Microwave Oven
TMV151F
Español . . . . . . . . . . . . . . . 25
Français . . . . . . . . . . . . . . 49
Welcome & Congratulations . . . . . . . 2
Important Safety Instructions . . . . . 3
Features & Specifications . . . . . . . . . 7
Before Operating . . . . . . . . . . . . . . . .9
Manual Operation . . . . . . . . . . . . . . 10
Operating Instructions . . . . . . . . . .14
Questions or for Service Call:
1-800-944-9044
1-800-668-4606
READ AND SAVE THESE INSTRUCTIONS
(U.S.)
(Canada)
Care and Cleaning . . . . . . . . . . . . . . 20
Before You Call . . . . . . . . . . . . . . . . . 22
(Troubleshooting Guide)
Warranty . . . . . . . . . . . . . . . . . . . . . . 24
P/N: 316488500
C/N: DE68-03267A
Welcome & Congratulations
Congratulations on your purchase of a new range! At Electrolux Home Products, we are very proud of our product and
are completely committed to providing you with the best service possible. Your satisfaction is our number one priority.
We know you’ll enjoy your new range and Thank You for choosing our product.
We hope you consider us for future purchases.
PLEASE CAREFULLY READ AND SAVE THESE INSTRUCTIONS
This Use & Care Manual provides specific operating instructions for your model. Use your microwave oven only as
instructed in this manual. These instructions are not meant to cover every possible condition and situation that may
occur. Common sense and caution must be practiced when installing, operating and maintaining any appliance.
Please record your model and serial numbers below for future reference.
Model Number :
Serial Number
Purchase Date :
This Use & Care Manual contains general operating instructions for your range andfeature information for several
models. Your microwave oven may not have all the described features. The graphics shown are representational. The
graphics on your microwave oven maynot look exactly like those shown.
:
2
Important Safety Instructions
What You Need to
Know About Safety
Instructions
Warning and Important Safety Instructions appearing in
this Use & Care Guide are not meant to cover all possible
conditions and situations that may occur. Common sense,
caution, and care must be exercised when installing,
maintaining, or operating microwave.
Always contact your dealer, distributor, service agent, or
manufacturer about problems or conditions you do not
understand.
Recognize Safety
Symbols, Words, Labels
DANGER
DANGER – Immediate hazards which WILL result in
severe personal injury or death.
WARNING
WARNING – Hazards or unsafe practices which COULD
result in severe personal injury or death.
CAUTION
CAUTION – Hazards or unsafe practices which COULD
result in minor personal injury.
CAUTION
To avoid personal injury or property damage, observe
the following:
Do not deep fat fry in oven. Fat could overheat and
1.
be hazardous to handle.
Do not cook or reheat eggs in shell or with an
2.
unbroken yolk using microwave energy. Pressure
may build up and erupt. Pierce yolk with fork or knife
before cooking.
3. Pierce skin of potatoes, tomatoes, and similar foods
before cooking with microwave energy. When skin is
pierced, steam escapes evenly.
Do not operate oven without load or food in oven
4.
cavity.
5. Use only popcorn in packages designed and labeled
for microwave use. Popping time varies depending
on oven wattage.
popping has stopped. Popcorn will scorch or burn.
Do not leave oven unattended.
Do not use regular cooking thermometers in oven.
6.
Most cooking thermometers contain mercury and
may cause an electrical arc, malfunction, or damage
to oven.
Do not use metal utensils in oven.
7.
8. Never use paper, plastic, or other combustible
materials that are not intended for cooking.
9. When cooking with paper, plastic, or other
combustible materials, follow manufacturer’s
recommendations on product use.
Do not use paper towels which contain nylon or
10.
other synthetic fibers. Heated synthetics could melt
and cause paper to ignite.
Do not continue to heat after
Do not heat sealed containers or plastic bags in
11.
oven. Food or liquid could expand quickly and cause
container or bag to break. Pierce or open container
or bag before cooking.
12. To avoid pacemaker malfunction, consult physician
or pacemaker manufacturer about effects of
microwave energy on pacemaker.
SAVE THESE INSTRUCTIONS
3
Important Safety Instructions
WARNING
To avoid risk of electrical shock or death, this oven must
be grounded and plug must not be altered.
Grounding Instructions
Oven MUST be grounded.
Grounding reduces risk of electric
shock by providing an escape wire
for the electric current if an electrical
short occurs. This oven is equipped
with a cord having a grounding wire with a grounding plug.
The plug must be plugged into an outlet that is properly
installed and grounded. See Installation Instructions.
Consult a qualified electrician or servicer if grounding
instructions are not completely understood, or if doubt
exists as to whether the oven is properly grounded.
Do not use an extension cord. If the product power cord
is too short, have a qualified electrician install a three-slot
receptacle. This oven should be plugged into a separate
60 hertz circuit with the electrical rating as shown in
specifications table. When the oven is on a circuit with
other equipment, an increase in cooking times may be
required and fuses can be blown.
Microwave operates on standard household current,
110-120V.
Federal
Communications
Commission Radio
Frequency Interference
Statement (U.S.A. Only)
This equipment generates and uses ISM frequency
energy and if not installed and used properly, that is in
strict accordance with the manufacturer’s instructions, may
cause interference to radio and television reception. It has
been type tested and found to comply with limits for ISM
Equipment pursuant to part 18 of FCC Rules, which are
designed to provide reasonable protection against such
interference in a residential installation.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause interference to radio or television reception, which
can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by
one or more of the following:
• Reorient the receiving antenna of the radio or television.
• Relocate the microwave oven with respect to the
receiver.
• Move the microwave oven away from the receiver.
• Plug the microwave oven into a different outlet so that
the microwave oven and the receiver are on different
branch circuits.
The manufacturer is not responsible for any radio
or television interference caused by unauthorized
modification to this microwave oven. It is the
responsibility of the user to correct such interference.
