www.teamcracing.net
GT8LE-RA
Instruction manual
1:8 Scale GP 4WD TOURING CAR
Dimensions
Length …………………………………………………………………………630mm
Width …………………………………………………………………………320mm
Height …………………………………………………………………………160mm
長度
寬度
高度
尺寸：
Transmitter Preparation
Battery Charger
(Not Included)
Battery
Servo
Motor
Electronic Speed
Controller / Switch
Receiver
Note: When done driving Turn Off the
ESC and THEN Transmitter
Install Transmitter Batteries1.
Connect Battery to ESC2.
Switch on Transmitter First3.
Switch on ESC Second4.
安裝發射電池
連接電池到電調
首先接通發射機
其次接通電調
注意：當停止駕駛首先要關掉電調
其次再關掉發射機
電池
充電器（不包括）
馬達
伺服
接收機
電子變速器
调整遥控器
Tools required
组裝需要的工具
Needie Nose Pllers
尖嘴钳
Differential Grease
差速油
Molybdenum Grease(Black)
钼油(黑)
Hex Wrench
六角扳手
Awl
锥
Hex Wrench
十字套筒
Grease
润滑油
H154
Body Reamer
车壳绞刀
No need to pre-drill precise holes
(1mm to 15mm)can be drilled
可以对预钻的孔准确的钻1mm-15mm
Screw Cement
螺丝胶水
Wire Cutters
钢丝钳
Sharp Hobby knife
美工刀
H162
Instant Glue
瞬间胶水
H096
ROUND CUTTER
剪刀
For trimming bodies!
用于修剪車壳！
Servo Saver Turnbuckle
1
伺服拉杆
Bag-A
1:1
Approx.27mm
大约27mm
Select the servo horn matching the servo being used.
根据伺服机选择伺服臂
TG8019 3x45 Turnbuckle
3x45拉杆
…………1
T08760 5.8 Ball End
5.8 球头座
…………2
T08759 5.8 Ball stud
5.8球头
……………………2
T08666 M3 Nylon Nut
M3尼龙螺母
…………………1
T08674 M3x14 Screw
M3x14 螺丝
………1
Buffer
2
缓冲
Bag-A
Approx.8mm
大约8mm
T08760
5.8 Ball End
5.8 球头座
T08650
Servo Saver Nut
缓冲螺母
T08759
5.8 Ball stud
5.8球头
▲Projection.Note direction
注意方向
4mm
TG8019
3x45 Turnbuckle
3x45 拉杆
T08759
5.8 Ball stud
5.8球头
T08760
5.8 Ball End
5.8 球头座
Futaba-25T Hitec-24T Sanwa/JR/KO-23T
T08666 M3
T08620
Steering Servo Horn-F
转向伺服臂-F
T08674 M3x14
T08674 M3x14
T08651 Buffer Screw
缓冲螺丝
……2
T02081 3x7x0.8 Washer
3x7x0.8垫片
…………………2
T08666 M3 Nylon Nut
M3尼龙螺母
…………………1
T08674 M3x14 Screw
M3x14 螺丝
………1
T08650
Servo Saver Spring
缓冲弹簧
T08762
Servo Saver-Top
缓冲座-上
T08762
Servo Saver-Bottom
缓冲座-下
T08650
Servo Saver Body
缓冲筒身
T08666 M3
T08651
Buffer Screw
缓冲螺丝
T08651
Steering Rack
转向缓冲连接板
T02081 3x7x0.8
T08762
Servo Saver-Left
缓冲座-左
Ture-to -scale diagram
1:1
图形比例
1
Servo Saver Post/Side Plate
3
缓冲柱/侧板
TG8003
Side Plate-Right
侧板-右
T08674 M3x8
Bag-A
T08650
Servo Saver Post
缓冲柱
Bag-B
T08674
M3x8
T08840
Chassis
底盘
TG8003
Side Plate-Left
侧板-左
T08674
Screw
Cement
M4x10
Buffer
4
缓冲
Bag-A
T08673 M3x5
T08673 M3x5 Screw
M3x5 螺丝
………………1
T08674 M3x10 Screw
M3x10 螺丝
…………1
T08674 M3x12 Screw
M3x12 螺丝
…………1
T08674 M3x14 Screw
M3x14 螺丝
T08828
Buffer Plate-Aluminium
缓冲顶板-铝
T08828
Buffer Plate-Plastic
缓冲顶板-塑胶
………1
T08662 6x10x3
T08662 6x10x3
T08674
M4x10
T08674 M3x14
Screw
Cement
T08674
M4x10
T08619
Front Chassis Stiffener
前支撑杆
T08666 M3
Screw
Cement
T08674 M3x8 Screw
M3x8螺丝
…………7
T08674 M4x10 Screw
M4x10螺丝
…………2
T08674 M4x10 Screw
M4x10 螺丝
…………2
T08662 6x10x3 Ball Bearing
6x10x3 轴承
………………4
T08666 M3 Nylon Nut
M3 尼龙螺母
…………………2
Apply threadlocker(screw cement)
Screw
Cement
打螺丝膠水
T08674 M3x10
T08674 M3x12
2
Front/Rear Differential
5
前/后差速器
x2
T08633
20T Diff Gear
20T差速齿轮
T08633
2.5x11.5 Pin
2.5x11.5 钢针
T08669 6.1x11x0.2
T08600 5.8x1.9
Bag-C
T08633
10T Diff Gear
10T差速齿轮
T08633 4.1x12x0.2
T08633
Diff Shaft
差速轴
T08633
2.5x11.5 Pin
2.5x11.5 钢针
T08633
20T Diff Gear
20T差速齿轮
T08669 6.1x11x0.2
T08600
Differential Pads
差速垫片
T08636 5.8x1.9
T08636 M3x12
T08600
Differential Housing
差速壳
T08664 8x16x5
T08634
Diff Connecting Cup
差速接杯
T08600/T08636 5.8x1.9 O-Ring
5.8x1.9 O环
…………………4
Front Differential Case
6
前差速箱
Bag-C
10000# for Front
5000# for Rear
T08633 4.1x12x0.2 Washer
4.1x12x0.2垫片
…………8
Bag-D
TG8016
87mm Center Front CVD
87mm中前CVD
Oil
T08669 6.1x11x0.2 Washer
6.1x11x0.2垫片
…………4
T08636
43T Diff Gear
43T差速齿轮
T08664 8x16x5
T08634
Diff Connecting Cup
差速接杯
T08664 8x16x5 Ball Bearing
8x16x5 轴承
………4
T08636 M3x12 Screw
M3x12螺丝
……8
T08601
Differential Case
差速箱
T08663 6x13x5
T08663 6x13x5
T08636
10T Gear
10T齿轮
Apply threadlocker(screw cement)
Screw
Cement
打螺丝膠水
TG8016
Screw
Cement
M5x4
T08673 M3x16
T08304
13.1x15.9x0.2
Assemble as many times as specified
x2
需组装数量
3
T08601
Differential Case
差速箱
T08663 6x13x5 Ball Bearing
6x13x5 轴承
………2
T08304 13.1x15.9x0.2 Washer
13.1x15.9x0.2垫片
…………2
T08673 M3x16 Screw
M3x16 螺丝
……2
TG8016 M5x4 Screw
M5x4 螺丝
………………1
Front Swaybar
7
前防倾杆
Bag-D
T08756
Screw
Cement
M3x3
x2
T08756
T08756
T08760
T08674 M2.5x8 Screw
M2.5x8螺丝
………………3
T08601
Swaybar Mount
防倾杆固定座
Front Hub Carrie
8
前轮座
T08674 M2.5x8
T08601 M3x3
Bag-D
T08639 2.5x12.8
T08647
Front Swaybar
前防倾杆
T08603
Left
Front Hub Carriers 12 Degree
前轮座12度
Right
T08601/T08756 M3x3 Screw
M3x3螺丝
……………………4
T08756 6.8 Ball stud
6.8球头
…………………2
T08755 6.8 Ball stud
