OWNER’S MANUAL
LCD Color Monitor
P1550LA
P1750LA
P1950LA
○C 2005 TOSHIBA CORPORATION
All Rights Reserved
Owner’s Record
The model number and serial number are on the back of your monitor. Record these numbers in the spaces below Refer to these numbers whenever you communicate with your Toshiba dealer about this monitor.
Model Number:
Serial Number:
Part Number:
V.1.0
Important Information
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
The lightning symbol in the triangle tells you that the voltage inside this product may be strong enough to cause an electric shock.
DO NOT TRY TO SERVICE THIS PRODUCT YOURSELF.
The exclamation point in the triangle tells you that important operating and maintenance instructions follow this symbol.
CAUTION:
TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLET UNLESS THE PRONGS CAN BE FULLY INSERTED INTO THE OUTLET TO PREVENT ANY EXPOSURE OF THE PRONGS ON THE POLARIZED PLUG.
2
Important Information
FCC compliance information in USA
FCC Declaration of Conformity Compliance Statement (Part 15):
The Toshiba LCD Color Monitor complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
The party responsible for compliance to these rules is: TOSHIBA AMERICA INFORMATION SYSTEMS, INC. 9740 IRVINE BLVD., IRVINE, CA92618-1697
TEL: (949) 583-3000
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and the receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications to this equipment not expressly approved by Toshiba could void the user’s authority to operate this equipment.
IMPORTANT SAFEGUARDS
1. READ INSTRUCTIONS
All the safety and operating instructions should be read before the unit is operated. 2. RETAIN INSTRUCTIONS
The safety and operating instructions should be retained for future reference. 3. HEED WARNINGS
All warnings on the unit and in the operating instructions should be adhered to. 4. FOLLOW INSTRUCTIONS
All operating and usage instructions should be followed. 5. CLEANING
Unplug this unit from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Clean only with a
dry cloth.
6. ATTACHMENTS
The manufacturer of this unit does not make any recommendations for attachments, as they may cause hazards. 7. WATER AND MOISTURE
Do not use this unit near water. For example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet
basement, or near a swimming pool. 8. ACCESSORIES
Do not place this unit on an unstable cart, stand, tripod, bracket, or table. The unit may fall, causing serious injury, and serious damage to the unit. An appliance and cart combination should be moved with care. Quick stops,
excessive force, and uneven surfaces may cause the appliance and cart combination to overturn. 9. VENTILATION
Slots and openings at the rear cabinet and bottom are provided for ventilation, these are to ensure reliable operation of the unit, and to protect it from overheating. These openings must not be blocked or covered. The openings should never be blocked by placing the unit on a bed, sofa, rug, or other similar surface. This unit should never be placed near or over a radiator or heat source. This unit should not be placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to. 10. POWER SOURCE
This unit should be operated only from the type of power source indicated on the rating plate. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company.
Use the supplied power supply cord at AC 120V or less. 3
Important Information
11. POWER-CORD PROTECTION
Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit
from the appliance. 12. LIGHTNING
To protect your unit from a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the unit due to lightning and power line surges. However, while it is thundering or lightning, do not touch the apparatus and any connected
cable and/or equipment. This will prevent you from receiving the electric shock by an electric surge. 13. POWER LINES
An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall onto or against such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits, as contact with them might
be fatal.
14. OVERLOADING
Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric shock. 15. OBJECT AND LIQUID ENTRY
Do not push objects through any openings in this unit, as they may touch dangerous voltage points or short out parts
that could result in fire or electric shock. Never spill or spray any type of liquid into the unit. 16. HEAT
The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products
(including amplifiers) that produce heat. 17. CONNECTING
When you connect the product to other equipment, turn off the power and unplug all of the equipment from the wall outlet. Failure to do so may cause a product damage. Read the owner's manual of the other equipment carefully and
follow the instructions when making any connections. 18. LCD
Do not press on or jolt the LCD panel. Doing so may cause the LCD panel glass to break and injury may occur. Should the LCD panel be broken and liquid leaks out, do not inhale or swallow it. Doing so may cause poisoning. If you have got it into your mouth, wash it out and consult your doctor. If your hands or clothes have touched it, wipe them with alcohol and a cleaning cloth and then wash them well.