SAVE THESE INSTRUCTIONS
4
Important Safety Instructions
Precautions to Avoid
Possible Exposure to
Excessive Microwave
Energy
A. DO NOT attempt to operate this oven with the door
open since open door operation can result in harmful
exposure to microwave energy. It is important not to
defeat or tamper with the safety interlocks.
B. DO NOT place any object between the oven front
face and the door or allow soil or cleaner residue to
accumulate on sealing surfaces.
C. DO NOT operate the oven if it is damaged. It is
particularly important that oven door close properly
and that there is no damage to:
1. door (bent),
2. hinges and latches (broken or loosened),
3. door seals and sealing surfaces.
D. Oven should not be adjusted or repaired by anyone
except properly qualified service personnel.
WARNING
Liquids such as water, coffee, or tea are able to be
overheated beyond the boiling point without appearing
to be boiling due to surface tension of the liquid. Visible
bubbling or boiling when the container is removed from
the microwave oven is not always present. THIS COULD
RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING
OVER WHEN A SPOON OR OTHER UTENSIL IS
INSERTED INTO THE LIQUID. To reduce the risk of
injury to persons:
Do not overheat the liquid.
1.
2. Stir the liquid both before and halfway through
heating it.
Do not use straight-sided containers with narrow
3.
necks.
4. After heating, allow the container to stand in the
microwave oven for a short time before removing the
container.
5. Use extreme care when inserting a spoon or other
utensil into the container.
SAVE THESE INSTRUCTIONS
5
Important Safety Instructions
WARNING
When using electrical appliances, basic safety
precautions should be followed to reduce the risk
of burns, electric shock, fire, or injury to persons or
exposure to excessive microwave energy.
READ all instructions before using oven.
1.
2. READ AND FOLLOW the specific “PRECAUTIONS
TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY” on page 5.
3. Install or locate this oven ONLY in accordance with
the installation instructions in this manual.
4. Some products such as whole eggs and sealed
containers—for example, closed glass jars—are able
to explode and SHOULD NOT
oven.
5. Use this oven ONLY for its intended use as described
in this manual. Do not use corrosive chemicals or
vapors in this oven. This type of oven is specifically
designed to heat, cook, or dry food. It is not designed
for industrial or laboratory use.
6. As with any appliance, CLOSE SUPERVISION
necessary when used by CHILDREN or INFIRM
PERSONS.
7. See door cleaning instructions in the Care and
Cleaning section on page 20.
8. Baby food jars shall be open when heated and
contents stirred or shaken before consumption, in
order to avoid burns.
9. DO NOT use this oven for commercial purposes. It is
made for household use only.
be HEATED in this
is
10. DO NOT heat baby bottles in oven.
11. DO NOT operate this oven if it has a damaged cord
or plug, if it is not working properly, or if it has been
damaged or dropped.
12. This oven, including power cord, must be serviced
ONLY by qualified service personnel. Special tools
are required to service oven. Contact nearest
authorized service facility for examination, repair, or
adjustment.
13. DO NOT cover or block filter or other openings on
oven.
14. DO NOT store this oven outdoors. DO NOT use this
product near water – for example, near a kitchen
sink, in a wet basement, near a swimming pool or
similar locations.
15. DO NOT immerse cord or plug in water.
16. Keep cord AWAY
17. DO NOT let cord hang over edge of table or counter.
18. Clean the ventilating hood frequently.
19. DO NOT allow grease to accumulate on the hood or
filters.
20. Use care when cleaning the ventilating hood filters.
Corrosive cleaning agents such as lye-based oven
cleaners may damage the filters.
21. When flaming foods under the hood, turn the fan on.
22. Suitable for use above both gas and electric cooking
equipment 36 inches or less wide.
from HEATED surfaces.
CAUTION
To avoid risk of fire in the oven cavity:
a. DO NOT overcook food. Carefully attend oven when
paper, plastic, or other combustible materials are
placed inside the oven to facilitate cooking.
b. Remove wire twist-ties from paper or plastic bags
before placing bag in oven.
SAVE THESE INSTRUCTIONS
6
c. If materials inside the oven ignite, keep oven door
CLOSED, turn oven off and disconnect the power
cord, or shut off power at the fuse or circuit breaker
panel.
d. DO NOT use the cavity for storage. DO NOT leave
paper products, cooking utensils, or food in the cavity
when not in use.
Features & Specifications
R
OVEN SPECIFICATIONS
Power Supply 120 VAC,60 Hz
Input Power 1,650 W
Cooking Power 1,000 W
(IEC 60705 Standard)
Frequency 2,450 MHz
Rated Current 14.5 A
Outer Dimensions
29 7/8” x 16 1/2” x 15”
(WxHxD)
Cavity Volume 1.5 Cu. Ft.
Net Weight 45.4 lbs.
7
Features & Specifications
FEATURES
1. DISPLAY: The Display includes a clock and indicators
to tell you time of day, cooking time settings and
cooking functions selected.
2. POPCORN: Touch this pad when popping popcorn
in your microwave oven. See page 14 for more
information.
3. COOK: Touch this pad to cook beverage, bacon,
frozen dinner, frozen breakfast. See page 15 for more
information.
4. PIZZA SLICE: Touch this pad to reheat pizza. See
page 14 for more information.
5. BAKED POTATO: Touch this pad to cook potatoes.
See page 14 for more information.
6. VEGETABLES: Touch this pad to cook fresh
vegetables, frozen vegetables. See page 14 for more
information.
7. REHEAT: Touch this pad to reheat dinner plate,
casserole, and pasta. See page 16 for more
information.
8. AUTO DEFROST: Touch this pad to defrost food by
weight. See page 17 for more information.
9. LESS: Touch this pad to subtract the cooking time.
See page 11 for more information.
11. NUMBER: Touch number pads to enter cooking time,
power level, quantities, or weights.
12. KITCHEN TIMER: Touch this pad to set the kitchen
timer. See page 10 for more information.
13. CLOCK: Touch this pad to enter the time of day. See
page 9 for more information.
14. VENT HI/LO/OFF: Touch this pad to turn the fan on or
off. See page 10 for more information.
