RANGE

COMPOSITION

The range consists of 6 fan assisted models of 600 litre refrigeration cabinets that offer excellent standards in terms of performance and efficiency. These models come in freezer version with a choice of materials (stainless steel or white painted steel) and are available with full doors.

726318

AU SERIES

600 LT DIGITAL FREEZERS ZANUSSIP R O F E S S I O N A L

FUNCTIONAL AND CONSTRUCTION FEATURES

Internal and external structure in

model RS06FX1F4). 150 mm high -

stainless steel or white painted steel,

adjustable feet.

external base, top and back in



galvanized steel (stainless steel on



TECHNICAL DATA













CHARACTERISTICS





MODELS







RS06FX1F4

RS06FX1F

RS06F41FS

RS06FW1F

RS06FX2H

RS06FX1FR



726457

726318

728303

726474

726690

727104

Operating temperature - min/max °C

-22/-15

-22/-15

-22/-15

-22/-15

-22/-15

-22/-15

Operating mode

Ventilated

Ventilated

Ventilated

Ventilated

Ventilated

Ventilated

Type of stainless steel













external

304 AISI

304 AISI

Stainless Steel

Prepainted Steel

Stainless Steel

304 AISI











AISI 304 Scotch













Brite



internal

304 AISI

304 AISI

Stainless Steel

Stainless Steel

Stainless Steel

304 AISI











AISI 304 Scotch













Brite



Gross capacity (D.I.N. 8952) - l.

600

600

600

600

600

600

Cooling unit

Built-In

Built-In

Built-In

Built-In

Built-In

Remote

External dimensions - mm













width

720

720

720

720

720

720

depth/with open doors

788, 1440

788, 1440

788, 1440

788, 1440

788, 1450

788, 1440

height

2000

2000

2000

2000

2000

2000

Door hinges

Right Side

Right Side

Right Side

Right Side

Right Side

Right Side

N° and type of grids (included)

3, GN 2/1

3, GN 2/1

3, GN 2/1

3, GN 2/1

4, GN 2/1

3, GN 2/1

N° defrost in 24 hrs.

4/30'

4/30'

4/30'

4/30'

4/30'

4/30'

Refrigerant type

R404a

R404a

R404a

R404a

R404a

R404a

Refrigerant quantity - g.

270

270

270

270

270



Refrigeration power - W

752

752

752

752

752

843

Power - kW













installed-electric

0.66

0.66

0.66

0.66

0.66

0.175

Internal light











Noise level - dBA

59.5

59.5

59.5

59.5

59.5



Net weight - kg.

134

134

128

134

134

134

Power supply - V, phases, Hz

230 V, 1, 50

230 V, 1, 50

230 V, 1, 50

230 V, 1, 50

230 V, 1, 50

230 V, 1, 50

INCLUDED ACCESSORIES













2 S/S RUNNERS FOR 600-650/1300-1400L.REF

3

3

3

3



3

2 S/S SIDE RUNNERS FOR 600-1300L REFRIG.









4



2/1 GN GREY "RILSAN" GRID

3

3

3

3

4

3

Digital control panel allowing the easy and precise setting and control of the internal temperature.

Completely automatic defrosting and automatic evaporation of defrost water (304 AISI models), manual emptying of defrost water (Stainless steel models).

High standards of hygiene and ease of cleaning are guaranteed by the rounded internal corners of the cabinet and easily removable runners and grids (without the use of tools).

The refrigeration unit can operate in tropical climates (+43°C ambient temperature).

Extremely quiet operation at 51 dBA.

Excellent forced air cooling system that ensures the utmost uniformity of temperature in the cabinet and guarantees a perfect storage quality of the goods.

High-density expanded polyurethane insulating foam, 60 mm in thickness, with cyclopenthane injection, guarantees exceptional, long-term insulation and notable energy savings.

The rational use of the internal space of the refrigerator guarantees a large storage area suitable to contain 2/1 GN grids.

600 LT DIGITAL FREEZERS

AU SERIES

Reversible self-closing door, in positions less than 90°, with a stop at 95° and a maximum opening at 180°, equipped with a magnetic door seal to guarantee perfect closure. The pressed stainless steel recessed door handle without joints makes opening the cabinet extremely easy. All the doors are fitted as standard with locks and keys and a microswitch to switch off the fan when the door is opened.

Stainless steel feet (plastic interior).

A wide range of optional accessories are available.

CFC and HCFC free.

OPTIONAL ACCESSORIES

















ACCESSORIES





MODELS











RS06FX1F4

RS06FX1F

RS06F41FS

RS06FW1F

RS06FX2H

RS06FX1FR







726457

726318

728303

726474

726690

727104





2 S/S RUNNERS FOR

881456

881456

881456

881456



881456





600-650/1300-1400L.REF

















2 S/S SIDE RUNNERS FOR 600-1300L









880557







REFRIG.

















2 WHEELS FOR

880539

880539

880539

880539

880539

880539





REFRIGERATORS/REFRIG.TABLES

















2/1 GN AISI 304 S/S GRID

881067

881067

881067



881067

881067





2/1 GN GREY "RILSAN" GRID

880720

880720

880720

880720

880720

880720





ENERGY FREE ALARM DEVICE



881089

881089

881089

881089

881089





KIT HACCP EKIS

922166

922166

922166

922166

922166

922166





KIT INTEGRATED HACCP-DIG. REFR.

880205

880205

880205

880205

880205

880205





(IR33)

















KIT TO FIT 11 PASTRY TRAYS

881031

881031

881031

881031

881031

881031





(400X600 MM)

















MEAT RAIL FOR 650-1400 L

881451















REFRIGERATORS

















PRINTER FOR HACCP BASIC VERSION

881457

881457

881457

881457

881457

881457





REFRIG.















ZANUSSI

REMOTE UNIT -24-15°C FOR 550/650











881465



LT















P R O F E S S I O N A L

www.zanussiprofessional.com

DAFB01 2009-07-03

The Company reserves the right to alter technical specifications without prior notice.