6.8球头
………………………2
T08760 6.8 Ball End
6.8球头座
………………2
T08604
T08639
95.5mm Front CVD
95.5mm前CVD
T08639 5x8.5
T08639 2.5x12.8 Pin
2.5x12.8钢针
………………2
T08665 13x19x4 Ball Bearing
13x19x4 轴承
………2
T08664 8x16x5 Ball Bearing
8x16x5 轴承
………2
Apply threadlocker(screw cement)
Screw
Cement
打螺丝膠水
T08639 5x8.5 CVD Shaft
5x8.5 CVD轴
……………………2
T08603 King Pin Bushing
大王銷軸套
………4
T08933 2.5x16.8 Pin
2.5x16.8 钢针
……………2
T08639 M4x4 Screw
M4x4 螺丝
…………………2
T08673 M4x14 Screw
M4x14 螺丝
……4
Assemble as many times as specified
x2
需组装数量
T08639
T08673 M4x14
L
R
T08665 13x19x4
4
T08603
King Pin Bushing
大王銷軸套
Assemble both Left and Right
L
组装左和右
R
Steering Block-Left
转向臂-左
T08664 8x16x5
T08933
Wheel Hex Hub
六角轮座
Steering Block-Right
转向臂-右
T08933 2.5x16.8
T08639 M4x4
Front Hub Carrie
9
前轮座
Bag-D
T08675 M4x10 Screw
T08607 Front Hub Carrier Bushing
T08673 M4x16 Screw
10
M4x10 螺丝
……………2
前輪座軸套
M4x16 螺丝
Front Suspension
前悬吊系统
………4
……4
Bag-D
T08675 M4x10
L
R
T08673 M3x16
T08607
Front Lower Arm
前下摆臂
T08607
Front Hub Carrier Bushing
前輪座軸套
T08673 M4x16
T08673 M4x16
T08645 4x73 Arm Pin
4x73 擺臂軸
……2
T08674 M3x35 Screw
M3x35 螺丝
T08645 4x73
T08674 M3x35
T08763
Front Arm Mount-F
前摆臂固定座-前
T08827
Front Arm Mount-R
前摆臂固定座-后
T08645 4x73
T08674 M3x16
…………2
T08674 M3x16 Screw
M3x16 螺丝
………2
T08673 M3x16 Screw
M3x16 螺丝
……2
T08673 M3x16
Assemble both Left and Right
L
组装左和右
R
5
Front Shock Tower
11
前避震架
TU0884
Ball stud
球头
Bag-D
TU0884 M3.5
T08674 M3x12
T08674 M3x12 Screw
12
T08760
7.8 Ball End-Front Upper
7.8 球头座-前上
M3x12 螺丝
……4
Front Upper Turnbuckle
前上拉杆
T08757
7.8 Ball stud
7.8 球头
TU0884 M3.5 Nylon Nut
M3.5 尼龍螺母
……………2
Bag-D
5mm
T08778
5x58 Turnbuckle
5x58 拉杆
T08842
Front Shock Tower
前避震架
T08758
7.8 Ball stud
7.8 球头
1:1 x1
1:1 x1
Front Upper-Left
前上-左
▲Projection.Note direction
注意方向
Front Upper-Right
前上-右
Approx.32mm
大约32mm
Approx.32mm
大约32mm
T08778 5x58 Turnbuckle
1:1
5x58 拉杆
Ture-to -scale diagram
圖形比例
T08760
7.8 Ball End-Front Upper
7.8 球头座-前上
Assemble as many times as specified
x1
需组装数量
▲Projection.Note direction
注意方向
T08758 7.8 Ball stud
7.8 球头
………2 ……………2 ……………2
6
T08757 7.8 Ball stud
Apply threadlocker(screw cement)
Screw
Cement
打螺丝膠水
7.8 球头
T08760 7.8 Ball End-Front Upper
7.8 球头座-前上
…………4
Steering Turnbuckle
13
转向拉杆
Bag-D
T08753
6.8 Ball stud
6.8球头
T08754
6.8 Ball stud
6.8球头
5mm
T08776
4x53 Turnbuckle
4x53 拉杆
T08760
6.8 Ball End-Steering
6.8 球头座-转向
1:1 x1
1:1 x1
Steering-Left
转向-左
Steering-Right
转向-右
Approx.27mm
大约27mm
▲Projection.Note direction
注意方向
Approx.27mm
大约27mm
T08760
6.8 Ball End-Steering
6.8 球头座-转向
T08776 4x53 Turnbuckle
14
4x53 拉杆
Front Upper/Steering Turnbuckle
前上/转向拉杆
Front Upper Turnbuckle-Right
前上拉杆-右
………2 ……………2 ……………2
Bag-D
T08753 6.8 Ball stud
6.8球头
T08674 M3x16
Steering Turnbuckle-Right
转向拉杆-右
T08666 M3
▲Projection.Note direction
T08754 6.8 Ball stud
6.8球头
T08676 M3x20 Screw
M3x20 螺丝
T08676 M3x25 Screw
M3x25 螺丝
T08666 M3
注意方向
T08760 6.8 Ball End-Steering
6.8 球头座-转向
……………4
T08674 M3x16 Screw
……2
T08666 M3 Nylon Nut
……2
Front Upper Turnbuckle-Left
前上拉杆-左
M3x16 螺丝
M3尼龙螺母
……………6
T08674 M3x16
……2
T08676 M3x25
Ture-to -scale diagram
1:1
图形比例
T08666 M3
T08676 M3x20
Assemble as many times as specified
x1
需组装数量
7
Steering Turnbuckle-Left
转向拉杆-左
T08676 M3x25
T08666
M3
Front Suspension
15
前悬吊系统
Bag-D
T08674 M3x18
T08674 M4x10
T08674 M3x18
T08829
Front Bumper Plate-Lower
前防撞板-下
Solid Axle Gear Set
16
直轴齿轮组
T08664 8x16x5 Ball Bearing
8x16x5 轴承
………2
T08853/T08867 M5x4 Screw
M5x4 螺丝
……………………4
TG8030 M3x6 Screw
M3x6螺丝
…………………3
T08666 M4
Bag-C
T08674
M4x14
T08674
M4x10
T08867
Screw
Cement
M5x4
Screw
Cement
T08867
M5x4
T08674 M4x14
T08664
8x16x5
T08666 M4 Nylon Nut
M4 尼龙螺母
T08674 M3x18 Screw
T08674 M4x10 Screw
T08674 M4x14 Screw
T08853
Screw
Cement
M5x4
M3x18 螺丝
M4x10 螺丝
M4x14 螺丝
T08853
Center Connecting Cup
中接杯
TG8030 M3x6
T08867
Solid Axle Gear Mount
直轴齿轮座
………………1
……2
…………3
………4
T08853
Screw
Cement
M5x4
T08664
8x16x5
T08853
Center Connecting Cup
中接杯
Apply threadlocker(screw cement)
Screw
Cement
打螺丝胶水
T08868
Solid Axle
直轴
8
T08823
42T Gear
42T齿轮
Solid Axle Gear Set
17
直轴齿轮组
Bag-C
T08673 M3x10 Screw
M3x10 螺丝
…………4
T08865
Center Differential Plate
中央差速器固定板
T08686
Motor Mount
马达固定座
T08673
M3x10
Screw
Cement
T08686
Center Differential Mount-Rear
中央差速器固定座-后
Motor
18
马达
Bag-C
T08686 M3x12 Screw
T08686 M3x14 Screw
T08686 M4x14 Screw
T08686 3x7x0.8 Washer
M3x12螺丝
M3x14螺丝
M4x14 螺丝
3x7x0.8 垫片
……1
……1
………2
T08686 M4x14
X
Motor
马达
T08686
Motor Mount
马达固定座
H396
Screw
Cement
M4x4
H396
Screw
Cement
T08686
3x7x0.8
Tighten the screws with one sheet of paper inserted
between both gears.
