R Tra de ma rk
Please do not return unit to retailer.
Por favor, no devuelva el aparato al lugar de compra.
Veuillez ne pas retourner l’outil au détaillant.
1-800-554-6723
www.weedeater.com
Instruction Manual
Manual de Instrucciones
Manuel d’Instructions
EBV 200W
FOR HOUSEHOLD USE ONLY
PARAUSOCASEROSOLAMENTE
POUR UTILISATION À DES FINS
DOMESTIQUES SEULEMENT
ENGLISH ESPAÑOL
WARNING:
Read and follow all Safety Rules and Operating Instructions before
using this product. Failure to do so can result in serious injury.
ADVERTENCIA:
Lea el manual de instrucciones y siga todas las advertencias e
instrucciones de seguridad. El no hacerlo puede resultar en lesiones
graves.
AVERTISSEMENT:
Veuillez lire le manuel d’instructions et bien respecter tous les
avertissements et toutes les instructions de sécurité. Tout défaut
de le faire pourrait entraîner des blessures graves.
WEED EATER
1030 Stevens Creek Road
Augusta, GA 30907
Mississauga, Ontario L5V 3E4
WEED EATER
5855 Terry Fox Way
545117535 8/8/06
FRANÇAIS
SAFETY RULES
Y
IMPORTANT WARNINGSAND
SAFET
INSTRUCTIONS
WARNING:
When using electric gardening appli ances, basic saf ety pr ecauti ons should al ways be
followed to reduce the risk of fire, electric shock, and serious injury. The warnings and
safety instructions in this manual must be followed to reduce the risk of fire, electric
shock, or injury, and to provide reasonable safety and efficiency in using this unit. The
operator is responsible for following the warnings and instructions in this manual and on
the unit. Read the entire instruction manual before assembling and using the unit! Restrict the use of this unit to persons who read, understand, and follow the warnings and
instructions in this manual and on the unit. Never allow children to use this unit. Do not
allow the unit to be used as a toy. Close attention is necessary when used near children.
Always disconnect unit from power source before servicing, cleaning, performing maintenance, or storing. Nonconforming replacement components or the removal of safety
devices may cause damage to the unit and possible injury to the operator or bystanders.
Use only accessories and replacement parts as recommended. Use only for jobs explained in this manual.
OPERATOR SAFETY
S Always wear safety glasses or similar eye
protection when operating, servicing, or
performing maintenance on your unit.
Wearing eye protection can help to prevent rocks or debris from being blown or
ricocheting into eyes and face which can
result in blindness or serious injury.
S Always wear a respirator or face mask
when working with the unit in dusty environments.
S Dress safely in long pants. Do not go
barefoot or wear short pants or sandals.
S Do not operate the unit when you are
tired, ill, upset, or if you are under the influence of alcohol, drugs, or medication.
S Secure hair so it is above shoulder length.
Keep loose hair, loose clothing, fingers,
and all other parts of the body away from
openings and moving parts. Hair, jewelry,
loose clothing, or clothing with loosely
hanging straps, ties, tassels, etc., can be
caught in moving parts.
ELECTRICAL SAFETY
WARNING:
Avoid a dangerous environment. To reduce the risk of electrical shock, do not
use in rain, in damp or wet locations, or
around swimming pools, hot tubs, etc. Do
not expose to snow,rain, or water to avoid
the possibility of electrical shock. Do not
use on wet surfaces. Do not handle extension cord pl ug or unit with wet hands.
Avoid dangerous situations. Do not use in
the presence of flammable liquids or
gases to avoid creati ng a fire or explosion
and/or causing damage to unit . Do not
abuse cord.Never carry the unit by the extension cord or yank extension cord to disconnect unit. To unplug, grasp the plug,
not the cord. Do not use cord as a handle,
close a door on cord, or pull cord around
sharp edges or corners. Turn off all controls before unplugging. Do not expose
cords to heat,oil, or water . Do not use with
damaged cord or plug. If unit is not working as it should, has been dropped, damaged, left outdoors, or dropped into water,
return it to your authorized service dealer
for repair. Unplug the unit from the power
source when not in use, before servicing,
cleaning, performing maintenance, or
storing. Do not put any object into openings. Do not use with any opening
blocked; keep free of dust, lint, hair and
anything that may reduce air flow.