15. ADD 30 SEC: Touch this pad to set and start
quickly at 100% power level. See page 10 for more
information.
16. SOUND ON/OFF: Touch this pad to turn off the
sound. OFF will appear in the display.
17. LIGHT HI/LO/OFF: Touch this pad to turn on the
cooktop light. See page 10 for more information.
18. POWER LEVEL: Touch this pad to select a cooking
power level.
19. STOP/CLEAR: Touch this pad to stop the oven or to
clear all entries.
20. ENTER/START: Touch this pad to start a function. If
you open the door after oven begins to cook, close
door and touch ENTER/START again.
10. MORE: Touch this pad to add more cooking time. See
page 11 for more information.
8
Before Operating
LEARN ABOUT YOUR MICROWAVE OVEN
This section introduces you to the basics you need to know to operate your microwave oven. Please read this
information before use.
CAUTION
• To avoid risk of personal injury or property damage, do not run oven empty.
• To avoid risk of personal injury or property damage, do not use stoneware, aluminum foil, metal utensils, or metal
trimmed utensils in the oven.
CLOCK
Example: To set 8:00.
1. Touch Clock pad.
2. Enter the time by using the number pads.
3. Touch ENTER/START pad.
MICROWAVE UTENSIL GUIDE
USE DO NOT USE
OVEN PROOF GLASS (treated for high intensity
heat):
Utility dishes, loaf dishes, pie plates, cake
plates, liquid measuring cups, casseroles and
bowls without metallic trim.
CHINA:
Bowls, cups, serving plates and platters without
metallic trim.
PLASTIC:
Plastic wrap (as a cover)-- lay the plastic wrap
loosely over the dish and press it to the sides.
Vent plastic wrap by turning back one edge
slightly to allow excess steam to escape. The
dish should be deep enough so that the plastic
wrap will not touch the food.
As the food heats it may melt the plastic wrap
wherever the wrap touches the food.
Use plastic dishes, cups, semirigid freezer
containers and plastic bags only for short
cooking times. Use these with care because the
plastic may soften from the heat of the food.
PAPER
Paper towels, waxed paper, paper napkins, and
:
paper plates with no metallic trim or design.
Look for the manufacturer’s label for use in the
microwave oven.
METAL UTENSILS
Metal shields the food from microwave energy and produces uneven
cooking. Also avoid metal skewers, thermometers or foil trays. Metal
utensils can cause arcing, which can damage your microwave oven.
METAL DECORATION
Metal-trimmed or metal-banded dinnerware, casserole dishes, etc. The
metal trim interferes with normal cooking and may damage the oven.
ALUMINUM FOIL:
Avoid large sheets of aluminum foil because they hinder cooking and
may cause harmful arcing. Use small pieces of foil to shield poultry
legs and wings. Keep ALL aluminum foil at least 1 inch from the side
walls and door of the oven.
WOOD
:
Wooden bowls and boards will dry out and may split or crack when
you use them in the microwave oven. Baskets react in the same way.
TIGHTLY COVERED UTENSILS
Be sure to leave openings for steam to escape from covered utensils.
Pierce plastic pouches of vegetables or other food items before
cooking.
Tightly closed pouches could explode.
BROWN PAPER:
Avoid using brown paper bags.
They absorb too much heat and could burn.
FLAWED OR CHIPPED UTENSILS
Any utensil that is cracked, flawed, or chipped may break in the oven.
METAL TWIST TIES
Remove metal twist ties from plastic or paper bags.
They become hot and could cause a fire.
:
:
:
:
:
9
Manual Operation
KITCHEN TIMER
You can use your microwave oven as a timer. Use the
Kitchen Timer for timing up to 99 minutes, 99 seconds.
Example: To set for 3 minutes.
1. Touch Kitchen Timer pad.
When the time is over, you will hear beeps and
display.
2. Enter the time by using the number
pads.
3. Touch ENTER/START pad.
End will
SOUND ON/OFF
1. Touch Sound On/off pad. The display
shows On.
2. Touch Sound On/off pad. The display
shows OFF.
3. Touch ENTER/START pad. The display
returns to the time of day.
CHILD LOCK
You may lock the control panel to prevent the microwave
from being accidentally started or used by children.
The Child Lock feature is also useful when cleaning the
control panel. Child Lock prevents accidental programming
when wiping the control panel.
Example: To set the child lock.
Touch and hold ENTER/START pad more
than 3 seconds. L will appear in the
display window with one beep.
Example: To cancel the child lock.
Touch and hold ENTER/START pad more
than 3 seconds. L will disappear and you
hear one beep.
LIGHT HI/LO/OFF
Touch Light Hi/Lo/Off pad once for bright
light, twice for night light, or three times to
turn the light off.
VENT HI/LO/OFF
The VENT moves steam and other vapors from the
cooking surface. The vent will operate at low speed
whenever the oven is on.
To operate the vent manually: Touch Vent
Hi/Lo/Off pad once for High fan speed,
twice for Low fan speed, or three times to
turn the fan off.
NOTE
• If the temperature gets too hot around the microwave
oven, the fan in the vent hood will automatically turn
on at the LOW setting to cool the oven. The fan will
automatically turn off when the internal parts are cool.
When this occurs, the vent cannot be turned off.
ADD 30 SEC.
A time-saving pad, this simplified control lets you quickly
set and start microwave cooking without the need to touch
the ENTER/ START pad at 100% power level.
Example: To set ADD 30 SEC. for 2 minutes.
Touch Add 30 Sec. pad 4 times. The oven
begins cooking and display shows time
counting down.
10
Manual Operation
DEMONSTRATION MODE
You can use the Demonstration mode to see how your
microwave oven operates without the oven heating.
To turn demo mode off, repeat step 1 above.
Touch 0 pad and 1 pad at the same time.
MORE/LESS
The More(9)/Less(1) pads allow you to adjust preset cooking times. They only work in the Reheat, Auto
Cooking, Add 30 sec, Time Cook modes. Use the More(9)/
Less(1) pads only after you have already begun cooking
with one of these procedures.
