SIGNIFY EA0749 Instruction Manual

01

AFTER SALES SUPPORT

AUS 1300 777 137 EMAIL [e-mail]

High Powered Entertainment

System with Karaoke Function

and Bluetooth

®

Model Number: EA0749

INSTRUCTION MANUAL

02

AFTER SALES SUPPORT

AUS 1300 777 137 EMAIL [e-mail]

Contents

Welcome 03

Important Safety Instructions 04

Box Content 06

Product Overview 07

Top Panel 07

Panels 08

Remote Control 09

Before First Use 12

Instructions 13

Using the Audio Modes 13

Preparing the FM Antenna 13

Auto-Search for FM Radio Stations 13

Manual Searching for AM/FM Radio Stations 13

Using the USB Input Function 13

Using the SD Card Input Function 14

Using the Bluetooth® Function 15

Using the Microphone 17

Technical Specifications 18

Tips and Troubleshooting 18

Warranty Details 19

03

AFTER SALES SUPPORT

AUS 1300 777 137 EMAIL [e-mail]

Welcome

Congratulations on choosing to buy a Signify®product.

All products brought to you by Signify® are manufactured to the highest standards of performance
and safety, and, as part of our philosophy of customer service and satisfaction, are backed by our
comprehensive 1 Year Warranty.

This comprehensive instruction manual will provide you with a detailed guide on how to operate your
product and will also assist you in troubleshooting any problems that you may encounter.

If you have any queries regarding the use of this product, please feel free to phone our technical
support line for advice. If you are experiencing difficulties or believe that the product may have a
technical fault, we will also assist you in rectifying the issue. We can generally solve most problems
simply and quickly over the phone, so please always phone us first!

We are sure that you will enjoy using this product and you can expect to gain years of service from this
product when it is used and maintained in the correct manner.

IMPORTANT: Only audio files in MP3 format can be played successfully on your Entertainment
System. Please ensure your audio files loaded on your USB drive and SD card are converted to MP3
format before playing on the Entertainment System.

04

AFTER SALES SUPPORT

AUS 1300 777 137 EMAIL [e-mail]

Important Safety Instructions

RETAIN FOR FUTURE USE

Read this manual thoroughly before first use, even if you are familiar with this type of product.
The safety precautions enclosed herein reduce the risk of fire, electric shock and injury when
correctly adhered to. Please keep this user manual in a safe place along with your purchase receipt
and carton for future reference. If applicable, pass these instructions on to the next owner of the
product. Always follow basic safety precautions and accident prevention measures when using an
electrical product.

1. Before installing the Entertainment System, ensure the electrical voltage and circuit frequency
correspond to the voltage stated on the rating label of your product and your power outlet is
properly earthed.

2. Do not use the Entertainment System with an extension cord unless this cord has been checked
and tested by a qualified electrician. If an extension cord is used, please ensure that it has a rating
equal or exceeding the rating of this product.

3. Do not pull or carry by the cord, use the cord as a handle, close a door on the cord, or pull the
cord around sharp edges or corners. Check the power cord regularly for visible damage. If it is
damaged, please contact the After Sales Support line for further advice.

4. Check the power cord regularly for visible damage. If it is damaged, please contact the After Sales
Support line for further advice.

5. When the Entertainment System is not in use, switch it off and unplug from the power outlet. Do
not leave the product unattended when connected to the power supply. To unplug, grip the plug
and pull from the power outlet. Never pull by the cord.

6. This product is not user-serviceable. Contact with high voltage components may cause a risk of
electric shock, therefore do not attempt to open the back cover of the Entertainment System.

7. The installation of a residual current device (safety switch) is recommended to provide additional
safety protection when using electrical devices. It is advisable that a safety switch with a rated
residual operating current not exceeding 30mA be installed in the electrical circuit supplying the
device. See your qualified electrician for professional advice.

8. This Entertainment System is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the product by a person responsible for
their safety.

9. Install and operate the Entertainment System in a cool and sufficiently ventilated room to ensure it
does not overheat.

