1. Product Description
In this section, we introduce the 2N®Indoor Compact product, outline its application options
and highlight the advantages following from its use. The section also includes safety
precautions.
•
1.1 Product Description
•
1.2 Differences between Models and Associated Products
•
1.3 Terms and Symbols Used
•
1.4 Safety Precautions
1.1 Product Description
2N® Indoor Compactis a stylish, compact-design indoor IP/SIP unit providing audio and video
communication with the 2NIP intercoms.The device includes a 4 mm enhanced glass
touchscreen panel, Speakerphone, high-quality microphone with excellent audibility and
intelligibility properties, Ethernet LAN interface and induction loop and doorbell external supply
connectors.2N® Indoor Compact is a top-quality, cost efficient and easy to install and
configure answering unit.One installation can combine variable answering units manufactured
by 2N Telekomunikace a.s.
2N® Indoor Compact is equipped with a specific user interface for an increased user comfort
and safety.
Basic Features2N® Indoor Compact:
•
4.3" color LCD video display
•
full duplex handsfree HD audio communication
•
LAN interface with PoE supply option
•
easy flush mounting
•
combination with 2N®Indoor Touchand 2N® Indoor Talk answering units
•
remote administration and configuration via 2N® Remote Configuration
•
call setup option via 2N®Mobile Video on a smartphone
•
DND mode and parental lock
•
remote door lock control
•
time display at relax
•
integrated user web interface
•
external doorbell button input
•
external power supply input
•
induction loop output
2N® Indoor Compact User Manual
1.2 Differences between Models and Associated Products
2N® Indoor Compact
•
2N® Indoor Compact – black
•
2N Part No. 91378501
Axis Part No. 01935-001
Indoor answering audio/video unit with touch buttons
designed for all 2N IP intercoms
2N® Indoor Compact User Manual
•
2N® Indoor Compact – white
•
2N Part No. 91378501WH
Axis Part No. 01936-001
Indoor answering audio/video unit with touch buttons
designed for all 2N IP intercoms
Other Indoor Units and Accessories
Part Numbers:
2N Part No. 91378375
Axis Part No. 01668-001
2N Part No. 91378376
Axis Part No. 01670-001
•
2N® Indoor Touch 2.0 – black
•
WiFi version (third and fourth Part Nos.)
•
2N® Indoor Touch 2.0, an elegant indoor touch
panel, is designed for all of the 2N IP intercoms. The
display panel shows you the person standing at your
door and helps you make conversation with the
visitor, open the door lock or switch on the entrance
hall lights.
2N® Indoor Compact User Manual
2N Part No. 91378382
Axis Part No. 01425-001
Part Numbers:
•
2N® Indoor Touch – desk stand black
•
2N® Indoor Touch 2.0 – white
•
WiFi version (third and fourth Part Nos.)
2N Part No. 91378375WH
Axis Part No. 01669-001
2N Part No. 91378376WH
Axis Part No. 01671-001
2N Part No. 91378382W
Axis Part No. 01426-001
•
2N® Indoor Touch 2.0, an elegant indoor touch
panel, is designed for all of the 2N IP intercoms. The
display panel shows you the person standing at your
door and helps you make conversation with the
visitor, open the door lock or switch on the entrance
hall lights.
•
2N® Indoor Touch– desk stand white
2N® Indoor Compact User Manual
•
The exclusive type of power adapter SYS1561-0912
Part Numbers:
2N Part No. 91378381E
2N Part No. 91378381GB
2N Part No. 91378381US
2N Part No. 91378401
Axis Part No. 01698-001
to be used with all 2N® Indoor Touch 2.0 devices.
•
Stabilised 12 V / 0,75 A source to be used where PoE
supply is unavailable.
•
The part numbers differ in their electric socket
markings (E/GB/US).
•
2N® Indoor Talk – black
•
Indoor answering audio unit with touchscreen
designed for all 2N IP intercoms
2N Part No. 91378401WH
Axis Part No. 01699-001
•
2N® Indoor Talk – white
•
Indoor answering audio unit with touchscreen
designed for all 2N IP intercoms
2N® Indoor Compact User Manual
VoIP Phones
Part No. 91378358
Axis Part No. 01421-001
Part.No. 91378357
Axis Part No. 01422-001
•
Grandstream GXV3240 VoIP video telephone
•
GXV3240 is the successor to the popular GXV3140
model, which provides comfortable video calls in
the IP network. Touchscreen and keypad control.
•
Grandstream GXV3275 VoIP video telephone
•
GXV3275 is the successor to the popular GXV3175
model, which provides comfortable video calls in
the IP network. Touchscreen control.
Mounting Accessories
•
2N Part No.
91378800
Axis Part No.
01700-001
•
Flush mounting box is necessary for brick/plasterboard walls.
Not included in the 2N® Indoor Compact package.
2N® Indoor Compact User Manual
2N Part No.
91378803
Axis Part No.
02320-001
2N Part No.
91378802
Axis Part No.
02039-001
•
Wall mounting box for 2N answering units
•
Not included in the 2N® Indoor Compact package.
•
2N Indoor answering unit desk stand.
•
Not included in the 2N® Indoor Compact package.
2N® Indoor Compact User Manual
1.3 Terms and Symbols Used
The following symbols and pictograms are used in the manual:
Safety
•
Always abide by this information to prevent persons from injury.
Warning
•
Always abide by this information to prevent damage to the device.
Caution
•
Important informationfor system functionality.
Tip
•
Useful informationfor quick and efficient functionality.
Note
•
Routines or advice for efficient use of the device.
2N® Indoor Compact User Manual
1.4 Safety Precautions
The manufacturer reserves the right to modify the product in order to improve its qualities. The
manufacturer continuously responds to the clients' requirements by improving the software.
Refer to the www.2n.comcompany websites for the latest 2N®Indoor Compact firmware and
User Manual.
•
Where necessary, the device can be installed at a safe distance from the prohibited area
and an Ethernet cable can only be carried to the required site.
•
Install 2N®Indoor Compact out of reach of sensitive devices and human bodies as it
emits electromagnetic interference.
•
Refer to6.Technical Parameters for the range of operating temperatures.
•
The device may not be operated at places exposed to direct sunlight or near heat sources.
•
2N®Indoor Compact is designed for indoor use. It may not be exposed to rain, flowing
water, condensing moisture, fog, and so on.
•
It may not be exposed to aggressive gases, acid and solvent vapors, etc.
It is designed for LAN connection.
Caution
•
This product and its installation and configuration techniques are not intended for
persons with diminished physical, sensory or mental capacities or persons with
limited experience and knowledge unless expertly supervised or duly advised as to
the use of this product by a person responsible for their safety.
2N® Indoor Compact User Manual
2. Description and Installation
This section describes how to install and connect 2N®Indoor Compact properly.
Here is what you can find in this section:
•
2.1 Before You Start
•
2.2 Brief Installation Guide
•
2.3 Installation Conditions
•
2.4 2N® Indoor Compact LAN Location via 2N® Network Scanner
•
2.5 IP Address Lookup
2.1 Before You Start
Package Completeness Check
Please check the product delivery before starting installation: Contents:
1
2 External power and doorbell button terminals
1 Certificate of ownership
1 2.5 mm hexagon key wrench
1 Quick Start manual
1 Display cleaning cloth
2N®Indoor Compact
2N® Indoor Compact User Manual
Front Layout
1.
Display
2.
Microphone
3.
MENU buttons
4.
Lock button
5.
Call end button
6.
Speaker
7.
Anchoring holes
8.
Call answering button
2N® Indoor Compact User Manual
Backside Connectors
1.
External induction loop output
2.
Reset button
3.
Doorbell button input
4.
12 V / 1 A DC power supply input
5.