1. To ADD more time to an automatic
cooking procedure: Touch the More(9)
pad.
2. To REDUCE the time of an automatic
cooking procedure: Touch the Less(1)
pad.
COOKING AT HIGH POWER LEVELS
COOKING AT LOWER POWER LEVELS
HIGH power cooking does not always give you the best
results with foods that need slower cooking, such as
roasts, baked goods, or custards. Your oven has 9 power
settings in addition to HIGH.
Example: To cook food for 7 minutes 30 seconds at
70% power.
When the cook time is over, you will hear four beeps and
End will display.
See cooking guide for Power levels, page 12.
1. Enter the cook time.
2. Touch Power Level pad.
3. Enter the power level.
4. Touch ENTER/ START pad.
COOKING WITH MORE THAN ONE
COOK CYCLE
Example: To cook food for 8 minutes 30 seconds at
100% power.
When the cook time is over, you will hear four beeps and
End will display.
1. Enter the cook time.
2. Touch ENTER/ START pad.
For best results, some recipes call for one Power Level
for a certain length of time, and another Power Level for
another length of time.Your oven can be set to change
from one to another automatically, for up to three cycles at
the first cycle is defrost.
Example: To cook food for 3 minutes at 90% power
and then 70% power for 7 minutes 30 seconds.
When the cook time is over, you will hear four beeps and
End will display.
1. Enter the first cook time.
2. Touch Power Level pad.
3. Enter the power level.
4. Enter the second cook time.
5. Touch Power Level pad.
6. Enter the power level.
7. Touch ENTER/ START pad.
11
Manual Operation
COOKING GUIDE FOR POWER LEVELS
The 9 power levels in addition to HIGH allow you to choose the best power level for the food you are cooking. Below are
listed all the power levels, examples of foods best cooked at each level, and the amount of microwave power you are
using.
POWER LEVEL MICROWAVE OUTPUT USE
10 High 100 % • Boil water.
• Cook ground beef.
• Make candy.
• Cook fresh fruits and vegetables.
• Cook fish and poultry.
• Preheat browning dish.
• Reheat beverages.
• Bacon slices.
9 90 % • Reheat meat slices quickly.
• Saute onions, celery, and green pepper.
8 80 % • All reheating.
• Cook scrambled eggs.
7 70 % • Cook breads and cereal products.
• Cook cheese dishes, veal.
• Cook cakes, muffins, brownies, cupcakes.
6 60 % • Cook pasta.
5 50 % • Cook meats, whole poultry.
• Cook custard.
• Cook whole chicken, turkey, spare ribs, rib roast, sirloin
roast.
4 40 % • Cook less tender cuts of meat.
• Reheat frozen convenience foods.
3 30 % • Thaw meat, poultry, and seafood.
• Cook small quantities of food.
• Finish cooking casserole, stew, and some sauces.
2 20 % • Soften butter and cream cheese.
• Heat small amounts of food.
1 10 % • Soften ice cream.
• Raise yeast dough.
12
Manual Operation
Getting The Best Cooking Results
To get the best results from your microwave oven, read and follow the guidelines below.
• Storage Temperature: Foods taken from the freezer or refrigerator take longer to cook than the same foods at
room temperature.
• Size: Small pieces of food cook faster than large ones, pieces similar in size and shape cook more evenly. For
even cooking, reduce the power level when cooking large pieces of food.
• Natural Moisture: Very moist foods cook more evenly because microwave energy is attracted to water
molecules.
• Stir foods such as casseroles and vegetables from the outside to the center to distribute the heat evenly and
speed cooking. Constant stirring is not necessary.
• Turn over foods like pork chops, roasts, or whole cauliflower halfway through the cooking time to expose all
sides equally to microwave energy.
• Place delicate areas of foods, such as asparagus tips, toward the center of the dish.
• Arrange unevenly shaped foods, such as chicken pieces or salmon steaks, with the thicker, meatier parts
toward the outside of the dish.
• Shield,
of poultry.
• Let It Stand: After you remove the food from the microwave, cover food with foil or casserole lid and let it stand
to finish cooking in the center and avoid overcooking the outer edges. The length of standing time depends on
the density and surface area of the food.
• Wrapping in waxed paper or paper towel: Sandwiches and many other foods containing prebaked bread
should be wrapped prior to microwaving to prevent drying out.
with small pieces of aluminum foil, parts of food that may cook quickly, such as wing tips and leg ends
13
Operating Instructions
POPCORN
CAUTION
• DO NOT leave microwave oven unattended while
popping corn.
Popcorn pad lets you pop 3.0 and 3.5 ounce bags of
commercially packaged microwave popcorn. Pop only one
package at a time. If you are using a microwave popcorn
popper, follow manufacturer’s instructions.
To correctly set your microwave oven, follow this chart:
Bag Size-ounces Times to touch
3.5 Once
3.0 - 3.5 Twice
Example: To pop a 3.5 oz. bag.
1. Touch Popcorn pad once.
2. The oven will start automatically.
When the cook time is over, you will hear four beeps and
End will display.
Recommended amounts: 3.0-3.5 ozs.
PIZZA SLICE
Pizza Slice pad lets you reheat up to three 3-5 oz. slices
of pizza.
Example: To reheat 1 slice of pizza.
1. Touch Pizza Slice pad once.
2. The oven will start automatically.
When the cook time is over, you will hear four beeps and
End will display.
Recommended amounts: 1-3 slices, (about 3-5 ozs. per
each slice)
NOTE
Use the More/Less pads to fit your temperature
preference.
VEGETABLES
The Vegetables pad lets you cook Vegetables with the
preset times and cook powers.
VEGETABLES provide two preset categories (fresh and
frozen) with a choice of 1 to 4 servings for each category.
IMPORTANT
When using Auto Cook, the oven must cool for 5 minutes
between uses or food will not cook properly.
