CONTENTS
1. Introduction...................................................3
2. AC Power.....................................................5
3. Installation....................................................6
4. Control Panel................................................8
5. Optical Path Configuration..........................13
6. Trouble Shooting........................................14
7. Technology Specifications ..........................14
© Starw ay 2006
www.st ar-way.com
2
Page 3
I/ INTRODUCTION
Thank you for selecting the Max Spot 250. This automated luminary provides 8 dichroic
color filters, high-speed mechanical shutter, 4-digit LED control Panel, 510° of pan by 260°
of tilt, DMX, Stand-Alone, and Master/Slave control Options; and switch-selectable power
supply settings. The Max Spot 250 provides a 17° hard-focused beam, manually adjustable
focus, and 7 Gobos.
SAFETY INFORMATION
Warning! This product is for professional use only. It is not for household Use.
This product presents risks of lethal or severe injury due to fire and heat, electric shock,
ultraviolet radiation, lamp explosion, and falls. Read this manual before powering or
installing the fixture, follow the safety precautions listed below and observe all warnings in
this manual and on the fixture.
To protect yourself and others from electric shock
• Disconnect the fixture from AC power before removing or installing the lamp, fuses,
or any part, and when not in use.
• Always ground (earth) the fixture electrically.
• Use only a source of AC power that complies with local building and electrical
codes and has both overload and ground-fault protection.
• Do not expose the fixture to rain or moisture.
To protect yourself and others from UV radiation and lamp
Explosion.
• Never operate the fixture with missing or damaged lenses and/or covers.
• When replacing the lamp, allow the fixture to cool for at least 5 minutes before
opening the fixture or removing the lamp. Protect your hands and eyes with gloves
and safety glasses.
• Do not stare directly into the light. Never look at an exposed lamp while it is lit.
• Replace the lamp if it becomes defective or worn out.
© Starw ay 2006
www.st ar-way.com
3
Page 4
To protect yourself and others from burns and fire
• Never attempt to bypass the thermostatic switch or fuses. Always replace defective
fuses with ones of the specified type and rating.
• Keep all combustible materials (for example fabric, wood, paper) at least 0.3
meters (12 inches) away from the fixture. Keep flammable materials well away
from the fixture.
• Do not illuminate surfaces within 0.3 meters (12 inches) of the fixture.
• Provide a minimum clearance of 0.1 meters (4 inches) around fans and air vents.
• Never place filters or other materials over the lens.
• The exterior of the fixture can reach temperatures up to 60° C (140° F). Allow the
fixture to cool before handling.
• Do not modify the fixture or install other than genuine parts.
• Do not operate the fixture if the ambient temperature (Ta) exceeds 40° C (104° F).
To protect yourself and others from injury due to falls
• When suspending the fixture above ground level, verify that the structure can hold
at least 10 times the weight of all installed devices.
• Verify that all external covers and rigging hardware are securely fastened and use
an approved means of secondary attachment such as a safety cable.
• Block access below the work area whenever installing or removing the fixture.
UNPACKING
The packing material is carefully designed to protect the fixture during shipment - always
use it to transport the fixture.
The Max Spot 250 comes with:
• ELC 24V 250W lamp
• 3 m, 3-pin IEC mains cable
• Attachment bracket for mounting clamp
• User manual
© Starw ay 2006
www.st ar-way.com
4
Page 5
II/ AC POWER
The Max Spot 250 has switch-selectable settings to configure the power supply for local
conditions. Always use the setting that is closest to the local AC supply.
Warning! For protection from electric shock, the fixture must be
grounded (earthed). The power supply shall have overload and
ground-fault protection.
Important! Install fuse and verify that power supply settings match local
AC supply before use.
To change the voltage setting
1. Disconnect the fixture from power.
2. Remove the 4 base cover bolts with a 4 mm Allen wrench. Move the cover
out of the way of the switches without disconnecting wires.