05

AFTER SALES SUPPORT

AUS 1300 777 137 EMAIL [e-mail]

Important Safety Instructions (cont)

10. Never block the ventilation holes and openings. Do not place this product against soft surfaces,
drapery or fabric that may block the ventilation holes. The product should not be placed in an “in­built” installation unless all ventilation holes are provided with adequate ventilation.

11. Do not expose the Entertainment System near water, rain moisture, liquids or dust. Do not store or
use the Entertainment System in high moisture environments. Moisture can damage the speaker
cone and surround and cause corrosion of electrical contact and metal parts.

12. Unplug the Entertainment System in cases of electrical storms to protect against the possibility of
power surges damaging the device.

13. The manufacturer and retailer are not responsible for any eventual damages caused by improper
or faulty use.

14. This Entertainment System is intended to be used indoors, for household use only. Do not use the
device outdoors.

15. The Entertainment System and its power adaptor have no user-serviceable parts contained within.
Do not attempt to repair, disassemble or modify the Entertainment System. This will void the
warranty.

16. Never operate the Entertainment System with wet hands, submerge under water or spill liquids
into or onto the device.

17. Do not place the Entertainment System near a hot burner (gas or electric), other heat emitting
sources or open flames.

18. Always position the Entertainment System on a flat and stable surface.

19. Be careful when transporting the Entertainment System. This unit is equipped with wheels and
will roll if it's not secure. Please ensure it is secure so it does not come into contact with any other
items or people.

20. If the Entertainment System has been exposed to strong fluctuations in temperature (for example,
after transport), do not switch it on immediately. Moisture and condensation could damage the
equipment. Do not switch on the equipment until it has reached room temperature.

To prevent possible hearing damage, avoid listening at high volume levels over long
periods of time. Even exposure to short bursts of loud noise can result in hearing loss.
Please keep the volume consistently at a comfortable level.

06

AFTER SALES SUPPORT

AUS 1300 777 137 EMAIL [e-mail]

Box Content

Please ensure you carefully unpack the product package and check you have the below accessories
before you dispose the package:

1. Signify High Powered Entertainment System with Karaoke Function and Bluetooth

®

2. AC Power cord

3. Remote Control

4. Wireless Microphone

5. RCA Stereo Audio Cable

6. 2 x AAA batteries (included)

7. 2 x AA batteries (included)

8. User manual

07

AFTER SALES SUPPORT

AUS 1300 777 137 EMAIL [e-mail]

Product Overview

7

6

89

101112

Top Panel

1. USB/SD Input

2. 5 Band Equaliser

3. Microphone Input Sockets

4. Bass Control

5. Treble Control

6. Master Volume Control

7. EQ Selector

8. Remote Control Receiver

9. Next Song/FM Next Frequency

10. Pause/Play/FM Search

11. Mode Display

12. Previous Song/FM Previous Frequency

13. AUX/BT/FM/USB/SD Mode Select

14. Microphone Volume Control

15. Power On/Off

16. Microphone Echo Control

-10+ 10-10+ 10

BASS TREBLE

-10+ 10

ECHO

M

A

X

MIC
INPU T

PROFESSIONAL ACTIVE STAGE SPEAKER SYSTEM

MIC VOLUME

MASTER VOLUME

MIN

M

A

X

MIN

1

16

15

14

13

2 3 4 5

08

AFTER SALES SUPPORT

AUS 1300 777 137 EMAIL [e-mail]

Product Overview (cont)

Rear Panel

1. RCA Audio Input: Connect a CD player, TV, DVD, or other audio play equipment

2. AC Power Input

3. FM Antenna Input

4. LED Light Power Switch On/Off

2

23

4

09

AFTER SALES SUPPORT

AUS 1300 777 137 EMAIL [e-mail]

Product Overview (cont)

Remote Control

1. Standby

2. Previous Track/FM Previous Frequency

3. MP3 Pause/Play/FM Auto Scan

4. Volume Control Up (+)

5. EQ Selector

6. Volume Control Down (-)

7. Mode Selection: AUX/BT/FM/USB/SD

8. Next Track/Next FM Frequency

9. Mute

10. Select Repeat Function
(Single Repeat or All Repeat)

11. 0~9: Song Selection/Manual FM Radio
Frequency Selection. 100+ skips 100 tracks.

