Bose AE2i, AE2IW User Manual

BOSE® AE2i AUDIO HEADPHONES
| |
|
Tab 5, 11 Tab 4, 10 Tab 3, 9 Tab 2, 8
English
Safety Information
Please take the time to follow the instructions in this owner’s guide carefully. It will help you set up and operate your product properly and enjoy its advanced features. Please save this owner’s guide for future reference.
CAUTIONS
• Long-term exposure to loud music may cause hearing dam­age. Please avoid extreme volume when using headphones, especially for extended periods.
• Do not use headphones when operating a motor vehicle or anywhere the inability to hear outside sounds may present a danger to you or others.
• Sounds that you rely on as reminders or warnings may have an unfamiliar character when using headphones. Be aware of how these sounds may vary in character so you can recognize them as needed.
• Do not drop, sit on or allow the headphones to be immersed in water.
WARNING: DO NOT use mobile phone adapters to connect headphones to airplane seat jacks as this could result in personal injury such as burns or property damage due to overheating. Remove and disconnect immediately if you experience warming sensation or loss of audio.
Limited Warranty
Your Bose® headphones are covered by a limited warranty. Details of the limited warranty are provided on the product registration card that is included in the carton. Please refer to the card for instructions on how to register. Failure to register will not affect your limited warranty rights.
What you must do to obtain Limited Warranty Service:
Return product, with proof of purchase from an authorized Bose dealer, using the following procedures:
1. Contact the Bose organization in your country/region (visit
Global.Bose.com/register for Bose contact information in your country/region) for specific return and shipping instructions;
2. Label and ship the product, freight prepaid, to the address
provided by the Bose organization in your country; and
3. Place any necessary return authorization number
prominently on the outside of the carton. Cartons not bearing a return authorization number, where required, will be refused.
Note: The serial number is located inside the right earcup.
1
English
Replaceable earcup cushions
1
/8 inch
(3.5 mm) plug
Adjustable headband
L or R mark
Remote and Microphone
2.5 mm
Detachable audio cable
Tab 5, 11Tab 4, 10Tab 3, 9Tab 2, 8
Introduction
Thank you for purchasing the Bose® AE2i audio headphones for select Apple products. These headphones were designed to give you easy access and greater control of your Apple audio device. With Bose AE2i audio headphones, you can immerse yourself in your music and enjoy an around-ear fit that stays comfortable for hours.
For use with:
The remote and mic are supported only by iPod nano (4th generation and later), iPod classic (120GB, 160GB only), iPod touch (2nd generation and later), iPhone 3GS, iPhone 4, iPad, iPad 2 and 2009 models or later of MacBook and MacBook Pro.
remote is supported by iPod shuffle (3rd generation and later).
The Audio is supported by all iPod models.
Components
2
Tab 5, 11 Tab 4, 10 Tab 3, 9 Tab 2, 8
Volume up
Answer/End
Volume down
English
Wearing the headphones
Put on the headphones using the markings which identify the left (L) and right (R) earcups. Adjust the headband so it rests gently on top of your head and the earcup cushions fit comfortably around your ears.
Connecting to your Apple device
Ensure the smaller 2.5 mm plug is securely inserted into the left earcup. Plug the other end of the cable securely into the audio output jack of the Apple audio device.
Using the headphones with your Apple device
The Bose with an integrated microphone for convenient control of select Apple products. Easily control volume, track selection and voice applications, plus switch between your calls and music.
®
AE2i headphones come with a small in-line remote
Note: Full controls may not be available for some Apple products.
Headphone controls
3
English
Basic functions
Increase volume Press and release the + button. Decrease volume Press and release the – button.
Call-related functions
Answer a call When you receive an incoming call, press
End a call Press and release the Answer/End button. Decline an incoming
call Switch to an incom-
ing or on-hold call and put the current call on hold
Switch to an incom­ing or on-hold call and end the current call
Use Voice Control Press and hold the Answer/End button.
Media playback functions
Play or pause a song or video
Skip to the next song or chapter
Fast-forward Press and release the Answer/End button
Go to the previous song or chapter
Rewind Press and release the Answer/End button
and release the Answer/End button to answer.
Press and hold the Answer/End button for about two seconds, then release.
