Page 1
For Discount Tecumseh Engine Parts Call 606-678-9623 or 606-561-4983
LEV120-361113D Page 1 of 5
Engine Parts List #1
www.mymowerparts.com
Page 2
For Discount Tecumseh Engine Parts Call 606-678-9623 or 606-561-4983
LEV120-361113D Page 2 of 5
Engine Parts List #1
Ref # Part Number Qty Description
1 37266 Cylinder (Incl. 2,20 & 150)1
2 26727 Dowel Pin2
6 33734 Breather Element1
7 36557 Breather Ass'y. (Incl. 6 & 12A)1
12A 36558 Breather Cover & Tube1
14 28277 Washer1
15 31513 Governor Rod (Incl. 14)1
16 34839A Governor Lever1
17 31335 Governor Lever Clamp1
18 651018 Screw, Torx T-15, 8-32 x 19/64"1
19 36281 Extension Spring1
20 32600 Oil Seal1
30 37200 Crankshaft1
40 40027 Piston, Pin & Ring Set (Std.)1
40 40028 Piston, Pin & Ring Set (.010" OS)1
41 40025 Piston & Pin Ass'y. (Std.) (Incl. 43)1
41 40026 Piston & Pin Ass'y. (.010" OS) (Incl. 43)1
42 40006 Ring Set (Std.)1
42 40007 Ring Set (.010" OS)1
43 20381 Piston Pin Retaining Ring2
45 36777 Connecting Rod Ass'y. (Incl. 46)1
46 32610A Connecting Rod Bolt2
48 27241 Valve Lifter2
50 37477 Camshaft (Exhaust MCR)(Inc. ref 104)1
52 29914 Oil Pump Ass'y.1
69 37609 Mounting Flange Gasket1
70 37658 Mounting Flange (Incl. 58,72 thru 83, 306)1
72 37614 Oil Drain Plug1
75 26208 Oil Seal1
80 30574A Governor Shaft1
81 30590A Washer1
82 30591 Governor Gear Ass'y. (Incl. 81)1
83 30588A Governor Spool1
86 650488 Screw, 1/4-20 x 1-1/4"5
89 611004 Flywheel Key1
90 611112 Flywheel1
92 650815 Belleville Washer1
93 650816 Flywheel Nut1
100 34443B Solid State Ignition1
101 610118 Spark Plug Cover1
103 651007 Screw, Torx T-15, 10-24 x 15/16"2
104 37480 Cam Bushing1
104 37480 Cam Bushing1
110 37047 Ground Wire1
119 36787 * Head Gasket1
120 36825 Cylinder Head1
125 37288 Exhaust Valve (Std.) (Incl. 151)1
126 37289 Intake Valve (Std.) (Incl. 151)1
130 6021A Screw, 5/16-18 x 1-1/2"8
135 35395 Resistor Spark Plug (RJ19LM)1
150 31672 Valve Spring2
151A 40017 Intake Valve Seal1
151 31673 Valve Spring Cap2
169 36783 * Valve Cover Gasket1
172 36784 Valve Cover1
174 30200 Screw, 10-24 x 9/16"2
178 29752 Nut & Lock Washer, 1/4-282
182 6201 Screw, 1/4-28 x 7/8"2
www.mymowerparts.com
Page 3
For Discount Tecumseh Engine Parts Call 606-678-9623 or 606-561-4983
LEV120-361113D Page 3 of 5
Engine Parts List #1
Ref # Part Number Qty Description
184 26756 * Carburetor To Intake Pipe Gasket1
185 36785 Intake Pipe1
186 32653 Governor Link1
189 650839 Screw, 1/4-20 x 27/64"2
191 36559A S.E. Brake Bracket (Incl. 195)1
195 610973 Terminal1
207 34336 Throttle Link1
223 650451 Screw, 1/4-20 x 1"2
224 36786 * Intake Pipe Gasket1
238 650806 Screw, 10-32 x 5/8"2
239 34338 * Air Cleaner Gasket1
240 37115A Air Cleaner Body1
245A 37117 Breather Filter1
245 37116 Air Cleaner Filter1
250 37118 Air Cleaner Cover Ass'y1
260 37125 Blower Housing1
261 30200 Screw, 10-24 x 9/16"2
262 650831 Screw, 1/4-20 x 1/2"2
275 36986A Muffler1
277 650988 Screw, 1/4-20 x 2-5/16"2
285 35000A Starter Cup1
287 650926 Screw, 8-32 x 21/64"2
290 34357 Fuel Line (4.83")1
292 26460 Fuel Line Clamp1
292 26460 Fuel Line Clamp2
300 35586 Fuel Tank (Incl. 292 & 301)1
301 35355 Fuel Cap (Red)1
305 35577 Oil Fill Tube1
306 36996 * "O"-Ring1
307 35499 "O"-Ring1
309 650562 Screw, 10-32 x 1/2"1
310 35578 Dipstick1
313 34080 Spacer1
370A 36261 Identification Decal2
370C 37318 Primer Decal (3 X)1
370K 36695 Starter Decal1
380 640282 Carburetor (Incl. 184)1
390 590737 Rewind Starter (NOTE: This engine could hav e been built
1
with 590694 starter).
