BAT.PAR 6 RGBWA
BAT.PAR 6 RGBUV
LED spotlight
User manual
Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: +49 (0) 9546 9223-0
E-mail: info@thomann.de
Internet: www.thomann.de
29.12.2017, ID: 385435, 385475
Table of contents
1 General information................................................................................................................................. 6
1.1 Further information........................................................................................................................... 7
1.2 Notational conventions.................................................................................................................... 8
1.3 Symbols and signal words............................................................................................................... 8
2 Safety instructions.................................................................................................................................. 11
3 Features....................................................................................................................................................... 18
4 Installation.................................................................................................................................................. 19
5 Starting up.................................................................................................................................................. 23
6 Connections and operating elements........................................................................................... 25
7 Operating.................................................................................................................................................... 31
7.1 Starting the device........................................................................................................................... 31
7.2 Operating controls on the unit................................................................................................... 31
7.3 Operating via IR remote control................................................................................................. 35
7.4 Menu overview................................................................................................................................. 36
7.5 Functions in 1-channel DMX mode........................................................................................... 38
Table of contents
BAT.PAR 6 RGBWA BAT.PAR 6 RGBUV
3
LED spotlight
7.6 Functions in 4-channel DMX mode........................................................................................... 38
7.7 Functions in 5-channel DMX mode........................................................................................... 39
7.8 Functions in 6-channel DMX mode........................................................................................... 40
7.9 Functions in 7-channel DMX mode........................................................................................... 41
7.10 Functions in 8-channel DMX mode........................................................................................ 44
8 Technical specifications....................................................................................................................... 47
9 Plug and connection assignments.................................................................................................. 50
10 Troubleshooting...................................................................................................................................... 51
11 Cleaning....................................................................................................................................................... 53
12 Protecting the environment.............................................................................................................. 54
Table of contents
4
BAT.PAR 6 RGBWA BAT.PAR 6 RGBUV
LED spotlight
BAT.PAR 6 RGBWA BAT.PAR 6 RGBUV
5
LED spotlight
1 General information
This manual contains important instructions for the safe operation of the unit. Read and follow
the safety instructions and all other instructions. Keep the manual for future reference. Make
sure that it is available to all those using the device. If you sell the unit please make sure that
the buyer also receives this manual.
Our products are subject to a process of continuous development. Thus, they are subject to
change.
General information
6
BAT.PAR 6 RGBWA BAT.PAR 6 RGBUV
LED spotlight
1.1 Further information
On our website (www.thomann.de) you will find lots of further information and details on the
following points:
Download This manual is also available as PDF file for you to download.
Keyword search
Use the search function in the electronic version to find the topics of
interest for you quickly.
Online guides
Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service
If you have any problems with the device the customer service will
gladly assist you.
General information
BAT.PAR 6 RGBWA BAT.PAR 6 RGBUV
7
LED spotlight
1.2 Notational conventions
This manual uses the following notational conventions:
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
1.3 Symbols and signal words
In this section you will find an overview of the meaning of symbols and signal words that are
used in this manual.
Letterings
General information
8
BAT.PAR 6 RGBWA BAT.PAR 6 RGBUV
LED spotlight
Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
WARNING! This combination of symbol and signal word indicates a pos-
sible dangerous situation that can result in death or serious
injury if it is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos-
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – high-voltage.
Warning – suspended load.
General information
BAT.PAR 6 RGBWA BAT.PAR 6 RGBUV
9
LED spotlight
Warning signs Type of danger
Warning – danger zone.
General information
10
BAT.PAR 6 RGBWA BAT.PAR 6 RGBUV
LED spotlight
2 Safety instructions
This device is intended to be used as an electronic illumination effect using LED technics. The
device is designed for professional use and is not suitable for use in households. Use the
device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. No
liability will be assumed for damages resulting from improper use.