BAKED POTATO
The Baked Potato pad lets you cook potatoes with the
preset times and cook powers. You can choose from 1 to 4
potatoes.
NOTES
• Cooking times based on an average 8-10 oz. potato.
• Before baking, pierce potato with fork several times.
• After baking, let stand for 5 minutes.
Example: To cook 2 potatoes.
1. Touch Baked Potato pad twice.
2. The oven will start automatically.
When the cook time is over, you will hear four beeps and
End will display.
Example: To cook 2 servings of Frozen vegetables.
1. Touch Vegetables pad twice.
2. Enter the serving size (1 to 4) using the
number pads.
3. Touch ENTER/START pad.
When the cook time is over, you will hear four beeps and
End will display.
NOTE
If food is not thoroughly cooked or reheated when using
the Auto Cook feature, complete cooking using a power
level and cooking time.
DO NOT continue using the Auto Cook pad.
Recommended amounts: 1-4 potatoes (about 8-10 ozs.
each).
14
Operating Instructions
COOK
Cook pad provides four preset categories for cooking.
Example: To Cook 8 ozs of Frozen Dinner.
1. Touch Cook pad three times.
2. Touch number pads to enter quantity,
serving size or package weight.
3. Touch ENTER/START pad.
Category Times to touch Display
Beverage
once Ac-1
Bacon twice Ac-2
Frozen Dinner
three times Ac-3
Frozen Breakfast four times
Ac-4
When the cook time is over, you will hear four beeps and
End will display.
COOK TABLE
CATEGORY DIRECTIONS AMOUNT
Popcorn
Potato
(Fr-1)
Fresh
Vegetables
(Fr-2)
Frozen
VEGETABLES
Vegetables
Pizza Slice
(Ac-1)
Beverage
(Ac-2)
Bacon
COOK
(Ac-3)
Frozen
Dinner
(Ac-4)
Frozen
Breakfast
Use only one microwave-only bag of popcorn at a time. Use caution when removing and
opening the hot bag from oven. Let oven cool for at least 5 minutes before using again.
Prick each potato several times with fork. Place on turntable in spoke-like fashion. Let stand 3-5
minutes. Let oven cool for at least 5 minutes before using again. Use More(9) pad when cooking
larger potatoes.
Place fresh vegetables in microwave-safe ceramic, glass or plastic dish and add 2-4 Tbs. water.
Cover with lid or vented plastic wrap during cooking and stir before standing. Let oven cool for
at least 5 minutes before using again. Use
carrots or broccoli spears.
Place frozen vegetables in microwave-safe ceramic, glass or plastic dish and add 2-4 Tbs.
water. Cover with lid or vented plastic wrap during cooking and stir before standing. Let oven
cool for at least 5 minutes before using again. Use
such as carrots or broccoli spears.
Put 1-3 slices of pizza on a microwave-safe plate with wide end of slice toward the outside edge
of the plate. Do not let slices overlap. Do not cover. Let oven cool for at least 5 minutes before
using again. Use
Use measuring cup or mug; do not cover. Place the beverage in the oven. After heating, stir well.
Let oven cool for at least 5 minutes before using again.
Note: • Reheat times based on an 8 ounce cup.
• Beverage heated with the beverage feature may be very hot.
• Remove container with care.
Place 2 paper towels on plate and arrange bacon on towels, do not overlap.
Cover with additonal paper towel. Remove paper towel immediately after cooking.
Use More(9)/Less(1) pads for desired crispness.
Remove food from outer wrapping and follow box instructions for covering and standing. Let
oven cool for at least 5 minutes before using again.
Follow package instructions for covering and standing. Use this pad for frozen sandwich,
breakfast entree, etc. Let oven cool for at least 5 minutes before using again.
More(9) pad to increase reheat time for thick crust pizza.
More(9) pad when cooking dense vegetables such as
More(9) pad when cooking dense vegetables
3.0-3.5 oz
1 package
1 to 4 potatoes
1 to 4 servings
1 to 4 servings
1 to 3 slices
0.5 cup
1 cup
2 cups
2 to 6 slices
8 to 14 oz.
4 to 8 oz.
NOTE
Desired food temperature varies from person to person.Use the More(9)/Less(1) pads to fit your temperature
preference.
15
Operating Instructions
REHEAT
Reheat pad provides three preset categories for reheating.
Example: To reheat 3 servings of Casserole.
1. Touch Reheat pad 2 times.
2. Touch number pads to enter quantity/
servings.
3. Touch ENTER/START pad.
When the cook time is over, you will hear four beeps and
End will display.
Category Times to touch Display
Dinner Plate once rh-1
Casserole twice rh-2
Pasta
3 times rh-3
REHEAT TABLE
CATEGORY DIRECTIONS AMOUNT
Use only pre-cooked, refrigerated foods. Cover plate with vented plastic wrap or waxed paper,
tucked under plate. If food is not as hot as you prefer after heating with REHEAT, continue
Dinner Plate
Casserole Cover plate with lid or vented plastic wrap. If food is not as hot as you prefer after heating with
Pasta
heating using time and power.
Contents: • 3-4 oz. meat, poultry or fish (up to 6 oz. with bone)
• 1/2 cup starch (potatoes, pasta, rice, etc.)
• 1/2 cup vegetables (about 3-4 oz.)
REHEAT, continue heating using time and power.
Stir foods once before serving.
Contents: • Casserole-refrigerated foods. (Examples: Beef stew, Lasagna)
• Pasta-Canned spaghetti and ravioli, refrigerated foods.
1 serving
(1 plate)
1 to 4 servings
NOTES
• Desired food temperature varies from person to person.Use the More(9)/Less(1) pads to fit your temperature
preference.
• Allow food to stand 1 to 5 minutes before serving.
16
Operating Instructions
AUTO DEFROST
Defrost choices are preset in the oven. The defrost feature
provides you with the best defrosting method for frozen
foods, because the oven automatically sets the defrosting
times according to the weight you enter. For added
convenience, the AUTO DEFROST beeps to remind you to
check or turn over the food during the defrost cycle.
