Wi Gear MA110 Users Manual
1313
© 2005-2006 Wi-Gear, Inc. All rights reserved. iMuffs, Wi-Gear, and the Wi-Gear logo are trademarks of WiGear Inc. The Bluetooth word mark and logo are owned by the Bluetooth SIG, Inc. and any use of such marks
by Wi-Gear Inc. is under license. iPod is a trademark of Apple Computer, Inc., registered in the U.S. and other
countries. All other products and services may be marks of their respective owners. Printed in China.
www.wi-gear.com
USER GUIDE
Contents
Introduction 1
What's included in this package? 2
Product Features 3
Getting Started 5
Playing Music 6
Bluetooth phone operation 8
Troubleshooting 10
Specifications 11
Regulatory Information 13
Regulatory Information
FCC Compliance Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
Radio and Television Interference
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
IMPORTANT: Changes or modifications not expressly approved by Wi-Gear Inc. could void
the user's authority to operate the equipment.
IC Compliance Statement
The term "IC": before the certification/registration number only signifies that the Industry
Canada technical specifications were met.
13
Introduction
Battery
n
Battery Type: Lithium-Polymer 500mAh
(built-in, not user-serviceable)
n
Charge Time: Quick charge, 80% in 2 hours /
Full charge in 5 hours
n
Up to 16 hours of continuous operation of the
headphones depending on usage pattern, distance
from adaptor, and battery age. iMuffs Adaptor for iPod
is dependent on iPod's actual battery capacity.
Power Input
n
Standard USB voltage input (mini-USB, 5-pin) or
Provided AC-DC
n
USB Power Adapter (110-240V)
Temperature
n
Operating: 0°-35° C (32°-95° F)
n
Storage: -20-50° C (-68°- 122° F)
Weight
n
2.3 oz (headphones)
n
0.3 oz (adaptor)
Cut the cord today!
Congratulations on purchasing iMuffs™ wireless
headphones for your iPod™ AND Bluetooth® phone!
Soon you'll be enjoying these benefits:
Wireless Freedom - Throw your iPod in your backpack
and listen to your music wirelessly! No more cords to
untangle or snag. Enjoy near-CD quality sound up to 30'
(10m) away thanks to the Advanced Audio Distribution
Profile (A2DP) and Bluetooth 2.0.
Never Miss a Call - When your Bluetooth phone rings,
the iMuffs automatically pause your iPod and ring in the
headphones, and let you talk through the integrated
microphone.
Versatile - Listen to music from your laptop or
desktop1, iPaq, or MP3 smartphone2. Talk on the phone
or over iChat or Skype. Even chat while playing video
games.
Ergonomic Controls - Intuitive controls let you pause,
change volume, and skip tracks right from the
headphones.
1
Currently, Windows XP only and requires a Bluetooth adaptor with A2DP
support (Bluetooth Stereo).
2
Must support Bluetooth Stereo using A2DP.
