FRAPPE COFFEE MACHINE
SDP2000BK
User Guide
SDP2000BK
SDP2000BK_24EM1 (ANZ).indd 1SDP2000BK_24EM1 (ANZ).indd 1 2024/5/23 09:492024/5/23 09:49
Contents
Sunbeam’s Safety Precautions
Sunbeam’s Safety Precautions 1
Features of your Frappe Machine 2
Let's get you started 4
How to use the Blender 4
How to clean your Frappe Coffee Machine 5
FAQ 6
FOR YOUR SUNBEAM FRAPPE COFFEE MACHINE:
• Take care when removing the jug from base,
emptying the bowl/jug or cleaning the bowl/jug, as
blades are extremely sharp.
• Take care when blending hot liquids, as it can eject
out of the blender jug due to sudden steaming.
• Switch off the appliance and disconnect from supply
before changing accessories or approaching parts
that move in use.
• Always place the unit on a flat, level surface.
• Do not place in a cabinet when in use.
• Do not operate without water in water reservoir.
Fill water reservoir with filtered water. Observe
the maximum filling volume.
• Do not allow the power cord to come into contact
with the hot parts of the machine.
• Do not place hands directly under the brew spout
Sunbeam is very safety conscious when designing
and manufacturing consumer products, but it is
essential that the product user also exercise care
when using an electrical appliance. Listed below are
precautions which are essential for the safe use of
an electrical appliance:
• Read carefully and save all the instructions
provided with an appliance.
• Always turn the power off at the power outlet
before you insert or remove a plug. Remove by
grasping the plug - do not pull on the cord.
• Turn the power off and remove the plug when the
appliance is not in use and before cleaning.
• Do not use your appliance with an extension cord
unless this cord has been checked and tested by
a qualified technician or service person.
• Always use your appliance from a power outlet of
the voltage (A.C. only) marked on the appliance.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure that they
do not play with the appliance.
• The temperature of accessible surfaces may be
high when the appliance is operating.
• Never leave an appliance unattended while in use.
• Do not use an appliance for any purpose other
as this can lead to scalding or injury.
• The temperature of accessible surfaces may be
high when the appliance is operating. Even after
use, the heating element surface is subject to
residual heat after use.
• Always switch off and unplug at power outlet
before cleaning the coffee machine.
• Children should not perform cleaning and user
maintenance without supervision.
• Always switch off and unplug at power outlet if
there is any problem during the coffee making
process.
• Do not use an appliance for any purpose other than
its intended use. Injury could occur from misuse.
• CAUTION: To prevent damage to the appliance do
not use alkaline cleaning agents when cleaning,
use a soft cloth and detergent.
than its intended use.
• Do not place an appliance on or near a hot gas
flame, electric element or on a heated oven.
• Do not place on top of any other appliance.
• Do not let the power cord of an appliance hang
over the edge of a table or bench top or touch
any hot surface.
• Do not operate any electrical appliance with a
damaged cord or after the appliance has been
damaged in any manner. If damage is suspected,
return the appliance to the nearest Sunbeam
Appointed Service Centre for examination, repair
or adjustment.
• For additional protection, Sunbeam recommend
the use of a residual current device (RCD)
with a tripping current not exceeding 30mA in
the electrical circuit supplying power to your
appliances.
• Do not immerse the appliance in water or any
other liquid unless recommended.
• Appliances are not intended to be operated by
means of an external timer or separate remote
control system.
• This appliance is intended to be used in
household and similar applications such as: staff
kitchen areas in shops, offices and other working
environments; farm houses; by clients in hotels,
motels and other residential type environments;
bed and breakfast type environments.
If you have any concerns regarding the performance and use of your appliance,
please visit www.sunbeam.com.au or contact the Sunbeam Consumer Service Line.
Ensure the above safety precautions are understood.
1
SDP2000BK_24EM1 (ANZ).indd 2-1SDP2000BK_24EM1 (ANZ).indd 2-1 2024/5/23 09:492024/5/23 09:49
Features of your Frappe Machine
Features of your Frappe Machine
19
8
7
18
21
20
9
6
10
5
4
3
2
1
11
12
13
17
16
15
14
22
14. Blender base
15. Blender blades
1. Drip tray
2. Drip tray cover
3. Over ice button
4. Hot brew button
5. Blender mount
6. Brew spout
7. Lid
2 3
SDP2000BK_24EM1 (ANZ).indd 2-3SDP2000BK_24EM1 (ANZ).indd 2-3 2024/5/23 09:492024/5/23 09:49
8. Showerhead
9. Reusable coffee fi lter
10. Brew basket
11. On/Off button
12. Blend button
13. Pulse button
16. Blender jar
17. Blender lid
18. Blender measuring cap
19. Coffee ground scoop
20. Tumbler
21. Tumbler lid
22. Tumbler straw
Let's get you started
How to use the Blender
Let’s make Iced Coffee!