Precautions
Notes on handling
Do not subject the LCD panel to physical shock, such as dropping it. It may cause malfunction. Retain the original shipping carton and packing materials. Repack the unit as it was originally packed at the factory. For maximum protection when shipping.
Do not use volatile liquids, such as insecticide, near the unit. Do not leave rubber or plastic products in contact with the unit for long periods of time. Doing so will leave marks on the finish.
The top and rear panels of the unit may become warm after a long period of use. This is not a malfunction.
When the unit is not in use, turn off the power. Notes on locating the unit
Place the unit on a level surface. Do not use it on a shaky or unstable surface such as a wobbling table or inclined stand. Doing so may damage the unit.
When you place this unit near a TV, radio, or VCR, the playback picture may become poor and the sound may be distorted. In this case, place the unit away from the TV, radio, or VCR.
4
Notes on cleaning
Clean only with a soft, dry, lint-free cloth. Notes on LCD
The color LCD is manufactured using extremely high precision technology, but even so may include certain pixels that do not operate properly (that do not light, that remain lit constantly, etc.). We do our best to keep the number of these defective pixels to a minimum, but please understand that they cannot be completely eliminated even with the most advanced manufacturing technologies available today.
The fluorescent tube which illuminates the panel from the inside will deteriorate with use. When the LCD becomes dim, flickers, or does not illuminate, contact your dealer for replacement.
The brightness of the LCD monitor differs slightly depending on the viewing angles. Adjust the angle to obtain the best viewing.
Table of Contents
Important Information…………………………………………………………………… 2 Table of Contents……………………………………………………………………….. 5 Exploring your New Monitor……………………………………………………………. 6 Front Panel……………………………………………………………………….…. 6 Back…………………………………………………………………………………. 6 Side…………………………………………………………………………………. 6 Selecting a Location for the Monitor……………………………………………….……7 Connecting your Monitor…………………………………………………………………7 Connecting a DVR (Digital Video Recorder)………………………………………….. 8 Connecting a Camera…………………………………………………………………… 8 Connecting a PC (Personal Computer)………………………………………………. 9
Rack Mount……….……………………………………………………………………… 10 Arm Mount (VESA standard)……….……………………………………………………10 Setting up your Monitor………………………………………………………………… 11 General Setup…………………………………………………………………………… 12 Video Setup……………………………………………………………………………… 13 PC-In Setup……………………………………………………………………………… 14 Troubleshooting………………………………………………………………………… 15 LCD Color Monitor Specifications……………………………………………………….16 LCD Color Monitor Dimensions ……………………………………………………… ..17 Limited Warranty
5
Exploring your New Monitor
You can operate your Monitor by using the buttons on the front panel. The side panels provide the inputs to connect other equipment to your Monitor.
Front Panel
P1550LA
P1750LA
|
TO |
N |
U |
|
N |
P |
|
T |
|
R |
||
|
U |
|
|
W |
U |
|
U |
E |
||||
A |
ME |
|
|
IN |
P |
OW |
|
|||||
|
DO |
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
P |
|
|
P1950LA
Back |
Side |
|
|
Audio 2 |
Audio 2 |
|
IN |
OUT |
|
Audio 1 |
Audio 1 |
|
IN |
OUT |
|
|
S-VideoVideoIN |
|
|
Video 2 |
|
|
OUT |
|
|
Video 2 |
|
|
IN |
|
|
Video 1 |
|
|
OUT |
|
|
Video 1 |
|
|
IN |
|
|
PC Audio |
|
|
IN |
|
|
VGAAIN |
|
|
AC IN |
|
Note: |
|
Auto: Auto adjust the optimal display screen in PC mode. |
45 15 |
Menu: Enter Setup Menu page & confirm selection. |
