Instruction Manual
Food Processor
Model - FP 2663
Dear Customer,
Congratulations!
You are now the proud owner of Usha Food Processor.
Innovatively designed, using only the highest quality material and components, your Usha Food Processor is designed for years of trouble free performance.
Please read this Instruction Manual carefully before using and keep it cautiously after reading for future reference.
Best Wishes
2
Important precautions
•Keep the appliance out of reach of children.
•This appliance is for house hold use only.
•Switch off the appliance and disconnect it from the mains before storing it.
•Always fit the safety cover before using the food processor.
•Do not spill water on basic unit. In case it happens please get it checked from the service personnel before operating.
•Never use Food processor on wet surface as it may cause an electrical shock.
•Never push the food through feeder tube with your finger. Always cut food into small pieces and push the food into FP bowl with food pusher only.
•Never touch moving parts during operation as they revolve at high speed and may cause injury.
•Handle the blade/ discs with care as they are very sharp. Hold the blades from the plastic parts only.
•Never allow the processed food to touch the disc during operation. It could force the disc upward and cause damage. If bowl begins to fill, empty it out in between operations.
•Never exceed the maximum level when working with liquids.
•Always keep a visual check on food being processed till you become conversant with the Food processor. It is fast and powerful enough to finish operation before you know it.
•Never lay any cloth or plastic sheet under basic unit as it may get sucked up and block the ventilation holes in the bottom during operation.
•Place the processor bowl on base of the processor before fitting any attachments.
•All blades & attachments should be removed before cleaning.
•Don’t place the appliance near hot surfaces like electrical hob, hot gas, heat oven etc.
•While using the grinder/ blender make sure there are no blades fitted in the processor.
•While using the processor grinder or blender ensure the lid is in place before switching on and do not remove the lid until the blade has stopped rotating.
•Always remove the processor blade before emptying the processor bowl of its contents.
3
Technical Specifications
Model No. |
FP 2663 |
|
|
Rating |
230V,-AC single phase, 50Hz |
|
|
Wattage |
600 Watts |
|
|
Type of motor |
Universal motor |
Time rating |
30 minutes |
Speed |
3 speeds with pulse |
|
|
Over Load Protector |
Resetting type - amp |
|
|
FP Bowl capacity |
2 ltr |
|
|
BL Jar capacity |
1.5 ltr |
|
|
Multipurpose Jar Capacity |
1.0 ltr. |
|
|
Chutney Jar Capacity |
400 ml. |
*Due to continuous effort for product upgradation, specifications are subject to change without prior notice.
Features
•Extra powerful motor
•Over load protector to protect motor from burn out
•Unbreakable FP bowl/cover
•Safety switch for safe operation of FP bowl & jars
•Fruit Filter
•Citrus & Centrifugal juicer attachment
•Cord storage attachment
IDENTIFICATION OF PARTS
4
Parts List
A.Main Unit
1.Basic Unit
2.Rotary Switch
3.Processor Spindle
4.Over Load Indicator
5.Power Indicator
6.Reset Button
7.Whipping Switch
8.Safety Cover
9.Safety Knob
10.Spatula
B.Bowl Assembly
11. Bowl
12. Bowl Lid
13. Feeder Tube
14. Food Pusher
15. Spindle Extension (Type A)
C.Blade Attachment
16.Kneading Blade
17.Chopping Blade
18.Blade Holder
19.Shredding Blade (Fine)
20.Shredding Blade (Course)
21.Slicing Blade
22.French Fries Blade
D.Multipurpose jar (1000 ml)
23. MP jar
24. Ring
25. Jar Lid
26. Handle
E.Blending jar (1500 ml)
27.Jar
28.Jar Lid