1. Start with the unit unplugged.
WARNING: To prevent injury from hot
steam or potential damage to the unit do
not plug the unit in until the water is in
the reservoir and the tumbler is put in
place.
2. Fill the tumbler to the “WATER” marking
with filtered water.
3. Pour water into the reservoir.
NOTE: Do not pour above 475ml max fill
line as water reservoir will overflow.
4. Using the Over Ice side of the coffee
scoop, add 1-2 scoops of coffee grounds
to the coffee filter. Rotate the shower
head over the coffee filter and grinds.
Close the lid.
NOTE: Ensure grounds do not spill into
water reservoir when filling coffee filter.
Removing coffee filter to fill with grounds
can help prevent accidental spills into the
reservoir.
5. Fill the tumbler with large ice cubes to
the “ICE” marking.
6. Place the tumbler under the brew spout
and plug unit in. Press the OVER ICE
button – ensure the LED is illuminated.
7. While your coffee is brewing, prepare your
frothed milk if you wish.
8. Wait 3-4 minutes for brewing to
complete, then add your favourite coffee
mix-ins.
9. Insert straw in lid, place lid on tumbler
and enjoy!
Let’s make Hot Coffee!
1. Start with the unit unplugged.
WARNING: To prevent injury from hot steam
or potential damage to the unit do not plug
the unit in until the water is in the reservoir
and the tumbler is put in place in.
2. Grab desired coffee cup or mug and fill with
as much water as you would like coffee.
TIP: Taller coffee mugs work best to avoid
any splashing during brewing.
3. Fill the reservoir with the desired amount
of water, according to the marks on the
inside of the reservoir.
NOTE: Do not pour above 475ml max fill
line as water reservoir will overflow.
4. Using the HOT side of the coffee scoop,
measure coffee grounds that correspond
to amount of water poured.
NOTE: If you prefer bolder hot coffee, you
can use an extra ½ - 1 scoops of coffee
grounds.
5. Pour coffee grounds into reusable coffee
filter.
NOTE: Ensure grounds do not spill into water
reservoir when filling coffee filter. Removing
coffee filter to fill with grounds can help
prevent accidental spills into the reservoir.
6. Rotate the shower head over the coffee
filter and grinds. Close the lid.
7. Place the mug that was used to measure
water under the Brew Spout. Press HOT
BREW button.
8. Wait 3-4 minutes for brewing to
complete, then add in your favourite
coffee mix-ins. Enjoy!
Let's use your blender
NOTE: Please take caution when using the
blender and do not put your hands into the
jug, as the blades are sharp.
1. Start with the unit unplugged.
WARNING: To prevent injury from hot
steam or potential damage to the unit do
not plug the unit in until the water is in
the reservoir and the tumbler is put in
place.
2. Fill the blender jar to the "WATER"
marking with clean, filtered water.
3. Lift the lid of the unit and pour the water
into the reservoir.
4. Place the reusable coffee filter into the
brew basket.
5. Using the ICED side of the coffee scoop,
pour 2 scoops of grounds into the
reusable coffee filter. Close the lid.
6. Fill the blender jar with milk to the
"MILK" line.
7. Fill the blender jar with ice cubes to the
"ICE" marking.
8. Place the blender jar full of ice and milk
under the brew spout and plug unit in.
Press the power button. it will blink slowly
in standby for brew or blend. Press the
"OVER ICE" button - ensure the LED is
illuminated.
9. Wait 3-4 minutes for brewing to
complete. Once dripping slows and stops
take the the blender jar from underneath
the spout.
10. Pour desired syrups, flavourings and
mix-ins into the blender.
11. Place the blender lid on to the blender
jar. Place the blender jar on to the
blender mount. Twist handle to the left to
lock into place.
12. Press the "BLEND" button. The blender
will automatically blend your frappe to the
perfect consistency.
13. When blending is complete, remove lid
and pour your frappe into the reusable
tumbler.
14. Insert straw in lid, place lid on tumbler
and enjoy!
4 5
SDP2000BK_24EM1 (ANZ).indd 4-5SDP2000BK_24EM1 (ANZ).indd 4-5 2024/5/23 09:492024/5/23 09:49
How to clean your Frappe
Machine
Minerals (like calcium and limestone) found
in water can leave deposits in your machine
and affect its performance. Decalcifying your
machine is an important part of ensuring your
coffee always tastes great!
We recommend decalcifying your machine
once per month to keep it at peak
performance. It’s an easy process – See steps
below.
Sunbeam Eco-friendly descaling sachets
(EMA0015CL) are available for purchase from
Sunbeam.