Ethernet
2N®Indoor Compactis designed for flush mounting (brick, plasterboard, wood). Use the flush
mounting box (Part No. 91378800), which is not included in the package. Alternatively, the
product can be mounted into a desk stand (Part No. 91378802), which is not included in the
package.
Caution
•
Before starting the mechanical installation on a selected place, make sure
carefully that the preparations connected with it (drilling, wall cutting) cannot
damage the electrical, gas, water and other existing wires and pipes.
2N® Indoor Compact User Manual
Cut a circular hole in the wall of the diameter of 103 mm and depth of 50 mm before installation.
It is assumed that all necessary cables of the maximum length of 25 cm will lead to the hole.Put
the flush mounting box in the hole to make sure that the hole is deep enough.If the hole
complies with the box size, wall in the box and level the box using a water level on the holding
clips. When the mortar hardens, break off the clips and cap the box with the cover provided. Use
anchoring elements to fix the device into plasterboard.
2N® Indoor Compact User Manual
Downloads
Drilling template.pdf
Use a 2.5 mm hexagon key wrench (included in the 2N®Indoor Compact delivery) for fitting 2N
Indoor Compact into the flush mounting box.
Note
•
While flush mounting2N®Indoor Compactrespect the local standards concerning
installation of electronic devices on flammable materials.
®
2N® Indoor Compact User Manual
2.2 Brief Installation Guide
Remove the cover from the walled-in 2N®Indoor Compact flush mounting box. Remove the preprepared cabling, UTP cable, doorbell twin cable and power supply cable. Shorten the cables to
150 mm or less as required. Connect the doorbell twin cable or power supply cable to the
connector provided. Crimp the RJ-45 connector onto the UTP cable. Take2N®Indoor Compact
and lean its bottom edge against the wall below the flush mounting box. First plug the green
power/doorbell connector. Connect the LAN connector. Put the cables carefully in the pre-
drilled 2N®Indoor Compact back slot to prevent them from blocking any horizontal levelling
movement during the final installation stage. Insert 2N®Indoor Compact in the flush mounting
box making sure that it clicks onto the levelling pins, which allow for a 5–6° inclination on either
side for accurate horizontal levelling. Apply the box screw nuts with the hexagon key wrench
provided. Level 2N®Indoor Compact with a water level and tighten the screws gently.Now
2N®Indoor Compact is ready for basic operation.
2N®Indoor Compact consumption with variable power supplies:
Supply type Consumption
PoE, IEEE 802.3af 12 W
12 V / 1 A 12 W
2N® Indoor Compact User Manual
Warning
•
Do not connect any external power supply if PoE is used and vice versa.
•
If you use a power adapter other than the recommended one, do not exceed the 12
V rated supply voltage. Also check the supply voltage polarity. Higher voltage
values or misconnections may result in an irreplaceable device damage.
2N® Indoor Compact User Manual
2.3 Installation Conditions
Make sure that the following2N®Indoor Compact installation conditions are met:
•
There must be enough space for the device installation.
•
The device is designed for vertical wall mounting (perpendicular to the floor) in the height
of up to 120 cm above the floor.If necessary, operate the device in a position other than as
aforementioned for a short time only, for quick testing purposes in a servicing center, for
example.
•
Exceeding the allowed operating temperature may not affect the device immediately but
leads to premature ageing and lower reliability. For the acceptable range of operating
temperatures and relative humidity values refer to Technical Parameters.
•
The device is not designed for environments with increased vibrations such as means of
transport, machine rooms and so on.
•
The device is not intended for dusty environments and places with unstable humidity and
abrupt temperature changes.
•
Thedevice may not be exposed to aggressive gas, acid vapors, solvents, etc.
•
The device is not intended for direct connection into the Internet/WAN.
•
The device must be connected to the Internet/WAN via a separating active network
element (switch/router).
•
The device is designed for indoor use. It may not be exposed to rain, flowing water,
condensing moisture, fog, etc.
•
The device cannot be operated on places exposed to direct sunshine and near heat
sources.
•
Keep some free space above and below the device to allow air to flow and conduct heat
away.
•
No strong electromagnetic radiance is allowed on the installation site.
•
Make sure that the VoIP connection is configured properly according to the SIP and other
VoIP recommendations.
•
It is recommended that the power adapter be connected to the mains via a UPS and
reliable overvoltage protection.
Power Supply Connection
You can feed 2N®Indoor Compact as follows:
1.
Use a 12 V / 1 A DC power adapter connected to the backside terminal board.
2.
Use an Ethernet cable connected to a PoE supply or PoE supporting Ethernet switch/
router.
PoE Supply Connection
Use a standard straight RJ-45 terminated cable to connect2N®Indoor Compact to the Ethernet.
The device supports the 10BaseT and 100BaseT protocols. The Ethernet connection state is
2N® Indoor Compact User Manual
indicated by a hung-up receiver symbol . If the symbol flashes, the device is disconnected
from the network.
Caution
•
Factory reset results in a change of the Ethernet interface configuration!
•
A defective Ethernet cable may lead to a high packet loss in the Ethernet and
subsequent instability and poor call quality!
Warning
•
Do not connect any external power supply if PoE is used and vice versa.
•
Connection of a defective or improper power supply may lead to a temporary or
permanent device failure.
Ethernet cable connector Ethernet socket
Firmware Upload
We recommend you to upgrade the 2N® Indoor Compact firmware during installation. Refer
towww.2n.comfor the latest FW version. Refer to3.2.5 System for the firmware upgrade
procedure.
2N® Indoor Compact User Manual
2.4 2N® Indoor Compact LAN Location via 2N® Network Scanner
2N®Indoor Compactis configured via the administration web server. Connect the device to the
LAN IP and make sure it is properly powered.
2N®Network Scanner Description
The application helps find the IP addresses of all the 2N®Indoor Compact devices in the LAN.
Download the app from the 2N web sites (www.2n.com). Make sure that Microsoft .NET
Framework 2.0 is installed for successful app installation.
1.
Run the 2N®Network Scanner.
2.
Use the Setup Wizard for successful installation.
2N®IP Network Scanner Installer
3.
Having installed the 2N®IP Network Scanner, start the application using the Microsoft
Windows Start menu.
Once started, the application begins to automatically search for all the 2N IP intercoms in the
LAN including their smart extensions (2N® Indoor Compact,2N®Indoor Talk,2N®Indoor
Touch), which are DHCP/statically assigned IP addresses. All the devices are displayed in a table.
2N® Indoor Compact User Manual
2N® IP Network Scanner
1.
Select the 2N®Indoor Compact device to be configured and right-click it. Select
Browse…… to open the 2N®Indoor Compact administration web interface login window
for configuration. To change the device IP address, select Config and enter the required
static IP address or activate DHCP. The default configuration password is 2n. If the found
device is grey highlighted, its IP address cannot be configured using this application. In
that case, click Refresh to find the device again and check whether multicast is enabled in
your network.
Tip
•
Double click the selected row in the 2N®IP Network Scannerlist to access
the device web interface easily.
2N® IP Network Scanner IP Address Change
2N® Indoor Compact User Manual
2.5 IP Address Lookup
To look up the device IP address, take the following steps: Use the free 2N® Network Scanner
application or view the information on the device display.
To find the 2N®Indoor Compact IP address via the 2N®Network Scanner, follow the steps
mentioned in the previous subsection, 2.4 2N® Indoor Compact LAN Location via 2N® Network
Scanner.Once started, the application begins to automatically search for all the 2N IP
intercoms in the LAN including their smart extensions (2N®Indoor Compact,2N®Indoor
Talk,2N®Indoor Touch), which are DHCP/statically assigned IP addresses. All the devices are
displayed in a table including the IP addresses assigned to them.
To find the 2N®Indoor Compact IP address using the display, press any key on the display to
quit the sleep mode. Click the right-hand lower button at the icon on the home screen to
display the Settings menu. Find the IP address information in the Settings / System / About
device menu.
