1x10 DVD Duplicator
User’s Manual
Model
DVW-D110H
Safety Precautions
TEAC DVD Duplicator systems are high-precision electronic devices. Do not use them in
any manner other than as specified in this manual. Please read this manual in its entirety
before you begin the installation procedure. Use of controls, adjustments, or performance
of procedures other than those specified herein may result in hazardous radiation exposure.
To prevent fire or shock, do not expose the unit to moisture or rain.
To prevent electrical shock, do not attempt to disassemble the DVD Duplicator system.
Refer servicing to authorized personnel.
TEAC DVD Duplicator drives utilize a laser beam that can be harmful to your eyes. Do not
disassemble the cabinet or unit. Do not attempt to look through the front panel or into the
unit while the power is turned on.
A user who changes or modifies the unit or operating procedures specified herein without
expressed written approval by the manufacturer will void user authority to operate the
equipment.
Specifications and features subject to change without notice or obligation.
Copyright and Trademark Information
© Copyright 2005 TEAC America, Inc. All rights reserved.
TEAC America, Inc. reserves the right to modify product offerings or specifications
without advanced notice. No part of this publication may be reproduced in any format
without the expressed written permission of TEAC America, Inc.
TEAC is a trademark of TEAC Corporation. All other trademarks and registered
trademarks are the property of their respective owners.
Piracy Statement
Copying audio, video, or software without the permission of the copyright holder is illegal.
TEAC accepts no responsibility for copyright infringement or misuse of this equipment. It
is the sole responsibility of the user to ensure that the legal copyrights of the copyright
owners are respected.
TEAC 1x10 DVD Duplicator User’s Manual i
About This Manual
This
TEAC 1x10 DVD Duplicator User’s Manual
Duplicator. It is divided into the following chapters:
Chapter 1: Introduction
This chapter describes the shipping package contents and introduces the TEAC DVD
Duplicator.
Chapter 2: Using the DVD Duplicator
This chapter explains how to set up the DVD Duplicator. It also details its basic copy
operation.
Chapter 3: DVD Duplicator Functions
This chapter explains all available functions of the DVD Duplicator.
Appendix A: List of Functions
Appendix A includes a complete list of all DVD Duplicator functions.
Appendix B: LCD Error Code Definitions
Appendix B lists all messages that may appear on the LCD display.
Appendix C: About DVD and CD Discs
Appendix C contains information about handling, loading, and ejecting discs.
Appendix D: Specifications
Appendix D includes technical specifications for the TEAC DVD Duplicator unit.
Appendix E: Technical Support and Warranty
This appendix explains how to contact technical support at TEAC America, Inc. and
provides Limited Warranty information.
explains how to operate the TEAC DVD
ii TEAC 1x10 DVD Duplicator User’s Manual
Table of Contents
Table of Contents
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i
Copyright and Trademark Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i
Piracy Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i
About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
List of Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
Chapter 1. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
DVD Duplicator Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Chapter 2. Using the DVD Duplicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Basic Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Copying from the Optical (DVD) Source Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Loading Data to and Copying from the Hard Disk Source Drive . . . . . . . . . . . . . . . . . 9
Chapter 3. DVD Duplicator Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Operation Mode Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Copy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Compare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Copy and Compare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Verify . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Erase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Setup Mode Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Automatic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Partition Name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Set as Default . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Update Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
CD Reading Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
CD Writing Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
DVD Reading Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
DVD Writing Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Advanced Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Advanced Mode Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Choose Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Disc Counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Skip Read Err . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
CD Writing Way . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
DVD Writing Way . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Check TRK LEN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Show Disc Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Show System Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Show Exe. Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Auto Exe. Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
TEAC 1x10 DVD Duplicator User’s Manual iii
Table of Contents
Enable Send OPC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Support UPC/ISRC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Region Free Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Partition Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
CD Gigarec Rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Disable LO Change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Boot Delay Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Appendix A. List of Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Operation Mode Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Setup Mode Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Advanced Mode Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Appendix B. LCD Error Code Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Appendix C. About DVD and CD Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Handling Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Loading and Ejecting Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Appendix D. Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Appendix E. Technical Support and Warranty . . . . . . . . . . . . . . . . . . . . . . 24
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
iv TEAC 1x10 DVD Duplicator User’s Manual
List of Figures
Figure 1. DVD Duplicator Unit Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Figure 2. Front Panel of the DVD Duplicator Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Figure 3. LCD Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Figure 4. Rear Panel of the DVD Duplicator Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Figure 5. Test Function on LCD Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Figure 6. How to Handle Compact Discs (DVD and CD) . . . . . . . . . . . . . . . . . . . . . . . . 21
Figure 7. Ejecting the Disc Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
TEAC 1x10 DVD Duplicator User’s Manual v
vi
TEAC 1x10 DVD Duplicator User’s Manual
Chapter 1. Introduction
Thank you for purchasing a TEAC 1x10 DVD Duplicator.