两齿轮之间的间隙大约为一张普通纸的厚度。
T08686
Screw
Cement
M3x14
T08686
M3x12
…………………2
H396 M4x4 Screw
M4x4 螺丝
…………………1
Apply threadlocker(screw cement)
Screw
Cement
打螺丝膠水
Must be purchased separately
X
需另购物品
9
Solid Axle Gear Set
19
直轴齿轮组
Bag-C
T08674 M3x8 Screw
M3x8 螺丝
………………2
T08674 M4x10 Screw
M4x10螺丝
……………4
T08681
Motor Mount
马达扶持座
T08674 M4x10
Rear Differential Case
20
后差速箱
Bag-C
T08601
Differential Case
差速箱
T08663
6x13x5
T08636
10T Gear
10T齿轮
Bag-E
Screw
Cement
T08663
6x13x5
T08849
M5x4
T08849
128mm Center Rear CVD
128mm中后CVD
T08674 M3x8
T08304
13.1x15.9x0.2
T08663 6x13x5 Ball Bearing
6x13x5 轴承
………2
T08304 13.1x15.9x0.2 Washer
13.1x15.9x0.2 垫片
…………2
T08673 M3x16
Apply threadlocker(screw cement)
Screw
Cement
打螺丝胶水
T08601
Differential Case
差速箱
10
T08673 M3x16 Screw
M3x16 螺丝
……2
T08849 M5x4 Screw
M5x4 螺丝
………………1
Rear Swaybar
21
后防倾杆
Bag-E
Screw
Cement
T08756
M3x3
T08755
T08760
T08756
T08601/T08756 M3x3 Screw
M3x3 螺丝
……………………4
T08601 M2.5x8 Screw
M2.5x8 螺丝
………………3
T08756 6.8 Ball stud-Swaybar
6.8 球头-防倾杆
…………………2
T08755 6.8 Ball stud-Swaybar
6.8 球头-防倾杆
………………………2
Rear Hub Carrie
22
Screw
Cement
后轮座
T08640
M4x4
TU0802
Wheel Hex Hub
六角轮座
Bag-E
T08601
Swaybar Mount
防倾杆固定座
T08601
M2.5x8
T08601
M3x3
TU0802
2.5x16.8
T08664 8x16x5
T08640
2.5x12.8
T08640
T08665 13x19x4
x2
T08647
Rear Swaybar
后防倾杆
油
Oil
T08640
5x8.5
T08640
94mm Rear CVD
94mm后CVD
L
R
Left Right
T08605
Rear Hub Carriers
后轮座
Rear Hub Carrie
23
后轮座
Bag-E
T08666 M3 Nylon Nut
M3尼龙螺母
………………2
T08675 M4x10 Screw
M4x10 螺丝
……………2
T08605 3.1x9x2.5 Plastic Washer
3.1x9x2.5 垫片
………………4
T08646 3x51.5 Arm Pin
3x51.5 擺臂軸
……………2
T08664 8x16x5 Ball Bearing
8x16x5 轴承
……2
T08605 3.1x9x2.5
T08666 M3
T08646 3x51.5
T08665 13x19x4 Ball Bearing
13x19x4 轴承
……2
T08640 2.5x12.8 Pin
2.5x12.8钢针
……………2
T08640 5x8.5 CVD Shaft
5x8.5 CVD轴
…………………2
TU0802 2.5x16.8 Pin
2.5x16.8 钢针
…………2
T08640 M4x4 Screw
M4x4 螺丝
…………………2
T08675 M4x10
T08608
Rear Lower Arm-Left
后下摆臂-左
L
R
Apply threadlocker(screw cement)
Screw
Cement
打螺丝胶水
Assemble both Left and Right
L
组装左和右
R
11
Assemble as many times as specified
x2
需组装数量
Rear Suspension
24
后悬吊系统
Bag-E
T08608
T08613
Rear Arm Mount-R
T08613
+1 Degree Bushing-Right
+1 度轴套-右
后摆臂固定座-后
T08674 M3x35
T08646 4x77
Rear Shock Tower
25
后避震架
T08674 M3x12
Bag-E
T08666 M4
T08613
0 Degree Bushing
T08613
Rear Arm Mount-F
后摆臂固定座-前
0 度轴套
TU0884 M3.5
T08673 M3x16
T08613
+1 Degree Bushing-Left
+1 度轴套-左
TU0884
Ball stud
球头
T08666 M4 Nylon Nut
M4 尼龙螺母
………………2
T08673 M3x16 Screw
M3x16 螺丝
T08674 M3x12 Screw
M3x12 螺丝
…………2
T08674 M3x35 Screw
M3x35 螺丝
T08646 4x77 Arm Pin
……………2
4x77 擺臂軸
……………2
……2
T08674 M3x12 Screw
M3x12 螺丝
……………4
TU0884 M3.5 Nylon Nut
M3.5 尼龍螺母
…………………2
Apply threadlocker(screw cement)
Screw
Cement
打螺丝胶水
12
T08843
Rear Shock Tower
后避震架
T08674 M3x12
Rear Upper Turnbuckle
26
后上拉杆
Bag-E
T08760
7.8 Ball End-Rear Upper
7.8 球头座-后上
1:1 x1
Rear Upper-Left
后上-左
Approx.14mm
大约14mm
T08760
7.8 Ball End-Rear Upper
7.8 球头座-后上
T08757
7.8 Ball stud
7.8 球头
T08778 5x40 Turnbuckle
27
5x40 拉杆
Rear Upper Turnbuckle
后上拉杆
Bag-E
5mm
T08758
7.8 Ball stud
7.8 球头
T08778
5x40 Turnbuckle
5x40 拉杆
T08760 7.8 Ball End-Rear Upper
………2 ………4 ………………2 ……………2
7.8 球头座-后上
Rear Upper Turnbuckle-Right
后上拉杆-右
1:1 x1
Rear Upper-Right
后上-右
▲Projection.Note direction
注意方向
Approx.14mm
大约14mm
▲Projection.Note direction
注意方向
T08758 7.8 Ball stud
7.8 球头
T08757 7.8 Ball stud
7.8 球头
T08666 M3
T08673
M4x22
T08762
Rear Chassis Stiffener Mount
后支撑杆固定座
T08676 M3x25
T08674 M4x12
T08666
M4
T08619
Rear Chassis Stiffener
后支撑杆
T08666 M3
T08666 M3 Nylon Nut
M3尼龙螺母
T08666 M4 Nylon Nut
M4 尼龙螺母
Rear Upper Turnbuckle-Left
后上拉杆-左
T08676 M3x25
T08676 M3x20
T08666 M3
T08673 M4x22 Screw
M4x22 螺丝
Ture-to -scale diagram
1:1
图形比例
T08674 M4x12 Screw
Assemble as many times as specified
x1
需组装数量
M4x12螺丝
……2
13
………………1……………4
T08676 M3x20 Screw
M3x20 螺丝
T08676 M3x25 Screw
……2
………1
M3x25 螺丝
……2
Rear Suspension
28
后悬吊系统
Bag-E
T08666 M3
T08666 M3 Nylon Nut
M3尼龙螺母
……………1
T08674 M3x10 Screw
M3x10螺丝
………1
T08674 M3x12 Screw
M3x12 螺丝
……1
T08674 M4x14 Screw
M4x14螺丝
…4
Shock
29
避震器
Bag-F
T08627 2.75mm Plastic Washer
2.75mm 塑胶垫片
…………………4
