to 7,700 pages of documents can be stored in the Mail Boxes.

Once received, eCopy Desktop Software can be

used to manipulate these images via an extensive

group of markup tools. Scanned images can also

be run through an OCR program embedded within

the software and then delivered via fax or E-mail to

their ultimate destinations.

** Please check with your local Canon-authorized

Dealer for availability.

Canon’s NetSpot®Suite

Connectivity Software Simplified

Like all Canon networked systems, the

imageRUNNER 105 comes equipped with a compre-

hensive set of system utilities designed to simplify

operation and management for both end-users and

network administrators. Canon’s NetSpot

consists of the three utilities outlined below:

NetSpot Console

NetSpot Console is a web-based utility capable of

installing and managing Canon networked systems,

including the imageRUNNER 105, on most customer

networks. Through NetSpot Console, network

administrators are provided a convenient, platform-

independent utility to install and manage Canon

devices from anywhere within the enterprise. In

addition to basic installation support, NetSpot

Console also delivers administrator alerts, notifying

administrators of device status conditions, including

low toner and paper jams. For added convenience,

NetSpot Console is also capable of managing

third-party printers complying with the standard

Printer MIB, thereby consolidating network-device

management via one utility.

NetSpot Job Monitor

To manage and track the progress of print jobs, Canon

supplies NetSpot Job Monitor. NetSpot Job Monitor

runs as an automated task in the Windows

System

Suite

Tray, and can be configured to report job conditions

based on administrator or end-user preferences.

Significant to NetSpot Job Monitor is its ability to

deliver end-of-job notification to end-users, ensuring

that they are always informed of job completion.

NetSpot Accountant

NetSpot Accountant is an optional utility available

for the imageRUNNER 105 that is capable of providing

comprehensive job-tracking and analysis for

cost-accounting and workflow optimization. Using

NetSpot Accountant, network administrators can

track all activity at the imageRUNNER 105, including

copying, printing, and scanning for billing of internal

or external clients for device utilization. NetSpot

Accountant is ideal for Legal customers, or any

customer who desires to account for imageRUNNER 105

device utilization.

Enterprise-management Integration

Canon also supplies plug-in modules for the most

popular enterprise-management applications in use

today. Supported applications include Microsoft

Management Console, CA-Unicenter, HP®OpenView®,

NetView®, and BMC Patrol®. Through these

Tivoli

plug-ins, Canon permits easy management of the

imageRUNNER 105 from directly within the

enterprise-management system console.

** Please check with your local Canon-authorized

Dealer for availability.

NetSpot® Suite

Centralized Management

NetSpot Job Monitor

Queue Management

Job Done Notification

CLC 5000

NetSpot® Suite enables users to manage a mixed environment of imageRUNNER, imageCLASS, and CLC products from a centralized location.

Status Monitoring

Configuration

NetSpot

Monitoring Monitoring MonitoringMonitoring

imageRUNNER 8500

Management

NetSpot Console

Management

Status Monitoring

Configuration

Browser

imageCLASS 2250

Web Server

Accounting

Analysis

Browser

imageRUNNER 105

NetSpot Accountant

Monitoring

iR3250

Remote UI User-interface

Remote UI

The imageRUNNER 105 ships standard with Canon’s

Remote UI (User-interface) feature. The Remote UI

feature makes it possible for users to access device

status and configuration, job status, address books,

and more, simply by entering the IP address of the

device using a standard web browser. Users can

stop, start, or reprint jobs, send images stored in

Mail Boxes, even operate unique SEND functions for

previously stored documents, all from a desktop PC,

with no additional software requirements.

An Impressive Line-up

The imageRUNNER 105 joins an already impressive

line-up of Canon digital multifunction products

ranging in speed from 16 to 110 pages per minute.

Canon’s pioneering effort in creating the digital

multifunction

considerable advantage in identifying emerging

marketplace has provided us with a

customer needs. Our past experience, combined

with our huge ongoing commitment to research

and development, has allowed us to assume a

commanding position in today’s office and produc-

tion environments.

Our goal is simple: to provide you with the best

solutions to your document and information-

management needs.

With a fast, 105-page-per-minute speed, high

image quality, extensive document finishing, and

seamless integration to customer networks, the

imageRUNNER 105 is a solution that truly sets new

standards for the networked production environ-

ment, and one that will clearly enable users to

achieve greater levels of productivity, efficiency, and

a competitive advantage.

high-volume

Document Insertion Unit-B1

Booklet Trimmer-A1

▲

Paper Folding

▲

Unit-C1

Finisher-K2N

Finisher-K1N

Automatic

Document Feeder

LCD Control Panel

Paper Deck-N1

Saddle Finisher-K3N

imageRUNNER 105 Specifications

Type: Digital, Multifunction Imaging System Imaging System: Laser Dry Electrostatic Transfer Developing System: Dry Monocomponent Toner Projection Image Server Memory: Standard 192MB RAM + 10GB H DD First-copy Time: 2.8 Seconds from Platen Glass

