TANDBERG MCU 8420, MSE 8420 User Manual

Codian MCU
MSE 8420
Getting started
Codian MCU
MSE 8420
Getting started
Copyright © Codian 2008. All rights reserved. This Getting Started Guide may not be copied, photocopied, translated, reproduced, or converted into any electronic or machine-readable form in whole or in part without prior written approval of Codian Limited.
Codian Limited provides this documentation without warranty, term, or condition of any kind, either implied or expressed, including, but not limited to, the implied warranties, terms or conditions of merchantability, satisfactory quality, and fitness for a particular purpose. Codian Limited may make improvements or changes to the product(s) and/or the program(s) described in this documentation at any time.
All other product and company names herein may be trademarks of their respective owners. 61-0007-03 rev 01
TANDBERG Philip Pedersens vei 20 1366 Lysaker Norway Telephone: +47 67 125 125 Telefax: +47 67 125 234 Video: +47 67 117 777 E-mail: tandberg@tandberg.com www.tandberg.com

Table of contents

General information ................................................................................................................ 1
About the MSE 8420 Media blade ........................................................................ 1
Port and LED location ................................................................................................ 1
LED behavior ..............................................................................................................................2
Installing the Media blade .....................................................................................................4
Step one: Install the Media blade into the MSE 8000 chassis ..................... 4
Step two: Connect to Ethernet Port A ................................................................. 6
Initial configuration ................................................................................................................. 7
Step one: Configure Ethernet Port A settings .................................................. 7
Step two: Assign an IP address to the Media blade ........................................ 7
Configuring the Media blade ............................................................................................... 8
Step one: Log in to the Media blade .................................................................... 8
Step two: Using an H.323 gatekeeper or SIP registrar (optional) ..............8
Step three: Add endpoints (optional) .................................................................. 9
Using the Media blade ..........................................................................................................10
Creating conferences ..............................................................................................10
Calling participants in to a conference .............................................................11
Calling in to a conference ......................................................................................11
Streaming conferences ...........................................................................................12
Instructing conference participants ................................................................................13
Checking for updates ............................................................................................................13
Troubleshooting and technical support information ...............................................14
Using the event log to help solve a problem ..................................................14
Getting more help ....................................................................................................14

General information

General information

About the MSE 8420 Media blade

The MSE 8420 Media blade is a technologically advanced Multipoint Control Unit that fits into an MSE 8000 chassis. It is designed to provide high quality voice and video conferencing.

Port and LED location

Figure 1 shows the position of ports and LEDs on the Media blade.

Figure 1: Media blade front panel

Compact Flash Activity LED
Console
Console Port
Status LED
Link LED
Alarm LED
System Load LEDs
Ethernet Ports
Power LED
Ethernet Port Status LEDs
1

LED behavior

Table 1 describes the behavior of the LEDs.

Table 1: Media blade LED behavior

LED Color Indicates
Compact Flash Activity Flashing
green
One of:
the Media blade is bootinga configuration change has been madethe configuration is being transferred
by FTP
Console Link Green A PC is connected to the console port
Status Green The Media blade is operating normally
Alarm Red The Media blade is booting or has
developed a fault, for example:
temperature is outside normal limitsbattery failure of the internal clock
Refer to the web interface for more information about the problem (go to
Status > Health)
System Load Green The Media blade is processing conference
data. The LEDs represent the media processing load of the Media blade. The column numbered 1 represents audio load. The other columns represent video DSP load. Media processing load is also displayed in the web interface: go to
Status > General
2
LED behavior
Table 1: Media blade LED behavior (continued)
LED Color Indicates
Ethernet Port Status, for each Ethernet port :
FDX Green The link has been negotiated as a full-
duplex link
Act Green Packets are being transmitted on this port
Link Green The speed of the link from this port,
which is either 10, 100, or 1000 Mbps
Power Blue The Media blade is receiving power from
the MSE 8000 chassis
3

Installing the Media blade

Important: Before installing the Media blade into the MSE 8000, you must read the safety information for the MSE 8000 chassis at: http://www.codian.com/safety.htm
Although blades are hot-swappable parts, you must only remove one
!
blade at any time. Remove the power from the MSE 8000, if you need to remove more than one blade at a time.
Before hot-swapping a blade, shut down the blade using the web interface.
!
Do not shut down a blade during a software upgrade or if the blade is processing (for example if a conference is taking place on a Media blade).
For information about powering the MSE 8000, refer to the Getting Started Guide that accompanied the chassis.