400 37613 * Gasket Set (Incl. items marked PK i n notes). Incl. Part
416 36085 Spark Arrestor Kit (Incl. 417)(Option al)1
417 650821 Screw, 10-32 x 1/2" (Optional)1
420 730225A SAE 30 4-Cycle Engine Oil (Quart)1
1
#'s 26756 (1), 29673 (1), 34338 (1), 36783 (1), 36786 (1),
36787 (1), 37609(1), 37610 (1)
www.mymowerparts.com
Page 4
For Discount Tecumseh Engine Parts Call 606-678-9623 or 606-561-4983
LEV120-361113D Page 4 of 5
Engine Parts List #2
www.mymowerparts.com
Page 5
For Discount Tecumseh Engine Parts Call 606-678-9623 or 606-561-4983
LEV120-361113D Page 5 of 5
Engine Parts List #2
Ref # Part Number Qty Description
19 36281 Extension Spring1
41 40025 Piston & Pin Ass'y. (Std.) (Incl. 43)1
41 40026 Piston & Pin Ass'y. (.010" OS) (Incl. 43)1
53 31745 Tang Washer1
54 31747 Washer1
55 35218A P.T.O. Shaft1
56 33401 R.H. Worm Gear1
57 33537 Retainer Ring1
58 31744 Oil Seal1
69 37609 Mounting Flange Gasket1
72 37614 Oil Drain Plug1
75 26208 Oil Seal1
86 650488 Screw, 1/4-20 x 1-1/4"5
87 650492 Screw, 1/4-20 x 2-1/4"1
90 611112 Flywheel1
182 6201 Screw, 1/4-28 x 7/8"2
185 36785 Intake Pipe1
186 32653 Governor Link1
216 33086 R.P.M. Adjusting Lever1
223 650451 Screw, 1/4-20 x 1"2
238 650806 Screw, 10-32 x 5/8"2
239 34338 * Air Cleaner Gasket1
240 37115A Air Cleaner Body1
245 37116 Air Cleaner Filter1
250 37118 Air Cleaner Cover Ass'y1
260 37125 Blower Housing1
261 30200 Screw, 10-24 x 9/16"2
262 650831 Screw, 1/4-20 x 1/2"2
263A 37197 Starter Grill1
275A 36838 Spark Arrestor Muffler (Optional) (Incl. 284,284A,416 & 417)1
284A 650821 Screw, 10-32 x 1/2" (Optional)1
284 36663 Muffler Deflector (Incl. 284A)(Option al1
300 35586 Fuel Tank (Incl. 292 & 301)1
301 35355 Fuel Cap (Red)1
370A 36261 Identification Decal2
416 36085 Spark Arrestor Kit (Incl. 417)(Option al)1
417 650821 Screw, 10-32 x 1/2" (Optional)1
www.mymowerparts.com
