RANGE

COMPOSITION

The range consists of 25 models of refrigerated tables with a capacity varying from 265 to 560 litres that offer excellent standards in terms of performance and efficiency. These models are available with built in or remote refrigerating unit and with variuos combinations of doors and drawers.The models detailed on this sheet are refrigerated tables with a capacity of 560 litres and with built in refrigerating unit.

726147

AU SERIES

560 LT REFRIGERATED TABLES ZANUSSIP R O F E S S I O N A L

FUNCTIONAL AND CONSTRUCTION FEATURES

Internal and external doors, front and side panels and removable worktop in 304 AISI stainless steel (excluding model RCSN4M44).

External back in galvanized steel.

The removable top is made in 304 AISI and is 50 mm in thickness (models RCSN4M4, RCSN4M32, RCSN4M24, RCSN4M4U).

High-density expanded cyclopenthane insulating foam, 50 mm in thickness guarantees exceptional, long-term insulation and notable energy savings.

Legs (150mm high) in 304 AISI stainless steel - adjustable in height.

Evaporator foamed in the backside protected from acids.

Digital control panel allowing the easy and precise setting and control of the internal temperature.

Completely automatic defrosting and automatic evaporation of defrosting water by hot gas.

TECHNICAL DATA













CHARACTERISTICS





MODELS







RCSN4M4

RCSN4M4T

RCSN4M32

RCSN4M24

RCSN4M4U

RCSN4M44



726147

726670

726148

726170

726197

727008

Operating temperature - min/max °C

-2/10

-2/10

-2/10

-2/10

-2/10

-2/10

Operating mode

Ventilated

Ventilated

Ventilated

Ventilated

Ventilated

Ventilated

Type of stainless steel













external

304 AISI

304 AISI

304 AISI

304 AISI

304 AISI

Stainless













Steel

Gross capacity (D.I.N. 8952) - l.

560

560

560

560

560

560

Control type

Digital

Digital

Digital

Digital

Digital

Digital

External dimensions - mm













width

2201

2201

2201

2201

2201

2201

depth/with open doors

700, 1102

700, 1102

700, 1102

700, 1102

700, 1102

700, 1102

height

850

800

850

850

950

850

Internal dimensions - mm













width

365

365

365

365

365

365

depth

580

580

580

580

580

580

height

543

543

543

543

543

543

Upstand











Without worktop











Top material

304 AISI

Galvanized

304 AISI

304 AISI

304 AISI

Stainless





Steel







Steel

Min/Max internal humidity - %

57

57

57

57

57

57

N° of drawers





2

4





Door hinges

2 Left+2

2 Left+2

2 Left+1

1 Left+1

2 Left+2

2 Left+2



Right

Right

Right

Right

Right

Right

N° and type of grids (included)

4, GN 1/1

4, GN 1/1

3, GN 1/1

2, GN 1/1

4, GN 1/1

4, GN 1/1

N° defrost in 24 hrs.

every 6

every 6

every 6

every 6

every 6

every 6



hours

hours

hours

hours

hours

hours

Refrigerant quantity - g.

210

210

210

210

210

210

Refrigeration power - W

343

343

343

343

343

343

Power - kW













installed-electric

0.34

0.34

0.34

0.34

0.34

0.34

Noise level - dBA

58.5

58.5

58.5

58.5

58.5

58.5

Net weight - kg.

186

178

194

198

187

186

Power supply - V, phases, Hz

230 V, 1N,

230 V, 1N,

230 V, 1N,

230 V, 1N,

230 V, 1N,

230 V, 1N,



50

50

50

50

50

50

INCLUDED ACCESSORIES













1/1 GN GREY "RILSAN" GRID

4

4

3

2

4

4

Operating temperature:-2/+10ºC.

High standards of hygiene and ease of cleaning are guaranteed by the rounded internal corners and easily removable supports and grids.

Self-closing door, in positions less than 90°, equipped with a door seal to guarantee perfect closure.

Refrigerant gas R404a.

Possibility to install on socket.

Kit 1/2 drawers available as accessory.

The refrigeration unit can operate in tropical climates (+43°C ambient temperature).

CFC and HCFC free.

OPTIONAL ACCESSORIES













ACCESSORIES





MODELS







RCSN4M4

RCSN4M4T

RCSN4M32

RCSN4M24

RCSN4M4U

RCSN4M44



726147

726670

726148

726170

726197

727008

KIT 2 S/S GRIDS GN1/1 FOR

880139



880139

880139

880139

880139

REFRIG.TABLES













KIT 4 WHEELS (2 W/BRAKE)+4

880025

880025

880025

880025

880025

880025

(40MM)SPACERS













KIT DOOR REVERSIBILITY FOR

880046

880046

880046

880046

880046

880046

REF.TABLES













KIT HACCP EKIS

922166

922166

922166

922166

922166

922166

KIT INTEGRATED HACCP-DIG. REFR.

880205

880205

880205

880205

880205

880205

(IR33)













LOCK KIT

880024

880024

880024

880024

880024

880024

PLASTIC CONTAINER GN 1/1 H=150

881040

881040

881040

881040

881040

881040

MM













PLASTIC CONTAINER GN 1/1 H=65 MM

881038

881038

881038

881038

881038

881038

PRINTER FOR HACCP BASIC VERSION

881457

881457

881457

881457

881457

881457

REFRIG.













S/S STRUCTURE TO SUPPORT 6

880140



880140

880140

880140

880140

GRIDS (R+L)













STRUCTURE TO SUPPORT 3

880047

880047

880047

880047

880047

880047

GRIDS(RIGHT+LEFT)













TWO ½ DRAWER KIT

880023

880023

880023

880023

880023

880023

560 LT REFRIGERATED TABLES

AU SERIES

ZANUSSI

P R O F E S S I O N A L

www.zanussiprofessional.com

DBAF5

2009-07-03

The Company reserves the right to alter technical specifications without prior notice.