3. Set the 5-position switch (A) to the setting closest to the AC voltage. Use the
higher setting if the voltage is halfway between 2 settings. For example, use
the 230 V setting instead of the 210 V setting for operation with 220 V power.
4. Set the 2-position switch (B) to the AC frequency (50 / 60 Hz).
5. Replace the cover and apply a new power setting label to the serial number
label.
To install the main fuse
Fuses are provided for 100 - 130 V and 200 - 250 V operation.
Use only the fuse specified for the operating voltage.
1. Locate the bag containing the fuse for your AC voltage. Insert the fuse in
the fuse holder. The holder may be packed with the other fuse.
2. Remove the label covering the mains input socket.
3. Insert the fuse holder in the empty slot in the mains input socket (C).
To install a plug on the power cable
The power cable must be fitted with a grounding-type cord cap that fits your power
distribution system. Consult an electrician if you have any doubts about proper
installation.
Following the cord cap manufacturer’s instructions, connect the yellow and green wire
to ground (earth), the brown wire to live, and the blue wire to neutral. The table below
shows some pin identification schemes.
© Starw ay 2006
www.st ar-way.com
5
Page 6
Table 1: Cord cap connections
Wire Pin Marking Screw color
brown live “L” yellow or brass
blue neutral “N” silver
yellow/green ground
green
To apply power
Warning! The power cables must be undamaged and rated for the electrical
requirements of all connected devices. Important! Powering through a dimmer
system can damage the fixture.
• Connect the prepared cable to the mains input socket and the AC mains
distribution system. Do not connect the fixture to a dimmer system.
III/ INSTALLATION
LOCATION AND ORIENTATION
For safe operation, install the Max Spot 250 in a location where: -
• It is at least 0.3 meters (12 inches) away from illuminated surfaces and
combustible materials.
• It is not easily touched or bumped.
• It is protected from rain and moisture.
• There is at least 0.1 meters (4 inches) clearance around the fans and air vents.
• There are no flammable materials nearby. The Max Spot 250 may be installed in
any orientation as described below or placed directly on a stage or floor. The
intense light can burn or melt parts within a distance of 0.3 meters (12 inches).
When installing fixtures side-by-side, avoid illuminating one fixture with another.
Clamp
The Max Spot 250 includes a bracket for attaching a rigging clamp with 12 mm (1/2 in.)
hardware.
TO RIG THE FIXTURE WITH A CLAMP
© Starw ay 2006
www.st ar-way.com
6
Page 7
WARNING! Ensure a safety Cable is secured to the safety anchor point at
the base of the fixture.
1. Verify that the clamp is undamaged and can bear at least 10 times the
weight of the fixture. Verify that the structure can bear at least 10 times the
weight of all installed fixtures, clamps, cables, auxiliary equipment, etc.
2. Bolt a clamp to the included bracket with a grade 8.8 (minimum) M12 bolt
and locknut, or as recommended by the clamp manufacturer, through the
13 mm hole in the bracket.
3. Al ign the brac ket with the keyholes in the base. Insert both lock ing pins
into the holes and turn both levers a full 1/4 turn clockwise to lock. The
fasteners are locked only when turned fully clockwise.
4. Attached the safety cable that can bare at least 10 times its weight,
through the safety cable anchor point at the base.
5. Block access below the work area.
6. Working from a stable platform, clamp the fixture to the structure.
© Starw ay 2006
7
www.st ar-way.com
Page 8
IV/ CONTROL PANEL
The control panel is used to set control modes, address, and personalities; to display
information readouts, to run tests, and to control the fixture manually.
TO NAVIGATE THE CONTROL MENU
Error messages, if any and mode information are displayed at the top of the menu tree.
If the fixture is in (1) DMX mode, the address is displayed; (2) Automatic Stand-alone
mode, SA is displayed. The top of the menu can be reached by pressing [menu]
repeatedly.
1. From the top of the control menu, press [menu] to enter the main menu.
2. Press [up] or [down] to scroll through menus and press [enter] to view
submenus.