This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Intended use
Safety instructions
BAT.PAR 6 RGBWA BAT.PAR 6 RGBUV
11
LED spotlight
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never
remove any covers.
There are no user-serviceable parts inside.
Do not use the device if covers, protectors or optical components are missing or
damaged.
Safety
Safety instructions
12
BAT.PAR 6 RGBWA BAT.PAR 6 RGBUV
LED spotlight
DANGER!
Electric shock caused by short-circuit
Always use proper ready-made insulated mains cabling (power cord) with a protective contact plug. Do not modify the mains cable or the plug. Failure to do so
could result in electric shock/death or fire. If in doubt, seek advice from a registered electrician.
WARNING!
Eye damage caused by high light intensity
Never look directly into the light source.
WARNING!
Risk of epileptic shock
Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons
should avoid looking at strobe lights.
Safety instructions
BAT.PAR 6 RGBWA BAT.PAR 6 RGBUV
13
LED spotlight
WARNING!
Incorrect handling of lithium batteries can result in injury
In the event of a short circuit, overheating or mechanical damage, lithium batteries can cause severe injuries.
Follow the advice on the correct handling of lithium batteries in the present section.
NOTICE!
Risk of fire
Do not block areas of ventilation. Do not install the device near any direct heat
source. Keep the device away from naked flames.
Safety instructions
14
BAT.PAR 6 RGBWA BAT.PAR 6 RGBUV
LED spotlight
NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
NOTICE!
Power supply
Before connecting the device, ensure that the input voltage (AC outlet) matches
the voltage rating of the device and that the AC outlet is protected by a residual
current circuit breaker. Failure to do so could result in damage to the device and
possibly injure the user.
Unplug the device before electrical storms occur and when it is unused for long
periods of time to reduce the risk of electric shock or fire.
Safety instructions
BAT.PAR 6 RGBWA BAT.PAR 6 RGBUV
15
LED spotlight
NOTICE!
Risk of fire due to incorrect polarity
Incorrectly inserted batteries may destroy the device or the batteries.
Ensure that proper polarity is observed when inserting batteries.
NOTICE!
Possible damage by leaking batteries
Leaking batteries can cause permanent damage to the device.
Take batteries out of the device if it is not going to be used for a longer period.
Safety instructions
16
BAT.PAR 6 RGBWA BAT.PAR 6 RGBUV
LED spotlight
NOTICE!
Possible staining
The plasticiser contained in the rubber feet of this product may possibly react
with the coating of your parquet, linoleum, laminate or PVC floor and after some
time cause permanent dark stains.
In case of doubt, do not put the rubber feet directly on the floor, but use felt-pad
floor protectors or a carpet.
NOTICE!
Possible damage due to incorrect storage
Deep discharge can cause batteries to become permanently damaged or lose
some of their capacity.
Before prolonged rest periods, charge the batteries to around 50 % of their
capacity and then switch the equipment off. Store the equipment at a temperature between 10 °C and 32 °C in as dry an environment as possible. During
extended storage periods, charge the batteries to 50 % approximately every three
months.
Safety instructions
BAT.PAR 6 RGBWA BAT.PAR 6 RGBUV
17
LED spotlight
3 Features
Special features of the device:
n
Model BAT.PAR 6 RGBWA: six RGBWA LEDs (red, green, blue, white, amber, 8 W each)
n
Model BAT.PAR 6 RGBUV: six RGBUV LEDs (red, green, blue, UV, 8 W each)
n
Stand-alone, master-slave or DMX mode operation
n
Control via DMX, four different modes, with the supplied infrared remote control or the
buttons and display on the unit
n
Stand-alone operation with static colours
n
Sound control
n
Battery or mains powered
n
Power supply and infrared remote control included
n
Suitable for use in clubs, bars, theatres, exhibitions, etc. or for mobile use
Features
18
BAT.PAR 6 RGBWA BAT.PAR 6 RGBUV
LED spotlight
Loading...