T08627 1mm Plastic Washer
1mm 塑胶垫片
……………………4
T08627 3.3x1.9 O-ring
3.3x1.9 O环
……………………8
T08844/T08625 9x1.0 O-ring
9x1.0 O环
…………………4
T08845 2.7x5.8x0.5 Washer
2.7x5.8x0.5 垫片
……………………4
T08845 M2.5 Nylon Nut
M2.5 尼龍螺母
…………………4
T08622 6.8 Ball stud
6.8 球头
………………………4
T08622 6.8 Ball End
6.8 球头座
T08674 M3x12
T08844/T08625
Shock Bottom cover
避震下盖
T08627
2.75mm Plastic Washer
2.75mm 塑胶垫片
T08627
3.3x1.9 O-ring
3.3x1.9 O环
T08627
1mm Plastic Washer
1mm 塑胶垫片
T08844/T08625
9x1.0 O-ring
9x1.0 O环
T08844
Front Shock Body-Short
前避震筒身-短
T08625
Rear Shock Body-Long
后避震筒身-长
F
R
T08674 M3x10
x2
T08845 M2.5
T08627
Shock Piston
避震活塞
T08845
2.7x5.8x0.5
T08845
Front Shock Shaft-Short
前避震轴-短
Rear Shock Shaft-Long
后避震轴-长
Front-Short
前-短
Rear-Long
后-长
T08622
6.8 Ball End
6.8 球头座
T08622
6.8 Ball stud
6.8 球头
T08674
M4x14
……………4
Assemble both Front and Rear
F
组装前和后
R
Assemble as many times as specified
x2
需组装数量
14
30
Shock
避震器
Bag-F
800#
Front-Short
前-短
Rear-Long
后-长
F
R
T08844/T08625
Shock Top cover
避震上盖
T08622
Diaphragm
气室
Front-Short
前-短
Rear-Long
后-长
x2
T08844/T08625
18.5x1.5
T08844/T08625 18.5x1.5 O-Ring
18.5x1.5 O环
……………4
Front-Short
前-短
Rear-Long
后-长
T08628
Front Shock Spring-Short
前避震弹簧-短
Rear Shock Spring-Long
后避震弹簧-长
T08622
Spring Mount
弹簧固定座
Front Shock
31
前避震器
Bag-F
87005 M3 Flanged Nylon Nut
M3帶邊尼龍螺母
………………2
T08622
Plastic Bushing
塑胶衬套
87005 M3
T08844/T08625
Spring Adjuster
弹簧调节座
T08622 Plastic Bushing
塑胶衬套
………………………2
T08673 M3x18 Screw
M3x18 螺丝
Assemble both Front and Rear
F
组装前和后
R
……2
T08673 M3x18
L
R
Assemble as many times as specified
x2
需组装数量
15
Rear Shock
32
后避震器
Bag-F
87005 M3 Flanged Nylon Nut
M3帶邊尼龍螺母
………………2
87005 M3
T08622
Plastic Bushing
塑胶衬套
T08622 Plastic Bushing
T08673 M3x18 Screw
33
塑胶衬套
………………………2
M3x18 螺丝
Front Bumper
前防撞
Bag-G
T08932
Front Bumper Sponge
前防撞海绵
……2
L
R
T08673 M3x8
T08829
Front Bumper Plate-Upper
前防撞板-上
T08673 M3x18
Assemble both Left and Right
L
组装左和右
R
T08674 M3x10
T08673 M3x8 Screw
M3x8 螺丝
………………1
T08674 M3x10 Screw
M3x10螺丝
………………3
16
Rear Bumper Plate
34
后防撞板
Bag-G
T08666 M4
T08832
Rear Bumper Plate
后防撞板
35
Body Mount
车壳架
Bag-G
T08833
Body Washer
车壳垫
T08863
M2.5x15
T08674 M4x12
T08926
Body Washer
车壳垫
T08666 M2.5
T08833
Body Washer
车壳垫
T08863
M2.5x15
T08674 M4x12 Screw
M4x12螺丝
…………2
T08666 M4 Nylon Nut
M4 尼龙螺母
………………2
T08863 M2.5x15 Screw
M2.5x15螺丝
…………10
T08666 M2.5 Nylon Nut
M2.5 尼龙螺母
………………2
T08863
M2.5x15
T08835
Front Body Mount
前车壳架
T08833
Body Column-Long
车壳柱-长
T08863
M2.5x15
T08835
Rear Body Mount
后车壳架
17
T08833
Body Column-Short
车壳柱-短
T08863
M2.5x15
Front Body Mount
36
前车壳架
Bag-G
T08673 M3x12 Screw
M3x12 螺丝
…………2
T08673
M3x12
Rear Body Mount
37
后车壳架
Bag-G
T08673 M3x12
T08673 M3x12 Screw
M3x12 螺丝
…………2
18
Receiver/Servo
38
接收机/伺服机
T02081 3x7x0.8 Washer
3x7x0.8 垫片
……………………4
T08673 M3x8 Screw
M3x8 螺丝
Bag
……………1
-B
Bag
X
-J
Receiver
接收机
T08674 M3x8
T08614
Receiver Cover
接收机盖
T08673 M3x8
T02087
Antenna Pipe
天线管
T08793 M3x15 Screw
T08674 M3x8 Screw
T08675 M3x5 Screw
39
M3x15 螺丝
M3x8螺丝
……………1
M3x5 螺絲
…………………1
Servo / Receiver
伺服机/接收机
…………4
Bag-B
X
T08793
M3x15
T02081
3x7x0.8
Servo
伺服机
T08675 M3x5
T08614
Receiver Box
接收机盒
T08616
Servo Mount
伺服机座
T08674 M3x10 Screw
M3x10螺絲
……………5
T08674
M3x10
T08674 M3x10
Must be purchased separately
X
需另购物品
19
40
Battery
电池
x2
X
Bag-B
Battery
电池
T08821
Battery Mount
电池固定座
T08821
Velcro Tape
魔鬼粘
Battery
41
电池
T08674 M3x8 Screw
Bag-B
M3x8螺絲
………………8
Must be purchased separately
X
需另购物品
Assemble as many times as specified
x2
需组装数量
T08674 M3x8
20
Electronic speed controller
42
电子变速器
Bag-J
Electronic speed controller
X
电子变速器
T02087
Double-sided tape
双面胶
43
Tyre
轮胎
Bag
-H
x4
T08929
Tyre
轮胎
T08929
Sponge
海棉
T08912
Rim
轮框
Must be purchased separately
X
需另购物品
Assemble as many times as specified
x4
需组装数量
21
44
45
Tyre
轮胎
Tyre
Bag-D Bag-E
轮胎
Glue
胶水
x4
T08913 17mm Hex Nut
17mm 六角螺帽
……4
L
R
Assemble as many times as specified
x2
需组装数量
Assemble both Left and Right
L
组装左和右
R
22
T08913
17mm Hex Nut
17mm 六角螺帽
46
Body
车壳
Bag-I
T08931
Body-Lexan
车壳-PC
Car Light / Wing
47
车灯/尾翼
T08931
Wing
尾翼
T08931
Wing
尾翼
Bag-I
Paint the wing from the
inside using spray colors.