Warm-up Time: 6 Minutes or Less Acceptable Originals: Sheets, Books, 3-Dimensional Items Max. Original Size: 11" x 17" (Ledger) Max. Copy Size: 11" x 17" (Ledger) Min. Copy Size: 4-1/8" x 5-7/8" Max. Mail Boxes Supported: 100 Max. Copy Reservation: 5 Jobs Copy/Scanning Resolution: 600 dpi x 600 dpi

Printing Resolution: 600 dpi x 600 dpi

Halftone: 256 Gradations of Gray Copy Speed: 105 cpm (Letter)*

Duplexing: Standard Automatic Trayless Magnification Reduction/

Enlargement: 25% to 400% in 1% Increments

Paper Supply

Standard: Dual Front-loading Trays

Optional: 3,500-sheet Paper Deck-N1

Multiple Copies: 1 to 999 Paper Weights: 17 lb. Bond to 110 lb. Index (All Paper Sources)

Supplies

Drum: Amorphous Silicon – Estimated Yield:

Maximum Duty Cycle: 600,000 Impressions per Month Toner: Magnetic Negative Toner –

ACCESSORIES Automatic Document Feeder

Acceptable Originals: Statement to Ledger Scanning Speed: 80 ppm (Letter) Capacity: 100 Sheets (All Sizes/20 lb.) Paper Weights: 13 lb. Bond to 110 lb. Index

Finisher-K1N/K2N (Optional)

Number of Trays: 2 Trays Tray Capacity

Top Tray: 1,000 Sheets (All Sizes)

Dimensions Table

4.1 Seconds from ADF

1200 dpi x 600 dpi Interpolated

2400 dpi x 600 dpi Interpolated

52 cpm (Ledger)

(1,500 Sheets Each)

Dual Front-loading Cassettes

(550 Sheets Each)

50-sheet Stack Bypass

(Total: 7,650 Sheets)

5,000,000 Impressions

Estimated Yield: 36,600 Images

Offset Stacking

Dimensions (H x W x D)

Lower Tray: 2,000 Sheets (Letter)

Staple Position: 1 - Any Corner

Max. Stapling Capacity: 100 Sheets (Letter/Statement)

Hole-punch (K2N Only): 3 Holes (11" x 17", Letter)

Saddle Finisher-K3N (Optional)

Number of Trays: 3 Trays Tray Capacity

Top Tray: 1,000 Sheets (All Sizes)

Lower Tray: 2,000 Sheets (Letter)

Saddle-stitch Tray: 30 Sets

Staple Position: 1 - Any Corner

Max. Stapling Capacity: 100 Sheets (Letter/Statement)

Hole-punch: 3 Holes (11" x 17", Letter)

Saddle-stitch Capabilities

Saddle-stitch Paper Sizes: 11" x 17", Letter Stapling Capacity: 15 Sheets (60 Pages) Folding: V-folding Standard

Paper Deck-N1 (Optional)

Paper Capacity: 3,500 Sheets Paper Size: Letter Paper Weights: 17 lb. Bond to 110 lb. Index

Document Insertion Unit-B1

Paper Sizes: Letter-R to 11" x 17" Paper Weights: 17 lb. Bond to 110 lb. Index Feeder Capacity: Letter, Letter-R: 100 Sheets

Paper Folding Unit-C1

Paper Sizes: 11" x 17" Only Paper Weights: 17 lb. Bond to 22 lb. Bond Fold Type: Z-fold

Booklet Trimmer-A1

Sheet Capacity: 30 Sheets (60 Pages) Stack Capacity: 2,000 Pages Dust Capacity: 2,000 Pages

Weight

▲

Power

▲

(Optional)

▲

(Optional)

imageRUNNE R 105 Main Unit 54-7/8" x 30-1/8" x 31-3/8" 617 lb. 208V, 60Hz, 12A

(1395mm x 764mm x 795mm) (280kg)

Finisher-K1N 39-1/4" x 26-1/4" x 29-1/8" 141 lb. Directly from Main Unit

(995mm x 667mm x 738mm) (64kg)

Finisher-K2N 39-1/4" x 26-1/4" x 29-1/8" 145 lb. Directly from Main Unit

(995mm x 667mm x 738mm) (66kg)

Saddle Finisher-K3N 39-1/4" x 31-5/8" x 29-1/8" 280 lb. Directly from Main Unit

(995mm x 803mm x 738mm) (127kg)

Paper Deck-N1 23" x 12-3/4" x 22-1/2" 90.3 lb. Directly from Main Unit

(583mm x 323mm x 570mm) (41kg)

Document Insertion Unit-B1 5-5/8" x 22-1/8" x 23" 35 lb. Directly from Main Unit

(with Auxiliary Tray Opened) (16kg) (144mm x 561mm x 584mm)

Paper Folding Unit-C1 39-1/4" x 7-1/4" x 26-5/8" 108 lb. Directly from Main Unit

(995mm x 184mm x 675mm) (49kg)