The TEAC 1x10 DVD Duplicator is a stand-alone disc-to-disc DVD Duplicator
system that does not require connection to a computer. It can duplicate a single
master DVD to DVD media at up to 16X speeds, resulting in an exact replica of a
4.7GB disc. It can also duplicate discs to CD-R media.
The TEAC DVD Duplicator is designed to perform DVD copying quickly and
accurately. The DVD Duplicator automatically identifies source DVD formats
and replicates the content as required.
The TEAC DVD Duplicator performs continuous copying with no waiting. It is
an ideal DVD Duplicator for the advanced user who requires speed and accuracy.
You can set up your TEAC DVD Duplicator very quickly and easily. There is no
need to install any software. There is no need to attach any cables to your
computer. The TEAC DVD Duplicator functions entirely as a stand-alone unit.
Caution:
220VAC voltage. Before you turn on the power to the unit, be certain to select
the correct voltage for your region by setting the AC Voltage Selector on the rear
panel. Failure to do so can result in damage to the unit. For more information,
refer page 5.
Your TEAC DVD Duplicator can operate on either 115VAC or
TEAC 1x10 DVD Duplicator User’s Manual 1
DVD Duplicator Package Contents
DVD Duplicator Package Contents
Your TEAC DVD Duplicator package includes the following items (see
Figure 1).
❑
TEAC 1x10 DVD Duplicator unit
❑
AC power cable
❑
TEAC 1x10 DVD Duplicator User’s Manual
1x10 DVD Duplicator
(this manual on CD-ROM)
User’s Manual
(in PDF format on CD-ROM)
AC power cable
Figure 1. DVD Duplicator Unit Package Contents
Note:
If any of the items above is missing from your package upon purchase,
please contact your vendor immediately.
2 TEAC 1x10 DVD Duplicator User’s Manual
Front Panel
Figure 2 illustrates the front panel of the DVD Duplicator unit.
source drive
target drives
LCD control panel
target drives
Front Panel
LED status indicator
stabilizing feet
source drive:
Figure 2. Front Panel of the DVD Duplicator Unit
Insert the disc to be copied into the source drive. Use the disc
power switch
tray to load a DVD into the drive. You can open the tray by pressing the eject
button (if the tray fails to open, you can use the emergency eject mechanism).
You can close the tray by pressing the eject button.
Notes:
❑
TEAC strongly recommends that you do not push the tray in to close it.
Please press the eject button to eject or retract the tray.
❑
The DVD Duplicator includes an internal hard disk drive as an alternate source drive. Please refer to “Loading Data to and Copying from
the Hard Disk Source Drive” on page 9 for detailed information.
TEAC 1x10 DVD Duplicator User’s Manual 3
Front Panel
LCD control panel:
Use the control panel buttons to navigate through the
various functions viewed on the LCD display.
Figure 3. LCD Control Panel
The DVD Duplicator control panel features an LCD display and two buttons.
These buttons are described in the following table:
In Operation mode, press the SET button to scroll up through the functions
or menus.
In Operation mode, press the RUN button to execute the selected function.
target drives:
Insert a blank disc into each target drive to make a copy of the
source disc. You can open the tray by pressing the eject button (if the tray fails
to open, you can use the emergency eject mechanism). You can close the tray
by pressing the eject button.