2N® Indoor Compact User Manual
Dynamic/Static IP Address Switching
To be connected to the LAN properly, 2N®Indoor Compact has to be assigned a valid IP address
or obtain the IP address from the LAN DCHP server. Configure the IP address and DHCP in the
System / Network menu.
•
Use DHCP server – enable automatic obtaining of the IP address from the LAN DHCP
server. If there is no DHCP server or the DHCP cannot be used in your network, use the
manual network setting.
•
Static IP address – static IP address of the device. The address is used together with the
parameters below unless Use DHCP server is enabled.
•
Network mask – set the network mask.
2N® Indoor Compact User Manual
•
Default gateway – address of the default gateway, which provides communication with
off-LAN equipment.
•
Primary DNS – primary DNS address for domain name-to-IP address translation.
•
Secondary DNS – secondary DNS address where the primary DNS is unavailable.
2N® Indoor Compact User Manual
3. Configuration
•
3.1 Factory Reset
•
3.2 Software Configuration
Login
Fill in the 2N®Indoor Compact address or domain name into the internet browser to display the
login screen. The default login user name and password are as follows:
•
Username:Admin
•
Password:2n
Should the login screen fail to appear, you must have typed a wrong IP address/port or
the2N®Indoor Compact administration web server has been switched off. To find the correct IP
address, use the 2N®Network Scanner as described in 2.4 2N® Indoor Compact LAN Location
via 2N ® Network Scanner.
Language Selection
Use the menu in the right-hand upper corner of the web interface to select language.
Language Selection
3.1 Factory Reset
Reset Button
Located among the main unit connectors, the Reset button helps you reset the factory default
values, restart the device, find the device IP address and switch the static/dynamic mode.
IP Address Finding
Follow the instructions below toidentify thecurrent IP address:
•
Press and hold the RESET button.
•
Wait until the red and green LEDs go on simultaneously on the device and the acoustic
signal can be heard (approx. 15–35 s).
•
Release the RESET button.
•
The device automatically announces the current IP address.
2N® Indoor Compact User Manual
Note
•
The delay after pressing RESET till the first light and sound signalling is set to 15–
35 s depending on the 2N IP intercom/answering unit model used.
•
15 s is the valid value for 2N®Indoor Compact.
Static IP Address Setting
Follow the instructions below to switch on theStatic IP addressmode (DHCP OFF):
•
Press and hold the RESET button.
•
Wait until the red and green LEDs go on simultaneously on the device and the acoustic
signal can be heard (approx. 15–35 s).
•
Wait until the red LED goes off andthe acoustic signal can be heard (approx. for
another 3 s).
•
Release the RESET button.
The following network parameters will be set after restart:
•
IP address: 192.168.1.100
•
Network mask: 255.255.255.0
•
Default gateway: 192.168.1.1
2N® Indoor Compact User Manual
Dynamic IP Address Setting
Follow the instructions below to switch on theDynamic IP addressmode (DCHP ON):
•
Press and hold the RESET button.
•
Wait until the red and green LEDs go on simultaneously on the device and the acoustic
signal can be heard (approx. 15–35 s).
•
Wait until the red LED goes off andthe acoustic signal can be heard (approx. for
another 3 s).
•
Wait until the green LED goes off and the red LED goes on again andthe acoustic signal
can be heard (approx. for another 3 s).
•
Release the RESET button.
Factory Reset
Follow the instructions below toreset the factory default values:
•
Press and hold the RESET button.
2N® Indoor Compact User Manual
•
Wait until the red and green LEDs go on simultaneously and the acoustic signal can be
heard (approx. 15–35 s).
•
Wait until the red LED goes off andthe acoustic signal can be heard (approx. for
another 3 s).
•
Wait until the green LED goes off and the red LED goes on again andthe acoustic signal
can be heard (approx. for another 3 s).
•
Wait until the red LED goes off andthe acoustic signal can be heard (approx. for
another 3 s).
•
Release the RESET button.
Device Restart
Press the RESET button shortly (< 1 s) to restart the system without changing configuration.
2N® Indoor Compact User Manual
Note
•
The time interval between the short press of RESET and reconnection after restart
is 18 s for 2N® Indoor Compact.
2N® Indoor Compact User Manual
3.2 Software Configuration
Start Screen
The start screen gets displayed when you have logged in to the 2N® Indoor Compact web
interface. Use the button in the left-hand upper corner on each of the following web
interface pages to return to this screen anytime.The screen header includes the device name
(refer to the Display Name parameter in the Services / Phone / SIP menu). Use the buttons to
select the web interface languages. Click the Log out button in the right-hand upper corner to
log out.
The start screen also provides the first menu level and quick tile navigation to selected
2N®Indoor Compact configuration sections. Some tiles also display the state of selected
services.
•
3.2.1 Status
•
3.2.2 Directory
•
3.2.3 Services
•
3.2.4 Hardware
•
3.2.5 System
2N® Indoor Compact User Manual
3.2.1 Status
TheStatus menu provides clear status and other current information on the device. The menu
consists of three tabs:Device,Servicesand Events.
•
3.2.1.1 Device
•
3.2.1.2 Services
•
3.2.1.3 Events
2N® Indoor Compact User Manual
3.2.1.1 Device
Device
The tab displays information on the model, its features, firmware and bootloader versions, etc.
•
Factory Certificate Installed–specify the user certificate and private key to validate the
intercom right to communicate with the ACS.
•
Locate device– optical and acoustic signalling of a device. Optical signalling is possible
only if the device is equipped with control backlight (2N®IP Verso,2N®IP Solo,2N®IP
2N® Indoor Compact User Manual
Base,2N®IPVario,2N®IPForce,2N®IPSafetya2N®IPUni,2N®IndoorCompact,2N
®
IndoorTalk,2N®Indoor Touch,2N®IP Indoor Toouch 2.0). If a speaker is not integrated
in the device, make sure than an external speaker is connected (2N®IPAudio
Kitand2N®IPVideo Kit) to use sound signalling.
2N® Indoor Compact User Manual
3.2.1.2 Services
Services
The Services tab displays the status of the network interface and selected services.
2N® Indoor Compact User Manual
2N® Indoor Compact User Manual
3.2.1.3 Events
Events
The tab displays the last 500 events captured by the device. Every event includes the capturing
time and date, event type and detailed description. The events can be filtered by type in a
dropdown menu above the event log.
2N® Indoor Compact User Manual
3.2.2 Directory
Directory is one of the crucial parts of the device configuration. It helps add new devices (2N IP
intercoms and other answering units) and provides essential information on them.Up to 200
devices can be added to the directory.
The Search function works as a fulltext search in names and phone numbers.It searches for all
matches in the whole directory. The icon helps find registered devices and add them to the
Directory list if necessary.The icon helps create a new device and the icon displays
the user settings details. The icon helps remove a device from the list deleting all its data.
You can arrange the list according to the name or feature ( indicates that the device may be
displayed, indicates that incoming calls are allowed to the device and indicates the
feature of the device to which the alarm call started with a doorbell button press is created). One
list page can include 15, 25 or 50 devices.
2N® Indoor Compact User Manual
Each device list item includes the following data:
•
Device Name – enter the device name for the selected Phone Book position. This
parameter is optional and helps you find items in the Phone Book more easily.
•
Displayed Icon – display the reception desk symbol or a standard symbol.
•
Device Type – set this parameter manually or automatically using the search for
registered devices in the directory.
•
Phone Number – set the phone number for the call to be directed to. Enter sip:
[user_id@]domain[:port] for Direct SIP calling, e.g.: sip:200@192.168.22.15 or
sip:name@yourcompany.Enter device:device_name for calls to the 2N® IP Mobile
application. Set the device name in the mobile application. Enter/1 or/2 behind the phone
number to specify which SIP account shall be used for outgoing calls (account 1 or 2).