S Use only a voltage supply as shown on
the nameplate of the unit.
S Avoid dangerous environments. Do not
use in unventilated areas or where dust or
explosive vapors can build up.
S T o reduce the risk of electrical shock, this
unit has a polarized plug (one blade is
wider than the other) and will require the
use of a polarized extension cord. The
appliance plug will fit into a polarized extension cord only one way. If the plug
does not fit fully into the extension cord,
reverse the plug. If the plug still does not
fit, obtain a correct polarized extension
cord. A polarized extension cord will require the use of a polarized wall outlet.
This plug will fit into the polarized wall outlet only one way. If plug does not fit fully
into the wall outlet, reverse the plug. If it
2
still does not fit, contact a qualified electrician to install the proper wall outlet. Do not
change the equipment plug, extension
cord receptacle, or extension cord plug in
any way.
S T o reduce the risk of electrical shock, use
extension cords specifically marked as
suitable for outdoor appliances. The electrical rating of the cord must not be less
than the rating of the unit. The cord must
be marked with the suffix “W-A” (in Canada, “W”). Make sure your extension cord
is in good condition. Inspect extension
cord before use and replace if damaged.
An undersized extension cord will cause
a drop in line voltage resulting in loss of
power and overheating. If in doubt, use
the next heavier gauge. The smaller the
gauge number, the heavier the cord.
(NOTE: The correct size to be used depending on the cord length is shown in
this manual. See
CORD
in the ASSEMBLY section).
S Do not use multiple cords.
S Keep the extension cord clear of operator
and obstacles at all times.
S Tie cord to cord retainer and connect to
recessed plug as shown in this manual to
prevent damage to unit and/or extension
cordandtoreducethepossibilityofthe
extension cord disconnecting from the
unit during operation.
S Do not attempt to repair unit. Inspect the
insulation and connectors on the unit
and extension cord before each use. If
there is any damage, do not use until
damage is repaired by your authorized
service dealer.
S Do not use the unit if the switch does not
turn the unit on and off properly. Have the
unit repaired by your authorized service
dealer.
S Avoid accidental starting. Be sure the
switch is in the
your hand and fingers away from the
switch while connecting the unit to the
power source or when carrying a unit connected to the power source.
S Avoid any body contact with any
grounded conductor, such as metal
fences, or pipes, to avoid the possibility of
electric shock.
S Ground Fault Circuit Interrupter (GFCI)
protection should be provided on the circuit or outlet to be used for this unit. Receptacles are available having built-in
GFCI protection and may be used for this
measure of safety.
S Stop the motor immediately if you are ap-
proached.
SELECT AN EXTENSION
OFF position and keep
DOUBLE INSULATION
CONSTRUCTION
This unit is double insulated to help protect against electric shock. Double insulation construction consists of two separate
“layers” of electrical insulation instead of
grounding. Tools and appliances built with
a double insulation system are not intended to be grounded. No grounding
means is provided on this unit, nor should
a means of grounding be added to this
unit. As a result, the extension cord used
with your unit can be plugged into any
standard 120 volt electrical outlet. Safety
precautions must be observed when operating any electrical tool. The double insulation system only provides added protection against injury r esulti ng fr om an
internal electrical insulation failure.
WARNING:
All electrical repairs to this unit, including
housing, switch, motor, etc., must be diagnosed and repaired by qualif i ed service
personnel. Replacement parts for a
double insulated appliance must be identical to the parts they replace. A double insulated appliance is marked with the
words “double insulation” or “double insulated”. The symbol
square) may also be marked on the appliance. Failure to have the unit repaired
by an authorized service dealer can
cause the double insulation construction
to become ineffective and result in serious
injury.
UNIT/MAINTENANCE SAFETY
S Do not set the unit on any surface except
a clean, hard area while the unit is running. Debris such as gravel, sand, dust,
grass, etc., could be picked up by the air
intake and thrown out through the discharge opening, damaging the unit, property , or causing serious injury to bystanders or operator.