After touching the Auto Defrost pad once, select the food
weight. Available weight ranges are 0.1 to 6.0 lbs.
Example: To defrost 1.2 lbs of meat.
1. Touch Auto Defrost pad.
2. Enter the weight.
3. Touch ENTER/START pad.
NOTES
• After you touch ENTER/ START pad, the display
counts down the defrost time. The oven will beep
twice during the Defrost cycle. At this time, open
the door and turn the food as needed. Remove any
portions that have thawed then return frozen portions
to the oven and touch ENTER/START pad to resume
the defrost cycle.
• The oven will not stop during the BEEP unless the
door is opened.
DEFROSTING GUIDE
Follow the instructions below when defrosting different
types of food.
Food
Roast
Beef,
Pork
Steaks,
Chops,
Fish
Ground
Meat
Standard
Amount
2.5-6.0 lbs. Start with the food placed fat side
down. After each stage, turn the food
over and shield any warm portions
with narrow strips of aluminum foil.
Let stand, covered for 15-30 minutes.
0.5-3.0 lbs. After each stage, rearrange the food.
If there are any warm or thawed
portions of food, shield them with
narrow flat pieces of aluminum foil.
Remove any pieces of food that are
nearly defrosted. Let stand, covered,
for 5-10 minutes.
0.5-3.0 lbs. After each stage, remove any pieces
of food that are nearly defrosted.
Let stand, covered with foil, for 5-10
minutes.
Procedure
Food
Whole
Chicken
Chicken
Pieces
Standard
Amount
2.5-6.0 lbs. Remove giblets before freezing
poultry. Start defrosting with the
breast side down. After the first
stage, turn the chicken over and
shield any warm portions with
narrow strips of aluminum foil. After
the second stage, again shield any
warm portions with narrow strips of
aluminum foil. Let stand, covered, for
30-60 minutes in the refrigerator.
0.5-3.0 lbs. After each stage, rearrange or
remove any pieces of food that are
nearly defrosted. Let stand for 10-20
minutes.
Procedure
DEFROST TIPS
• When using AUTO DEFROST, the weight to be entered
is the net weight in pounds and tenths of pounds (the
weight of the food minus the container).
• Use AUTO DEFROST only for raw food. AUTO
DEFROST gives best results when food to be thawed is
a minimum of 0°F (taken directly from a true freezer). If
food has been stored in a refrigerator-freezer that does
not maintain a temperature of 5°F or below, always
program a lower food weight (for a shorter defrosting
time) to prevent cooking the food.
• If the food is stored outside the freezer for up to 20
minutes, enter a lower food weight.
• The shape of the package alters the defrosting time.
Shallow rectangular packets defrost more quickly than a
deep block.
• Separate pieces as they begin to defrost. Separated
pieces defrost more easily.
• Shield areas of food with small pieces of foil if they start
to become warm.
• You can use small pieces of alu-minum foil to shield
foods like chicken wings, leg tips, and fish tails, but the
foil must not touch the side of the oven. Foil causes
arcing, which can damage the oven lining.
17
Operating Instructions
COOKING GUIDE
Guide for Cooking Meat in Your Microwave
• Place meat on a microwave-safe roasting rack in a microwave-safe dish.
• Start meat fat side down. Use narrow strips of aluminum foil to shield any bone tips or thin meat areas.
• Check the temperature in several places before letting the meat stand the recommended time.
• The following temperatures are removal temperatures. The temperature of the food will rise during the standing time.
Food Cook time Power level Directions
10-15 min./lb. for 145° F
Place roast fat-side down on
roasting rack. Cover with wax
paper. Turn over half way through
cooking. Let stand 10 to 15
minutes.
Place roast fat-side down on
roasting rack. Cover with wax
paper. Turn over half way through
cooking. Let stand 10 to 15
minutes.
Roast Beef Boneless
(Up to 4 lbs.)
Roast Pork Boneless or
bone-in (Up to 4 lbs.)
(Rare)
12-17 min./lb. for 160° F
(Medium)
14-19 min./lb. for 170° F
(Well Done)
15-20 min./lb. for 170° F
(Well Done)
High(10) for first 5 minutes,
then medium(5)
High(10) for first 5 minutes,
then medium(5)
• Expect a 10°F rise in temperature during the standing time.
Food Remove from oven After standing (10 -15 min.)
Beef Rare
Medium
Well Done
Pork
Poultry
Medium
Well Done
Dark meat
Light meat
135°F 145°F
150°F 160°F
160°F 170°F
150°F 160°F
160°F 170°F
170°F 180°F
160°F 170°F
Guide for Cooking Poultry in Your Microwave
• Place poultry on a microwave-safe roasting rack in a microwave-safe dish.
• Cover poultry with wax paper to prevent spattering.
• Use aluminum foil to shield bone tips, thin meat areas, or areas that start to overcook.
• Check the temperature in several places before letting the poultry stand the recommended time.
Food Cook Time/Power Level Directions
Whole Chicken
Up to 4 lbs.
Chicken Pieces
Up to 2 lbs.
Cooking Time: 7-10 min. / lb.
180°F dark meat
170°F light meat
Power Level: Medium High(7).
Cooking Time: 7-10 min. / lb.
180°F dark meat
170°F light meat
Power Level: Medium High(7).
Place chicken breast-side down on roasting rack. Cover with
wax paper. Turn over half way through cooking. Cook until
juices run clear and meat near the bone is no longer pink. Let
stand 5-10 minutes.
Place chicken bone-side down on dish, with the thickest portions
toward the outside of the dish. Cover with wax paper. Turn over
half way through cooking. Cook until juices run clear and meat
near the bone is no longer pink. Let stand 5-10 minutes.
18
Operating Instructions
Guide for Cooking Seafood in Your Microwave
• Cook fish until it flakes easily with a fork.
• Place fish on a microwave-safe roasting rack in a microwave-safe dish.
• Use a tight cover to steam fish. A lighter cover of wax paper or paper towel provides less steaming.