Note:
TEAC strongly recommends that you do not push the tray in to close
it. Please press the eject button to eject or retract the tray.
LED power indicator:
when the DVD Duplicator power is on
power switch:
Use the power switch to turn the power to the DVD Duplicator
The LED power indicator will be continuously lit
.
unit on and off.
stabilizing feet:
A stabilizing support foot is located at each of the DVD
Duplicator’s lower four corners. When you set up the Duplicator, you should
extend each of these feet outward to provide stable support for the unit.
4 TEAC 1x10 DVD Duplicator User’s Manual
Rear Panel
Figure 4 illustrates the rear panel of the DVD Duplicator unit.
cooling fans
AC voltage selector
AC IN power connector
cooling fans
Rear Panel
Figure 4. Rear Panel of the DVD Duplicator Unit
cooling fans:
AC voltage selector:
Caution:
Ball-bearing fans cool the DVD Duplicator.
Use this switch to select either 115VAC or 220VAC.
Before you turn on the power to the DVD Duplicator, make sure
the correct voltage is selected. Otherwise, you risk damage to the unit. The
default setting is 115VAC.
AC IN power connector:
Connect the included AC power cable to this input
connector. Plug the other end of the power cable into a three-prong receptacle
AC power outlet.
Caution:
Do not attempt to bypass the grounding plug. Otherwise, you risk
electrical shock or damage to the unit.
TEAC 1x10 DVD Duplicator User’s Manual 5
Rear Panel
6 TEAC 1x10 DVD Duplicator User’s Manual
Setup
Chapter 2. Using the DVD Duplicator
This chapter explains how to set up the DVD Duplicator, as well as basic
operation and menu functions.
Setup
1. Select a well-ventilated area for the DVD Duplicator. Carefully remove
the DVD Duplicator unit, AC power cord and user’s manual CD-ROM
from the shipping box.
Note:
Please keep the original box and packaging materials for use in the
event of future storage or transportation of the unit.
2. To ensure that the unit is properly balanced, place the DVD Duplicator
on a flat surface. Extend the Duplicator’s feet outward at each its four
lower corners.
For more information, refer to the section “Front Panel” on page 3.
3. Connect one end of the included power cable to the back of the DVD
Duplicator. Connect the other end of the power cable to a three-prong
receptacle AC outlet.
Caution:
Do not attempt to bypass the grounding plug. Otherwise, you risk
damage to the unit and electrical shock.
4. Turn on the power to the DVD Duplicator by pressing the power button
on the lower right-hand side of the unit.
During initialization, the DVD Duplicator performs a self-test in which the
unit’s internal buffer is tested, source and target drives are detected, and the
LCD display is tested. Once the initialization is complete, the DVD
Duplicator is ready for use.
The LCD initially displays the
Figure 5. Test Function on LCD Panel
TEAC 1x10 DVD Duplicator User’s Manual 7
Test
function by default.
Basic Operation
Basic Operation
This section explains the basic operation of the DVD Duplicator.
Copying from the Optical (DVD) Source Drive
1. Place a source disc in the disc tray of the source drive.
2. Switch to the
function by pressing the SET button.
Copy
3. Place a blank DVD±R disc into as many of the target drives as you
desire, then press the RUN button to start copying.
You do not need to insert a DVD disc into every available target drive. You
can make fewer copies if you prefer. The internal controller will
automatically detect inserted discs and issue the record command to only
those target drives that contain a blank disc.
When the copy operation is complete, the DVD disc in each of the target
drives will be ejected automatically.
Note:
❑
With the default setting, after a source disc has been successfully copied, the
DVD Duplicator automatically ejects the target DVD discs.
❑
With the default setting, if the copy operation fails, the failed target DVD disc
remains in the target drive. To remove the failed DVD disc, press the eject
button on the target drive and retrieve the disc. Press the eject button again
to retract the disc tray.