S Do not overreach or use from unstable
surfaces such as ladders, trees, steep
slopes, rooftops, etc. Use extra care
when cleaning on stairways. Keep firm
footing and balance at all times. Keep
hands out of tubes.
S Inspect the entire unit before each use for
worn, loose, missing, or damaged parts.
Do not use until the unit is in proper working order.
S
This unit is double insulated. See the
DOUBLE INSULA T I ON CONSTR UCT ION
section. Have all internal service performed by qualified service repair personnel to avoid creating a hazard or
voiding your warranty.
(square within a
3
S Have all maintenance other than the rec-
ommended procedures described in the
instruction manual performed by your authorized service dealer.
S Always see your authorized service deal-
er to replace a damaged impeller. Parts
that are chipped, cracked, broken, or
damaged in any other way can fly apart
and cause serious injury. Replace damaged parts before using the unit.
S Never place any object in the air intake
opening as this could restrict proper air
flow and cause damage to the unit.
S Never douse the unit with water or other
liquids or squirt with a water hose. Clean
theunitusingadampcloth.Wipeoffwith
a clean dry cloth. See
S Check air intake openings and tubes fre-
quently , always with the unit stopped and
power source disconnected. Keep vents
and tubes free of debris which can accumulate and restrict proper air flow.
S Do not burn, incinerate, or expose this
unit to extreme heat.
S Store the unit unplugged in a high, cool,
dry , indoor area out of the reach of children.
S Use only recommended attachments and
replacement parts to avoid creating a
hazard and/or voiding warranty.
S Maintain the unit according to recom-
mended procedures.
S Use only for jobs explained in the
section of this manual.
TION
MAINTENANCE.
OPERA-
BLOWER SAFETY
S Use only in daylight or in good artificial
light.
S Inspect the area before using the unit.
Remove all debris and hard objects such
as rocks, glass, wire, etc., that can ricochet, be thrown, or otherwise cause injury
or damage during operation.
S Never run the unit without the proper
equipment attached. When used as a
blower, always install a blower tube. Use
only recommended attachments.
S T o avoid spreading fire, do not use blower
near leaf or brush fires, fireplaces, barbecue pits, ashtrays, etc.
S Never place objects inside the blower
tubes; always direct the blowing debris
away from people, animals, glass, and
solid objects such as trees, automobiles,
walls, etc. The force of air can cause
rocks, dirt, or sticks to be thrown or to ricochet which can hurt people or animals,
break glass, or cause other damage.
S Never use for spreading chemicals, fertil-
izers, or any other substances which may
contain toxic materials.
VACUUM SAFETY
S Stop the motor and disconnect the power
source before opening the air inlet door or
attempting to insert or remove the vacuum tubes. The motor must be stopped
and the impeller blades no longer turning
to avoid serious injury from the rotating
blades.
S Hard objects can be thrown through the
collection bag or the housing and become
dangerous missiles which can cause serious injury to the operator or others.
S When using the vacuum attachment, the
unit is designed to pick up dry material
such as leaves, grass, small twigs, and
bits of paper. Do not vacuum stones,
gravel, metal, broken glass, etc., to avoid
severe damage to the impeller. To avoid
the possibility of electrical shock, do not
attempt to vacuum water or other liquids.
S Never run the unit without the proper
equipment attached. When used as a
vacuum, always install vacuum tubes and
collection bag assembly. Make sure the
collection bag assembly is completely
zipped when unit is running to avoid flying
debris. Use only recommended attachments.
S Avoid situations which could set the col-
lection bag on fire. Do not vacuum discarded matches, cigars, cigarettes, or
ash from fireplaces, barbecue pits, brush
piles, etc. To avoid spreading fire, do not
use blower near leaf or brush fires, fireplaces, barbecue pits, ashtrays, etc.
S Always use the collection bag shoulder
strapwhenvacuumingtoavoidlossof
control.
S Check air intake openings, elbow tube,
and vacuum tubes frequently, always with
the unit stopped and the power source
disconnected. Keep vents and tubes free
of debris which can accumulate and restrict proper air flow. Do not use with any
opening blocked, Keep free of dust, lint,
hair and anything that may reduce air
flow.
STANDARDS
This product is listed by Underwriters Laboratories, Inc., in accordance with UL
Standard 1017.