Contact details are on the back page.
1. Dissolve half the contents of a Sunbeam
Descaler sachet in 450ml of warm water.
Pour the solution into the water reservoir.
Fold the sachet (containing the remaining
descaler) up tightly and store for next use.
2. Place the reusable coffee filter into the
brew basket and close the lid.
3. Place the tumbler under the spout and
press the HOT BREW button to run a
brew cycle.
4. When the descaling solution begins to
pour through the brew spout, press the
HOT BREW button again to stop the pour.
Leave the descaling solution in the Frappe
Machine for 1 minute. Then press the
HOT BREW button to resume the pour.
5. When the brew cycle has completed,
discard the contents of the tumbler.
Remove the reusable coffee filter from the
brew basket.
6. Rinse out the tumbler, reusable coffee
filter and brew basket with clean water.
7. Place tumbler under spout.
8. Fill the water reservoir to the 475ml mark
with clean water, and press the HOT
BREW button to run a brew cycle.
9. When the brew cycle has completed,
discard the contents of the tumbler and
rinse tumbler thoroughly with clean water.
10. Repeat steps 7-9 one more time, to
ensure the machine is thoroughly rinsed.
Your Frappe Machine is now clean and ready
to brew delicious Iced or Hot coffee whenever
you need a pick-me-up!
DISHWASHER SAFE PARTS OF YOUR FRAPPE
COFFEE MACHINE
To thoroughly clean your Frappe coffee
machine, you can put the following parts into
the top rack of the dishwasher:
1. Reusable coffee filter
2. Brew Basket
CAUTION: THE ELECTRICAL BASE, POWER
CORD AND PLUG ARE NOT DISHWASHER
SAFE AND SHOULD NEVER BE IMMERSED
IN WATER OR OTHER LIQUIDS.
FAQ
My frappe didn’t blend properly, what’s wrong?
Sorry about this! There could be a few causes
for this:
1. There might be too much ice. Only add ice
to the line on the blender jar.
2. There might not be enough liquid. Ensure
that water is filled to the water line before
pouring into the reservoir or try adding
more milk to improve consistency.
3. There might not be any sugar to help
consistency while blending. We have found
that syrup or sugar of some form greatly
helps blending texture and consistency.
Try one of our favorite recipes from our
online recipe book!
My iced or hot coffee isn’t strong enough for my
taste – what now?
No problem – everyone’s tastes are different!
Add another half scoop of coffee grounds into
the reusable coffee filter next time you make
iced coffee. If that’s still not strong enough,
try a full extra scoop.
Try selecting the “OVER ICE” setting for Hot
Coffee, as this pre-infuses the coffee for best
extraction.
Is the tumbler dishwasher safe?
No, the tumbler, lid and straw should be
hand-washed only.
Why is there no ice left in my cup after brewing
iced coffee?
Try using bigger ice cubes when making your
iced coffee – these will melt slower and give
you ice in your drink for longer! Also be sure
you have filled your tumbler all the way to the
“ICE” marking.
Why are there coffee grounds in my coffee?
You may have over-filled your reusable coffee
filter with coffee grounds, and they could
have spilled over the top. Although this is
uncommon, try using a little less grounds
next time and that should solve this problem!
Can I use a different tumbler or cup for making
iced coffee?
Sure thing! Just ensure you keep the same
ratio of water-ground-ice to create the best
tasting iced coffee!
6 7
SDP2000BK_24EM1 (ANZ).indd 6-7SDP2000BK_24EM1 (ANZ).indd 6-7 2024/5/23 09:492024/5/23 09:49
Australia
www.sunbeam.com.au
1300 881 861
New Zealand
www.sunbeam.co.nz
0800 786 232
8
SDP2000BK_24EM1 (ANZ).indd 8-9SDP2000BK_24EM1 (ANZ).indd 8-9 2024/5/23 09:492024/5/23 09:49
Need help with your appliance?
Contact our customer service team or visit our
website for information and tips on getting the
most from your appliance.
Australia | visit www.sunbeam.com.au
phone 1300 881 861
New Zealand | visit www.sunbeam.co.nz
phone 0800 786 232
Newell Australia Pty Ltd. ABN 68 075 071 233
Sunbeam is a registered trade mark.
Made in China to Sunbeam’s specification.
Due to minor changes in design or otherwise,
the product you buy may differ slightly from the one shown here.
Approved by the appropriate electrical regulatory authorities.
©Copyright Sunbeam 2024.
04/24
SDP2000BK_24EM1 (ANZ)_GCDS-LD
PN: NWL0001663804
SDP2000BK_24EM1 (ANZ).indd 10SDP2000BK_24EM1 (ANZ).indd 10 2024/5/23 09:492024/5/23 09:49
Loading...