8 TEAC 1x10 DVD Duplicator User’s Manual
Loading Data to and Copying from the Hard Disk Source Drive
Loading Data to and Copying from the Hard Disk Source Drive
During initialization (see Step 4 on page 7), the DVD Duplicator performs a selftest to detect source drives. The DVD-ROM drive and hard disk drive will be
detected as available source drives. The DVD-ROM drive is the default source
drive.
The internal hard disk drive was formatted and partitioned at the factory. Each
partition occupies 9GB of hard disk space. Partitions are arranged in numerical
order starting with partition 00000, and initially contain no data. A set of data
loaded into a partition on the hard disk drive is called an “image file.”
To use the hard disk drive as the source drive, you must first load an image file
from a DVD into a partition on the hard disk drive, select the partition that
contains the data you want to copy, then execute the copy function.
1. Insert a source DVD into the DVD-ROM drive.
This disc contains the data that you wish to copy to the partition on the
internal hard disk drive.
2. Press the SET button to select the
Load
function, then press the RUN
button to execute the function.
The data will be loaded into the default first partition (00000).
After a few moments, the source disc will be ejected, signaling the
completion of the data load procedure.
3. Remove the source disc from the DVD-ROM drive.
Note:
If you need to load additional data from various sources, change to
another partition first (e.g., 00001) using the
mode, then repeat steps 1 and 2 above.
Setup
Partition Name
function in
4. Once the data has been copied to the hard disk drive, insert a blank disc
into as many of the target drives as you desire.
5. Using the SET button, change to the
Copy
function, then press RUN to
copy from the hard disk drive to the discs.
The discs will be ejected when the copying process is complete.
6. Remove the copied discs from the Duplicator.
You can repeat this procedure from Step 4 if desired.
TEAC 1x10 DVD Duplicator User’s Manual 9
Loading Data to and Copying from the Hard Disk Source Drive
10 TEAC 1x10 DVD Duplicator User’s Manual
Chapter 3. DVD Duplicator Functions
The DVD Duplicator features three (3) modes of operation:
Operation Mode Functions
❑
❑
❑
Operation
Setup
Advanced
mode
mode
mode
Operation Mode Functions
Operation
Test
The
after the test is complete. This function is recommended if you are using
unsupported media. This function enables the target drive to adjust the laser to the
proper intensity. The source drive, which is determined by the setting on the
Duplicator controller, can be either the DVD-ROM drive or the hard disk drive.
Copy
The
on the internal hard disk drive. For more information, refer to “Basic Operation”
on page 8.
Compare
mode includes seven (7) functions. Each function is explained below.
Test
function simulates writing to the target disc. The discs will remain blank
Copy
function enables you to copy data from the source DVD or a partition
The
Compare
function compares data on the source and target discs after the copy
process is complete.
Copy and Compare
The
Compare
function follows immediately as soon as the
Copy
function is
completed.
Verify
Verify
The
function verifies that the target disc was written completely and with
no errors.
TEAC 1x10 DVD Duplicator User’s Manual 11
Erase
Erase
The
Erase
function erases the data from /RW media. The default setting performs
Quick Erase
a
when you press the RUN button.
You can also press and hold the RUN button for three (3) seconds to perform a
Full Erase
. The
Full Erase
requires more time than the
Quick Erase
.
Load
The factory-installed hard disk drive was partitioned and formatted at the factory.
Each partition is approximately 9GB in size.
The Load function enables you to transfer data from the DVD-ROM or DVD
Writer drive to the current partition on the hard disk drive.
If you are loading various sources to the hard disk drive, change the Partition
Name
to specify a new partition after the Load function is completed. This will
prevent you from overwriting data that has already been loaded into the previous
partition.
12 TEAC 1x10 DVD Duplicator User’s Manual
Setup Mode Functions
Setup Mode Functions
The Setup mode includes nine (9) functions. To enter the Setup mode, press and
hold the SET button until you hear a beep. The LCD will then display SETUP.
Press the SET button to scroll through the available functions. To exit the Setup
mode, press and hold the SET button until you hear a beep. Each function is
explained below.
Automatic
This function is for factory use only.
Partition Name
The Partition Name function enables you to setup the ID and partition number of
the hard disk drive.
