Digital Switchover
8IFO EPFT TXJUDIPWFS IBQQFO
$PQFMBOE TXJUDIFT PO 0DUPCFS
5IF FYBDU EBUF ZPV TXJUDI EFQFOET PO UIF USBOTNJUUFS ZPV BSF TFSWFE CZ 5P DIFDL XIFO ZPV TXJUDI HP UP %JHJUBM 6,µT QPTUDPEF DIFDLFS PO XXX EJHJUBMVL DP VL
$IFDL ZPVS *57 OFXT TFSWJDF PS MPPL BU 5FMFUFYU QBHF UP TFF XIBU 57 SFHJPO ZPVµSF JO
,FFQ UIJT JNQPSUBOU JOGPSNBUJPO BCPVU IPX UP SF UVOF ZPVS 57 EVSJOH UIF EJHJUBM 57 TXJUDIPWFS
Television in the UK is going digital, bringing us all |
switchover, and you won’t need to re-tune. Keep this |
|
more choice and new services. Starting in late 2007 |
important information about how to re-tune your TV |
|
and ending in 2012, television services in the UK will |
during the digitalTV switchover |
|
go completely digital, TV region by TV region. |
How to re-tune: |
|
Please see above to find out when your area switches |
As new services are broadcast it will be necessary to |
|
to digital. Digital UK is the independent, non-profit |
re-tune the television in order to view them. Auto tuning |
|
organisation leading the process of digital TV |
will completely retune the television and can be used |
|
switchover in the UK. |
to update the channel list. |
|
Digital UK provides impartial information on what |
• Press MENU button on the remote control unit. |
|
people need to do to prepare for the move to digital, |
• Select Install and Retune option and then select |
|
and when they need to do it. |
||
Automatic channel scan (Retune). |
||
How the switchover affects your TV equipment: |
||
• A screen will appear warning that previous digital |
||
Your new TV has a digital tuner built in, which means |
||
programmes and settings will be deleted. |
||
it is ready to receive the Freeview signal by simply |
• You must allow the television to complete the |
|
plugging it into your aerial socket (check if you can |
||
search... |
||
get digital TV through your aerial now, or whether |
||
• When the search is complete the Auto tuning screen |
||
you’ll have to wait until switchover, at www.digitaluk. |
||
co.uk). |
will display the total number of service found. |
|
When the TV switchover happens in your area, there |
NOTE: Further detailed instructions on Auto tuning |
|
are at least two occasions when you will need to |
can be found in the TV owners manual. |
|
re-tune your TV in order to continue receiving your |
If you are missing channels, it may be that they are |
|
existing TV channels, and also to pick up new ones, |
not available in your area, or that your aerial needs |
|
Digital UK, the body leading the digital TV switchover, |
upgrading. |
|
will advise you when you need to re-tune during the |
If you have any further questions, please contact your |
|
switchover. |
||
equipment supplier or call Digital UK on 08456 50 50 |
||
If you choose to connect your TV to satellite or |
||
50 or visit www.digitaluk.co.uk |
||
cable with a digital box then it will not be affected by |
- 2 - |
|
|
32BL505B_MB62_[GB]_(IB_INTERNET)_DVB-T_(3910UK)_10076099.indd |
|
|
2 |
21.01.2012 17:53:17 |
|
|
|||
|
|
|
|
|
Re-tuning: TOSHIBA Freeview Products
Toshiba Digital TV
This guide can be used to help you re-tune the following product with the remote control below. Make sure your TV is on and press 80 for the BBC News channel
SCREEN LANG SUBTTL PIP
1 2 3
4 5 6
7 8 9
|
0 |
BACK |
MENU |
|
OK |
EPG |
FAV |
SOURCE |
INFO |
PRESETS SLEEP |
1 ) Press MENU and press ◄ or ► to select Install and Retune and press OK. Press
▲ or ▼ to select Automatic channel scan (Retune) to start the process.
MENU
OK |
OK |
2 ) Select the desired search mode using ► and press OK button.
- V +
OK |
OK |
- P +
3 ) Whenever you select an automatic search type and press OK button, a confirmation screen will appear on the screen. To start installation process, select Yes by using ◄ or ► and OK button.
OK |
OK |
4 ) After auto channel scan type is set and selected and confirmed, installation process will start and progress bar will move along. The television will start to search for all available stations. You must allow the television to complete the search.
* This process may affect any saved information stored on your product. Please consult your instruction manual or contact the manufacturer using the details above.
TOSHIBA Customer Helpline: 0844 856 0730 TOSHIBA Online Support: www.toshiba.co.uk/tv-dvd-support
- 3 -
32BL505B_MB62_[GB]_(IB_INTERNET)_DVB-T_(3910UK)_10076099.indd |
|
|
3 |
21.01.2012 17:53:17 |
|
|
|||
|
|
|
|
|
Manual Re-tuning
If your Freeview TV or box picks up a different regional service to your preferred service (e.g. BBC England instead of BBC Scotland, or ITV Central instead of ITV Anglia), you can use this manual re-tune If you are missing some services you may find they have moved to channel 800 or above, this guide will help you put them in your preferred position. If you find manual re-tuning too difficult, contact your local electrical retailer or installer. This is a guide only, Freeview models operate slightly differently. Some early models do not oer a manual re-tune facility
– check your instruction book. Please note: Every time you re-tune, you will need to go through this process.
1 ) Go to the Postcode Checker at digitaluk.co.uk Enter your postcode on the right hand side of the web page.
Remember to include your house number or name. If you do not have internet access, contact the Digital UK helpline on 08456 50 50 50* and ask for manual re-tune guide support.
2 ) Once you have entered your address details, the next page gives you an indication of which TV services you should receive, based on your most likely transmitter. You may be able to receive television services from more than one transmitter and you can check alternatives, where available. On the results page click on the pink button to see your full reception forecast and channel information for switchover.
3 ) Click on the How do I re-tune? pink banner. Scroll down to the manual re-tune table where you will see the relevant “RF Channel” numbers for the digital services that can be received at your home.**
*Calls are free for BT customers within inclusive calling plans. Call charges from other providers may vary. The standard business hours for Digital UK’s contact centre are 9am to 7pm Monday to Friday and 10am to 4pm on a Saturday. Opening hours will be extended during switchover in each area. Digital UK, PO Box 26833, Kirkcaldy,KY2 9AG . **Please note that the Freeview channel line-up is subject to change.
- 4 -
32BL505B_MB62_[GB]_(IB_INTERNET)_DVB-T_(3910UK)_10076099.indd |
|
|
4 |
21.01.2012 17:53:18 |
|
|
|||
|
|
|
|
|
4 ) Write down the “RF Channel” numbers for your transmitter using the Group boxes here:
5 ) Press MENU and use ◄ or ► to select Install and Retune.
6 ) Select Manual Channel Scan from the Installation menu and press OK.
MENU
OK |
OK |
7 ) Select Search Type as Digital by using ◄ or ►.
OK
8 ) Select Channel and use ◄ or ► to change the channel number.
OK |
OK |
9 ) Press OK to start search.
10 ) Press MENU button. You should find that you now have your preferred service installed.
- 5 -
32BL505B_MB62_[GB]_(IB_INTERNET)_DVB-T_(3910UK)_10076099.indd |
|
|
5 |
21.01.2012 17:53:19 |
|
|
|||
|
|
|
|
|