3. To activate a setting or function, press [enter].
4. To return to the previous menu or to escape without making a selection,
press [menu].
PERSONALITIES
The following settings are available to modify fixture behavior.
Pan/tilt swap: Map pan to the tilt channel and tilt to the pan channel to provide
more intuitive control of fixtures mounted sideways.
Inverse pan: Flip pan movement to right-to-left instead of left-to-right.
Inverse tilt: Flip tilt movement to down-to-up instead of up-to-down.
DMX lamp-off: By switching the fixture between 6 and 7 channels, you are able to
strike the lamp via DMX.
Display: Flip the display for truss mounting.
USER INTERFACE PICTURE / DIAGRAM
© Starw ay 2006
www.st ar-way.com
8
Page 9
MENU FUNCTIONS AND DISTRIBUTION
The Max Spot 250 has 9 menu functions. Bellow is a Menu tree, which will help you to read
understand the menu codes.
ADDR MODE rPAN rTILT r-PT nchn TEST DSPL
1
To
512
M-DM
M-SO
STND
REV
STND
REV
STND
REV
7ch
6ch
ALL
PAN
REV REST
STND
M-SL
TILT
STAL
COL
GOBO
SHUT
MENU CODE MEANINGS
ADDR This allows you to change the start address one to 512.
MODE This allows you to change the control mode: M-DM DMX MODE
M-SO SOUND ACTIVE MASTER
M-SL SOUND ACTIVE SLAVE
STAL STAND ALONE
rPAN This allows you to change the pan direction: -
REV REVERSE
STND STANDARD
rTILT This allows you to change the tilt direction: -
REV REVERSE
STND STANDARD
r-PT This allows you to change the pan and tilt direction simultaneously: -
REV REVERSE
STND STANDARD
nchn This allows you to control the ELC lamp via DMX: -
7ch lamp controlled via DMX
6ch lamp controlled via fixture
REST
© Starw ay 2006
www.st ar-way.com
9
Page 10
TEST This function allows the user to test the fixtures f eatures from the fixture
without DMX signal: PAN Tests the pan movement
TILT Tests the tilt movement
COL Tests the color wheel
GOBO Tests the gobo wheel
SHUT Tests the shutter
DSPL This allows you to change the display orientation for upside down truss
mounting: -
REV REVERSE
STND STANDARD
REST This allows you to reset the fixture: -
REST RESET
DMX VALUE TABLE
CHANNEL 1 – PAN (510°)
NO. DMX VALUE EFFECT
1 0 PAN LEFT
2 127 PAN CENTER
3 255 PAN RIGHT
CHANNEL 2 – TILT (260°)
NO. DMX VALUE EFFECT
1 0 TILT LEFT
2 127 TILT CENTER
3 255 TILT RIGHT
CHANNEL 3 – SPEED
The speed of the pan and tilt from left to right, up and down. DMX value 0-255.
© Starw ay 2006
www.st ar-way.com
10
Page 11
CHANNEL 4 – COLOR
NO. DMX VALUE EFFECT
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
0 -15 OPEN
16 -31 COLOR 1
32 - 43 COLOR 2
44 - 55 COLOR 3
56 - 67 COLOR 4
68 - 79 COLOR 5
80 - 91 COLOR 6
92 - 107 COLOR 7
108 -119 COLOR 8
120 -135 1 COMBINED COLOR
136 -151 2 COMBINED COLOR
152 -167 3 COMBINED COLOR
168 -183 4 COMBINED COLOR
184 -199 5 COMBINED COLOR
200 -215 6 COMBINED COLOR
216 -227 7 COMBINED COLOR
228 -239 8 COMBINED COLOR
240 -255 CONTINUOUSLY CYCLING
CHANNEL 5 – GOBOS
NO. DMX VALUE EFFECT
1
2
3
4
5
6
7
8
9
0 - 23 OPEN
24 - 47 GOBO 1
48 - 71 GOBO 2
72 - 95 GOBO 3
96 - 119 GOBO 4
120 - 143 GOBO 5
144 - 167 GOBO 6
168 – 191 GOBO 7
192 - 255 CONTINUOUSLY CYCLING
CHANNEL 6 – SHUTTER / DIMMER
NO. DMX VALUE EFFECT
1
2
3
4
0 - 15 SHUTTER
10 - 127 DIMMING
128 - 239 STROBE (FAST TO SLOW)
240 - 255 OPEN
© Starw ay 2006
www.st ar-way.com
11
Page 12
CHANNEL 7 – RESET & LAMP CONTROL
NO. DMX VALUE EFFECT
1
2
3
4
0 – 127 STRIKE LAMP
128 – 191 REPOSITION AFTER 5 SECS
192 – 250 TURN OFF LAMP
251 – 255 TURN LAMP OFF AFTER 10 SECS
ADDRESS SELECTION
The control address, also known as the start channel, is the first channel used to
receive instructions from the controller. The total number of channels used depends on
the control mode.
