LCD HDTV WITH VIZIO INTERNET APPS®
M420SV / M470SV / M550SV
QUICK START GUIDE
PACKAGE CONTENTS
VIZIO LCD HDTV with Base
Remote Control with |
Cleaning Cloth |
Safety Cable |
Power Cord |
User Manual and |
Batteries |
|
|
|
Quick Start Guide |
USING THE REMOTE
Input |
Power/Standby |
App Launcher |
|
|
A/V Controls |
CC |
Info |
Exit |
Menu |
OK |
Arrow |
|
|
Back |
Guide |
V Button |
VIA Shortcuts |
|
|
Volume |
Channel |
Up/Down |
Up/Down |
Mute |
Last |
Number Pad |
|
Wide |
Dash (-) |
|
Battery Compartment |
QWERTY Keypad |
|
Arrow |
VIA Shortcuts |
Power/Standby: Turn the TV on or off. Input: Change the input device.
App Launcher: Launch the VOD (VIZIO On-Demand), Netflix, or
VUDU App.
A/V Controls: Control external device (CEC-enabled devices only). Info: Display the Info Window.
CC: Open the Closed Captioning menu. Menu: Display the on-screen menu.
Exit: Close the on-screen menu.
Arrow: Navigate the on-screen menu and episode guide. OK: Select highlighted menu option.
Guide: Display the episode guide (digital channels only). Back: Go to the previous on-screen menu options.
VIA Shortcuts: Control VIZIO Internet Apps.
Channel Up/Down: Change the channel. With each press of the button, the channel will increase or decrease by one.
Volume Up/Down: Increase or decrease the loudness of the TV’s audio. V Button: Start VIA Internet Apps.
Mute: Turn the sound off or on. When mute is activated, the TV’s audio is turned off.
Last: Return to the channel last viewed.
Number Pad: Use the number pad to manually enter a channel.
Dash (-): Use with number pad to manually enter a digital sub-channel. (For example, 18-4 or 18-5.)
Wide: Switch between display modes. QWERTY Keypad: Enter letters and numbers.
INSTALLING THE BASE |
|
1 |
2 |
Place the TV screen-down on a clean, flat surface.
To prevent scratches or damage to the screen, place the TV on a soft surface, such as carpet, rug, or blanket.
Push the base into the hole on the bottom of the TV.
Use a phillips-head screwdriver to tighten the 4 screws.
3 |
4 |
Attach the plastic cover. |
|
Move the TV with attached base into an upright position and |
|
|
place on a flat, level, and stable surface. |
|
|
|