Enter /S or /N to force an encrypted or unencrypted call respectively. The account and
encryption selections can be combined into the suffix /1S, for example.
•
Enable Camera Switching – set whether or not an external camera is available at the
contact terminal equipment (accordingly, the internal/external camera button is/is not
displayed during calls and call previews). With some 2Nterminal equipment in the LAN,
the information sent by the 2Nterminal equipment is preferred to this setting (i.e. this
setting is not needed for contacts using 2N terminals or camera-less devices).
2N® Indoor Compact User Manual
•
Display Device – display this device. The user can select and call for any device displayed.
•
Display on top – display the device on the top.
•
Alternative name – display an alternative name instead of the device name.
Caution
•
The <, > and / characters are not allowed for the Device name and Alternative
name parameters.
•
Start call with a short press – a phone call to this device will be set up after a short press
of the call button. The entrance door will be unlocked after a short press of the unlock
button.
•
Start call with a dorbell button press – a phone call to this device will be set up after the
call button is pressed. Set alarm call activation for the doorbell in the HW / Digital inputs /
Doorbell button section.
•
Name –enter the code assigned to unlock button #1, #2, #3.
•
Lift–selectthe door lock / lift unlock button icon on the display.
2N® Indoor Compact User Manual
• Code 1, 2, 3, 4– It is used for remote unlocking of the entrance door, for example. Make
sure that the code includes at least two door unlocking characters via the intercom
keypad and at least one door unlocking DTMF character via a phone.The supported
characters also inlcude * or#.Four characters at least are recommended.
2N® Indoor Compact User Manual
3.2.3 Services
•
2.3.2.3 HTTP Command
•
3.2.3.1 Phone
•
3.2.3.2 Unlocking
•
3.2.3.4 User Sounds
•
3.2.3.5 Web Server
2N® Indoor Compact User Manual
3.2.3.1 Phone
Phone is the basic function of 2N®Indoor Compact allowing you to establish connections with
other IP network terminals.2N®Indoor Compact supports the extended SIP.
List of Parameters
2N®Indoor Compact Phone includes the following four tabs:
•
SIP 1– complete SIP account settings.
•
SIP 2– complete SIP account settings.
•
Calls – incoming and outgoing call settings.
•
Audio – audio codec, DTMF and other audio stream parameter transmission settings.
•
Video –video codec and SDP codec settings.
•
2N Indoor Units – general parameters and count of identified LAN devices.
SIP 1 and SIP 2
2N®Indoor Compact helps you configure one SIP account.
2N® Indoor Compact User Manual
•
Display Name – set the name to be displayed as CLIP on the called party's phone.
•
Phone Number (ID) – set your device phone number (or another unique ID composed of
characters and digits). Together with the domain, this number uniquely identifies the
device in calls and registration.
•
Domain – set the domain name of the service with which the device is registered.
Typically, it is equivalent to the SIP Proxy or Registrar address.
•
Test Call – display a dialogue window enabling you to make a test call to a selected phone
number, see below.
•
Use Authentication ID – select the use of an alternative ID for device authentication.
Otherwise, the Phone number value from the previous section is used for authentication.
•
Authentication ID – set the alternative user ID for device authentication.
•
Password – set the device authentication password. If your PBX requires no
authentication, the parameter will not be applied.
2N® Indoor Compact User Manual
•
Proxy Address – set the SIP Proxy IP address or domain name.
•
Proxy Port – set the SIP Proxy port (typically 5060).
•
Backup Proxy Address – set the backup SIP Proxy IP address or domain name. The
address is used where the main proxy fails to respond to requests.
•
Backup Proxy Port – set the backup SIP Proxy port (typically 5060).
•
Registration Enabled – enable device registration with the set SIP Registrar.
•
Registrar Address – set the SIP Registrar IP address or domain name.
•
Registrar Port – set the SIP Registrar port (typically 5060).
•
Backup Registrar Address – set the backup SIP Registrar IP address or domain name. The
address is used where the main registrar fails to respond to requests.
•
Backup Registrar Port – set the backup SIP registrar port (typically 5060).
•
Registration Expiry– set the registration expiry, which affects the network and SIP
Registrar load by periodically sent registration requests. The SIP Registrar can alter the
value without letting you know.
•
Registration State – display the current registration state (Unregistered, Registering...,
Registered, Unregistering...).
•
Failure Reason – display the reason for the last registration attempt failure: the registrar’s
last error reply, e.g. 404 Not Found.
2N® Indoor Compact User Manual
•
SIP Transport Protocol – set the SIP communication protocol: UDP (default), TCP or TLS.
•
Lowest Allowed TLS Version– set the lowest TLS version to be accepted for device
connection.
•
Verify Server Certificate– verify the SIP server public certificate against the CA
certificates uploaded in the device.
•
Client Certificate – specify the client certificate and private key used for verifying the
intercom’s authority to communicate with the SIP server.
•
Local SIP Port – set the local port for thedevice for SIP signaling. A change of this
parameter will not be applied until the deviceis restarted. The default value is 5060.
•
PRACK Enabled – enable the PRACK method for reliable confirmation of SIP messages
with codes 101–199.
•
REFER Enabled – enable call forwarding via the REFER method.
•
Send Keep Alive Packets – set that the device shall inquire periodically about the state of
the called station via SIP OPTIONS requests during the call (used for station failure
detection during the call).
2N® Indoor Compact User Manual
•
IP Address Filter Enabled – enable the blocking of SIP packet receiving from addresses
other than SIP Proxy and SIP Registrar. The primary purpose of the function is to enhance
communication security and eliminate unauthorized phone calls.
•
Receive encrypted calls only (SRTP) – set that SRTP encrypted calls shall only be
received on this account. Unencrypted calls will be rejected. At the same time, TLS is
recommended as the SIP transport protocol for higher security.
•
Encrypted outgoing calls (SRTP) – set that outgoing calls shall be SRTP encrypted on this
account. At the same time, TLS is recommended as the SIP transport protocol for higher
security.
•
Do Not Play Incoming Early Media – disable playing of the incoming audio stream before
the call sent by some PBXs or other devices is picked up (early media). A standard local
ringtone is played instead.
•
QoS DSCP Value – set the SIP packet priority in the network. The set value is sent in the
TOS (Type of Service) field in the IP packet header. Enter the value as a decimal number.A
change of this parameter will not be applied until the deviceis restarted.
•
External IP Address – set the public IP address or router name to which the device is
connected. If the device IP address is public, leave this parameter empty.
•
Starting RTP Port – set the initial local RTP port in the range of 64 ports used for audio
and video transmission. The default value is 4900 (i.e. the range is 4900–4963). The
parameter is only set for account 1 but applies to both the SIP accounts.
•
RTP Timeout – set the audio stream RTP packet receiving timeout during a call. If this
limit is exceeded (RTP packets are not delivered), the call will be terminated by the device.
Enter 0 to disable this parameter.The parameter is only set for account 1 but applies to
both the SIP accounts.
•
Broadsoft Compatibility Mode – set the Broadsoft PBX compatibility mode. Having
received re-invite from a PBX in this mode, the intercom replies by repeating the last sent
SDP with currently used codecs instead of sending a complete offer.
•
Rotate SRV Records – allow SRV record rotation for SIP Proxy and Registrar. This is an
alternative method of transition to backup servers in the event of main server failure or
unavailability.
Calls
•
Call Time Limit – set the call time limit after which the call is automatically terminated.
The intercom signals termination with a beep 10 s before the call end. Enter any DTMF
character into the call (# on your IP phone, e.g.) to extend the call time.
2N® Indoor Compact User Manual
•
Call Answering Mode (SIP 1, SIP 2) – set the way of receiving incoming calls. The
following three options are available:
•
Always busy–the device rejects incoming calls.
•
Manual Pickup– the device rings to signal incoming calls and the user can press a
keypad button to pick up.