If situations occur which are not covered
in this manual, use care and good judgment. If you need assistance, contact
your authorized service dealer or call
1--800--554--6723. Failure to follow all
Safety Rules and Precautions can result
in serious injury .
SAVE THESE INSTRUCTIONS
4
ASSEMBLY
V
WARNING: Stop the unit and dis-
connect from the power source before
opening the inlet cover or attempting to insert or remove the inlet restrictor, blower
tube, or vacuum tubes. The motor must
be stopped and the impeller blades no
longer turni n g to avoid serious injury from
the rotating blades.
of sc rewdriver toward the front of the
unit to release the latch while pulling
up on the vacuum inlet cover with
your other hand.
Bottom view
of unit
Latch Area
WARNING: If received assembled,
ensure your unit is proper ly assembled
and all fasteners are secure.
S A standard screwdriver is required for as-
sembly .
BLOWER ASSEMBLY
NOTE: Assembl y instructions for using
your unit as a vacuum follow this section.
Attaching the blower tube
If you have already assembled your unit
for use as a vacuum, refer to the section
HOW TO CONVERT UNIT FROM VACUUM
USE TO BLOWER USE.
To attach blower tube:
1. Align the grooves on the blower tube
with the grooves on the blower outlet.
2. Push the blower tube onto theblower
outlet until it snaps into place (tube is
secured by red tube release button).
3. To remove the blower tube, press the
tube release button while pulling on
tube.
Tube Release Button
Blower Tube
Blower outlet
VACUUM ASSEMBLY
NOTE: Assembly instructions for using
your unit as a blowerareexplained in the
previous section.
If you have already assembled your unit
for use as a blower , remove the blower
tube.
Remove the inlet restrictor
An inlet restrictor is used when using your
unit as a blower. This restrictor is not used
during vacuum use and must be removed
during assembly for vacuum use.
NOTE: Be sure to keep the inlet restrictor for us ing your unit a s a blower.
1. Ensure unit is stopped and extension
cord is unplugged.
2. Open the inlet cover by inserting the
tip of a screwdriver into the latch area
on the blower unit. Gently tilt handle
Vacuum Inlet Cover (closed)
Impeller
Vacuum Inlet Cover (opened)
Latch Area
3. Turn the inlet restrictor counterclockwise and remove it from the unit. Do
not close the inlet door. You will next
attach the vacuum tubes.
Vacuum
Inlet Cover
Inlet
Restrictor
Attaching the vacuum tubes
There are 2 vacuum tubes, an upper
tube and a lower tube. The upper tube
has a vacuum assist handle attached to
one end and is cut straighton both ends .
The upper tube attaches to the blower
unit. The lower tube has an angled end
that you point toward the ground during
vacuum use. The lower tube attaches to
the upper tube.
1. Ensure unit is stopped and extension cord is unplugged.
2. While holding inlet cover open, place
the hooks of the vacuum assist handle
on the retaining posts of the unit.
3. Raise the tube until it is secured to the
blower unit by the red inlet cover latch.
Upper
acuum Tube
Vacuum Assist Handle
Hook
Retaining Post
5
4. To attach the lower vacuum tube to
the upper vacuum tube, first align the
arrows on the two tubes. Then, press
the two tubes together until the lower
tube is securely seated in the upper
tube (about 3 inches).
Lower TubeUpper Tube
3. Place the shoulder s trap over your
head and onto your left shoulder.
4. Adjust the strap to allow a free flow of
air from the blower. If the collection
bag is kinked, the unitwillnotoperate
properly.
NOTE: The strap is designed to position the collection bag on your shoulder
without kinks. The strap is not intended
to support the weight of the unit.
Align arrows on upper
and lower tubes
COLLECTION BAG ASSEMBLY
1. Open the zipper on the collection
bag and insert the elbow tube.
2. Push the small end of the elbow tube
through the small opening in the bag.
NOTE: Make sure edg e of the small
opening is flush against the flared area
of the elbow tube and the hole for the
tube release button is on top.
Elbow Tube
Zipper
Opening
Tube
Release
Button
Hole
Small
Opening
3. Close the zipper on the bag. Make
sure the zipper is c losed completely.