While on a call, press and release the Answer/End button once. Press and release again to switch back to the first call.
While on a call, press and hold the Answer/ End button for about two seconds, then release.
See iPhone User Guide for compatibility and usage information about this feature.
Press and release the Answer/End button.
Press and release the Answer/End button twice quickly.
twice quickly and hold the second press. Press and release the Answer/End button
three times quickly.
three times quickly and hold the third press.
Tab 5, 11Tab 4, 10Tab 3, 9Tab 2, 8
4
Tab 5, 11 Tab 4, 10 Tab 3, 9 Tab 2, 8
English
Folding earcups
The Bose® AE2i audio headphones feature rotating earcups that fold flat for easy, convenient storage.
The earcups rotate in only one direction. Incorrectly rotating the earcups can damage the headphones.
Cleaning the headphones
The Bose AE2i audio headphones do not require scheduled cleaning. Should cleaning be necessary, simply wipe the outside surfaces with a soft cloth. Be sure the earcup ports are kept clear, and that no moisture is allowed to get inside the earcup.
Replacement parts and accessories
Accessories or replacement parts can be ordered through Bose Customer Service. See the contact information for your area included in this guide.
Part Product Code
Carry bag: 329585-0010 Replacement cushions: 329586-0010 Audio cable: 329583-0010 Cable with remote and microphone: 345443-0010
Reattaching earcup cushions
The earcup cushions are held in place by a mounting flange which snaps under 8 small tabs located around the inside rim of each earcup. If an earcup cushion becomes partially or completely detached, push the mounting flange of the earcup cushion back into the earcup. Using your finger or thumb, press around the edge of the mounting flange, making sure it snaps in place all the way around the earcup.
5
English
Tab 5, 11Tab 4, 10Tab 3, 9Tab 2, 8
Troubleshooting
Problem What to do
No audio or audio in one earcup only
Distorted bass • Ensure both ear cushions are firmly
Mis-shaped cushion • The high-density earcup foam will
Microphone is not picking-up sound
Phone not respond­ing to button presses
Apple product not responding to remote
If any problem persists, contact Customer Service. See the phone number for your area included in this guide.
• Ensure both ends of the audio cable are firmly seated.
• Try a different audio device.
secured.
regain its shape after a few minutes in a neutral position.
• Make sure that the headset plug is securely connected to the head­phone jack.
• Make sure the microphone is not being blocked or covered.
The microphone is located on the back of the Answer/End button.
• Make sure that the headset plug is securely connected to the head­phone jack.
• For multi-press functions: Vary speed of presses.
• Full controls may not be available for some Apple products.
6
©2011 Bose Corporation. No part of this work may be reproduced, modified, distributed, or otherwise used without prior written permission.
Apple, iPad, iPhone, iPod, iPod classic, iPod nano, iPod shuffle, iPod touch and MacBook are trademarks of Apple, Inc., registered in the U.S. and other countries.
“Made for iPod,” “Made for iPhone,” and “Made for iPad” mean that an electronic accessory has been designed to connect specifically to iPod, iPhone, or iPad, respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod, iPhone, or iPad may affect wireless performance.
Tab 5, 11 Tab 4, 10 Tab 3, 9 Tab 2, 8
English
Names and Contents of Toxic or Hazardous Substances or Elements
Toxic or Hazardous Substances and Elements
Part
Lead
Mercury
Cadmium
Name
(Pb)
(Hg)
PCBs
X0 0 0 0 0
Metal parts
X0 0 0 0 0
Plastic parts
00 0 0 0 0
Speakers
X0 0 0 0 0
Cables
X0 0 0 0 0
O: Indicates that this toxic or hazardous substance contained in all of the homogeneous materials for this part is below the limit requirement in SJ/T 11363-2006.
X: Indicates that this toxic or hazardous substance contained in at least one of the homogeneous materials used for this part is above the limit requirement in SJ/T 11363-2006.
(Cd)
Hexavalent
(CR(VI))
Polybrominated
Biphenyl (PBB)
Polybrominated
diphenylether (PBDE)
7
©2011 Bose Corporation, The Mountain,
| |
|
Framingham, MA 01701-9168 USA AM346022 Rev.01