• Do not overcook fish; check it at minimum cooking time.
Food Cook Time/Power Level Directions
Steaks
Up to 1.5 lbs.
Fillets
Up to 1.5 lbs.
Shrimp
Up to 1.5 lbs.
Cooking Time: 7-11 min. / lb.
Power Level: Medium-High(7).
Cooking Time: 4-8 min. / lb
Power Level:Medium-High(7).
Cooking Time: 4-6 ½ min. / lb.
Power Level: Medium-High(7).
Arrange steaks on roasting rack with meaty portions towards the
outside of rack. Cover with wax paper. Turn over and rearrange when
cooking time is half up. Cook until fish flakes easily with a fork. Let
stand 3-5 minutes.
Arrange fillets in a baking dish, turning any thin pieces under. Cover
with wax paper. If over ½ inch thick, turn over and rearrange when
cooking time is half up. Cook until fish flakes easily with a fork. Let
stand 2-3 minutes.
Arrange shrimp in a baking dish without overlapping or layering. Cover
with wax paper. Cook until firm and opaque, stirring 2 or 3 times. Let
stand 5 minutes.
Guide for Cooking Eggs in Your Microwave
• Never cook eggs in the shell, and never warm hard-cooked eggs in the shell; they can explode.
• Always pierce whole eggs to keep them from bursting.
• Cook eggs just until set; they become tough if overcooked.
Guide for Cooking Vegetables in Your Microwave
• Vegetables should be washed just before cooking. Often, no extra water is needed. If dense vegetables such as
potatoes, carrots and green beans are being cooked, add about ¼ cup water.
• Small vegetables (sliced carrots, peas, lima beans, etc.) will cook faster than larger ones.
• Whole vegetables, such as potatoes, acorn squash or corn on the cob, should be arranged in a circle on the turntable
before cooking. They will cook more evenly if turned over after half the cooking time has passed.
• Always place vegetables like asparagus and broccoli with the stem ends pointing towards the edge of the dish and the
tips toward the center.
• When cooking cut vegetables, always cover the dish with a lid or vented microwavable plastic wrap.
• Whole, unpeeled vegetables such as potatoes, squash, eggplant, etc., should have their skin pricked in several spots
before cooking to prevent them from bursting.
• For more even cooking, stir or rearrange whole vegetables halfway through the cooking time.
• Generally, the denser the food, the longer the standing time (Standing time refers to the time necessary for dense,
large foods and vegetables to finish cooking after they come out of the oven.). A baked potato can stand on the
counter for five minutes, while a dish of peas can be served immediately.
19
Care and Cleaning
CARE AND CLEANING
For best performance and safety, keep the oven clean
inside and out-side. Take special care to keep the inner
door panel and the oven front frame free of food or grease
build-up. Never use rough powder or pads. Wipe the
microwave oven inside and out, including the hood bottom
cover, with a soft cloth and a warm (not hot) mild detergent
solution. Then rinse and wipe dry. Use a chrome cleaner
and polish on chrome, metal and aluminum surfaces. Wipe
spatters immediately with a wet paper towel, especially
after cooking chicken or bacon. Clean your oven weekly or
more often, if needed.
Follow these instructions to clean and care for your
oven.
• Keep the inside of the oven clean. Food particles and
spilled liquids can stick to the oven walls, causing the
oven to work less efficiently.
• Wipe up spills immediately. Use a damp cloth and mild
soap. Do not use harsh detergents or abrasives.
• To help loosen baked on food particles or liquids, heat
two cups of water (add the juice of one lemon if you
desire to keep the oven fresh) in a four-cup measuring
glass at High power for five minutes or until boiling. Let
stand in the oven for one or two minutes.
• Remove the glass tray from the oven when cleaning the
oven or tray. To prevent the tray from breaking, handle
it carefully and do not put it in water immediately after
cooking. Wash the tray carefully in warm sudsy water or
in the dishwasher.
• Clean the outside surface of the oven with soap and a
damp cloth. Dry with a soft cloth. To prevent damage to
the operating parts of the oven, don’t let water seep into
the openings.
• Wash the door window with very mild soap and water.
Be sure to use a soft cloth to avoid scratching.
• If steam accumulates inside or outside the oven door,
wipe with a soft cloth. Steam can accumulate when
operating the oven in high humidity and in no way
indicates microwave leakage.
• Never operate the oven without food in it; this can
damage the magnetron tube or glass tray. You may wish
to leave a cup of water in the oven when it is not in use
to prevent damage if the oven is accidentally turned on.
CLEANING THE GREASE FILTER
The grease filter should be removed and cleaned often, at
least once a month.
CAUTION
To avoid risk of personal injury or property damage,
do not operate oven hood without filters in place.
1. To remove grease filter, slide filter to the side. Pull filter
downward and push to the other side. The filter will
drop out.
2. Soak grease filter in hot water and a mild detergent.
Rinse well and shake to dry. Do not use ammonia or
place in a dishwasher. The aluminum will darken.
3. To reinstall the filter, slide it into the side slot, then
push up and toward oven center to lock.
CHARCOAL FILTER REPLACEMENT
If your oven is vented to the inside, the charcoal filter
should be replaced every 6 to 12 months, and more often
if necessary. The charcoal filter cannot be cleaned. To
order a new charcoal filter, contact the Parts Department
at your nearest Authorized Service Center or call:
1-800-944-9044 (U.S.)
1-800-668-4606 (Canada)
20
1. Unplug oven or turn off power at the main power
supply.
2. Open the door.
3. Remove the two vent grille mounting screws. (3 middle
screws)
Care and Cleaning
4. Slide the grille to the left, then pull straight out.
5. Push the hook and remove old filter.
6. Slide a new charcoal filter into place. The filter should
rest at the angle shown.