7

8

10

5

4

2

1

3

6

11

9

10

AFTER SALES SUPPORT

AUS 1300 777 137 EMAIL [e-mail]

Product Overview (cont)

USB/SD Input

Use the USB/SD input to play tracks directly from your USB or SD device. To use the USB/SD
function, simply turn the Entertainment System on and insert a USB or SD device and the device will
automatically begin to play.

Master Equalization

The Entertainment System features a 5 band custom equalizer. This allows you to increase or decrease
the gain for specific frequency ranges and adjust the audio output to your own personal listening
preferences.

To adjust the equalizer settings, move the slider bars for each of the 5 frequency ranges.

Microphone

Included with your Entertainment System is a wireless microphone. Two Microphone Input Sockets
have also been included in your Entertainment System, for your enjoyment.

To use the microphone, ensure the batteries are correctly inserted into the bottom of your microphone
(refer to page 12 for more detailed instructions) and slide the on/off button all the way up to switch on.
The green indicator light will illuminate.

To connect your wired microphone (not included) to the Microphone Input Socket located on the front
panel, you will require an adaptor if your wired microphone does not use a 1/4'' plug.

Select a mode to play and adjust the volume of the microphone by turning the Mic Volume Adjustment
dial located on the top of the Entertainment System. If you want to hear the music at the same time,
then ensure you also adjust the Master Volume Control up to your preferred volume level.

Bass Control

To enhance the bass of your tracks and audio sounds you can manually adjust the bass by turning the
bass adjustment dial clockwise till you reach a preferred bass setting.

Treble Control

To enhance the treble of your tracks and audio sounds you can manually adjust the treble by turning
the treble control dial clockwise till you reach a preferred treble setting.

Master Volume Control

Use the Master Volume dial to control the volume of the Entertainment System. To increase the
volume, turn the Master Volume dial clockwise and to decrease, turn the dial anticlockwise.

EQ Selector

Press the EQ button to select from a range of EQ (tone) settings (Classic, Rock, Jazz, Pop and Country).

11

AFTER SALES SUPPORT

AUS 1300 777 137 EMAIL [e-mail]

Product Overview (cont)

Previous Song/FM Previous Frequency

Use the previous song/previous frequency button to skip to the previous track while it is playing and
to scroll through tracks (applicable for MP3 USB or SD card playback modes). The previous song/
previous frequency is also used in FM mode to skip to the previous pre-set radio station. When the
previous song/previous frequency button is held down this will also decrease the music volume to a
desired setting, U00 being no volume.

Pause/Play/FM Search

Use the pause/play button to play or pause tracks while in MP3 audio playback (AUX/USB/SD CARD),
FM radio, or Bluetooth®. The play/pause button is also used to auto-search for radio stations with a
strong enough signal to play. The stations found will automatically be allocated in order, to the presets
(up to 20 channels).

Next Song/FM Next Frequency

Use the next song/next frequency button to skip to the next track while it is playing and to scroll
through tracks (applicable for MP3 USB or SD card playback modes). The next song/next frequency
is also used in FM mode to skip to the next pre-set radio station. When the next song/next frequency
button is held down this will also increase the music volume to a desired setting, U30 being full
volume.

LED Light Display Effects

The Entertainment System features colour changing LED lights on the front panel of the device. To
turn on the LED lighting effects, simply switch the LED light power switch located on the rear of the
unit. The LED lights will illuminate and follow the rhythm of the music.

Power On/Off

Plug the power cord into a suitable power outlet, then turn on the power switch on at the outlet. Press
the power switch on the top panel to turn on the speaker. The display on the top panel will illuminate
and display into default mode AUX (except if there is a USB or SD card loaded).

Standby Mode

Press the power button on the remote to enter into standby mode on the Entertainment System. Press
again to turn the Entertainment System on from the standby mode.

Please note that to disconnect the Entertainment System completely from power, you will need to
switch off the power switch on the top panel and then turn off the power at the outlet.

12

AFTER SALES SUPPORT

AUS 1300 777 137 EMAIL [e-mail]

Before First Use

Prior to using your Entertainment System, please read all safety and operating instructions thoroughly.
Please ensure you follow the steps below before using this product. We recommend you keep the
original packaging for storing your Entertainment System when not in use.