在尾翼内臂喷漆。
23
48
Body
车壳
Bag-J
T08931
Mask sticker
遮盖贴纸
Mask sticker the windows from the inside.
在车窗内臂贴上遮盖贴纸。
49
Body
车壳
Paint the body shell from the inside
using spray colors.
在车壳内臂喷漆。
24
50
Wing
尾翼
Bag-I
T08931 M3
Body
51
T08660 Mid Clip
车壳
Bag-J
中号固定夹
……4
T08660
Mid Clip
中号固定夹
T08931 M3x6
T08931 M3 Nylon Nut
T08931 M3x6 Screw
M3尼龙螺母
………..............…4
M3x6 螺丝
…………………4
T08660
Mid Clip
中号固定夹
25
T08833
T08863
T08821
T08822
T08863
T02087
T08673
T08674
T08674
T08926
T08863
T08646
T08821
T08620
T08759
T08674
T08674
T08760
T08674
T08666
T08766
T08767
T08673
T08650
TG8019
T08759
T08833
T08647
T08634
T08675
T08821
T08609
T08651
T08666
T08835
T08863
T08601
T08664
T08674
T08662
T08674
TU0884
T08601
T08600
T08673
T08822
TU0884
TU0884
T08758
T08633
T08666
T08609
TU0884
T08609
T08760
T08600
T08636
T08663
T08663
T08619
T08674
T08760
T08662
T08676
T08757
T08760
T08666
T08636
T08633
T08666
T08666
T08820
T08674
T08753
T08776
T08674
T08843
T08673
T08777
T08601
T08760
T08754
T08832
T08666
T08666
T08639
T08634
T08664
T08636
T08673
T08767
T08849
T08666
T08828
T08650
T08662
T08605
T08676
T08304
T08865
T08765
T08666
T08674
T08674
TU0802
T08755
T08673
T08756
T08760
T08686
T08664
T08675
T08608
T08853
T08827
T08641
T08670
T08664
T08868
T08853
T08663
T08664
T08634
T08929
T08640
T08646
T08666
T08625
T08823
T02087
T08601
T08663
T08600
T08636
T08304
T08673
T08625
T08622
H396
T08867
T08636
T08633
T08669
T08636
T08912
T08666
T08627
TG8030
T08664
T08686
T08633
T08846
T08845
T08845
T08760
T08666
T08758
T08669
T08673
TU0884
T08842
TU0884
T08686
T08686
T08760
T08778
T08622
T08600
T08625
T08820
T08757
T08634
T08664
T08601
T08645
T08627
T08673
T08673
T08639
T08676
T08674
T08913
T08866
T08603
T08666
T08760
T08645
T08673
T08673
T08666
T08604
T08607
T08755
T08756
T08933
T08664
T08675
T08607
T08639
T08673
T08763
T08647
T08601
T08665
T08622
T08829
TG8003
T08673
T08673
T08627
T08844
T08912
T08844
T08845
T08845
TG8003
T08846
T08666
T08622
T08844
T08829
T08674
T08913
T08929
T08622
T08844
T08627
Explooded View
26
T08863
T08833
T08863
T08835
T08932
T08674
Parts list for GT8LE-RA 1/8 EP 4WD Touring Car-1
GT8LE-RA 1/8电动四驱房车配件包-1
T08823
T08832
Rear Bumper Plate
后防撞板
T08931
42T Gear
42T齿轮
1pcs
Body-Lexan
车壳-PC透明
1pcs
1pcs
T08827
1pcs
Arm Mount Front-R
摆臂固定座前-R
T08828 T08829
Aluminium Buffer Plate-Black
铝缓冲顶板-黑色
T08833 T08835
1pcs
1pcs
Body Mount
车壳架
T08843
Rear Shock Tower
后避震架
2pcs
T08842
Front Shock Tower
前避震架
4pcs
2pcs
4pcs
Body Column Set
车壳柱组
1pcs
Buffer Plate-Plastic
缓冲顶板-塑胶
1pcs
1pcs
1pcs
Front Bumper Plate
前防撞板
T08928
Tyre
轮胎
2pcs
Tyre Sponge
轮胎海绵
T08844
2pcs
Front Shock Body-Short
前避震筒身-短
1pcs
1pcs
2pcs
2pcs
2pcs
2pcs
2pcs
2pcs
T08932
Front Bumper Sponge
前防撞海绵
T08929
Tyre
轮胎
2pcs
Tyre Sponge
轮胎海绵
T08845
4pcs
Front Shock Shaft
前避震轴
Rear Shock Shaft
后避震轴
1pcs
2pcs
4pcs
2pcs
2pcs
T08846
Front Shock Spring
前避震弹簧
Rear Shock Spring
后避震弹簧
2pcs
T08849
M5x4 Screw
M5x4螺丝
128mm Center Rear CVD
128mm中后CVD
1pcs
1pcs
T08853
M5x4 Screw
M5x4螺丝
Connecting Cup
接杯
2pcs
2pcs
2pcs
T08847
Front Shock Absorber
前避震器
T08863
M2.5x15 Cup Head Hex Screw
M2.5x15圆柱头内六角螺丝
8pcs
2Set
T08865
Center Diff Upper Plate
中差顶板
1pcs
T08848
T08866
Chassis
底盘
Rear Shock Absorber
后避震器
1pcs
2Set
T08867
Solid Axle Gear Mount
直轴齿轮座
M5x4 Screw
M5x4螺丝
1pcs
2pcs
T08868
Solid Axle
直轴
1pcs
TU0884
M3
2pcs
Shock Ball Stud
避震球头
2pcs
M3.5
2pcs
TG8003
Side Plate-Left
侧板-左
Side Plate-Right
侧板-右
1pcs
1pcs
TG8016
M5x4 Screw
M5x4 螺丝
87mm Center Front CVD
87mm中前CVD
1pcs
1pcs
TG8019
3x45 Turnbuckle
3x45拉杆
2pcs
Parts list for GT8LE-RA 1/8 EP 4WD Touring Car-2
GT8LE-RA 1/8电动四驱房车配件包-2
TG8030