Be sure to allow adequate channels when setting the control address.
If control channels for one fixture overlap control channels for another fixture, then one
of the fixtures will receive the wrong commands. To find the highest usable address
channel, subtract the number of channels required from the last controller channel and
add 1. Two Max Spot 250’s of the same type, and operating in the same control
mode, may share the same address if they are to respond identically. They will receive
the same commands and individual control will be impossible.
To set the control address
1. Scroll to Addr in the main menu and press [enter]. The current address is
displayed.
2. Scroll to the address that is assigned to the fixture on the controller. Press
[enter] to activate the address setting.
© Starw ay 2006
www.st ar-way.com
12
Page 13
V/ Optical Path Configuration
GOBO WHEEL
This fixture has 7 static indexing metal
gobos plus one open . The gobos can be
chosen prior to manuf acture. Wheels can
be interchanged with replacement wheels
to vary the gobo effects.
COLOR WHEEL
This fixture has 8 Dichroic filters on one
single color wheel. They ar e Red, Gree n,
Blue, Yellow, Rose, Light Blue, Orange
Red, Pink plus Open.
FOCUS LENS
This fixture has a manual focus lens. By
turning it clock-wise and counter clock-wise
you are able to adjust the focal length
according to your requirements.
GOBO WHEEL DIAGRAM
red
green
blue
yellow
COLOR WHEEL DIAGRAM
FOCUS LENS DIAGRAM
pink
orange
cyan
magneta
© Starw ay 2006
www.st ar-way.com
13
Page 14
VI/ Trouble Shooting
PROBLEM REASO N TROUBLE SHO O TING
No Power
One or More Ensure you are sending signal
fixtures do not
respond
Fixture repositions
But undesired or no
reponse
Lamp Does not Strike
DMX ADDRESS
DMX CABLE
Poor signal from Control control DMX selection switch
DMX AD DRESS OFFSET and ensure all fixtures
No Power Check to see if fixture has power
Lamp is blown Replace lamp with same
Lamp is loose Ensure Lamp is properly
Turn on the power at mains
to the fixture
Che c k that the fu s e is in Fuse
tact and serviceable
Check to see that a proper
connection between control
and the fixture a is constant
Individually check each cable
for continuity on all three pins
Check polarity of DMX cable
Check DMX cables, Check
if one is present
Reassign DMX address
use the same profile
inserted into ceramic ba se
VII/ Technology Specifications
DMX Channels: 6 or 7 Channel selectable
Lamp: ELC 24V 250W
User Display Interface: Four LED bar Display with four soft touch keys and English menu
Color Wheel: One Color Wheel with 8 dichroic filters, 9 split colors and open
Gobo Wheel: One Gobo Wheel with 7 indexing metal gobos plus open
Pan: 510° of pan
Tilt: 260°
Volts: 220VAC 50Hz
Current: 5Amps
Size: 220 x 220 x 350mm
Weight: 6kg
© Starw ay 2006
www.st ar-way.com
14
Loading...