4. Align the grooves on the elbow tube
with the grooves on the blower outlet.
5. Push the elbow tube onto the blower
outlet until it snaps into place (elbow
tube is secured by red tube release
button).
ADJUSTING THE SHOULDER STRAP
ON THE COLLECTION BAG
1. Carefully loop the shoulder strap
through the buckle as shown in the illustration below.
Last In
First In
2. Position the unit on your right-hand
side, blower outlet and bag pointing
toward the rear. Hold the unit in an
upright position with the lower vacuum tube on the ground to suppo rt it.
Shoulder strap
on left shoulder
No kinks in bag
allows free air flow
HOW TO CONVERT UNIT FROM
VACUUM USE TO BLOWER USE
1. Stop unit and unplug the extension
cord.
2. Remove the vacuum tubes by inserting the tip of a screwdri ver into the
latch area on the vacuum assist handle. Gently tilt handle of screwdriver
toward the front of the unit to release
the latch while pulling up on the vacuum assist handle with your other hand.
Latch Area
Vacuum
Assist
Handle
3. Install the inlet restrictor that was removed when as sembling for vacuum
use.
NOTE: If you are unable to locate the
inlet restrictor, the unit will still operate.
This restrictor improves the blower
function.
4. Remove the collection bag.
5. Close the inlet cover and make sure
it is latched closed.
6. Re-install the blower tube. Refer to
TACHING THE BLOWER TUBE
instructions on how to attach this item.
SELECT AN EXTENSION CORD
Use only a 120 A.C. voltage supply as
shown on nameplate of the unit to
power your blower.
6
AT-
for
Theextensioncordusedtoreachthe
power source must be:
D Specifically marked as suitable for out-
door use. The cord must be marked with
Secure the extension cord to the unit by
threading the cord through the cord retainer (see illustration). Insert the cord
receptacl e into the recessed plug.
thesuffix“W-A”(inCanada“W”).
D Heavy enough to carry full current from
the power source to the unit. Otherwise,
loss of power and overheating can occur
causing damage to unit. Refer to table for
CAUTION: Failuretousecordretainer could result in damage to the unit,
extension cord, or both.
minimum wire gauge recommendations.
The cord must be marked with the proper
wire gauge. (Appropriate extension cords
are available.) Do not use multiple cords.
D In good condition. Cord insulation must
be intact with no cracks or deterioration.
Plug connectors must be undamaged.
DO NOT use multiple cords.
MINIMUM WIRE GAUGE
RECOMMENDATIONS
VOLTS
25 FT . 50 FT . 100 FT.
120 16
A.W.G.*16A.W.G.*
*American Wire Gauge
14
A.W.G.*
Cord
Receptacle
Recessed
Plug
on Unit
Cord
Retainer
USING YOUR UNIT
KNOW YOUR ELECTRIC BLOWER
READ THIS INSTRUCTION MANUAL AND SAFETY RULES BEFORE OPERATING YOUR
Compare the illustrations to your unit to familiarize yourself with the location of
UNIT.
the various controls and adjustments. Save this manual for future reference.
ON/OFF Switch
Cord
Retainer
Top Handle
Collection Bag
Air Vents
Elbow
Tube
Rear
Handle
Inlet Cover
Latch
Tube Release Button
Inlet Restrictor
Upper Vacuum Tube
Retaining Post
Blower Tube
ON/OFF SWITCH
The
ON/OFF SWITCH is used to activate
the motor.
Vacuum Assist Handle
Upper Vacuum Tube
Lower Vacuum Tube
INLET COVER LATCH
The INLET COVER LATCH is used to open
and c lose the inlet cover and to secure
the upper vacu um tube to the blower
unit.
7
BLOWER TUBE
The
BLOWER TUBE is designed to direct
the flow of air.
INLET RESTRICTOR
The
INLET RESTRICTOR improves the
blower function.
TUBE RELEASE BUTTON
The
TUBE RELEASE BUTTON secures the
blower tube or elbow tube to the blower
unit during operation. Also, pressing the
tube release button allows removal of the
blower tube or elbow tube.