•
Automatic– the device picks up incoming calls automatically. You can set the call
receiving mode for each SIP account separately.
•
Local Call Receiving Mode –set the way of receiving incoming local calls. The following
three options are available:
•
Always busy–the device rejects incoming calls.
•
Manual Pickup– the device rings to signal incoming calls and the user can press a
keypad button to pick up.
•
Automatic– the device picks up incoming calls automatically. You can set the call
receiving mode for each SIP account separately.
•
Pick up in – this parameter is only active when the Automatic pickup mode is enabled.
The call is picked up automatically after the preset timeout elapses.
•
Ring Time Limit – set the maximum call setup and ringing time in which all outgoing calls
are automatically terminated. If the calls are routed to the GSM network via GSM
gateways, you are advised to set a value longer than 20 s. Minimum value: 1 s, maximum
value: 600 s. Set 0 to disable the time parameter.
2N® Indoor Compact User Manual
••Save Image during Call – if enabled, one snapshot is automatically taken from each video
call and saved into the call log.
Caution
•
If the Save Image during Call function is disabled, all the snapshots will be deleted
while the call logs will be preserved.
Audio
Enable/disable the use of audio codecs for call setups and set their priorities.
The tab helps you define how DTMF characters shall be sent from the intercom. Check the DTMF
receiving options and settings of the opponent to make the function work properly.
2N® Indoor Compact User Manual
•
In-Band (Audio)– enable classic DTMF dual tone sending in the audio band.
•
RTP (RFC-2833)– enable DTMF sending via the RTP according to RFC-2833.
•
SIP INFO (RFC-2976)– enable DTMF sending via SIP INFO messages according to
RFC-2976.
The tab helps you define how DTMF characters shall be received from the intercom. Check the
opponent’s DTMF receiving options and settings to make the function work properly.
•
In-Band (Audio) – enable classic DTMF dual tone receiving in the audio band.
•
RTP (RFC-2833) – enable DTMF receiving via RTP according to RFC-2833.
•
SIP INFO (RFC-2976) – enable DTMF receiving via SIP INFO messages according to
RFC-2976.
•
•
Video
QoS DSCP Value – set the audio RTP packet priority in the network. The set value is sent in
the TOS (Type of Service) field in the IP packet header.
Jitter Compensation – set the buffer length for compensation of interval unevenness in
audio packet arrivals. A higher capacity improves the transmission resistance at the cost
of a greater sound delay.
2N® Indoor Compact User Manual
•
Enable/disable the use of video codecs for call setups and set their priorities.
•
H.264 Payload Type (1), (2) – set the video codec H.264 payload type (packetization
mode 1). Set a value from the range of 96 through 127, or 0 to disable this codec type.
Local Calls
•
Enable Local Calls – enable calls between devices in the LAN. With this function off, the
other LAN devices cannotlocate this device, i.e. cannot call the device in the
device:device_ID format.
•
Device ID – Set the device ID to be displayed in the LAN device list in all the 2N devices in
one and the same LAN. You can direct a call to this device by setting the user phone
number as device:device_ID in these devices.
2N® Indoor Compact User Manual
•
Access Key 1, 2 – set the access key shared by the 2N answering units and intercoms. If the
keys in the 2N answering units and intercoms fail to match, the device cannot
communicate, i.e. the intercom cannot call the 2N answering unit and vice versa.
•
Access Key – set the access key sharedby the 2N answering units.If the keys in the 2N
answering units fail to match, the answering units cannot communicate, i.e. the answering
units cannot call each other.
•
Multicast Address– set the network multicast address to which the anwering unit
message shall be sent.
•
LAN Device count – display the number of local devices in the network.
•
Show LAN devices list –display a detailed list of local devices in the network.
2N® Indoor Compact User Manual
3.2.3.2 Unlocking
Unlocking is another function of 2N®Indoor Compact, which sets the remote door unlocking
parameters.
•
Default Unlock Code – use this code when a call has been set up with a device/phone
number that is not added to the unit phone book.
•
Hang up After Door Unlocking – end the call when the door unlocking request has been
sent successfully.
•
Hang-up delay– end the call when the door unlocking request sending timeout has
elapsed.
2N® Indoor Compact User Manual
2.3.2.3 HTTP Command
HTTP příkaz na odpovídací jednotce2N®Indoor Compactslouží k odesílání až 3 zvolených
HTTP příkazů pomocí stisku tlačítka. Dlouhým stiskem tlačítka zámku budou na displeji
zobrazena dostupná tlačítka příslušných HTTP příkazův případě, že je funkce nastavena.
•
URL– set the HTTP command to be sent to an external device by pressing a button. The
command is sent via the HTTP (GET request). The command format ishttp://ip_address/
path. E.g.http://192.168.1.50/relay1=on. If the parameter is empty, the command is not
sent.
•
Icon– choose the HTTP command button icon. The button is displayed on the device
home page and can be used for sending the set HTTP command.
•
Jméno– uživatelské pojmenování HTTP příkazu.
•
Username– set the user name for authentication of the HTTP command to be sent by
pressing a button. The parameter is mandatory only if the requested device requires
authentication.
•
Password– set the password for authentication of the HTTP command to be sent by
pressing a button. The parameter is mandatory only if the requested device requires
authentication.
2N® Indoor Compact User Manual
3.2.3.4 User Sounds
2N® Indoor Compact signals variable operational statuses with a sequence of tones. If the
standard signaling tones do not meet your requirements, you can modify them.
The device allows you to modify sound signaling for the following states:
a.
Ringtone before call pickup
b.
Ringing tone
c.
Busy tone
d.
Call end signaling
e.
Doorbell
Sound Mapping
•
Ringing before Call Pickup – set the ringtone to be played before an incoming call is
picked up (device ringtone).
2N® Indoor Compact User Manual
•
Ringback Tone–set the sound to be played when the called user is ringing. The PBX
ringtone is preferred to the user ringtone in the device.
•
Call Busy Tone–set the tone to be played when the called user is busy.
•
Call Hang-Up Signaling – set the tone to signal the call end.
•
Doorbell–set the tone to be played when the doorbell is used.
Sound Upload
You can upload up to 10 user sound files to the device and name each of them for better
orientation.
Press to upload a sound file to the device. Select a file from your PC and click Upload. Press
to remove a file. Click to play a successfully uploaded sound file (locally on your PC).
Press to record a sound file via your PC microphone.
2N® Indoor Compact User Manual
3.2.3.5 Web Server
2N® Indoor Compact can be configured using a common browser that approaches the web
server integrated in the device. The HTTPS protocol is used for the browser - device
communication. Enter the login user name and password first. The default values are admin and
2n respectively. We recommend to you change the default password as soon as possible.
List of Parameters
•
Device Name – set the device name to be displayed in the right-hand upper corner of the
web interface, in the login window and in other applications if necessary (Network
Scanner, etc.)
•
Web Interface Language– set the default language after the administration web server
login. Use the upper toolbar buttons to change the web interface language temporarily
any time.
2N® Indoor Compact User Manual
•
Password – set the device login password. Click to edit the password. Make sure that
the password contains 8 characters at least, including one small alphabet letter, one
capital alphabet letter and one digit.
•
HTTP Port – set the web server port for HTTP communication. The port change will not be
applied until the device is restarted.
•
HTTPS Port – set the web server port for HTTPS communication. The port change will not
be applied until the device is restarted.
•
Minimum Allowed TLS Version – set the lowest TLS version to be accepted for device
connection.
•
HTTPS User Certificate – set the user certificate and private key for communication
encryption between the device HTTP server and the user web browser. Choose one of the
three sets of user certificates and private keys (refer to the Certificates subs.) or keep the
Self Signed setting, in which the certificate automatically generated upon the first
intercom power up is used.
•
Remote Access Enabled – enable remote access to the device web server from off-LAN IP
addresses.