1. Unpack the product but keep all packaging material until you have made sure your new
Entertainment System is undamaged and in good working order. Plastic wrapping can be a
suffocation hazard for babies and young children so ensure all packaging materials are out of their
reach.

2. Remove the twist-tie which is securing the electrical cord. Uncoil the cord and straighten it to
remove any kinks. Do not use the product if the cord, plug or unit is damaged, please call the After
Sales Support line for further advice.

3. Please remember that the Entertainment System has wheels for easy portability. At times, a wheel
chock or brick may have to be used to ensure that it doesn't roll around or shift position.

4. Plug the AC power cord into the AC power input located on the back of the Entertainment System,
then plug into an appropriate power outlet and turn on.

5. To install batteries into the remote control, slide the battery cover down on the back of the remote
control. Check the inside of the remote control battery chamber for the polarity symbols, then
insert the 2 x AAA batteries that have been provided.

6. To install batteries into the microphone, grasp the top of the microphone with one hand and rotate
the bottom anticlockwise to unscrew and access the battery compartment. Check the inside of the
microphone battery chamber for the polarity symbols, then insert the 2 x AA batteries that have
been provided.

NOTE: Please pay attention to the polarity markings before inserting the batteries into the remote
control and microphone.

NOTE: Do not mix old and new batteries, different types of battery (alkaline, carbon-zinc or
rechargeable), or rechargeable batteries of different capacities. Mixing different types of battery
could cause battery leaks or ruptures.

WARNING: Keep batteries away from children. If you suspect a battery may have been swallowed,

seek immediate medical assistance.

13

AFTER SALES SUPPORT

AUS 1300 777 137 EMAIL [e-mail]

Instructions

Using the Audio Modes

This Entertainment System has several different modes for audio playback. Select between MP3 audio
playback (AUX/USB/SD CARD), FM radio, or Bluetooth®. First ensure that the Entertainment System
is powered on by pressing the power switch located on the top panel. The display will illuminate, and if
no MP3/SD/USB audio device is connected it will default into AUX mode.

Press the INPUT button to navigate from AUX to Bluetooth® to FM radio mode. You can use a variety
of audio devices with the Entertainment System such as stereos, DVD players, mobile phones, MP3
players using the RCA connections on the back of the unit. You can also connect the supplied Wireless
Microphone while playing your songs for some portable karaoke fun!

Preparing the FM Antenna

On the rear of the Entertainment System, there is an FM antenna, which will need to be extended and
adjusted to the ideal direction. Once adjusted, the antenna will be much more effective in picking up
FM radio signals. Press the INPUT button to navigate through to FM radio mode.

Auto-Search for FM Radio Stations

The Entertainment System features an auto-search FM tuner to assist in finding radio stations with a
strong enough signal to play. To auto-search using the tuner press the pause/play button to scan the
entire FM band frequency. The auto-search will also save the stations into the 20 station memory of
the Entertainment System which are labelled P00 – P20 (program 1 – program 20). The first station
that the tuner finds will be saved under P01, the second station that the auto-search finds will be
saved under P02, and so on. This will continue until the tuner has scanned the entire frequency or until
it has saved stations into all 20 program pre-sets.

To navigate through the saved stations, use the CH+ button on the top panel to the skip forward to the
next station and the CH- button to skip backwards to the previous channel.

Manual Searching for AM/FM Radio Stations

The only way to manually select a radio station is to use the numbered buttons on the remote control.
For example to listen to 96.1 simply press the “9”, “6” and “1” buttons on the remote control and the
Entertainment System will automatically start to play the selected station.

Using the USB Function

The Entertainment System features a USB input which enables MP3 files to be loaded on to a USB
flash drive and played back through the Entertainment System.

IMPORTANT: Only audio files in MP3 format can be played successfully on your Entertainment
System. Please ensure your audio files loaded on your USB drive and SD card are converted to MP3
format before playing on the Entertainment System.