M3x6 Screw
M3x6螺丝
8pcs
T08600
Differential Housing
差速壳 1pcs
O-ring
1pcs
O环
T08605
Left 1pcs
Rear Hub Carriers
后轮座
Differential Pads
差速垫片 1pcs
Right 1pcs
Washer
垫片
4pcs
H396
16T Pinion Gear
16T马达齿 1pcs
M4x4 Screw
M4x4 螺丝 1pcs
T08686
Center Differential Mount / Motor Mount
中央差速器固定座/马达固定座
M4x14 Screw
M4x14 螺丝
T08601
1pcs
Differential Case
差速箱
1pcs
Swaybar Mount
防倾杆固定座
M2.5x8 3pcs
M3x3 2pcs
T08607 T08608
Left 1pcs
Right 1pcs
4pcs
Front Hub
Front Lower Arm
前下摆臂
Carrier Bushing
前輪座軸套
Rear Lower Arm
后下摆臂
1pcs
1pcs
2pcs
Left 1pcs
Right 1pcs
2pcs
1pcs
T08603
King Pin Bushing
大王銷軸套
1pcs
Front Hub Carriers 12 Degree
前轮座12度
T08616
1mm
2pcs
Transponder Mount
感应器架 1pcs
1.5mm
2pcs
1pcs
4pcs
2mm
2pcs
Servo Mount
伺服机座
1pcs
3pcs
M3x12 Screw
M3x12 螺丝
M3x14 Screw
M3x14 螺丝
3x7x0.8 Washer
3x7x0.8 垫片
T08604
Left 1pcs
Steering Block
转向臂
T08619
Front Chassis Stiffener
前支撑杆
T8 Rear Chassis Stiffener
T8后支撑杆
1pcs
1pcs
2pcs
Right 1pcs
1pcs
1pcs
T08620
1pcs 1pcs 1pcs
1pcs 1pcs 1pcs
Servo Arm
T08622
4pcs
Spring Mount
弹簧固定座
伺服臂
T08633
Diff Shaft
差速轴
2pcs
20T Diff Gear
20T差速齿轮
2pcs
10T Diff Gear
10T差速齿轮
4pcs
4pcs
4.1x12x0.2 Washer
4.1x12x0.2垫片
T08639 T08640
M4x4 Screw
M4x4 螺丝
2pcs
95.5mm Front CVD
95.5mm前CVD
2pcs
M4x4 Screw
M4x4 螺丝
94mm Rear CVD
94mm后CVD
2pcs
2.5x11.5 Pin
2.5x11.5钢针
2pcs
6.1x11x0.2 Washer
6.1x11x0.2垫片
2pcs
2pcs
T08625
2pcs
2pcs
2pcs
2pcs
2pcs
4pcs
6.8 Ball stud
6.8 球头
Ball End
球头座
4pcs
Ball stud
球头
T08634
Front/Rear Diff Connecting Cup
前后差速接杯
2pcs
4pcs
4pcs
2pcs
Rear Shock Body-Long
后避震筒身-长
T08636
10T Gear
10T 齿轮
1pcs
O-ring
1pcs
O环
T08645 T08646 T08647
4x73 Arm Shaft
4x73 摆臂轴
2pcs
3x51.5 Arm Shaft
3x51.5 摆臂轴
4x77 Arm Shaft
4x77 摆臂轴
2pcs
2pcs
T08627
Diaphragm
气室 4pcs
1mm Plastic Washer
1mm 塑胶垫片 4pcs
2.75mm Plastic Washer
2.75mm 塑胶垫片4pcs
3.3x1.9 O-ring
3.3x1.9 O环 8pcs
Shock Piston
避震活塞 4pcs
43T Front/Rear Diff Gear
43T 前/后差速伞齿
1pcs
1pcs
Front/Rear Swaybar
前后防倾杆
M3x12 Screw
M3x12 螺丝
1pcs
4pcs
T08933
Wheel Hex Hub
六角轮座
17mm Hex Nut
17mm六角螺帽
2pcs
2pcs
2.5x16.8 Pin
2.5x16.8销子
2pcs
T08650 T08651
Buffer Screw
1pcs
1pcs
1pcs
Servo Saver Set
缓冲组
2pcs
Steering Rack
转向缓冲转接板
缓冲螺丝
1pcs
2pcs
T08660
Small Clip
小号固定夹
Mid Clip
中号固定夹
8pcs
8pcs
T08662
6x10x3 Ball Bearing
6x10x3 軸承
6pcs
Parts list for GT8LE-RA 1/8 EP 4WD Touring Car-3
GT8LE-RA 1/8电动四驱房车配件包-3
T08663 T08664 T08665
6x13x5 Ball Bearing
6x13x5 軸承
6pcs 6pcs 6pcs
T08667
2.7x5.8x0.5 Washer
2.7x5.8x0.5 垫片
6pcs
8x16x5 Ball Bearing
8x16x5 軸承
T08668
4.1x12x0.2 Washer
4.1x12x0.2 墊片
6pcs
13x19x4 Ball Bearing
13x19x4 軸承
T08669
6.1x11x0.2 Washer
6.1x11x0.2垫片
T08673
M3x5 Screw
M3x5 螺絲
8pcs
M3x6 Screw
M3x6 螺絲
8pcs
M3x8 Screw
M3x8 螺絲
8pcs
M3x10 Screw
M3x10 螺絲
8pcs
M3x12 Screw
M3x12 螺絲
8pcs
M3x16 Screw
M3x16 螺絲
8pcs
M3x18 Screw
M3x18 螺絲
8pcs
12pcs
M3x30 Screw
M3x30 螺絲
8pcs
M3.5x25 Screw
M3.5x25 螺絲
8pcs
T08666
M2.5 Nylon Nut
M2.5 尼龍螺母
M3 Nylon Nut
M3尼龍螺母
T08670
3.5x9x1.0 Washer
3.5x9x1.0 墊片
6pcs
6pcs
6pcs
M4x10 Screw
M4x10 螺絲
8pcs
M4x14 Screw
M4x14 螺絲
M3.5 Nylon Nut
M3.5 尼龍螺母
T08675
8pcs
M4x16 Screw
M4x16 螺絲 8pcs
6pcs
M4 Nylon Nut
M4 尼龍螺母
M3x3 Screw
M3x3 螺絲
M4x4 Screw
M4x4 螺絲
M5x4 Screw
M5x4 螺絲
8pcs
M3x5 Screw
M3x5 螺絲
8pcs
M4x10 Screw
M4x10 螺絲
8pcs
M4x22 Screw
M4x22 螺絲 8pcs
6pcs
8pcs
8pcs
T08674
M2.5x8 Screw
M2.5x8 螺絲
M3x8 Screw
M3x8螺絲
M3x10 Screw
M3x10 螺絲
T08676
M2.5x8 Screw
M2.5x8 螺絲
8pcs
M3x10 Screw
M3x10 螺絲
T08304
13.1x15.9x0.2 Washer
13.1x15.9x0.2 墊片
8pcs
8pcs
8pcs
M2.5x18 Screw
M2.5x18 螺絲
8pcs
8pcs
6pcs
T08750
Buffer Screw
缓冲螺丝
2pcs
M3x12 Screw
M3x12 螺絲
M3x14 Screw
M3x14 螺絲
M3x15 Screw
M3x15 螺絲
M3x12 Screw
M3x12 螺絲
8pcs
M3x14 Screw
M3x14 螺絲
3x7x0.8 Washer
3x7x0.8 墊片
2pcs