The first two (2) digits are the ID number of the hard disk drive. This ID can range
from 00 to 99. The remaining three (3) digits represent the position of the partition.
The default setting is 00000.
Set as Default
This function allows you to set any changes or modification you have made as
your default settings.
Update Firmware
The Update Firmware function updates the firmware on the interface board via a
CD or DVD disc. The DVD Duplicator will locate the data and update its
firmware automatically.
During the update, do not turn off the power to the unit. Once the update is
complete, the LCD will display a message and all arguments will return to the
default setting. Please restart the system to complete the firmware update
procedure.
CD Reading Speed
The CD Reading Speed function controls the speed at which the source drive
reads a CD-ROM.
The default setting is MX (maximum) read speed.
❑ RUN: Modify parameter.
❑ SET: Save and quit.
TEAC 1x10 DVD Duplicator User’s Manual 13
CD Writing Speed
CD Writing Speed
The CD Writing Speed function controls the speed at which the source drive writes
to a CD-R disc.
The default setting is MX (maximum) write speed.
❑ RUN: Modify parameter.
❑ SET: Save and quit.
DVD Reading Speed
The DVD Reading Speed function controls the speed at which the source drive
reads a DVD disc.
The default setting is MX (maximum) read speed.
The MID is set according to the highest speed supported by the blank disc.
❑ RUN: Modify parameter.
❑ SET: Save and quit.
DVD Writing Speed
The DVD Writing Speed function controls the speed at which the source drive
writes to a DVD disc.
The default setting is MX (maximum) write speed.
The MID is set according to the highest speed supported by the blank disc.
❑ RUN: Modify parameter.
❑ SET: Save and quit.
Advanced Setup
The Advanced Setup function lets you access Advanced mode.
❑ To enter
Advanced mode, press the RUN button when Advanced Setup is
displayed on the LCD.
❑ To exit the
Advanced mode, press and hold the SET button until you hear a
beep.
14 TEAC 1x10 DVD Duplicator User’s Manual
Advanced Mode Functions
Advanced Mode Functions
The Advanced Operation mode includes 17 functions. Each function is explained
below.
Choose Source
The Choose Source function enables you to change the device code of the source
drive. The default setting is A, which indicates that the system will automatically
choose the source drive.
❑ RUN: Modify parameter.
❑ SET: Save and quit.
Disc Counter
The Disc Counter function keeps track of the number of discs copied during autooperation mode. The default setting is M, which indicates Manual operation mode.
❑ A: controller in Auto-operation mode determines the number of target discs
copied.
❑ RUN: Modify parameter.
❑ SET: Save and quit.
Skip Read Err
The Skip Read Err function enables you to control read errors from the source
drive. The default setting is No, which indicates that the system will stop when the
source drive encounters a read error and will reject the source disc.
❑ No: The source drive will instantly reject the source disc upon detection of a
read error.
❑ SHORT: The system skips read errors by sectors of 2kb.
❑ MED: The system skips read errors by sectors of 100KB.
LONG: The system skips read errors by sectors of a few MB.
❑
❑
SKIPA: The system skips the reading of a track upon detection of a read
error.
TEAC 1x10 DVD Duplicator User’s Manual 15
CD Writing Way
CD Writing Way
The CD Writing Way function enables you to select from the three writing methods
for CD-R media. The default setting is DAO.
❑ DAO: Disc at once
❑ TAO: Track at once
❑ RAW: This is only used when the writer supports RAW writing.
❑ RUN: Modify parameter.
❑ SET: Save and quit.
DVD Writing Way
The DVD Writing Way function enables you to select from the two writing methods
for CD-R media. The default setting is DAO.
❑ DAO: Disc at once
❑ INC: Improves readability in older DVD players.
❑ RUN: Modify parameter.
❑ SET: Save and quit.
Check TRK LEN
The Check TRK LEN function provides various methods for the detection of bad
sectors. Default setting is SHORT.
❑ NO: Read as GAP = 0.
❑ AUTO: Read the standard GAP
❑ SHORT: Read the short GAP.