•
Original Language– download an original file from the device including all user interface
texts in English. The file format is XML; see below.
•
Custom Language – upload, download and/or remove user files including translations of
the user interface texts.
2N® Indoor Compact User Manual
3.2.4 Hardware
The Audio menu clearly displays the current audio information and features.
•
3.2.4.1 Audio
•
3.2.4.2 Display
•
3.2.4.3 Digital Inputs
2N® Indoor Compact User Manual
3.2.4.1 Audio
2N®Indoor Compact is equipped with a speaker.Set the phone call and state signaling volume
control in this configuration section.Master Volume controls the general device volume
including call volume, signaling tone volume, and so on. Consider the noise level of the ambient
environment while setting this parameter.
List of Parameters
•
Call Volume – set the phone call volume.
•
Ringtone Volume – set the incoming call ringtone volume.
•
Call-Progress Tone Volume – set the dialtone, ringtone and busy tone volume levels. In
case the call progress tones are automatically generated by the PBX, this setting will not
be applied.
2N® Indoor Compact User Manual
•
Key Beep Volume–set the key beep volume. The volume values are relative against the
set master volume.
•
Warning Tone Volume – set the volume of warning and signaling tones.The volume
values are relative against the set master volume.
•
Suppress Warning Tones – suppress signaling of the following operational states:
Internal application started, IP address received and IP address lost.
•
User Sound Volume – set the volume of the user sounds. The volume values are relative
against the set master volume.
•
DND Mode for Doorbell Button– if this function is activated, the device will not ring when
the doorbell is pressed.
•
Reject Call– if this function is activated, the device reject calls in the Do not Disturb mode.
The function can be used for immediate call redirection at absence to a mobile phone call,
for example.
2N® Indoor Compact User Manual
3.2.4.2 Display
Set the basic display parameters on this tab.
•
Language – set the language for the texts to be displayed. Choose one of the seven pre-
defined languages (CZ, EN, DE, FR, ES, IT, RU).
•
Date Format – set the date format to be displayed.
•
Time Format – set the time format to be displayed.
•
Enable Screen Lock– activate the screen lock function.
•
Screen Lock PIN – set the screen lock activation/deactivation code.
•
Display Setting Menu – display the Setting menu.
•
Display Time in Idle Mode – switch off the device display and all backlight in the idle
mode.
2N® Indoor Compact User Manual
•
Intensity in Active Mode–set the display and button backlight intensity values.Set the
value as a percentage of the maximum possible LED brightness.
•
Decrease Intensity in Idle Mode to– backlight intensity decrease when the device has
switched to the idle mode.
•
Go to Idle Mode in– inactivity timeout after which the device switches to the idle mode.
•
Backlit Buttonsin Idle Mode – enablebutton backlight in idle mode if checked.
•
Original Language– download the localization file template for own translation. It is an
XML file with all the texts to be displayed.
Note
If none of the pre-defined languages is convenient for you, proceed as follows:
•
Download the original language file (English).
•
Modify the file using a text editor (replace the English texts with your own ones).
•
Upload the modified localization file back to the intercom.
•
Set Language Settings | Language to Custom.
•
Check and correct if necessary the texts on the intercom display.
2N® Indoor Compact User Manual
3.2.4.3 Digital Inputs
This subsection describes the digital input options of the device.
•
Doorbell Button Function – select doorbell function (doorbell, alarm call). The button is
used either as a classical doorbell or for alarm call activation.
2N® Indoor Compact User Manual
3.2.5 System
Here is what you can find in this section:
•
3.2.5.1 Network
•
3.2.5.2 Date and Time
•
3.2.5.3 Certificates
•
3.2.5.4 Auto Provisioning
•
3.2.5.5 Syslog
•
3.2.5.6 Maintenance
2N® Indoor Compact User Manual
3.2.5.1 Network
To be connected to the LAN properly, 2N®Indoor Compact has to be assigned a valid IP address
or obtain the IP address from the LAN DCHP server. The Network section helps you configure the
IP address and DHCP.
Tip
•
To look up the current 2N®Indoor Compact IP address, apply the 2N® Network
Scanner, which can be downloaded freely from www.2n.com, and use the
mechanism described in 2.4 2N® Indoor Compact LAN Location via 2N® Network
Scanner.
2N® Indoor Compact User Manual
List of Parameters
Basic
•
Use DHCP server – enable automatic obtaining of the IP address from the LAN DHCP
server. If the DHCP server is unavailable or otherwise inaccessible in your LAN, use the
manual network settings.
•
Static IP Address – static IP address of the device. The address is used together with the
parameters below unless Use DHCP server is enabled.
•
Network Mask – network mask setting.
•
Default Gateway – default gateway address for off-LAN communication.
•
Primary DNS – primary DNS address for domain name-to-IP address translation.
•
Secondary DNS – secondary DNS address where the primary DNS is unavailable.
•
Hostname–set the device LAN identification.
•
Vendor Class Identifier – set the manufacturer identifier as a character string for DHCP
Option 60.
2N® Indoor Compact User Manual
•
VLAN Enabled – enable the virtual network support (VLAN according to 802.1q).
Remember to set the VLAN ID too.
•
VLAN ID – choose a VLAN ID from the range of 1–4094. The device shall only receive
packets with the set ID. An incorrect setting may result in a connection loss and
subsequent factory reset.
•
Required Port Mode – set the LAN port mode to be preferred: Automatic or Half Duplex –
10 Mbps. The bit rate is reduced to 10 Mbps in case the available LAN cabling is unreliable
for a 100 Mbps traffic.
•
Current Port State – current LAN port state: Half or Full Duplex – 10 Mbps or 100 Mbps.
•
Verify the network address accessibility – check the accessibility of a given address in
the LAN via the Ping command like in common operating systems. Press Ping to display a
dialogue for you to enter the IP address/domain name and press Ping to send the test data
to the set address. If the IP address/domain name is invalid, a warning is displayed and the
Ping button remains inactive until the IP address becomes valid. The dialogue also
displays the procedure state and result. Failed means that either the IP address was
unavailable within 10 s or it was impossible to translate the domain name into an address.
If a valid response is received, the response sending IP address and response waiting time
in milliseconds are displayed. Press Ping again to send another query to the same address.
2N® Indoor Compact User Manual
801.1x
•
•
•
Device Identity– username (identity) for authentication via EAP-MD5 and EAP-TLS.
MD5 Authentication Enabled– enable authentication of network devices via the 802.1x
EAP-MD5 protocol. Do not enable this function if your LAN does not support 802.1x. If you
do so, the intercom will become inaccessible.
Password– enter the access password for EAP-MD5 authentication.
•
TLS Authentication Enabled– enable authentication of network devices via the 802.1x
EAP-TLS protocol. Do not enable this function if your LAN does not support 802.1x. If you
do so, the intercom will become inaccessible.
•
Trusted Certificate– specify the set of trusted certificates for verification of the RADIUS
server public certificate validity. Choose one of three sets of certificates; refer to the
Certificates subsection. If no trusted certificate is included, the RADIUS public certificate is
not verified.
•
User Certificate– specify the user certificate and private key for verification of the
intercom authorisation to communicate via the 802.1x-securednetwork element port in
2N® Indoor Compact User Manual
the LAN. Choose one of three sets of user certificates and private keys; refer to the
Certificates subsection.
2N® Indoor Compact User Manual
Note
•
This function is available with the Gold or Enhanced Security license only.
•
Authentication Allowed – enable authentication of network devices via the 802.1x PEAP
MSCHAPv2 protocol. Do not enable this function if your LAN does not support 802.1x. If
you do so, the device will become inaccessible.
•
Trusted Certificate – specify the set of trusted certificates for verification of the RADUIS
server public certificate validity. Choose one of three certificate sets, see the Certificates
subsection. If no trusted certificate is included, the RADIUS public certificate is not
verified.