WARNING: You MUST make sure
the tubes are secure before using the
unit.
WARNING: Do not use the unit
without the tubes or collection bag properly attached to avoid flying debris and/or
impeller contact which can cause serious
injury. Always wear eye protection to prevent rocks or debris from being blown or
ricocheting into the eyes and face which
can result in blindness or serious injury.
STOPPING YOUR UNIT
Slide the
ON/OFF switch to the OFF
position.
STARTING YOUR UNIT
Your unit has two run positions,
LOW
and HIGH. Slide the switch to one of
these positions to turn on the unit.
OPERATING POSITION
Eye Protection
Blower
Eye Protection
Vacuum
USING YOUR UNIT AS A BLOWER
WARNING: Inspect the area be-
fore using the unit. Remove all debris
and hard objects such as rocks, glass,
wire, etc., that can ricochet, be thrown,
or otherwise cause injury or damage
during operation.
Use your unit as a blower for:
D Sweeping debris or grass clippings from
driveways, sidewalks, patios, etc.
D Blowing grass clippings, straw, or leaves
into piles, or removing debris from corners, around joints, or between bricks.
Direct air flow by directing the blower
tube down or to one side. Always work
away from solid objects such as walks,
large stones, vehicles, and fences.
Clean corners by starting in corners and
moving outward. This will help prevent
an accumulation of debris which could
fly into your face.
Be careful when working near plants.
The force of the air could damage
tender plants.
USING YOUR UNIT AS A VACUUM
WARNING: Do not vacuum
stones, gravel, metal, broken glass,
etc., to avoid se vere damage to the impeller. To avoid the possibility of electrical shock, do not attempt to vacuum water or other liquids.
Use your unit as a vacuum to pick up
dry material such as leaves, grass,
small twigs, and bits of paper.
D For best results during vacuum use,
operate your unit at high speed.
D Move slowly back and forth over the
material as you vacuum. Avoid forcing the unit into a pile of debris as
this can clog the unit.
D Keep the vacuum tube about an inch
above the ground for best results.
WARNING: If the unit becomes
clogged, stop the unit and unplug the extension cord. Wait until the impeller has
completely stopped turning, then remove the vacuum tubes. Carefully
reach into the vacuum opening and
clear out the clogged debris.
8
MAINTENANCE
WARNING: Disconnect power
source before performing maintenance.
GENERAL RECOMMENDATIONS
The warranty on this unit does not cover
items that have been subjected to operator abuse or negligence. T o receive full
value from the warranty, the operator must
maintain unit as instructed in this manual.
V ar ious adjustments will need to be made
periodically to properly maintain your unit.
BEFORE EACH USE
CHECK FOR LOOSE
FASTENERS AND PARTS
S Inlet Cover
S Blower Tube
S Vacuum Tubes
S Collection Bag
CHECK FOR DAMAGED OR
WORN PARTS
Contact your authorized service dealer
for replacement of damaged or worn
parts.
S ON/OFF Switch - - Ensure switch functions
properly by moving the switch to the
position. Make sure motor stops; then restart motor and continue.
OFF
SERVICE
HOW TO REMOVE AN OBJECT
FROM THE AIR INTAKE
WARNING: Stop the unit and dis-
connect from the power source before
opening the inlet cover. The motor must
be stopped and the impeller blades no
longer turning to avoid serious injury
from the rotating blades.
S Inlet Cover - - Discontinue use of unit if in-
let cover fails to latch properly or if it is
damaged in any way.
AFTER EACH USE
INSPECT AND CLEAN UNIT & LABELS
Stop unit and unplug extension cord.
S After each use, inspect complete unit
for loose or damaged parts. Clean the
unit using a damp cloth.
S Wipe off unit with a clean dry cloth.
CLEANCOLLECTIONBAG
IMPORTANT:
MUST BE PROPERLY EMPTIED.
D You must properly empty and maintain
the collection bag to avoid deterioration
and obstruction of air flow.
D Remove the collection bag from the unit
and empty after each use. Do not store
bag without emptying the bag of all contents (grass, leaves, etc.).
D Wash the bag once a year. Remove the
bag from the blower and turn the bag inside out. Wash the bag with a water hose.