❑ LONG: Read the long GAP.
Show Disc Info
The Show Disc Info function provides information about the disc in the source or
writer drive.
❑ For CDs: The ATAPI code is typically displayed.
❑ For DVDs: The manufacturer code is displayed.
Show System Info
The Show System Info function enables you to display information about the
controller, source, and target drives.
16 TEAC 1x10 DVD Duplicator User’s Manual
Show Exe. Time
Show Exe. Time
The Show Exe Time function enables you to find out how long a function’s
execution time takes. The default setting is Disable.
❑ RUN: Enable or disable.
❑ SET: Save or quit.
Auto Exe. Time
The Auto Exe. Time function enables you to set the time allocated for drives to
detect blank discs. The default setting is 60 seconds.
❑ RUN: Modify parameter.
❑ SET: Save and quit.
Enable Send OPC
The Enable Send OPC function enables the system to make adjustments to
achieve optimum laser power. OPC (Optical Proximity Correction) enables the
system to determine the best laser power range for a disc. The default setting is
Enable.
❑ RUN: Enable or disable.
❑ SET: Save and quit.
Support UPC/ISRC
The Support UPC/ISRC function copies the UPC code of music CDs and the ISRC
code of individual tracks. The copy of the ISRC code includes the country of
manufacture, owner, date, and serial number of each track, etc. The default setting
is Disable.
RUN: Enable or disable.
❑
❑
SET: Save and quit.
Region Free Set
The Region Free Set function enables you to remove the DVD movie region
restriction on non-CSS discs. This function cannot be executed on discs that are
copy-protected. The DVD Duplicator will not duplicate copy-protected discs. The
default setting is Disable.
❑
RUN: Enable or disable.
❑ SET: Save and quit.
TEAC 1x10 DVD Duplicator User’s Manual 17
Partition Size
Partition Size
The Partition Size function enables you to assign different partition sizes to the
internal hard disk drive depending on requirements. The default setting is 9GB.
Please note that any data that is already present on the partitions will be erased.
You will need to reload the data onto the partitions as needed.
❑ RUN: Modify parameter
❑ SET: Save and quit
CD Gigarec Rate
This function is not supported by the DVD Duplicator.
Disable LO Change
The Disable LO Change function enables you to change the DL writing method.
This function makes it more efficient and quicker to backup an 8.5GB DL disc.
The default setting is Enable.
❑ RUN: Enable or disable.
❑ SET: Save and quit.
Boot Delay Time
This function is reserved for factory use only.
18 TEAC 1x10 DVD Duplicator User’s Manual
Appendix A. List of Functions
Operation Mode Functions
❑ Test
❑ Copy
❑ Compare
❑ Copy and Compare
❑ Verify
❑ Erase
❑ Load
Setup Mode Functions
❑ Automatic
❑ Partition Name
❑ Set as Default
❑ Update Firmware
❑ CD Reading Speed
❑ CD Writing Speed
❑ DVD Reading Speed
❑ DVD Writing Speed
❑ Advanced Setup
Advanced Mode Functions
❑ Choose Source
❑ Disc Counter
❑ Skip Read Err
❑ CD Writing Way
❑ DVD Writing Way
❑ Check TRK LEN
❑ Show Disc Info
❑ Show System Info
❑ Show Exe. Time
❑ Auto Exe. Time
❑ Enable Send OPC
❑ Support UPC/ISRC
❑ Region Free Set
❑ Partition Size
❑ CD Gigarec Rate.