8pcs
M3x18 Screw
M3x18 螺絲
8pcs
8pcs
8pcs
8pcs
M3x20 Screw
M3x20 螺絲
M3x25 Screw
M3x25 螺絲
M3x16 Screw
M3x16 螺絲
M3x18 Screw
M3x18 螺絲
8pcs
8pcs
T08751 T08752
Front Hub Carrier Bushing
前輪座軸套
4pcs
M4x16
4pcs
8pcs
8pcs
M3x35 Screw
M3x35 螺絲
T02081
3x7x0.8 Washer
3x7x0.8 墊片
King Pin Bushing
大王銷軸套
4pcs
8pcs
10pcs
M4x14
4pcs
M4x10 Screw
M4x10螺絲
M4x12 Screw
M4x12螺絲
M4x14 Screw
M4x14螺絲
T02087
Double-sided tape
1pcs
双面胶
Antenna pipe
1pcs
天线管
T08753
6.8 Ball Stud-Steering
6.8球头-转向
6pcs
8pcs
8pcs
8pcs
Antenna cover
天线帽
1pcs
T08754
6.8 Ball Stud-Steering
6.8球头-转向
6pcs
T08755
6.8 Ball Stud-Swaybar/Shock
6.8球头-防倾杆/避震器
6pcs
T08756 T08757
M3x3
6pcs
6.8 Ball Stud-Swaybar
6.8球头-防倾杆
6pcs
7.8 Ball Stud-Front/Rear Upper
7.8球头-前/后上
6pcs
T08758
7.8 Ball Stud-Front/Rear Upper
7.8球头-前/后上
6pcs
Parts list for GT8LE-RA 1/8 EP 4WD Touring Car-4
GT8LE-RA 1/8电动四驱房车配件包-4
T08759
5.8 Ball Stud-Steering Servo
5.8球头-转向伺服
6pcs
T08760
6.8 Ball End-Swaybar
6.8 球头座-防倾杆
1pcs
5.8 Ball End-Steering Servo
5.8 球头座-转向伺服
T08765 T08766
Arm Mount Rear-F
摆臂固定座后-F
1pcs
T08770
Shock Absorber Top cover
避震器上盖
4pcs
Arm Mount Rear-R
摆臂固定座后-R
1pcs
T08771
9x1.0 O-ring
9x1.0 O环
4pcs
2pcs
2pcs
18.5x1.5 O-ring
18.5x1.5 O环
4pcs
7.8 Ball End-Rear Upper
7.8 球头座-后上
2pcs
2pcs
6.8 Ball End-Steering
6.8 球头座-转向
7.8 Ball End-Front Upper
7.8 球头座-前上
T08767
1pcs
1pcs
Arm Adjust Set
摆臂调节座组
1pcs
1pcs
2pcs
2pcs
T08772 T08773
CVD Connecting Cup
CVD接杯
2pcs
T08762
1pcs
Rear Chassis Stiffener Mount
后支撑杆固定座
Left 1pcs
Top 1pcs
Bottom
1pcs
T08763
Arm Mount Front-F
摆臂固定座前-F
1pcs
T08768 T08769
Spring Mount
弹簧固定座
Shock Top Ball stud
避震上球头
4pcs
4pcs
Shock Top Mount
避震上固定座
T08774
5x8.5 Shaft
5x8.5轴
2.5x12.8 Pin
2.5x12.8钢针
94mm Drive Shaft
94mm传动轴
2pcs
2pcs
2pcs
5x8.5 Shaft
5x8.5轴
2.5x12.8 Pin
2.5x12.8钢针
95.5mm Drive Shaft
95.5mm传动轴
2pcs
Ball End
球头座
4pcs
2pcs
2pcs
4pcs
T08776 T08777 T08778
4x53 Turnbuckle
4x53拉杆
2pcs
T08786
T08787
T08789
T08790
T08791
T08792
T08793
T08794
T08795
T08797
T08799
T08800
T08801
T08802
T08803
5x40 Turnbuckle
5x40拉杆
2pcs
M2.5 Nylon Nut
M2.5 尼龍螺母
M3.5 Nylon Nut
M3.5 尼龍螺母
M3x6 Button Head Hex Screw
M3x6半圆头内六角螺丝
M3x8 Button Head Hex Screw
M3x8半圆头内六角螺丝
M3x10 Button Head Hex Screw
M3x10半圆头内六角螺丝
M3x12 Button Head Hex Screw
M3x12半圆头内六角螺丝
M3x15 Button Head Hex Screw
M3x15半圆头内六角螺丝
M3x16 Button Head Hex Screw
M3x16半圆头内六角螺丝
M3x18 Button Head Hex Screw
M3x18半圆头内六角螺丝
M3.5x25 Button Head Hex Screw
M3.5x25半圆头内六角螺丝
M4x14 Button Head Hex Screw
M4x14半圆头内六角螺丝
M4x16 Button Head Hex Screw
M4x16半圆头内六角螺丝
M4x22 Button Head Hex Screw
M4x22半圆头内六角螺丝
M2.5x8 Flat Head Hex Screw
M2.5x8平头内六角螺丝
M3x8 Flat Head Hex Screw
M3x8平头内六角螺丝
6pcs
6pcs
8pcs
8pcs
8pcs
8pcs
8pcs
8pcs
8pcs
8pcs
8pcs
8pcs
8pcs
8pcs
8pcs
5x58 Turnbuckle
5x58拉杆
2pcs
T08804
T08805
T08806
T08807
T08808
T08809
T08810
T08811
T08812
T08813
T08814
T08815
T08816
T08819
84002
T08779
3x51.5 Arm Shaft
3x51.5摆臂轴
2pcs
M3x10 Flat Head Hex Screw
M3x10平头内六角螺丝
M3x12 Flat Head Hex Screw
M3x12平头内六角螺丝
M3x14 Flat Head Hex Screw
M3x14平头内六角螺丝
M3x15 Flat Head Hex Screw
M3x15平头内六角螺丝
M3x16 Flat Head Hex Screw
M3x16平头内六角螺丝
M3x18 Flat Head Hex Screw
M3x18平头内六角螺丝
M3x35 Flat Head Hex Screw
M3x35平头内六角螺丝
M4x10 Flat Head Hex Screw
M4x10平头内六角螺丝
M4x12 Flat Head Hex Screw
M4x12平头内六角螺丝
M4x14 Flat Head Hex Screw
M4x14平头内六角螺丝
M3x5 Set Screw
M3x5机米螺丝
M4x10 Set Screw
M4x10机米螺丝
M5x4 Set Screw
M5x4机米螺丝
M3x25 Cap Head Screw
M3x25圆柱头螺丝
M4x4 Set Screw
M4x4机米螺丝
8pcs
8pcs
8pcs
8pcs
8pcs
8pcs
8pcs
8pcs
8pcs
8pcs
8pcs
8pcs
8pcs
8pcs
8pcs
T08780
4x77 Arm Shaft
4x77摆臂轴
2pcs
T08820
1pcs
36mm
1pcs
Motor Mount
马达扶持座
Front Chassis Stiffener
前支撑杆
42mm
T8E Center Differential Plate