Allow the bag to hang and dry completely
before you reuse the bag.
1. While holding the inlet cov er open,
remove the vacuum tubes. The inlet
cover must be held open through all
remaining steps.
2. Carefully reach into the vacuum
opening and clear out the air intake
area. Clear all debris from impeller.
3. Inspect the impeller for cracks. If
cracked or damaged, do not use the
unit. Have parts replaced by y our authorized service dealer. Do not attempt to replace them yourself.
THE COLLECTION BAG
STORAGE
WARNING: Perform the following
steps after each use:
S Stop unit and disconnect from the power
source.
S Allow motor to cool before storing or
transporting.
S Store unit with all guards in place. Posi-
tion unit so that any sharp object cannot
accidentally cause injury.
S Store unit unplugged, well out of the
reach of children.
SEASONAL STORAGE
Prepare unit for storage at the end of
the season or if it will not be used for
30 days or more.
If your blower is to be stored for a period
of time:
S Stop unit and disconnect from the power
source.
S Clean the entire unit before lengthy stor-
age.
S Open inlet cover and clean any dirt,
grass, or debris that has collected. Inspect the blower and all tubes. Close and
make sure the cover is latched.
9
S Clean air vents and air inlet of debris.
S Store your unit and extension cord in a
well ventilated area and covered, if possible, to prevent dust and dirt accumulation. Do not cover with plastic. Plastic cannot breathe and may cause condensation
and eventual rust or corrosion.
S Check entire unit for loose screws. Re-
place any damaged, worn, or broken
parts.
TROUBLESHOOTING TABLE
WARNING: Always stop unit and disconnect from the power source before
performing all of the recommended remedies below except remedies that require unit to be operating.
SYMPTOM CAUSE REMEDY
Unit fails to
operate.
Unit
vibrates
abnormally.
Impeller will
not turn
freely.
1. Switch in the OFF position.
2. Extension cord discon-nected.
3. Circuit breaker tripped, or
fuse blown.
4. Mechanical failure
1. Mechanical failure
1. Debris in air intake area.
2. Mechanical failure.
1.Slideswitchto
2. Reconnect extension cord.
3. Reset circuit breaker or
fuse.
4. Contact your authorized
service dealer.
1. Contact your authorized
service dealer.
1. Clean unit. Remove any
debris.
2. Contact your authorized
ON position.
service dealer.
LIMITED WARRANTY
WEED EATER warrants to the original
purchaser that each new WEEDEATER
brand electric or cordless product is free
from defects in material and workmanship and agrees to repair or replace under this warranty any defective WEED
EATER brand electric or cordless product within two (2) years from the original
date of purchase.
If your WEED EATER brand electric or
cordless product should fail within the
limited warranty period, return it, complete, prepaid, with proof of purchase, to
the dealer from whom it was purchased
for repair or replacement at the option of
WEED EATER.
This warranty is not transferable and
does not cover damage or liability
caused by improper handling, improper
maintenance or the use of accessories
and/or attachments not specifically recommended by WEED EATER for this
tool. Additionally, this warranty does not
cover parts that will wear and require replacement with reasonable use during
the warranty period. This warranty does
not cover predelivery setup or normal
adjustments explained in the instruction
manual.
THIS WARRANTY GIVES YOU SPECIFIC
LEGAL RIGHTS, AND YOU MAY HAVE
OTHER RIGHTS WHICH VARY FROM
STATE TO STATE.
NO CLAIMS FOR CONSEQUENTIAL OR
OTHER DAMAGES WILL BE ALLOWED,
AND THERE ARE NO OTHER EXPRESS
WARRANTIES EXCEPT THOSE EXPRESSLY STIPULATED HEREIN.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS OR THE EXCLUSION OR
LIMITAT IO NS O F IN CI DE NTA L OR C ON SE QUENTIAL DAMAGES, SO THE ABOVE
LIMITATIONS OR EXCLUSION MAY NOT
APPLY TO YOU.
The policy of WEED EATER to continuously improve its products. Therefore,
WEED EATER reserves the right to
change, modify, or discontinue models,
designs, specifications, and accessories of all products at any time without
notice or obligation to any purchaser.
10
Loading...