•
Password – enter the access password for PEAP-MSCHAPv2 authentication.
Trace
The Trace tab helps you trigger capturing of incoming and outgoing packets via the2N®Indoor
Compact LAN interface.The captured packets are stored in a 4 MB buffer. When the buffer
storage capacity is full, the oldest packets are rewritten automatically. You are recommended to
keep the video stream bit rate below 512 kbps while capturing packets.Press to start
capturing, to stop capturing and to download the captured packet file.
2N® Indoor Compact User Manual
3.2.5.2 Date and Time
2N®Indoor Compact is equipped with a real time clock to back up the device for even a few
days in case of power outage. ClickSynchronize to synchronize 2N®Indoor Compact with your
PC time value any time.
Time in 2N®Indoor Compact can be synchronized with any available SNTP server.
Note
•
A correct date/time value is unnecessary for the basic function of 2N®Indoor
Compact, but crucial for a proper function of time profiles and correct event times in
variable lists (Syslog, Entered cards, Logs downloaded via HTTP API, etc.).
In standard operational conditions, the2N®Indoor Compact real time circuit accuracy is ±0.005
%, which may represent an error of up to ±2 minutes per month.
2N® Indoor Compact User Manual
List of Parameters
•
Synchronize with browser – click the button to synchronize the device time with your
current PC time value.
•
Automatic Detection– define whether the time zone shall be detected automatically
from My2N. In case automatic detection is disabled, the Manual selection parameter is
Used (manually selected time zone or Own rule).
•
Detected Time Zone– display the automatically found time zone. In case the function is
unavailable or disabled, N/A is displayed.
•
Manual Selection– set the installation site time zone. Set the time shift and summer/
winter time transitions.
•
Custom Rule– if the device is installed on a site that it not included in the Time Zone
parameter, set the time zone rule manually. The rule is applied only if the Time Zone
parameter is set to Manual.
•
Use NTP Server – enable the use of the NTP server for internal time Synchronization.
•
NTP Server Address – set the IP address/domain name of the NTP server used for the
device internal time synchronization.
•
NTP Time Status – display the state of the last local time synchronization attempt via
NTP: Unsynchronized. Synchronized, Error.
2N® Indoor Compact User Manual
3.2.5.3 Certificates
Some2N®Indoor Compact LAN services use the secure TLS protocol for communication with
the other LAN devices. This protocol prevents third parties from eavesdropping on or modifying
call contents. TLS is based on one/two-sided authentication, which requires certificates and
private keys.
2N®Indoor Compact services that use TLS:
a.
Web server (HTTPS)
b.
E-mail (SMTP)
c.
802.1x (EAP-TLS)
d.
SIPs
2N®Indoor Compact allows you to download up to 3 sets of certificates issued by certification
authorities, which help you authenticate the communicating device, and also 3 user certificates
and private keys for encryption purposes.
Each certificate requiring service can be assigned one certificate set, refer to the Web Server,E-
mailandStreaming subsections. The certificates can be shared by multiple services.
2N®Indoor Compact accepts the DER (ASN1) and PEM certificates.
Once powered up, 2N®Indoor Compact generates automatically the so-called Self Signed
certificate and a private key, which can be used for the Web server and E-mailservices
without the need to upload a unique certificate and private key.
2N® Indoor Compact User Manual
Note
•
If you use the Self Signed certificate for encryption, the 2N® Indoor Compact web
server - browser communication is secure, but the browser notifies you that it cannot
authenticate the 2N®Indoor Compact certificate.
Refer to the tables below for the current list of trusted and user certificates:
Click to upload a certificate saved on your PC. Select the certificate (or private key) file in a
dialogue window and click Upload. Press to remove a certificate from 2N®Indoor
Compact.
2N® Indoor Compact User Manual
Caution
•
Note that a certificate with a private RSA key longer than 2048 bits may be rejected
and the following message will be displayed:
The private key file/password was not accepted by the device!
•
For certificates based on elliptic curves use the secp256r1 (aka prime256v1 aka
NIST P-256) and secp384r1 (aka NIST P-384) curves only.
2N® Indoor Compact User Manual
3.2.5.4 Auto Provisioning
2N® Indoor Compact helps you update firmware and configuration manually or automatically
from a selected TFTP/HTTP server storage according to predefined rules.
The TFTP and HTTP server addresses can be configured manually.2N® Indoor Compact
supports automatic address identification via the local DHCP server (Option 66).
My2N / TR069
Use this tab to enable and configure remote device management via the TR-069 protocol.
TR-069 helps you reliably configure the device parameters, update and back up configuration
and/or upgrade device firmware.
The TR-069 protocol is utilized by the My2N cloud service. Make sure that TR-069 is enabled and
Active profile set to My2N to make the device work with My2N properly. Only then the device will
be able to log in to My2N periodically for configuration.
This function helps you connect the device to your ACS (Auto Configuration Server). In this case,
the connection to My2N will be disabled in the device.
•
My2N / TR069 Enabled – enable connection to My2N or another ACS server.
2N® Indoor Compact User Manual
•
Active Profile – select one of the pre-defined profiles (ACS), or choose a setting of your
own and configure the ACS connection manually.
•
Next synchronization in – display the time period in which the device shall contact a
remote ACS.
•
Connection Status – display the current ACS connection state or error state description if
necessary.
•
Communication Status Detail – server communication error code or HTTP status code.
•
Connection test – test the TR069 connection according to the set profile, see the Active
profile. The test result is displayed in the Connection status.
•
My2N ID – unique identifier of the company created via the My2N portal.
•
My2N Security Code – device code for adding to My2N.
2N® Indoor Compact User Manual
3.2.5.5 Syslog
2N® Indoor Compact allows you to send syslog messages including relevant device state and
process information to a syslog server for recording and further analysis or auditing of the
device observed. It is unnecessary to configure this service for common operations.
List of Parameters
•
Send Syslog Messages– enable sending of syslog messages to the Syslog server. Make
sure that the server address is valid.
•
Server Address– IP/MAC address of the server on which the syslog recording application
is running.
•
Severity Level–set the severity level of the messages to be sent.Debug 1–3 level setting
is only recommended to facilitate troubleshooting for the Technical Support department.
2N® Indoor Compact User Manual
General overview of local syslog messages.
2N® Indoor Compact User Manual
3.2.5.6 Maintenance
This menu helps you maintain the device configuration and firmware. You can back up and
restore all the parameters, upgrade firmware and/or factory reset the device.
•
Restore Configuration – restore configuration from a previous backup. Press the button
to display a dialogue window to select a configuration file and upload it to the device.
Before uploading choose whether or not the LAN settings and SIP PBX connection settings
are to be applied.
•
Backup Configuration – back up the complete current device configuration. Press the
button to download the configuration file to your PC.
Caution
•
As the configuration may include delicate information, such as user phone numbers
and access passwords, handle the file cautiously.
•
Reset Configuration – reset all the device parameters except for the LAN parameters. To
reset the device completely, use the jumper or press Reset.
2N® Indoor Compact User Manual
•
Upgrade Device Firmware – upload a new firmware version to the device. Press the
button to display a dialogue window to select the proper firmware file. Once the firmware
is uploaded, the device is restarted automatically and becomes fully operational with a
new firmware version. The whole upgrading process takes less than one minute.
Download the current firmware version for your device fromwww.2n.com.Firmware
upgrade does not affect configuration. The device checks the firmware file and prevents
you from uploading an incorrect or corrupt file.
•
Firmware Status – check online if a later firmware version is available. If so, the
downloading option is offered followed by automatic upgrade.
•
Notify of Beta Versions – enable monitoring and downloading of the latest firmware beta
version.
•
Restart Device – restart the device. The process takes about 30 s. Once restart is
completed and the device is assigned its IP address, the login window will be displayed
automatically.