In order to play your MP3 files on the Entertainment System, first load them on to a compatible USB
storage device. We suggest using a USB flash drive and access by simply inserting the drive into your
computer’s USB port then copying and pasting (or drag and drop) compatible MP3 files on to the USB
drive.

14

AFTER SALES SUPPORT

AUS 1300 777 137 EMAIL [e-mail]

Instructions (cont)

Once all files have been loaded, you can remove the USB drive from the computer, however, please
ensure that the USB drive has been correctly ejected from the computer otherwise the files that
have been transferred on to the drive may be damaged. If you are using a Windows PC, eject the USB
device by clicking the “SAFELY REMOVE HARDWARE” icon in the Windows system tray, then select the
corresponding name of USB device and if required choose “STOP” and “CONFIRM” if prompted by the
pop up window. Physically disconnect the USB drive when your computer prompts you that it is safe
to remove your hardware. If you are using a Mac, you can safely remove the drive by dragging the USB
icon on the desktop to the “Trash”.

Switch on the Entertainment System and insert the USB drive into the USB input on the top panel. The
Entertainment System will automatically start playing from the USB drive.

NOTE: If the USB drive contains audio files which are not compatible with the Entertainment System,
the Entertainment System will not be able to read them, so they will not be included in the count of

tracks on the drive, and they will not play.

IMPORTANT: For optimum performance it is recommended to only use a USB 2.0 flash drive (not a

3.0 version).

Controlling the Playing Tracks

To control the tracks that are being played to customise and enhance your listening experience, please
follow these instructions.

Playing and Pausing a Track

To either pause tracks that are playing or play a track when it is paused; press the play/pause button.

To Skip to the Next Track

To skip to the next track, press the

button on the control panel. It will skip to the next track on the

USB device.

To Skip to the Previous Track

To skip to the previous track, press the

button on the control panel. It will skip to the previous

track on the USB device.

Using the SD Card Input Function

This Entertainment System features an SD card input which enables MP3 files to be loaded on to an SD
card and played back through the Entertainment System.

IMPORTANT: Only audio files in MP3 format will play successfully on your Entertainment System.
Please ensure your audio files loaded on your SD card are converted to MP3 format before playing
on the Entertainment System.

15

AFTER SALES SUPPORT

AUS 1300 777 137 EMAIL [e-mail]

Instructions (cont)

In order to play your MP3 files on the Entertainment System, first load them on to a compatible SD
card. Simply insert the drive into the computers SD card input then copy and paste (or drag and drop)
compatible MP3 files on to the SD card. Switch on the Entertainment System and insert the SD card
into the USB input on the top panel. The Entertainment System will automatically start playing from
the SD card.

NOTE: If the SD card contains audio files which are not compatible with the Entertainment System,
the Entertainment System will not be able to read them, so they will not be included in the count of
tracks on the disc, and they will not play.

Controlling the Playing Tracks

To control the tracks that are being played to customise and enhance your listening experience, please
follow these instructions.

Playing and Pausing a Track

To either pause tracks that are playing or play a track when it is paused; press the play/pause button.

To Skip to the Next Track

To skip to the next track, press the

button on the control panel. It will skip to the next track on the

SD card.

To Skip to the Previous Track

To skip to the previous track, press the

button on the control panel. It will skip to the previous

track on the SD card.

Using the Bluetooth® Function

This Entertainment System features a Bluetooth® receiver which enables it to be connected to
compatible Bluetooth® enabled devices such as smart phones and media players. Bluetooth®
enables a wireless connection between a device (such as a smart phone) and the Entertainment
System, enabling the user to play and control tracks directly from their Bluetooth® enabled device.

Firstly, the user must ensure that they have a compatible Bluetooth® enabled device with Bluetooth®
capability. Secondly, the user must ensure that they have loaded audio files that are compatible with
the device’s media player on to the device, in order to play through the Entertainment System. Once
these have both been confirmed, the user can connect their device to the Entertainment System.

To pair with a Bluetooth® enabled device, simply turn the Entertainment System on by pressing the
power switch on the top panel. Press the input button until “bLUE” is flashing on the LCD display. The
Entertainment System will now be “discoverable” to nearby Bluetooth® devices.

