Page 1
shown in Brushed Nickel
with Mahogany blades
With clean, fluid lines, the rotational fan is a striking centerpiece in any space. Its movement
about its cylindrical center housing is smooth and quiet. dual fan heads can be infinitely
positioned in 180-degree arcs for optimum and customized air movement. As the angle between
the fan heads and the horizontal support rods is increased, so does the speed of axial rotation.
Matthews rotational fans circulate heat and air conditioning more efficiently than traditional paddle
fans. Constructed from cast aluminum and heavy stamped steel, the carries a limited lifetime
warranty. This model is also available without a light kit.
Product Features
American
Labor
AC
Motor
360°
Rotation
Safety Cage
Compatible
Damp
Location
Soothing
White Noise
LED
Lamp
Remote
Control
Unipack
Shipping
Page 2
shown in Brushed Nickel
with Barn Wood Blades
FINISH AND BLADE OPTIONS
shown in Textured Bronze
with Metal Blades and
Decorative Cage
shown in Brushed Nickel
with Mohogany Blades
shown in Textured Bronze
with Barn Wood Blades
shown in Matte Black
with Matte Black Blades
Standard Finishes
Matte Black BK
Textured Bronze TB
Brushed Nickel BN
NEW
Blade Styles
and Material
Solid Wood / Barn Wood WDBW
Solid Wood / Mahogany WD
Solid Wood / Matte Black WDBK
Metal w/ Decorative Cage MTL
Metal w/ Safety Cage MSAF
TECHNICAL SPECS
Overall Drop 14 inches / 41 cm + downrod length
Fan Weight 22 lbs
Voltage 110 (Contact us for 220 conversion)
Motor Type AC
Rotation Ye s
Downrods Lengths
Field cuttable, Non-
Threaded
inches: 5, 10, 20, 30, 48, 72
centimeters: 13, 25, 51, 76, 122, 183
Downrod Diameter 1 inch
Damp locations for all finishes
Environment
Neither coastal, saltwater nor
chlorine compatible
Ambience Soothing White Noise
Safety Certification UL / CUL
Warranty Limited Lifetime
NEW JAN 21, 2020 DOE MOTOR EFFICIENCY DATA
Fan Head Options
Solid Wood Metal with Guard
Fan Diameter 41 inches / 104 cm 39 inches / 99 cm
Fan Blade Diameter 16 inches / 41 cm 13 inches / 33 cm
Guard Options No Cage Option
Safety Cage or
Decorative Cage
RPM (Low / High) 757 / 1256 1069 / 1442
CFM (Low / High) 2557 / 4171 1844 / 3067
Watts (High) 87.36 80.50
CFM/Watt (High) 50.00 39.00
Blade Pitch 19° 31°
LIGHT KIT PHOTOMETRICS
Lamping (Replaceable) Integrated LED
Remote Dimmable Yes
Delivered Temperature in K 2969
Delivered Lumens 523.7
CRI 90
Watts 18
Hours 50,000
Light kit longevity if used 6 Hours/Day: 22.8 Years
STANDARD EQUIPMENT
One downrod of 10 inches / 25 cm
Vaulted ceiling canopy for up to 29°
Black 3-speed RF remote
control with reverse
ACCESSORY
Decora-style, 3-speed,
non-dimmable wall control
Page 3
TECHNICAL SPECIFICATIONS
6" / 15 cm diameter
2" / 5 cm
Downrods available in
inches: 5, 10, 20, 30, 48 or 72
centimeters: 13, 25, 51, 76, 122, or 183
7" / 18 cm
16" / 41 cm
Wood Blades
I
n
c
r
e
a
41" / 104 cm wood fan head | 39" / 99 cm metal fan head
s
i
n
g
A
n
g
l
e
s
o
f
F
a
n
H
e
O
CEILING PITCH TABLE
0/12 0 degrees
1/12 4.76 degrees
2/12 9.46 degrees
3/12 14.04 degrees
4/12 18.43 degrees
5/12 22.62 degrees
6/12 26.57 degrees
7/12 30.26 degrees
8/12 33.69 degrees
9/12 36.87 degrees
10/12 39.81 degrees
11/12 42.51 degrees
13" / 33 cm
2" / 5 cm
Metal Blades
3" / 8 cm
n
o
i
t
a
t
o
R
l
a
i
x
A
f
o
d
e
e
p
S
s
e
s
a
d
s
t
o
S
u
p
p
t
r
o
p
t
i
m
u
m
F
a
n
e
H
s
e
l
o
P
o
P
d
a
a
e
r
c
n
I
o
i
t
i
s
°
0
6
s
i
n
CEILING HEIGHT / DOWNROD
TABLE
Ceiling
Height
10 ft or less
10 -12 feet 10 inches / 25 cm
13 feet 20 inches / 51 cm
14 feet 30 inches / 76 cm
15 feet 48 inches / 122 cm
16 feet + 72 inches / 183 cm
Downrod Lengths
Field cuttable. Non-threaded
5 inches / 13 cm
Use safety cages if applicable