T8E中央差速器固定板
1pcs
T08821
Battery Mount
电池固定座
Velcro Tape
魔鬼粘
T08822
Receiver Box
1pcs
接收机盒
1pcs
2pcs
6pcs
Receiver Cover
1pcs
接收机盖
2pcs
1mm
1.5mm
2pcs
2mm
Servo Mount
伺服机座
2pcs
1pcs
Parts list for GT8LE-RA 1/8 EP 4WD Touring Car-5
GT8LE-RA 1/8电动四驱房车配件包-5
83001
T08219
T08220
511129
511190
84001
87004
87006
TU0807
Aluminium Motor Washer 4MM
铝马达垫片4MM
M3x12 Cap Head Screw
M3x12圆柱头螺丝
M3x14 Cap Head Screw
M3x14圆柱头螺丝
M3x18 Cap Head Screw
M3x18
Mid Clip
中号固定夹
Small Clip
小号固定夹
M3x3 Set Screw
M3x3机米螺丝
M3 Nylon Nut
M3尼龙螺母
M4 Nylon Nut
M4尼龙螺母
OPOP
1pcs
圆柱头螺丝
TU0829
1pcs
Front Hub Carriers 14 Degree
前轮座14度
8pcs
8pcs
8pcs
10pcs
10pcs
8pcs
6pcs
6pcs
1pcs
OP
T08637
2.5x16.8 Pin
2.5x16.8销子
4pcs
T08926
2pcs
M2.5x15
2pcs
M2.5
Body Column
加高車殼柱
2pcs
TU0830
1pcs
Front Hub Carriers 12 Degree
前轮座12度
1pcs
OP
T08912
TU0801
Hex Mount +1
六角座+1
TU0831
1pcs
Steering Block
转向座
2pcs
Nut
螺母
1pcs
2pcs
Pin
钢针
2pcs
Rim
轮框
2pcs
OP
OP
T08913
17mm Hex Nut
17mm六角螺帽
TU0802
Hex Mount +2
六角座+2
TU0835
Servo Saver
缓冲座
1pcs
2pcs
4pcs
Nut
螺母
OP
2pcs
Pin
钢针
2pcs
OP
TU0842
Piston 1.2x6-Black
活塞1.2x6-黑色
TU0850
Front Shock Spring-Soft
前避震弹簧-软
TU0861B
M3 Aluminium
Nuts-Blue
M3铝螺母-蓝色
10pcs
M4 Aluminium
Nuts-Blue
M4铝螺母-蓝色
3pcs
2pcs
2pcs
OP
OP
OP
TU0845
4x52 Titan Turnbuckle
4x52钛拉杆
2pcs
TU0852
Rear Shock Spring-Soft
后避震弹簧-软
TU0862R
M3 Aluminium
Nuts-Red
M3铝螺母-红色
10pcs
M4 Aluminium
Nuts-Red
M4铝螺母-红色
3pcs
2pcs
OP
OP
OP
TU0846
5x40 Titan Turnbuckle
5x40钛拉杆
2pcs
TU0854
2pcs
Front Shock Spring-Hard
前避震弹簧-硬
TU0866
Front Sway Bar 2.3
前防倾杆-2.3
1pcs
OP
OP
OP
TU0847
Piston 1.4x6-White
Piston 1.4x6-White
活塞1.4x6-白色
活塞1.4x6-白色
TU0856
Rear Shock Spring-Hard
后避震弹簧-硬
TU0867
Front Sway Bar 2.6
前防倾杆-2.6
1pcs
2pcs
2pcs
OP
OP
OP
TU0848
5x58 Titan Turnbuckle
5x58钛拉杆
2pcs
TU0860G
M3 Aluminium
Nuts-Golden
M3铝螺母-金色
10pcs
3pcs
TU0868
Rear Sway Bar 2.6
后防倾杆-2.6
OP
OP
M4 Aluminium
Nuts-Golden
M4铝螺母-金色
OP
1pcs
TU0869
Rear Sway Bar 3.0
后防倾杆-3.0
1pcs
OP
TU0870
Shock Top Ball stud-Aluminium
避震上球头-铝
OP
4pcs
TU0871
5.8
2pcs
5.8/6.8mm Ball Stud-Aluminium
5.8/6.8球头-转向-铝
6.8
2pcs
OP
6.8
2pcs
TU0872
Front Hub Carriers 12 Degree
前轮座12度
1 set
Steering Block
转向座
OP
TU0874
Front Hub Carriers 14 Degree
前轮座14度
1 set
Steering Block
转向座
OP
Parts list for GT8LE-RA 1/8 EP 4WD Touring Car-6
GT8LE-RA 1/8电动四驱房车配件包-6
TU0875
4pcs
6.8 Swaybar Ball Stud-
6.8防倾杆球头-铝
H395
15T Pinion Gear
15T马达齿 1pcs
M4x4 Screw
M4x4 螺丝 1pcs
OP
Aluminium
OP
TU0876
4pcs
7.8mm Arm Ball Stud-Aluminium
7.8摆臂球头-铝
H397
17T Pinion Gear
17T马达齿 1pcs
OP
4pcs
OP
M4x4 Screw
M4x4 螺丝 1pcs
TU0877
2pcs
Wing Washer
尾翼垫-铝
H398
18T Pinion Gear
18T马达齿 1pcs
M3x12
2pcs
-Aluminium
M4x4 Screw
M4x4 螺丝 1pcs
OP
OP
TU0878
Diff Shaft
差速轴-铝
6pcs
H399
19T Pinion Gear
19T马达齿 1pcs
-Aluminium
M4x4 Screw
M4x4 螺丝
OP
1pcs
TU0879
Servo Saver Shaft-Aluminium
缓冲柱-铝
OP
OP
2pcs
Driver
GT8LE-RA
SETUP SHEET for the TeamC GT8LE-RA
Track Condition
Sandy Soft dirt Grass Hard soil Clay
Front Suspension
3
2
1
1
2
3
Ride height
Smooth Bumpy Low traction Med traction High traction
Shock Mounting&Camber link
Anti-roll bar:
Camber
2
1
mm
mm
°
Track / City
Event
Wet Dry Dusty Other
1
3
5
Date
/
/
Front Shocks
1
2
4
6
Degree
2
3
mm
Spring
°
Oil wt
Piston #
Rear Suspension
3
2
1
1
2
4
5
3
Ride height
Tires
Brand
Compound
Insert
Wheel
Brand
Compound
Insert
Wheel
Note
Shock Mounting&Camber link
Anti-roll bar:
Camber
mm
1
2
2
1
mm
°
2
1
Diff
Brand
Front
Rear
Oil wt
Brand
Oil wt
Brand
Oil wt
Rear Shocks
2
1
1
3
5
Wheelbase
2
2
4
Long
Medium
Short
1
mm
Spring
Oil wt
Piston #
Motor
ESC
Front
Motor
LiPo battery
Center
Rear
Spur
Pinion
Note
www.teamcracing.net
Loading...