On the Bluetooth® enabled device, activate (or turn ON) Bluetooth® wireless connection, and search
for nearby devices. When the device discovers “BT Audio”, select and connect to “BT Audio”. This
process should take a few seconds to connect – no PIN or pass code will be required. When the
Entertainment System and Bluetooth® enabled device have connected, you will notice that “bLUE” will
stop flashing on the display and the Bluetooth® enabled device should also show it is connected to
“BT Audio”.

16

AFTER SALES SUPPORT

AUS 1300 777 137 EMAIL [e-mail]

Instructions (cont)

Once connected, use the media player on your Bluetooth® enabled device to play the tracks you
wish to hear on the Entertainment System. Instead of playing the tracks on the built-in speaker of
the devices, it will play wirelessly through the Entertainment System. Depending on the device that
is connected, there may be additional steps required to select the Entertainment System as the
device that the audio is playing through. Please consult the instruction manual from the device if
any problems are encountered with playing the audio files through the Entertainment System via
Bluetooth® wireless technology. If this does not assist, please phone the After Sales Support phone
number listed in this instruction manual for assistance.

The tracks can be controlled via the media player on the phone. Depending on the device being used,
the device should be able to control skipping tracks, fast forward/backward, increasing and decreasing
the volume, repeating tracks etc. The control via the Bluetooth® enabled device depends solely on the
device and its capabilities.

Automatic reconnection will ONLY happen if:

1. The Bluetooth® enabled device was the last device that the Entertainment System was connected.

2. The Bluetooth® enabled device has maintained “BT Audio” as one of its paired devices (the device
should show a list of paired devices in the Bluetooth® menu or settings).

3. The Bluetooth® enabled device and the Entertainment System are in close proximity to one
another. Generally Bluetooth® wireless technology is only operable over an unobstructed distance
of approximately 10m.

Disconnecting and Reconnecting via Bluetooth®

To end the connection between the Bluetooth® enabled device and the Entertainment System, either:

1. Press the input button on the top control panel to enter a different function on the Entertainment
System. This will disable the Bluetooth® function on the Entertainment System and end the
connection.

2. Switch OFF the Entertainment System by pressing the power switch located on the top panel.

3. On the Bluetooth® enabled device, turn Bluetooth® connection OFF.

NOTE: If the last connecting device is within the Bluetooth® reception range of the Entertainment
System, you will not be able to pair new Bluetooth® enabled device to the Entertainment system.
You will need to turn off the Bluetooth connection on the last connecting device in order to connect a
new device.

17

AFTER SALES SUPPORT

AUS 1300 777 137 EMAIL [e-mail]

Instructions (cont)

Using the Microphone

This Entertainment System has two microphone input sockets which
allows you to connect two wired microphones. It also comes with a
wireless microphone for announcements or karaoke entertainment.
Before first use, you will have to install two AA batteries
(Please see page 12 for specific instructions).

NOTE: Remove the batteries when the microphone is not in use for
a long time to avoid leakage. Batteries can leak chemicals that can

damage electronic parts.

The microphone has one switch at the front, as illustrated above.

• Push the switch all the way up to the top to switch ON the microphone; the indicator light on the
microphone will illuminate.

• For best reception, do not move the wireless microphone further than 15 metres away from the
Entertainment System.

• Push the switch to the middle position to mute the sound temporarily; the indicator light on the
microphone will dim.

• Push the switch down to switch OFF the microphone.

NOTE: While using the microphone, avoid being close to metal surfaces or walls, as they may affect
the wireless transmission.

• For the best singing quality, keep the microphone within 5-15cm of the mouth and at a 45 degree
angle.

• When using the microphone, always pay attention to the battery. If the battery is low, the indicator
light will start to blink and the performance will progressively become poor.

* Trademarks

The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and
any use of such marks by Uncle Bill’s (Australia) Pty Ltd is under license. Other trademarks and trade
names are those of their respective owners.