❑ Disable LO Change
❑ Boot Delay Time
TEAC 1x10 DVD Duplicator User’s Manual 19
Appendix B. LCD Error Code Definitions
Error Code Definition
SET_SPEED_ERROR ‘S’ Incorrect speed setting
READ_ERROR ‘r’ Reading error
WRITE_ERROR ‘w’ Writing error
READ_DMA_ERROR ‘R’ DMA reading error
WRITE_DMA_ERROR ‘W’ DMA writing error
CUE-SHEET_ERROR ‘U’ Error while writing cue-sheet
ERASE_ERROR ‘E’ Erasing error
FORMAT_ERROR ‘F’ Formatting error
COMPARE_ERROR ‘C’ Comparison error
SYNCHRONIZE_ERROR ‘Z’ Synchronized writing error
CLOSE_ERROR ‘O’ Error while trying to close disc
TERMINATE_ERROR ‘T’ Data interrupt
BLANKMED_ERROR ‘B’ Disk type error between source and target
ATIPCODE_ERROR ‘A’ Blank disc cannot be recognized
MCODE_ERROR ‘M’ Only supports Ritek medium
READDISCINF_ERROR ‘D’ Disc closing incomplete
TARGNOTEMPTY_ERROR ‘N’ Non-blank medium
PLUSRTEST_ERROR ‘P’ Performing test function with +R medium
UNKNOW_ERROR ‘K’ Other error
READDISCINF_ERROR ‘D’ Medium format error
CDDVDDISC_ERROR ‘J’ Medium error
HD_READ_ERROR ‘G’ Hard disk read error
HD_WRITE_ERROR ‘H’ Hard disk write error
REV_TRACK_ERROR ‘I’ DVD-R medium capacity error
20 TEAC 1x10 DVD Duplicator User’s Manual
Appendix C. About DVD and CD Discs
This appendix explains how to handle, load, and eject DVD and CD discs.
Handling Discs
❑ Handle compact discs only by their edges to avoid getting fingerprints on the
surface. Do not touch the disc’s data surface (unlabeled side).
❑ Do not place discs in direct sunlight or in locations subject to high humidity,
high temperatures, or dusty conditions.
❑ If it becomes necessary to clean a disc due to erratic operation, visible dust,
or smudges, gently wipe the surface of the disc from the center to the outside
edge. Do not use benzene, alcohol, thinner, or other solvents.
wipe disc surface from
center to outside edge
Figure 6. How to Handle Compact Discs (DVD and CD)
handle discs
by their edges
TEAC 1x10 DVD Duplicator User’s Manual 21
Loading and Ejecting Discs
Loading and Ejecting Discs
To load a disc into the source or a target drive, first open the disc tray by pressing
the Eject button on the front of the drive. Place the disc on the disc tray with its
label side facing up. Then press the Eject button again to retract the disc tray back
into the drive.
To eject a disc from the source or a target drive, press the Eject button on the front
of the drive to extend the disc tray. Remove the disc from the disc tray and place
it in its protective case. Then press the Eject button again to retract the disc tray
back into the drive.
Press the Eject button
to extend and retract
the disc tray.
Figure 7. Ejecting the Disc Tray
22 TEAC 1x10 DVD Duplicator User’s Manual
Loading and Ejecting Discs
Appendix D. Specifications
The following table lists the product specifications for the TEAC DVD Duplicator.
Model DVW-D110H
HDD Capacity 160GB
Weight 50 lbs.
Dimensions (HxWxD) 25" x 7.5" x 16.5"
DVD Recorders TEAC 16X DVD-RW
Drive Interface IDE / ATAPI
Read Speed DVD: 16x; CD: 48x
Write Speed DVD: 16x; DVD+DL: 4x; CD: 48x
Drive Buffer Size 2MB
System Buffer Size 128MB
Supported Discs DVD+R, DVD+RW, DVD+DL, DVD-R, DVD-RW, CD-R, and
CD-RW discs
System Control SET and RUN buttons
System Display LCD panel; LED indicator
Write Method Auto Detect (DAO, TAO)
Operation Modes Test, Copy, Compare, Copy & Compare, Verify, Erase, Load
Firmware Upgrade Via CD-ROM/DVD-ROM
Power Supply AC Input: 115 - 220V
TEAC 1x10 DVD Duplicator User’s Manual 23
Limited Warranty
Appendix E. Technical Support and Warranty
For technical support, please contact the TEAC America Support Center
TEAC America, Inc. (USA)
Technical Support
Telephone: (323) 727-4860 • Fax: (323) 869-8751
Monday - Friday 8:00 a.m. - 5:00 pm PST
http://www.teac.com/DSPD/techsupport-America.htm
E-mail: dspdtsg@teac.com
Limited Warranty
This product is warranted by TEAC America, Inc. against defects in materials and workmanship.