4. Replace bulb cover, and mounting screws.
5. Turn the power back on at the main power supply.
OVEN LIGHT REPLACEMENT
1. Unplug oven or turn off power at the main power supply.
2. Open the door.
3. Remove the vent cover mounting screws. (3 middle
screws)
4. Slide the grille to the left, then pull straight out.
5. Remove the charcoal filter, if present.
7. Replace the grille and 3 screws and close the door.
Turn the power back on at the main power supply and
set the clock.
CHARCOAL FILTER PART NO.
COOKTOP/NIGHT LIGHT
REPLACEMENT
CAUTION
To avoid personal injury or property damage, wear
gloves when replacing light bulb.
1. Unplug the oven or turn off power at the main power
supply.
2. Remove the bulb cover mounting screws.
6. Press and hold the center snap while lifting the tab on
the left corner. Remove the cover. Remove the bulb by
turning gently.
7. Replace bulb with a 40 watt appliance bulb.
8. Replace the bulb holder.
9. Replace the grille and 2 screws. Turn the power back on
at the main power supply.
3. Replace bulb with 40 watt appliance bulb.
21
Before You Call
TROUBLESHOOTING GUIDE
Before you call a repair person for your oven, check this
list of possible problems and solutions.
Neither the oven’s display nor the oven
operate.
• Properly insert the plug into a grounded outlet.
• If the outlet is controlled by a wall switch, make sure the
wall switch is turned on.
• Remove the plug from the outlet, wait ten seconds, then
plug it in again.
• Reset the circuit breaker or replace any blown fuse.
• Plug another appliance into the outlet; if the other
appliance doesn’t work, have a qualified electrician
repair the outlet.
• Plug the oven into a different outlet.
The oven’s display works, but the power
won’t come on.
• Make sure the door is closed securely.
• Check to see if packing material or other material is
stuck to the door seal.
• Check for door damage.
• Press STOP/CLEAR
instructions.
The power goes off before the set time has
elapsed.
• If there has not been a power outage, remove the plug
from the outlet, wait ten seconds, then plug it in again.
If there was a power outage, the time indicator will
display:
pad twice and re-enter all cooking
You see sparks or arcing.
• Remove any metallic utensils, cookware, or metal ties. If
using foil, use only narrow strips and allow at least one
inch between the foil and interior oven walls.
The turntable makes noises or sticks.
• Clean the turntable, roller ring and oven floor.
• Make sure the turntable and roller ring are positioned
correctly.
Using your microwave causes TV or radio
interference.
• This is similar to the interference caused by other small
appliances, such as hair dryers. Move your microwave
further away from other appliances, like your TV or
radio.
NOTE
If the oven is set to cook for more than 25 minutes,
it will automatically adjust itself to 70 percent power
after 25 minutes to avoid overcooking.
If you have a problem you cannot
solve, please call our service line:
1-800-944-9044 (U.S.)
1-800-668-4606 (Canada)
• Reset the clock and any cooking instructions.
• Reset the circuit breaker or replace any blown fuse.
The food is cooking too slowly.
• Make sure the oven is on its own 20 amp circuit line.
Operating another appliance on the same circuit can
cause a voltage drop. If necessary, move the oven to its
own circuit.
22
Note
23
Major Appliance Warranty Information
Your appliance is covered by a one year limited warranty. For one year from your original date of purchase,
Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove to be defective in
materials or workmanship when such appliance is installed, used and maintained in accordance with the provided
instructions.
Exclusions
This warranty does not cover the following:
1. Products with original serial numbers that have been removed, altered or cannot be readily determined.
2. Product that has been transferred from its original owner to another party or removed outside the USA or
Canada.
3. Rust on the interior or exterior of the unit.
4. Products purchased “as-is” are not covered by this warranty.
5. Food loss due to any refrigerator or freezer failures.
6. Products used in a commercial setting.
7. Service calls which do not involve malfunction or defects in materials or workmanship, or for appliances not
in ordinary household use or used other than in accordance with the provided instructions.
8. Service calls to correct the installation of your appliance or to instruct you how to use your appliance.
9. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves,
etc., which are not a part of the appliance when it is shipped from the factory.
10. Service calls to repair or replace appliance light bulbs, air filters, water filters, other consumables, or knobs,
handles, or other cosmetic parts.
11. Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry trip
charges, or mileage expense for service calls to remote areas, including the state of Alaska.
12. Damages to the finish of appliance or home incurred during installation, including but not limited to floors,
cabinets, walls, etc.
13. Damages caused by: services performed by unauthorized service companies; use of parts other than
genuine Electrolux parts or parts obtained from persons other than authorized service companies; or
external causes such as abuse, misuse, inadequate power supply, accidents, fires, or acts of God.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT
REPAIR OR REPLACEMENT AS PROVIDED HEREIN. CLAIMS BASED ON IMPLIED WARRANTIES,
INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE
LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE
YEAR. ELECTROLUX SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH
AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS
WRITTEN LIMITED WARRANTY OR ANY IMPLIED WARRANTY. SOME STATES AND PROVINCES DO
NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR
LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES, SO THESE LIMITATIONS OR EXCLUSIONS
MAY NOT APPLY TO YOU. THIS WRITTEN WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY
ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.
If You Need
Service
This warranty only applies in the USA and Canada. In the USA, your appliance is warranted by Electrolux Major Appliances
North America, a division of Electrolux Home Products, Inc. In Canada, your appliance is warranted by Electrolux Canada Corp.
Electrolux authorizes no person to change or add to any obligations under this warranty. Obligations for service and parts under
this warranty must be performed by Electrolux or an authorized service company. Product features or specifications as described
or illustrated are subject to change without notice.
USA
1.800.944.9044
Electrolux Major Appliances
North America
P.O. Box 212378
Augusta, GA 30907
Keep your receipt, delivery slip, or some other appropriate payment record to establish the warranty period
should service be required. If service is performed, it is in your best interest to obtain and keep all receipts.
Service under this warranty must be obtained by contacting Electrolux at the addresses or phone numbers
below.
Electrolux Canada Corp.
Mississauga, Ontario, Canada
5855 Terry Fox Way
Canada
1.800.668.4606
L5V 3E4
Loading...