18

AFTER SALES SUPPORT

AUS 1300 777 137 EMAIL [e-mail]

Technical Specifications

Unit:

Power source: AC 220 - 240V ~ 50-60Hz
Output power: 100W RMS
Peak music power output: 1200W
Bluetooth: Version 2.1
Loudspeaker: 2x 10’’ Speaker + 2x 3’’High Frequency Tweeters
FM Frequency FM 87.5 – 108MHz
Wireless Effective Range: 15 metres
Weight: 18.5Kgs

Wireless microphone:

Operating Range: 2.4GHz
Transmitter Power: 10mW
Battery: DC 3V (1.5V AA x 2)

Tips and Troubleshooting:

Problem Solution

I can’t hear anything from
my microphone through the
Entertainment System

- Ensure that you adjust the Microphone Volume Control dial to increase
microphone volume.

- Check that the mic is turned on.

- Change the batteries.

There is humming or buzzing
through the Entertainment
System

- Try to keep any audio signal cables or mobile phones away from the Speaker
power cords. This can sometimes result in a humming or buzzing from the
speaker system.

My Entertainment System won’t
turn on

- Ensure that you have correctly connected the Power cable to the rear of the
unit. It should not be loose.

- Ensure the power switch on the top panel of the unit is switched ON.

- Make sure the power is on at the outlet.

The LED light won’t turn on - Ensure the light switch on the rear panel of the unit is switched ON.

- Make sure the power cord is correctly connected and the power is on at the
outlet.

I am not picking up any radio
stations

- The Entertainment System will only receive FM radio stations not AM.

- You can extend the telescopic antennas at the rear of the unit to increase the
reception.

The speaker makes a noise
when I first turn it on

- This is normal when the system first initialise.

- Try to keep any audio signal cables or mobile phones away from the Speaker.

I can’t connect my mobile phone
to the Entertainment System via
Bluetooth

- Ensure the Entertainment system has been switched to Bluetooth mode with
“bLUE” showing on the Mode Display

- Ensure the last mobile phone or Bluetooth device has been disconnected to
the Entertainment System. If they are in the range, the Entertainment will
pick up the last connection as default (please see page 15-16 for details).

19

AFTER SALES SUPPORT

AUS 1300 777 137 EMAIL [e-mail]

Warranty Details

High Powered Entertainment System with Karaoke Function and Bluetooth®

The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months
from the date of purchase. Defects that occur within this warranty period, under normal use and
care, will be repaired, replaced or refunded at our discretion. The benefits conferred by this warranty
are in addition to all rights and remedies in respect of the product that the consumer has under the
Competition and Consumer Act 2010 and similar state and territory laws.

Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods
fail to be of acceptable quality and the failure does not amount to a major failure.

Exclusions

This warranty does not cover:

• Normal wear and tear to the products or parts;

• Any defects caused by an accident, misuse, abuse, improper installation or operation, lack of
reasonable care, unauthorised modification, loss of parts, tampering or attempted repair by a person
not authorised by the distributor;

• Any product that has not been installed, operated or maintained in accordance with the
manufacturer’s operating instructions provided with the product; or

• Any product that has been used for purposes other than domestic use; or

• Any damage caused by improper power input or improper cable connection.

Item # EA0749

Model # DJ8210

Imported By:
Uncle Bill’s (Australia) Pty Ltd
48B Egerton Street
Silverwater NSW 2128
Australia

1

YEAR

WARRANTY

20

AFTER SALES SUPPORT

AUS 1300 777 137 EMAIL [e-mail]

Warranty Details (cont)

If you have any issues with this product or require further information, please contact our helpful
customer support team via phone or email (details below). The product comes with a full 12 months
warranty for your piece of mind. In many cases we will resolve the issue without you having to return
the product. Our friendly staff can also help you with troubleshooting or advice in relation to the use of
this product.

Customer Support Details:

Australian Customers: 1300 777 137
Email: [e-mail]

Hours of Operation: 9am – 4:30pm Monday – Friday
9am – 3pm Saturday
* Hours of Operation are Australian Eastern Standard Time.

ATTENTION: Your product is marked with this symbol. It means that used electrical and
electronic products should not be mixed with general household waste.

Disposing or recycling of electronic products correctly will help save valuable resources and prevent
any potential negative effects on the environment. For drop-off or collection of your e-waste, please
contact your local council for further details of your nearest designated collection point.