Step one: Install the Media blade into the MSE 8000 chassis

You must install either a blade or a blanking blade in each of the ten
!
positions in the chassis.
The Supervisor blade must be installed into slot 1 of the MSE 8000
!
chassis.
1 Remove the blade or blanking blade from the slot into which you are going to
install the Media blade: i Using a No.1 Phillips screwdriver, loosen the screws in the retaining latches
with an anti-clockwise quarter turn.
ii Open both retaining latches on the front of the blade or blanking blade.
When open, a retaining latch is at a 90 the blade.
iii Slide out the blade or blanking blade.
2 Open both retaining latches on the front of the Media blade. When open, a
retaining latch is at a 90 3 Slide the Media blade into the blade slot (as shown in Figure 2) until it stops. 4 Simultaneously close both retaining latches on the blade (thereby engaging the
connectors at the rear of the blade) to secure in the chassis as shown in Figure 3.
4
° angle perpendicular to the front of the blade.
° angle perpendicular to the front of
Installing the Media blade
5 Using a No.1 Phillips screwdriver, tighten the screws in the retaining latches
with a clockwise quarter turn.
Figure 2: Inserting a blade into the chassis
Figure 3: Closing the retaining latches on the front of a blade
5

Step two: Connect to Ethernet Port A

Connect an Ethernet cable from Ethernet Port A to an Ethernet switch (rather than a hub, to minimize interference from other devices on the network). The Ethernet port is a 10/100/1000 Mbps auto-sensing connection.
Only connect to Ethernet Port B if you need to connect the Media blade
i
to a second subnet.
Do not connect Ethernet Port A and Ethernet Port B to the same subnet.
!
6

Initial configuration

Initial configuration

Step one: Configure Ethernet Port A settings

The default setting for the Media blade Ethernet ports is auto-sensing mode. If the switch ports to which you connect the Media blade are not also set to auto-sensing mode, then you need to configure the Media blade Ethernet ports to use the same speed and duplex mode.
Only connect to Ethernet Port B if you need to connect the Media blade
i
to a second subnet.
Both ends of the Ethernet connection must be configured in the same
i
way. For example, either configure both ends of the link to be auto­sensing or configure both ends to operate at the same speed and duplex.
To establish a 1000Mbps connection, both ends of the link must be
i
configured as auto-sensing.
To configure Ethernet Port A, log in to the Supervisor’s web interface and go to
Hardware > Blades. For more information about configuring the port, refer to the
online help accessible from the Supervisor’s web interface.

Step two: Assign an IP address to the Media blade

You can use the Supervisor’s web interface to configure the IP addresses of all blades installed in the MSE 8000. Note that all blades are supplied with DHCP enabled. You can either keep this setting or assign static IP addresses to a blade from the Supervisor’s web interface. To view or configure the IP address of the Media blade, log in to the Supervisor and go to the Media blade, go to
Hardware > Blades and click the IP address of that blade.
Hardware > Blades. To access the web interface of
7

Configuring the Media blade

Step one: Log in to the Media blade

All administration of the Media blade is performed via the web interface.
To log in to the web interface of the Media blade:

1 Log in to the Supervisor’s web interface. 2Go to 3Click

Step two: Using an H.323 gatekeeper or SIP registrar (optional)

