starway Starway Spectrum Panasonic-FBA09A12M1A

FBA09A (92mm)

Panaflo

92

82.5

92

82.5

Housing with solid corner type is also available

CUT OUT

92

82.5

ø100 Inlet

ø104 Outlet

25.5

44

FLOW

ROTATION

FLOW

8-ø4.5

82.5

ROTATION

92

Inlet/Outlet

4-ø4.7

Features

• Operating Temperature: -10°C — +70°C (65% RH)

• Storage Temperature: -40°C

—

+75°C (65% RH)

• Bearing Type: Hydro Wave

• Connector Type: Plug-In

• Aerodynamic blade and venturi design

Basic Data

(nominal at room temperature)

Rated Operating Rated Rated Nominal Maximum Maximum

Voltage Voltage Current Input Speed Air Flow Air Pressure Noise

(V) (V) (mA) (W) (r/min)

FBA09A12L 12 7—13.8 110 1.32 2100 1.21 42.7 2.30 22.6 27.0

FBA09A12M 12 7—13.8 150 1.80 2450 1.36 48.0 3.00 29.4 30.0

FBA09A12H 12 7—13.8 225 2.70 2850 1.61 56.8 3.98 39.0 35.0

FBA09A12U 12 7—13.8 430 5.16 3450 1.95 68.8 5.0 49.0 43.0

FBA09A24L 24 14—27.6 80 1.92 2100 1.21 42.7 2.30 22.6 27.0

FBA09A24M 24 14—27.6 110 2.64 2450 1.36 48.0 3.00 29.4 30.0

• Locked rotor protection and auto-start function

• Lower circuit noise by new IC

• Optional third lead wire signal (Locked rotor alarm sensor, 2PPR)

• Easy value add access to lead wires via plug-in connector

on housing

(m3/min) (CFM) (mmH2O) (Pa)

(dB-A)

FBA09A24H 24 14—27.6 140 3.36 2850 1.61 56.8 3.98 39.0 35.0

16

FBA09A (92mm)

Characteristics

FBA09A12L / FBA09A24L

0)

2

(Pa)

(mmH

660

13.8V (27.6V)
12V (24V)

(r/min)

3000

Panaflo

300

10

All dimensions in mm.

Lead Wire

All lead wires are 295 mm. in
length ± 15 mm. (bare wire
10mm ± 5mm.)

Housing and Fan Blade: Plastic
(PET, PBT, ABS)

Size

92.0 x 92.0 x 25.5
(3.62 x 3.72 x 1.00)

Weight

110 grams (3.88 ounces)

Case Quantity

100 per box

+ (red)

(black)

-

strip and tin

440

Air Pressure

220

P

(Pa)

660

440

Air Pressure

220

P

(Pa)

660

440

Air Pressure

220

P

FBA09A12M / FBA09A24M

0)

2

(mmH

FBA09A12H / FBA09A24H

0)

2

(mmH

7V (14V)

3210

7V (14V)

3210

7V (14V)

2000

Nominal SpeedN

1000

3

/min)

(m
(CFM)100

(r/min)

3000

2000

Nominal SpeedN

1000

3

/min)

(m
(CFM)100

(r/min)

3000

2000

Nominal SpeedN

1000

10.2V (20.4V)

50

Air FlowQ

13.8V (27.6V)
12V (24V)

10.2V (20.4V)

50

Air FlowQ

13.8V (27.6V)

12V (24V)

10.2V (20.4V)

Conversion Factors

1 mm H2O = 9.8 PA

3

1 m

/min = 35.313 CFM

P— Q
N— Q

(Pa)

6
5

4000

4

Air Pressure

3

2000

2

P

1

0)

2

(mmH

0.5 1.0 2.01.50

50

Air FlowQ

FBA09A12U

25

Air FlowQ

3

/min)

3210

(m
(CFM)100

13.8V (27.6V)
12V (24V)

10.2V (20.4V)

7V (14V)

(CFM)50

(r/min)

4000

2000

(m3/min)

Nominal SpeedN