•
Licenses – click Show to open a dialogue window including a list of used licenses and
third-party libraries. It also includes a EULA link.
•
Send anonymous statistics data – enable sending of anonymous statistic data on device
usage to the manufacturer. No such delicate information as passwords, access codes or
phone numbers are included. This information helps 2N TELEKOMUNIKACE a.s. improve
2N® Indoor Compact User Manual
the software quality, reliability and performance. You can participate in this voluntarily
and cancel your statistic data deliveries any time.
2N® Indoor Compact User Manual
4. Device Control via Display
The backlit MENU buttons to the right and left help you control the device using the display. The
MENU buttons are used for shifting and confirming functions in the selected display menu. In
general, the MENU buttons to the right shift items up and down in the selected menu. The lefthand lower button confirms your selection and the left-hand upper button goes back by one
step with every press or returns to the home page.
Refer to the following subsections for more configuration details.
•
4.1 Directory
•
4.2 Call Log
•
4.3 Do Not Disturb Mode
•
4.4 Settings
1.
MENU buttons
2.
Lock button
3.
Call end button
4.
Call receiving button
Icons used on the display
2N® Indoor Compact User Manual
Icon Description
Directory
DND mode
Device configuration
Call log
Incoming call ringtone volume up
Incoming call ringtone volume down
Incoming call ringtone volume mute
Value up
Value down
Microphone mute in call
Locked, screen lock
Unlocked, screen lock activated/deactivated
Return to Home page
Confirmation
Device detail in Directory
2N® Indoor Compact User Manual
Icon Description
Call info
Camera 1
Camera 2
Back
Move up
Move down
4.1 Directory
Press the left-hand upper button at the icon to display the Directory list. The menu provides
a list of destinations that can be called. The destinations include their names and the device
type they are equipped with. The destinations that allow for some actions (calls) are white-
highlighted. The other destinations are gray.
2N® Indoor Compact User Manual
Use the backlit right-hand upper button and lower MENU button to move across the
Directory.Press the left-hand bottom button at the icon to show the camera preview if the
device is equipped with a camera. The camera preview option is based on the2N®Enhanced
Videolicense of the selected device. Together with the preview, if available, the device type,
name and icon details are displayed.
Press the call receiving button to start a call to the selected device or user. Click the lock button
to open the door during an incoming/outgoing call for the selected device.
When the intercom camera view is displayed on 2N® Indoor Compact during the call, you can
choose any of the following actions:
•
Switch camera using the left-hand upper MENU button at the / icon.
•
Mute microphone in callusing the left-hand lower MENU button at the icon.
•
Volume up using the right-hand upper MENU button at the icon.
•
Volume down using the right-hand lower MENU button at the icon.
•
Open door using the door lock button .
•
End call using the call end button.
Caution
•
The camera switching function is only displayed if it has been activated and
properly configured in the intercom.
Set the Directory via the web interface in the Directory / Device section. You can add a device
manually, by clicking on the device adding icon or automatically by clicking the registered
device searching icon . Select the device in the list to add it automatically to the Directory
list. The values are completed in the basic settings. With manual addition of a device/user to the
Directory, the basic parameters are not completed automatically but have to be added
manually. Make sure to complete the proper parameter in the Display section to display the
CLIP. This helps the user choose and call any device displayed; refer to 3.2.2 Directory for more
details.
2N® Indoor Compact User Manual
4.2 Call Log
Press the left-hand lower button at the icon todisplay the Call log.The menu provides a list
of all accomplished calls including date, time, status (ougoing/incoming/missed) and
information on from/to which destination the call was made. The destinations that allow for
some actions are white-highlighted; the other ones are gray. The maximum call count is 20.
You can choose any of the following actions from the 2N®Indoor Compactcall log:
•
Return to Home page using the left-hand upper MENU button at the icon.
•
Show detail of the accomplished call using the left-hand lower MENU button at the
detail icon.This displays an image from a camera if available including the caller's ID and
call time.
•
Record deletion– using the lower MENU button next to the icon .
•
Move up the list using the upper MENU button at the icon.
•
Move down the list using the lower MENU button at the icon.
Caution
•
The device restart results in a deletion of the call log.
2N® Indoor Compact User Manual
4.3 Do Not Disturb Mode
Press the right-hand upper MENU button at the icon to activate/deactivate the DND mode.
When DND is active, the device is at relax and the icon is red backlit. The device does not play the
selected ringtone to signal an incoming call.The display shows the camera view if available,
CLIP and Incoming call message.
4.4 Settings
Press the right-hand lower button at the icon to display the Device settings. Here set the
DND mode, screen lock, device sounds and tones and display/system properties.
2N® Indoor Compact User Manual
Do Not Disturb Mode
Enable/disable the DND mode using the left-hand lower button. With DND on, the icon on
the home page is red backlit.The device does not play the selected ringtone to signal an
incoming call.The display shows the camera view if available, CLIP and Incoming call message.
Screen Lock
2N® Indoor Compact User Manual
Enable/disable the screen lock (parental lock) using the left-hand lower button. Enter the PIN
code to enable the screen lock. Enter the same PIN code to disable the screen lock.
Sounds and Tones
Press the right-hand lower button at the icon to display the Sounds and Tones. Here set the
ringing/call volume and select the ringtone and door bell ringtone.
Ringing volume
2N® Indoor Compact User Manual
Press the right-hand upper/lower button to increase/decrease the ringing volume. Press the lefthand lower button to confirm the volume level selected. The change will not be saved unless
confirmed.
Call volume
Press the right-hand upper/lower button to increase/decrease the call volume. Press the lefthand lower button to confirm the call volume level selected. The change will not be saved unless
confirmed.
Key Beep Volume
2N® Indoor Compact User Manual
Press the right-hand upper/lower button to increase/decrease the key beep volume. Press the
left-hand lower button to confirm the key beep volume level selected. The change will not be
saved unless confirmed.
Ringtone
Press the right-hand upper/lower button to move up/down the ringtone list. Press the left-hand
lower button to confirm the ringtone selected. The change will not be saved unless confirmed.
Doorbell ringtone
2N® Indoor Compact User Manual
Press the right-hand upper/lower button to move up/down the doorbell ringtone list. Press the
left-hand lower button to confirm the ringtone selected. The change will not be saved unless
confirmed.
2N® Indoor Compact User Manual
Display
Press the right-hand lower button at the icon to display the Display section. Here set the
display brightness, idle timeout and button backlight.
2N® Indoor Compact User Manual
Brightness
Press the right-hand upper/lower button to increase/decrease the display brightness. Press the
left-hand lower button to confirm the brightness level selected. The change will not be saved
unless confirmed.
Screen timeout
Set the maximum idle time (i.e. when the user does not control the device) after which the sleep
mode is switched on automatically. Press the right-hand upper/lower button to move up/down
the time value list.The change will not be saved unless confirmed.
2N® Indoor Compact User Manual
Button backlight
Press the right-hand upper/lower button to increase/decrease the button backlight. Press the
left-hand lower button to confirm the backlight level selected. The change will not be saved
unless confirmed.
System
2N® Indoor Compact User Manual
Press the right-hand lower button at the icon to display the System section. Here set date
and time, My2N/SIP Proxy state and language and get basic information on the device.
Date and time
•
Automatic date and time– enable the use of the NTP server for automatic internal time
synchronization.
•
Date format– there are 3 date format options: 12.31.2019, 31.12.2019, 2019.12.31.
•
Use 24-hour time format– enable/disable the 24hour time format.
•
Set date – set the date manually unless automatic date synchronization is enabled.
•
Time Zone – set the time zone for your installation site to define time shifts and summer/
winter time transitions.
2N® Indoor Compact User Manual
Caution
•
The change will not be saved unless confirmed.
My2N/SIP Proxy State
The My2N/SIP Proxy section displays the current state of the My2N/SIP Proxy connections.
Loading...