If you have H.323 endpoints, using an H.323 gatekeeper can make it easier for participants to call in to a conference. You can configure the Media blade to use an external gatekeeper or its own built-in gatekeeper. For information about using the built-in gatekeeper, refer to the online help.
If you have SIP endpoints, using a SIP registrar can make it easier for participants to call in to a conference.
To configure the Media blade to use an H.323 gatekeeper:
1 In the web interface of the Media blade, go to 2Enable
3Click
To configure the Media blade to use a SIP registrar:
Hardware > Blades and click the IP address of the Media blade.
Log in, and then click Change log in and enter the user name admin with
no password.
Codian recommends that you change the admin account to use a
i
password as soon as possible. To do that, go to
Users, click the admin
link, and provide the required user information.
Settings > Gatekeeper.
H.323 gatekeeper usage and configure the settings you require, using
the online help for further assistance.
Apply changes.
1 In the web interface, go to
Settings > SIP.
2 Configure the settings you require, using the online help for further assistance. 3Click
Apply changes.
Before you configure the Media blade to use, and register conferences to,
i
a SIP registrar, you must set up the Media blade and its conferences on that SIP registrar.
8
Configuring the Media blade

Step three: Add endpoints (optional)

One way to add participants to a conference that you create is to have the Media blade automatically call them when the conference starts. To do this, you configure their endpoints on the Media blade. When you set up a conference, you can choose the endpoints from the each endpoint’s details every time. Participants that are pre-configured for a conference will automatically be called by the Media blade to join that conference.
To define pre-configured endpoints:
1 In the web interface of the Media blade, go to
To add a H.323 endpoint, click Add H.323
To add a SIP endpoint, click Add SIP
To add a VNC screen, click Add VNC
2 Configure the endpoint settings you require, using the online help for further
assistance. 3Click
Add endpoint.
Pre-configured participants list. This is easier than entering
Endpoints:
9

Using the Media blade

Creating conferences

To create a conference:
1 In the web interface of the Media blade, go to
conference
2Type a
.
Name for the conference, for example SalesMeeting.
3 Type an optional numeric identifier, for example
telephone number that participants can use to join the conference when calling
in to the Media blade via a gatekeeper or SIP registrar.
There are two types of conference participant: chairperson and guest.
i
IDs and PINs allow participants to connect to conferences as the correct participant type. Chairperson participants use the Numeric ID and optionally, the PIN; guest participants use the Guest numeric ID and optionally, the Guest PIN. For more information, refer to the online help.
Conferences and click Add new
123. This will be the
4 If you are using a gatekeeper, check
registrar, check 5 Ensure the
SIP registrar.
Maximum duration of the conference is sufficient (the default is one
H.323 gatekeeper; if you are using a SIP
hour). 6 All other values can be left at their default settings. Refer to the online help for
further information about the available settings.
Note that if you do not configure the conference to start immediately, it
i
will become a scheduled conference and will be inactive until its start time.
7 Scroll down and click
Add conference.
The conference you have created is now active (if you used the default immediate start time) and participants can join in one of two ways: either the Media blade can call out to specified endpoints or endpoints can dial in. Any endpoints that have been added to a conference, as pre-configured participants, will be called in to the conference by the Media blade.
10

Calling participants in to a conference

To call participants in to a conference:
Using the Media blade
1 In the web interface of the Media blade, go to
Conferences and click on the
name of an active conference. 2On the
Participants tab, click Add participant to call out to an H.323 or SIP
endpoint. 3In the
Address field:
where there is no H.323 gatekeeper or SIP registrar, type the IP address,
host name, or SIP URI of an accessible endpoint on your network
if you are using an H.323 gatekeeper, enter the number registered with the
gatekeeper for the required endpoint
if you are using a SIP registrar, enter the number registered with the SIP
registrar for the required endpoint
4 Leave the other fields as their default values and click
Call endpoint. The Media
blade automatically connects to the endpoint. 5 If the endpoint is not configured to automatically answer calls, accept the call on
the endpoint.