LENGTH OF WARRANTY – This warranty will be effective for both labor and parts, and this
warranty will be effective for one (1) year from the date of original purchase.
WHO MAY ENFORCE THE WARRANTY - This warranty is valid only in the United States, and
enforceable only by the original purchaser. This warranty is not valid outside the United States.
WHAT IS NOT COVERED BY THIS WARRANTY
1. Damage to or deterioration of the external cabinet.
2. Damage resulting from accident, misuse, abuse, or neglect.
3. Damage resulting from failure to follow instructions contained in your user’s manual.
4. Damage occurring during shipment of the product (claims must be presented to the carrier).
5. Damage resulting from repair or attempted repair by anyone other than TEAC Service Department.
6. Damage resulting from modification or attempted modification of product not authorized by
TEAC.
7. Damage resulting from causes other than product defects, including lack of technical skill,
competence, or experience of the user.
8. Damage to any unit that has been altered or on which the serial number has been defaced, modified
or removed.
9. Damage or malfunction resulting from installation and cabling.
10. For wireless configurations, TEAC cannot be responsible for interference or operation in locations
that restrict range.
11. Damage to or from interconnected network equipment.
12. Data integrity or loss of data.
HOW YOU CAN GET WARRANTY SERVICE – Please contact the TEAC service department for a Return
Authorization number before shipping unit(s) to TEAC. Information required for R/A request should
include your name and/or company name, telephone number, TEAC model, version and serial
number(s). Return Authorization (R/A) number must be clearly marked on the outside of each carton
shipped to TEAC. Return merchandise must be packed in original shipping containers or otherwise
packed adequately to prevent damage in shipment. You are responsible for all risk of damage to or loss
of merchandise in transit to TEAC. TEAC reserves the right to reject any merchandise that is not
packaged and/or marked as instructed herein. You must pay any shipping charges if it is necessary to
ship the product for service. However, if the necessary repairs are covered by the warranty, we will
pay the return shipping charges to any destination within the United States. Whenever warranty service
is required, you must present a copy of the original dated sales receipt as proof of warranty coverage.
Please contact us at the addresses listed at the end of this warranty statement.
WHAT TEAC WILL PAY FOR – We will pay all labor and material expenses for items covered by the
warranty. Payment of shipping charges is discussed in the next section of this warranty.
LIMITATION OF IMPLIED WARRANTIES
ANY IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE LENGTH
OF THIS WARRANTY.
24 TEAC 1x10 DVD Duplicator User’s Manual
Limited Warranty
EXCLUSION OF DAMAGES
TEAC’S LIABILITY FOR ANY DEFECTIVE PRODUCT IS LIMITED TO REPAIR OR
REPLACEMENT OF THE PRODUCT, AT TEAC’S OPTION. TEAC SHALL NOT BE LIABLE
FOR DAMAGES BASED UPON INCONVENIENCE, LOSS OF USE OF THE PRODUCT, LOSS
OF TIME, INTERRUPTED OPERATION OR COMMERCIAL LOSS, LOST PROFITS OR ANY
OTHER DAMAGES, WHETHER INCIDENTAL, CONSEQUENTIAL, PUNITIVE OR
OTHERWISE.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS AND/ OR DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS AND EXCLUSIONS MAY
NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC RIGHTS, AND MAY VARY FROM SOME OF THE
RIGHTS PROVIDED BY LAW. THESE RIGHTS MAY VARY FROM STATE TO STATE.
To contact the TEAC Service Center in the United States:
Tel: 1-323-727-7694 or 1-323-727-7616
Fax: 1-323-727-7606
E-mail:
dssvce@teac.com
TEAC America, Inc.
7733 Telegraph Road
Montebello, California 90640
TEAC 1x10 DVD Duplicator User’s Manual 25
Limited Warranty
26 TEAC 1x10 DVD Duplicator User’s Manual
Loading...