Booklet Trimmer-A1 22" x 44" x 24" 149 lb. 120V, 3A

(560mm x 1118mm x 610mm) (68kg)

imagePASS-M1 Print Controller 14" x 6-3/8" x 11" 11.6 lb. 110-240V, 1A

(355mm x 162mm x 279mm) (5.3kg)

As an Energy Star®Partner, Canon U.S.A., Inc. has determined that this product meets the Energy Star®guidelines for energy efficiency, except when attached to the optional Token Ring Adapter on the Network Multi-PDL Printer Kit-B2, or the optional imagePASS-M1 Print Controller. The Energy Star name is a registered trademark of the U.S. Environmental Protection Agency. Microsoft, Windows and Windows NT are registered trademarks of Microsoft Corporation in the United States and/or other countries. Adobe and PostScript are registered trademarks of Adobe Systems Incorporated. HP, PCL, and OpenView are registered trademarks of Hewlett-Packard Company. Fiery is a registered trademark, and EFI, Command WorkStation, Fiery Downloader, Fiery Link and FreeForm are trademarks of Electronics for Imaging, Inc. Intel and Pentium are registered trademarks of Intel Corporation. eCopy, eCopy ShareScan and Desktop are trademarks of eCopy, Inc. Unicenter is a registered trademark of Computer Associates International. Tivoli and NetView are registered trademarks of Tivoli Systems, Inc. in the United States and other countries. Patrol is a registered trademark of BMC Software, Inc. Canon and NetSpot are registered trademarks, and IMAGERU NNER, Canon Know How and the GE NUINE logo are trademarks of Canon Inc. Universal Send and Remote UI are trademarks, and IMAGE ANYWARE is a service mark of Canon U.S.A., Inc. All other terms and product names may be trademarks or registered trademarks of their respective owners and are hereby acknowledged.

Specifications are subject to change without notice.

0023W934

0901-iR105-100M

printed on recycled

paper in the u.s.a.

imageRUNNER 105

1,000 Sheets (11" x 17", Legal) Offset Stacking

2 - Side Margin

50 Sheets (Letter-R/Legal/11" x 17")

2 Holes (Legal, Letter-R)

Offset Stacking

1,000 Sheets (11" x 17", Legal) Offset Stacking

2 - Side Margin

50 Sheets (Letter-R/Legal/11" x 17")

2 Holes (Legal, Letter-R)

Legal, 11" x 17": 50 Sheets

Canon imagePASS-M1

Print Controller

Network Multi-PDL Printer Kit-B2 (Optional)

PDL Support: PostScript

Interface Connections: RJ-45 (10/100Base-T)

Protocol Stacks: Ethernet

Network OS: Novell

Print Service: NDPS, Port 9100, IPP Additional Functions

Supported: Network ScanGear, Remote UI,

Canon imagePASS-M1 Print Controller (Optional)

Hardware: External Stand-alone Controller Processor: Intel Mobile Pentium III 500MHz Memory: 128MB DIMM Storage: 10.2GB Hard Disk Drive PDL Support: Adobe PostScript 3

Interface Connections: RJ-45 (10/100Base-T)

Protocol Stacks: Ethernet

Network OS: Novell NetWare v3.2, 4.1, 4.11, 4.2, 5

Print Service: NDPS, Por t 9100, IPP Additional Functions

Supported: Network ScanGear, Remote UI, NetSpot

Additional Functions

Standard: Command WorkStation

*105 pages per minute when printing/copying letter-sized documents

from paper sources other than the Stack Bypass and lower two Cassettes

3 Emulation

PCL

5e, PCL®6

IEEE 1284 Token Ring (Optional Card)

IPX/SPX

: 802.2, 802.3 Ethernet II, 802.2 SNAP TCP/IP

AppleTalk Phase II

NetWare®v3.2, 4.1, 4.11, 4.2, 5, 5.1

95/98/Me

Windows

Windows NT

Solaris

1.x, 2.5 or Later

Apple System 7.5 or Higher

NetSpot, Universal Send

PCL 5e, PCL 6

IEEE 1284 Token Ring (Optional Card)

IPX/SPX: 802.2, 802.3 Ethernet II, 802.2 SNAP TCP/IP

AppleTalk: 802.2 SNAP and AppleTalk Phase II

Windows

95/98

Windows NT Solaris 1.x, 2.5 or Later Apple System 8.6 or Higher

(except Job Monitor), WebTools

Fiery Link

4.0/2000

■

, Fiery®DownloaderTM,

**Please check with your local Canon-authorized Dealer for availability.

▲

The Document Insertion Unit-B1, the Paper Folding Unit-C1, and the Booklet Trimmer-A1 can only be used with the Saddle Finisher-K3N.

■

The imageRUNNE R 105 is not ENERGY S TAR®-compliant when attached to the optional Token Ring Adapter on the Network Multi-PDL Printer Kit-B2, or the optional imagePASS-M1 Print Controller.