Calling in to a conference

Participants can call in to conferences in either one of two ways:
if you have given the conference a numeric identifier and you are using an H.323
gatekeeper or SIP registrar, tell participants to dial the numeric identifier from
their endpoint to join that conference
participants can dial the IP address of the Media blade to access the auto
attendant of the Media blade. Participants will see a menu of available
conferences on their video screen and will hear instructions
11

Streaming conferences

Streaming is a way of viewing a conference in a standard web browser. The Media blade allows streaming of video and, if enabled for a conference, the streaming of data. You can also conduct a text ‘chat’ and add notes and drawings to the data stream.
Note that to use the ‘chat’ facility when streaming a conference, your
i
Media blade needs the web conferencing feature key. For more information, refer to your reseller.
You can configure two streaming options on the Media blade that will be available for users to choose between when streaming conferences. For each streaming option, you must choose a media player (QuickTime, RealPlayer, or Windows Media Player) and a bit rate.
To configure streaming options:
1 In the web interface of the Media blade, go to 2 Configure the streaming options you require, referring to the online help for
more details about options. 3Click
Apply changes.
Streaming users will need to have installed one of the media players that you have chosen for the two streaming options. Streaming users might also need to install Java (from www.java.com).
To stream a conference:
1 In a web browser, go to the IP address of the Media blade (or if you are already
logged in, go to 2Type in a
and the 3Click
Stream this conference and streaming will start.
Conference ID (the numeric identifier of the conference).
Home and click Streaming-only interface).
Sign-in name (the name by which you will be identified if you ‘chat’)
Settings > Streaming.
12

Instructing conference participants

Instructing conference participants
You need to tell conference participants how to join conferences. You can also tell them how to use the Far-End Camera Controls (FECC) to navigate menus in the auto attendant and choose conference layouts. There is a document: Getting Started: Accessing Conferences available in the documentation area of the web site, which you can print out and give to conference participants.

Checking for updates

It is a good idea to regularly check for updates to the main Media blade software image. This section describes how to upgrade the Media blade using the web. Note that you can also upgrade the Media blade using FTP; this can be more reliable if you are upgrading the device remotely. Upgrading your device via FTP is described in the release notes that are available alongside the software images in the support section of the web site.
To check for, and download, updates:
1 Log in to the Media blade web interface and go to 2 Make a note of the software version that is currently installed. 3 Go to the support section of the web site and check if a more recent release is

available for the Media blade. 4 If a more recent release is available, download it and save it locally.

To upgrade the Media blade:

1 Unzip the software release file that you downloaded. 2 In the Media blade web interface, go to 3In the 4Click

Main software image section, click Browse and locate the unzipped file.
Upload software image. The browser begins uploading the file to the
Settings > Upgrade.
Media blade, and a new browser window opens to indicate the progress of the
upload.
When finished, the browser window refreshes and indicates that the software
upgrade is complete. 5Go to
Settings > Shutdown to shut down and restart the Media blade.
Status > General.
Note that shutting down the Media blade will disconnect all participants.
i
13

Troubleshooting and technical support information

Using the event log to help solve a problem

Unless you are experiencing a problem, all event logging sources should be set to the default, which is configuring the event log, refer to the online help accessible from the web interface.
You can use the event log to produce debugging information to assist technical support in solving your problem. However, we recommend that you only alter the setting of the event log under the guidance of technical support. In particular, you should not turn on event logging sources without good cause or advice from technical support.

Getting more help

If the documentation does not answer your question or you have a problem with one of our products:
1 Refer to the Technical FAQ section of the web site. We keep the Technical FAQ
section up to date with the latest information from our technical support team
regarding the resolution of customer issues. 2 Contact your reseller. Our resellers have a wealth of experience with our
products and this is often a quick way of solving a problem. 3 If your query remains unsolved, there is a web form in the support area of the
web site that you can complete. Ensure that you provide all the details requested
by the form to assist the technical support team in resolving your problem:
the serial number and product model number (for example: MSE8420) of
the MSE blade
the software build number (to find this, in the web interface, go to Status >
General
where you purchased the MSE blade
your contact email address or telephone number
Errors, warnings and information. For more information about
)
14
61-0007-03
Loading...
